Wiring
WPM
The WPM has two parallel-wired Neutrik® NL4 connectors
on angled panels at the rear of the cabinet, recessed to avoid
damage.
SXC(F)115
Connection is made via two NL4 connectors which are wired in
parallel.
Although these are nominally labeled 'INPUT' and 'LINK', either
connector can be used to connect to the sub or to link out to a
second speaker.
INPUT
LINK
WPM USER GUIDE V2
Copyright © 2023 Martin Audio Ltd.
SPEAKON CONNECTORS INPUT/LINK
The Front 15" driver is connected to pins 1+/-, the rear 12" driver
to pins 2+/-. A 4-core NL4 cable must be used.
