ACX2000 Universal Access Routers Quick Start

Step 4: Connect External Devices and Cables

Tools Required to Connect External Devices and Cables

Connect the ACX2000 Router to a Network for Out-of-Band Management
10
Figure 6: Ethernet Cable Connector
Figure 7: Front Panel of the ACX2000 Router
1 2 3 4
ACX2000
MGMT CONSOLE/AUX
ALARM
1PPS 10MHz
IN OUT IN OUT
SYS 0 1 EXT REF CLK IN
14 13 12 11 10
1— DC terminal
2— Management Ethernet port
3— Console or auxiliary port
4— Alarm contact port
5— T1/E1 and RJ45 Gigabit Ethernet network
ports
6— PoE Gigabit Ethernet ports
7— ESD point
Tools Required to Connect External Devices and Cables on page 10
Connect the ACX2000 Router to a Network for Out-of-Band Management on page 10

Connect the ACX2000 Gateway to a Management Console or Auxiliary

Device on page 11
Connect Network Interface Cables to the ACX2000 Router on page 11
To connect external devices and cables to the router, you need the following tools:
Ethernet cable with an RJ-45 connector attached (provided)
RJ-45 to DB-9 serial port adapter (provided)
Management host, such as a PC, with an Ethernet port (not provided)
Turn off the power to the management device.
1.
Plug one end of the Ethernet cable
2.
the port on the front of the chassis.
MGMT
5
T1/E1
0/0/9 0/0/10 0/0/11 0/0/13 0/0/14 0/0/15
0/0/8 0/0/12 0/1/4
0/0/0 0/0/1 0/0/2 0/0/3 0/0/4 0/0/5 0/0/6 0/0/7 0/1/0
8— 10-Gigabit Ethernet SFP+ ports
9— Gigabit Ethernet SFP ports
10— External clocking ports
11— External clocking input port
12— USB ports
13— System LED
14— Grounding terminal
(Figure 6 on page 10
Figure 7 on page 10
6 7
GE
0/1/5 0/1/6 0/1/7 POE
GE XE
0/1/1 0/1/2 0/1/3 POE
0/2/0 0/2/1 0/3/0 0/3/1
9 8
shows the connector) into
shows the port.
