Flown - WPMUNIV

Pre-select the inter-cabinet angles while in the case, release the

drop links from the cabinets by removing the rigging pins from the

LINK and ANGLE positions. .

Connect the cabinets together at the rear with the link and angle

rigging pins.

WPM USER GUIDE V2

Slide the drop links down into the cabinets below. Lining them up

with the angles predicted by the DISPLAY software.

Place the universal bracket on top of the array. Secure at the front

by removing the rigging pins from the bottom cabinet to link the

bracket to the array.
