6-3 Transferring Data from the CX-Designer
3. Select the NS-Runtime from the Comms. Method
4. Click the OK Button to close the Comms. Method Dialog Box.
5. Transfer the project data by any of the following methods.
-PT Menu – Transfer – Quick Transfer [To PT] Menu
(Use this method to send only changed data to NS-Runtime.)
-PT Menu – Transfer – Transfer [To PT] Menu
(Use this method to send all project data to NS-Runtime.)
-PT Menu – Transfer – Transfer [From PT] Menu
(Use this method to receive project data from NS-Runtime.)
- PT Menu – Transfer – Transfer Program – Screen data transfer program
6. After the transfer, restart the NS-Runtime.
N o t e
N o t
N o t
Project data cannot be transferred while NS-Runtime is running.
The downloaded project data will be stored in the following project storage folder.
\ NS-Runtime Installation folder \ Runtime
Project data that is stored in this folder can be directly opened from the CX-Designer.
In this case, it is not necessary to transfer the modified project data again.
Downloaded project data (Project data stored in \ NS-Runtime Installation folder
\ Runtime) cannot be transferred by the CX-Designer if the project data is being edited
with another CX-Designer.
Operation methods for using CX-Designer's Menus and screen data transfer program
are the same as those for NS Series. For details, refer to the Transferring Data to the PT
in the CX-Designer Online Help.
