BA02178C/66/EN/03.23
Products
70212042
Operating Instructions
Raman Rxn4
Solutions
Services

Advertisement

Table of Contents
loading

Related Manuals for Endress+Hauser Raman Rxn4

Summary of Contents for Endress+Hauser Raman Rxn4

  • Page 1 BA02178C/66/EN/03.23 Products Solutions Services 70212042 Operating Instructions Raman Rxn4...
  • Page 2 Operating Instructions Raman Rxn4 Endress+Hauser...

  • Page 3: Table Of Contents

    Raman Rxn4 Operating Instructions Table of Contents 5.5 Turning on the Raman Rxn4 analyzer ....23 About this document ......4 5.6 Turning off the Raman Rxn4 analyzer ....23 1.1 Warnings ..............4 Electrical connection ......25 1.2 Symbols on the device..........4 1.3 U.S.

  • Page 4: About This Document

    The CE Marking indicates conformity with health, safety, and environmental protection standards for products sold within the European economic area (EEA). U.S. export compliance The policy of Endress+Hauser is strict compliance with U.S. export control laws as detailed on the website of the Bureau of Industry and Security at the U.S. Department of Commerce.

  • Page 5: List Of Abbreviations

    Raman Rxn4 Operating Instructions List of abbreviations Term Description alternating current alternate ANSI American National Standards Institute active pharmaceutical ingredient advanced technology extended ATEX atmosphere explosible American wire gauge °C Celsius calibration CDRH Center for Devices and Radiological Health Code of Federal Regulations...
  • Page 6 Operating Instructions Raman Rxn4 Term Description millimeter mechanical transfer milliwatt numerical aperture network address translation nanometer Open Platform Communications OPC UA OPC Unified Architecture part number process analytical technology power control module portable document format quality by design remote terminal unit...

  • Page 7: Basic Safety Instructions

    Do not drape the power cord over counters, on hot surfaces, or in areas where damage to the integrity of the power cord may occur. • Do not open the Raman Rxn4 unless you have been specifically trained on service and maintenance of the unit. • Do not look directly into the laser beam.

  • Page 8: Product Safety

    Operating Instructions Raman Rxn4 CAUTION Activities while the analyzer is in operation introduce risk of exposure to hazardous materials.  Follow standard procedures for limiting exposure to hazardous chemical or biological materials.  Follow workplace policies on personal protective equipment including wearing protective clothing, goggles, and gloves and limiting physical access to analyzer location.

  • Page 9: Product Description

    Raman Rxn4 single-channel or four-channel configurations are available with a 532 nm, 785 nm, or 993 nm excitation wavelength laser.

  • Page 10: Product Design

    While the Raman Rxn4 four-channel configuration front panel has four LED indicators, the front panel of the Raman Rxn4 hybrid configuration has only two LED indicators, and the front panel of the Raman Rxn4 single-channel configuration has only one LED indicator.
  • Page 11 • Four remote interlock connections for the four-channel Raman Rxn4 analyzer (only one for the single-channel configuration), each intrinsically safe and in series with the fiber breakage detection loops described in previous bullet.

  • Page 12: Probe Connectors

    Ensure latch is engaged after inserting EO fiber connector. For the Rxn-20 channel of the Raman Rxn4 hybrid instrument, the main fiber-optic bundle is furcated into three FC fiber-optic connectors and one electrical interlock loop connector.

  • Page 13: Incoming Product Acceptance And Identification

    Raman Rxn4 Operating Instructions Incoming product acceptance and identification Incoming acceptance 1. Verify that the packaging is undamaged. Notify the courier of any damage to the packaging. Keep the damaged packaging until the issue has been resolved. 2. Verify that the contents are undamaged. Notify the supplier of any damage to the delivery contents. Keep the damaged goods until the issue has been resolved.

  • Page 14: Scope Of Delivery

    The Raman Rxn4 must be installed following all federal, state, and local codes required for the region of installation. Many regions around the world require specific certificates of type review such as IECEx or ATEX before they can be used in the region.

  • Page 15: Installation

    Temperature The Raman Rxn4 with enclosure is designed to operate within a temperature range of 5 to 50 °C (41 to 122 °F) within the enclosure. The unit uses an air-conditioning unit to maintain temperature for the analyzer below its maximum operating temperature.

  • Page 16: Raman Rxn4 Analyzer Mounted In A Computer Or Server Rack

    5.2.5 Temperature The Raman Rxn4 is designed to operate within a temperature range of 5 to 35 °C (41 to 95 °F) inside the computer or server rack. 5.2.6 Relative humidity The Raman Rxn4 is designed to operate within an ambient relative humidity range of 20 to 80 %, non-condensing.

  • Page 17: Raman Rxn4 Analyzer On A Benchtop

    The location selected should allow for adequate ventilation to both the front and rear of the base analyzer. 5.3.5 Temperature The Raman Rxn4 is designed to operate within a temperature range of 5 to 35 °C (41 to 95 °F) while sitting on a benchtop. 5.3.6 Relative humidity The Raman Rxn4 is designed to operate within an ambient relative humidity range of 20 to 80 %, non-condensing.

  • Page 18: Initial Analyzer Setup

    IQ/OQ. For IQ/OQ, a trained representative of either Endress+Hauser or one of its authorized representatives must be present for both initial inspection and installation of the Raman Rxn4 analyzer. Before the installation, refer to the applicable site requirements to prepare the site: •...
  • Page 19 Figure 6. Final clean of electro-optical fiber connector fiber tips 4. Release the latch and open the spring-loaded cap on the Raman Rxn4 analyzer device-side connector. Insert the cable-side connector into the instrument device-side connector fully and engage the latch to secure. The connectors are polarized and can only be inserted one way.
  • Page 20 Swipe the fiber tip once with the damp portion of the wipe, then swipe once more with a dry portion of the same wipe. Repeat for both fiber tips. 3. Employ the two strain reliefs on the rear of Raman Rxn4 hybrid analyzer (using the 7/64" ball driver) to secure the fiber cable assembly.
  • Page 21 Raman Rxn4 Operating Instructions A0048446 Figure 9. Employing strain reliefs to secure the fiber assembly for the Rxn-20 channel 4. Remove the threaded cap from the calibration (CAL) port. 5. Connect the clean calibration fiber to the CAL port, aligning the key on the fiber connector with the notch on the CAL port connector.
  • Page 22 Operating Instructions Raman Rxn4 7. Remove the excitation fiber clamp by loosening the clamp screw with a 3/32" ball driver (provided with analyzer) and sliding it out of the way. 8. Remove the threaded cap from the excitation (EXC) port.

  • Page 23: Turning On The Raman Rxn4 Analyzer

    The following instructions are not applicable to the Raman Rxn4 with enclosure. The only supported method of turning off a Raman Rxn4 with enclosure is by using the main power switch on the right side of the enclosure. Turning off the analyzer There are two ways to properly turn off the Raman Rxn4 analyzer.
  • Page 24 Operating Instructions Raman Rxn4 Performing a hard shutdown To perform a hard shutdown, there are two methods that can be used. Both hard shutdown options involve analyzer hardware and are not options selected from Raman RunTime. They should only be used if Raman RunTime is unresponsive: •...

  • Page 25: Electrical Connection

    Raman Rxn4 Operating Instructions Electrical connection Port connections A0048720 Figure 16. Rear panel of Raman Rxn4 Name Description CDRH product label Product information about the Raman Rxn4 analyzer Air exhaust Air exhaust fan and outlet Strain relief EO fiber cable strain relief mounting location AC inlet 100 to 240 V 50/60 Hz Power socket outlet that provides AC power to the base unit.

  • Page 26: Commissioning

    It is not recommended to use the shield as a signal ground. No provision for connecting the shield drain is provided at the Raman Rxn4. The shield may be connected to earth at the device on the opposite end of the cable attached to the Raman Rxn4.
  • Page 27 Power and grounding The Raman Rxn4 has a standard IEC-320 C-14 inlet for power at the rear of the instrument. Any power cord with an IEC-320 C-13 plug will connect to the base unit. The Raman Rxn4 accepts AC power from 100 to 240 V and 50/60 Hz.
  • Page 28 Operating Instructions Raman Rxn4 7.2.2 Electrical interconnect block diagrams 7.2.2.1 Raman Rxn4 single-channel configuration A0054422 Figure 18. Raman Rxn4 single-channel configuration Endress+Hauser...
  • Page 29 Raman Rxn4 Operating Instructions 7.2.2.2 Raman Rxn4 four-channel configuration A0054423 Figure 19. Raman Rxn4 four-channel configuration Endress+Hauser...
  • Page 30 Operating Instructions Raman Rxn4 7.2.2.3 Raman Rxn4 hybrid configuration A0054424 Figure 20. Raman Rxn4 hybrid configuration Endress+Hauser...
  • Page 31 4-pole switch shall be used. The four separate interlock loops are electrically isolated and may NOT be tied together electrically. Endress+Hauser recommends IDEC XN1E-BV404MR for a 4PST-NC emergency stop button switch. Refer to drawing 3000095 for remote interlock connection details.
  • Page 32 Operating Instructions Raman Rxn4 7.2.5 Interior of the Raman Rxn4 The interior of the Raman Rxn4 with the cover removed is shown below. The internal components are common among all configurations. A0054445 Figure 22. The interior of the Raman Rxn4 analyzer...
  • Page 33 Raman Rxn4 Operating Instructions A0048615 Figure 23. Embedded controller locked in service position Description Interlock IS barrier Embedded controller backup battery Endress+Hauser...

  • Page 34: Raman Rxn4 Hardware Components

    (ATX) power supply, which has no external fuses. If a short circuit were to occur inside the Raman Rxn4 it would be on the DC output side of the power supply. In this event, the power supply would turn itself off and the user must manually reset the power by removing the plug for five minutes after the source of the short circuit is resolved.
  • Page 35 Raman Rxn4 installation options The Raman Rxn4 analyzer is available with 4 different installation options: as a stand-alone single unit, in a rack holding up to two analyzers, as a single unit in an enclosure on a trolley, and as a single unit in an enclosure on a stand.
  • Page 36 There are lockable doors on the front and rear of the rack. The power distribution unit within the rack contains 8 power receptacles. Rack installation drawing is 3000097. A0048722 Figure 25. Two Raman Rxn4 analyzers in a rack A0048723 Figure 26. Two Raman Rxn4 analyzers in a rack...
  • Page 37 The enclosure is constructed of a welded 304 stainless steel cabinet with a door to access the touchscreen, and another door to access the Raman Rxn4 analyzer integrated within. The probes connect on the connection panel on the bottom of the unit. The external power cord protrudes from the enclosure on the right side. The USB port and air conditioner are on the left side.
  • Page 38 Air filter The Raman Rxn4 incorporates a tacked polyester spun air filter element to reduce dust intake into the base unit. The air filter is accessed by a magnetically secured access panel on the front of the instrument. The air filter should be cleaned with compressed air once every month or if the embedded software is reporting an internal over-temperature error (if ambient temperature is within specification).

  • Page 39: Operation

    Operating Instructions Operation WARNING  Whenever the Raman Rxn4 analyzer main power switch and laser key are in their ON position, probes should be shuttered or covered, or remain immersed in the sample to be measured. Raman RunTime embedded software Raman RunTime is the embedded control software installed on all the Raman Rxn4 analyzers.

  • Page 40: Calibration And Verification

    Probe calibration The sensitivity of the Raman Rxn4 varies with wavelength due to variations in the throughput of the optics and the quantum efficiency of the CCD. The probe calibration function in Raman RunTime can be used to remove the effects of this variation from measured spectra.
  • Page 41 8.3.3 Probe verification The probe verification wizard may be used to verify that the Raman Rxn4 is performing within specifications. Probe verification acquires a Raman spectrum of a standard Raman sample, usually 70 % IPA or cyclohexane, and analyzes the resultant spectrum for peak positions, peak area ratios and Raman signal strength. The peak position verification confirms that the spectrograph and laser wavelength calibrations are within specification.

  • Page 42: Diagnostics And Troubleshooting

    9.1.2 Uncalibrated channels In some cases, users may choose not to use all available channels on a Raman Rxn4 analyzer. These unused/uncalibrated channels may result in warnings generated, thereby putting the whole system in a warning state. To resolve these erroneous warnings about unused channels not being calibrated, the user can individually turn off unused probes/channels in the Options >...
  • Page 43 Raman Rxn4 Operating Instructions A0049222 Figure 30. Environment tab to view laser diode current and laser power 9.1.4 ON/OFF button flashing The ON/OFF button emits a flashing blink code to communicate a problem when the software is unavailable. Sign Problem...

  • Page 44: Raman Rxn4 System And Power Loss

    Operating Instructions Raman Rxn4 Raman Rxn4 system and power loss The instrument retains its last known power state in non-volatile memory. Should power be interrupted to the instrument at any time, the instrument recalls its last known power state and returns to that power state once power is restored.

  • Page 45: Maintenance

    Prior to performing a camera alignment operation, it is important to ensure that no stray light is entering any of the probes that are attached to the Raman Rxn4. Alignment is performed with an internal white light source, and stray light entering on any of the attached probes can interfere with the alignment light source.

  • Page 46: Servicing The Raman Rxn4 Analyzer

    WARNING General users should not open the Raman Rxn4 enclosure due to potential exposure to hazardous laser radiation or high voltages.  Only qualified personnel familiar with high voltage electronics should open the system enclosure to perform necessary maintenance or service.
  • Page 47 Check to see if the laser key is in place and the indicator is lit. The laser is not lasing. Contact Technical Service. The internal power Open the Raman Rxn4 base unit enclosure. The computer-style power cord plug has disconnected should be firmly plugged into its socket on the laser. from the laser.
  • Page 48 Wavelength calibration is performed with a light RunTime Stray light from light from entering the source internal to the Raman Rxn4 base unit. If stray indicates a connected probes is spectrograph. light from connected probes can enter the...

  • Page 49: Repair

    The two main user-serviceable or replaceable parts are the disposable air filter and the laser. Part numbers for these items are listed in the table below. The laser assembly has been designed for easy replacement and this is typically accomplished by the customer. Optionally, an Endress+Hauser service engineer can install the laser during a contracted service visit.

  • Page 50: Technical Data

    12.1 Specifications Raman Rxn4 analyzers may be configured to operate with one of several different laser wavelengths. Currently, Raman Rxn4 analyzers may be equipped with a 532 nm, 785 nm, or 993 nm laser as standard. 12.1.1 Base unit Item...
  • Page 51 175 to 1890 cm configuration (785 nm) Spectral coverage (993 nm) 200 to 2400 cm Slit 50 μm fixed (< 64.0 dB, A-weighted for the Raman Rxn4 hybrid) Spectral resolution (532 nm) 5 cm average Spectral resolution (785 nm) 4 cm...

  • Page 52: Certifications

    Raman Rxn4 12.2 Certifications Raman Rxn4 analyzers carry certifications for installation in a general-purpose zone with output into hazardous areas. For more specific information on the hazardous area rating for field measurements, refer to the Operating Instructions for the installed probe.

  • Page 53: Supplementary Documentation

    • On the media device supplied (not included in the delivery for all device versions) • On the Endress+Hauser Operations App for smartphone • In the Downloads area of the Endress+Hauser website: https://endress.com/downloads Part Number Document Type Document Title BA02180C...

  • Page 54: Index
