Install - WPM & SXC115
Remove all four M10 bolts from each side of the cabinet.
These will not be used to secure the FK550's to the SXC115.
When flown with WPM the front and middle position of the SXC115
should be used for the flying strips.
A maximum of 3 x SXC115's can be used in a mixed array.
WPM USER GUIDE V2
Copyright © 2023 Martin Audio Ltd.
Attach the FK550's (two on each side) using the M10 bolts provided
with the kit.
Position the SXC115GRIDI on top of the SXC115 sub woofer array.
