ACX2000 and ACX2100 Universal Access Routers Quick Start

Step 4: Connect External Devices and Cables

Tools Required to Connect External Devices and Cables

Connect the ACX Series Router to a Network for Out-of-Band Management
Connect the ACX Series Router to a Management Console or Auxiliary Device

Connect Network Interface Cables to the ACX Series Router

12
Figure 9: Ethernet Cable Connector
Tools Required to Connect External Devices and Cables on page 12
Connect the ACX Series Router to a Network for Out-of-Band Management on page 12
Connect the ACX Series Router to a Management Console or Auxiliary Device on page 12
Connect Network Interface Cables to the ACX Series Router on page 12
To connect external devices and cables to the router, you need the following tools:
Ethernet cable with an RJ-45 connector attached (provided)
RJ-45 to DB-9 serial port adapter (provided)
Management host, such as a PC, with an Ethernet port (not provided)
Turn off the power to the management device.
1.
Plug one end of the Ethernet cable
2.
the port on the front of the chassis.
MGMT
and Figure 3 on page 5
Plug the other end of the cable into the network device.
3.
Turn off the power to the console or auxiliary device.
1.
Plug the RJ-45 end of the serial cable
2.
the port on the front panel.
CONSOLE/AUX
and Figure 3 on page 5
Plug the female DB-9 end into the device's serial port.
3.
Have ready a length of the type of cable used by the network ports. For cable
1.
specifications, see the
ACX2000 and ACX2100 Universal Access Routers Hardware Guide
NOTE: Shielded cables are required for outside deployment.
Remove the rubber safety plug from the cable connector port.
2.
(Figure 9 on page 12
Figure 1 on page
show the port.
(Figure 9 on page 12
Figure 1 on page
show the port.
shows the connector) into
4, Figure 2 on page
shows the connector) into
4, Figure 2 on page
Copyright © 2012, Juniper Networks, Inc.
4,
4,
.
