5-6 Initialization/Setting Screen
No
1
2
3
4
3. After setting, click the Write Button to save the setting. (For details on the write button,
refer to Writing on page 5-29.)
4. The settings are enabled after the NS-Runtime is restarted.
Ethernet
This function is used to display and set whether to use the Ethernet and the detailed
conditions.
IP address, subnet mask, and default gateway cannot be set from the system menu.
To change the settings, change them from the Control Panel – Network Connections of
the Windows.
Make the Ethernet settings by using operations from the Comm. Tab Page as follows.
5-40
Item
Serial Port Selects the serial port to be used to
connect to the host.
Protocol Selects the method for connecting
to the host.
Comm. Speed Selects the baud rate.
Host Selection Selects the host type.
1
2
3
4
Function Setting Range
Select any port that can be used
with the NS-Runtime environment.
Toolbus, Host Link
19200,38400,57600 or 115200
SYSMAC-CV, SYSMAC-CS1,
SYSMAC-CJ1, or SYSMAC-CJ2
