Installation Manual
Monochrome LCD Monitor
Important
Please read this Installation Manual, and "Instructions for Use"
(separate volume) carefully to familiarize yourself with safe and
effective usage.
• Please refer to the "Instructions for Use" for basic information
ranging from connection of the monitor to a PC to using the monitor.
• The latest Installation Manual is available for download from our web
site:
http://www.eizoglobal.com

Advertisement

Table of Contents
loading

Related Manuals for Eizo Radiforce GX550

Summary of Contents for Eizo Radiforce GX550

  • Page 1 Installation Manual Monochrome LCD Monitor Important Please read this Installation Manual, and “Instructions for Use” (separate volume) carefully to familiarize yourself with safe and effective usage. • Please refer to the “Instructions for Use” for basic information ranging from connection of the monitor to a PC to using the monitor. •...
  • Page 2 EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifications are subject to change without notice.

  • Page 3: Table Of Contents

    Skipping Display Modes That Are Not Used ...............10 3-4. Setting Language .........10 3-5. Showing Monitor Information.....10 3-6. Displaying or Hiding the EIZO Logo ..11 3-7. Locking Operation Switches ......11 3-8. Rotating the Image ........12 3-9. Selecting the Input Signal for DDC Communication ..........12...

  • Page 4: Chapter 1 Basic Operations And Functions

    Chapter 1 Basic Operations and Functions 1-1. Basic Adjustment menu operations Displaying Adjustment Menu 1. Touch one of the switches (excluding 2. Select from the guide. The Adjustment menu is displayed. Adjusting/Setting 1. Choose a menu to adjust/set with , and then choose 2.

  • Page 5: Functions

    “3-4. Setting Language” (page 10) Information “3-5. Showing Monitor Information” (page 10) Administrator On-Screen Logo “3-6. Displaying or Hiding the EIZO Logo” (page 11) Settings Key Lock “3-7. Locking Operation Switches” (page 11) Image Rotation “3-8. Rotating the Image” (page 12) “3-9.

  • Page 6: Chapter 2 Adjusting Screens

    Chapter 2 Adjusting Screens 2-1. Compatible Resolutions For compatible resolutions of this product, refer to Instruction for Use "Compatible Resolutions". 2-2. Setting the Resolution Windows 10 1. Right-click the mouse anywhere on the desktop except on icons. 2. From the displayed menu, click “Display Settings”. 3.
  • Page 7 Mac OS X 10.8 and later 1. Select “System Preferences” from the Apple menu. 2. When the “System Preferences” dialog box is displayed, click “Displays”. (For Mac OS X 10.8, click "Displays" for "Hardware".) 3. On the displayed dialog box, select the “Display” tab, then choose "Change" for “Resolutions”. 4.

  • Page 8: Adjusting The Mode

    2-3. Adjusting the Mode ● Selecting the display mode (CAL Switch Mode) The display mode can be selected according to the monitor application. Display Modes √: Calibration is available. Mode Purpose 1-DICOM Applies gradation characteristics compliant with DICOM Part 14. √...

  • Page 9: Chapter 3 Setting The Monitor

    Chapter 3 Setting the Monitor 3-1. Switching among Input Signals Procedure 1. Select “Preferences” of the Adjustment menu, and choose 2. Select “Input” from “Preferences”, and choose 3. Using , select either “DVI” or “DisplayPort”. 4. Select after completing the setting. The selected input port name is displayed.

  • Page 10: Skipping Display Modes That Are Not Used

    3-3. Skipping Display Modes That Are Not Used When selecting a mode, you can skip particular modes. This setting is suitable when you are using limited display modes and you do not want to change the customized display state. Procedure 1.

  • Page 11: Displaying Or Hiding The Eizo Logo

    3-6. Displaying or Hiding the EIZO Logo The EIZO logo can be displayed or hidden. Procedure 1. Touch to turn off the monitor power. 2. While holding down the switch at the far left ( ), touch for at least two seconds to turn on the monitor power.

  • Page 12: Rotating The Image

    3-8. Rotating the Image The display direction of the image can be changed according to your environment. Attention • Refer to the User’s Manual of the graphics board. • The setting is available even when the PC is not started up. Procedure 1.

  • Page 13: Enabling/Disabling Dc5V Output

    3-10. Enabling/Disabling DC5V Output The DC5V output can be enabled/disabled. Turn off this setting normally. Procedure 1. Touch to turn off the power to the monitor. 2. While holding down the switch at the far left ( ), touch for at least two seconds to turn on the monitor power.

  • Page 14: Enabling/Disabling Sub Pixel Drive

    3-13. Enabling/Disabling Sub Pixel Drive The Sub Pixel Drive can be enabled/disabled. Attention • To display in 15 megapixel (15 MsP), software that supports 15 MsP is required. • When “Sub Pixel Drive” is “On”, “Sharpness Recovery” is disabled even if it is set to “On”. Procedure 1.

  • Page 15: Switching The Displayport Version Between 1.2 And 1.1

    3-15. Switching the DisplayPort Version between 1.2 and 1.1 The DisplayPort version can be switched. Attention • Use version 1.2 when setting up a daisy-chain connection. • When a PC is connected to the DisplayPort connector, the screen may not be displayed depending on the PC due to difference of the DisplayPort version.

  • Page 16: Chapter 4 Controlling Monitor Quality

    Chapter 4 Controlling Monitor Quality This product has the built-in Integrated Front Sensor, which allows the user to perform periodic calibration and Grayscale Check for the monitor independently. Note • To perform advanced quality control that conforms to medical standards, use the optional monitor quality control software kit “RadiCS UX1”.

  • Page 17: Checking Grayscale

    4-2. Checking Grayscale This function allows you to execute Grayscale Check and view the latest result. In addition, when the schedule is set using RadiCS, the next grayscale check schedule appears. ● Executing Grayscale Check Attention • Perform the Grayscale Check based on the actual temperature and illuminance of the working environment. Procedure 1.

  • Page 18: Setting On/Off For Warning And Qc History

    4-4. Setting On/Off for Warning and QC History This function allows you to set On/Off for Warning and QC History when the Grayscale Check result is Failed. Procedure 1. Choose “RadiCS SelfQC” from the Adjustment menu, and choose 2. Choose “Settings” from the “RadiCS SelfQC” menu, and choose 3.

  • Page 19: Chapter 5 Power Saving Functions

    Chapter 5 Power Saving Functions 5-1. Setting Power Save The monitor can be set to the power saving mode according to the PC status. When the monitor has shifted to the power saving mode, the images on the screen are not displayed. Attention •...

  • Page 20: Setting Displayport Power Save

    5-3. Setting DisplayPort Power Save If the PC is connected to the DisplayPort connector, and when the power is turned on or off or when the monitor recovers from power saving mode, window or icon positions may be shifted. If that occurs, set this function to "Off".
  • Page 21 Note • The sensitivity becomes lower when the ambient temperature is high, and higher when the temperature is low. Accordingly, you can set the sensitivity to a higher level when temperatures are higher, and to a lower level when temperatures are lower to ensure more appropriate operation. Chapter 5 Power Saving Functions...

  • Page 22: Chapter 6 Troubleshooting

    Chapter 6 Troubleshooting If a problem still remains after applying the suggested remedies, contact your local EIZO representative. 6-1. No picture Problem Possible cause and remedy 1. No picture • Check whether the power cord is connected properly. • Power indicator does not light.

  • Page 23: Imaging Problems

    • Use “Brightness” in the Adjustment menu to adjust it. (The LCD monitor backlight has a limited life span. When the screen becomes dark or begins to flicker, contact your local EIZO representative.) 2. Characters are blurred. • Check whether the PC is configured to meet the resolution and vertical scan frequency requirements of the monitor (see “Compatible Resolutions”...

  • Page 24: Other Problems

    “Instructions for Use”.). • Change the USB port to another one. If the PC or peripheral devices works correctly by changing the USB port, contact your local EIZO representative. (Refer to the manual of the PC for details.) • Reboot the PC.

  • Page 25: Error Code Table

    9. SelfCalibration/Grayscale Check failure • Refer to the error code table. • If an error code that does not appear in the error code table is displayed, contact your local EIZO representative. Attention • Do not touch the Integrated Front Sensor.

  • Page 26: Appendix

    User's Manual (the color temperature is 7500K) and the Warranty Period for the brightness is limited to fi ve (5) years from the date of purchase of the Product. EIZO and Distributors shall bear no liability or obligation with regard to the Product in relation to the Original Purchaser or any third parties other than as provided under this Warranty.
  • Page 27 Helligkeit, wie im Benutzerhandbuch (die Farbtemperatur beträgt 7500K) beschrieben, verwendet wird, und die Dauer der Garantiefrist für die Helligkeit beträgt fünf (5) Jahre ab dem Kaufdatum des Produkts. EIZO und die Vertriebe übernehmen über den Rahmen dieser Garantie hinaus hinsichtlich des Produkts keinerlei Haftung oder Verpfl ichtung dem Erstkäufer oder Dritten gegenüber.
  • Page 28 Haftung oder la Période de Garantie en matière de luminosité est limitée à cinq (5) ans à compter de la date d’achat du Produit. EIZO et ses Distributeurs déclinent toute responsabilité ou obligation concernant ce Produit face à l’Acheteur initial ou à toute shändler keine...
  • Page 29 EIZO y los distribuidores utilizarán repuestos que cumplan con nuestros estándares de control de calidad. Si no sette (7) anni se puede reparar la unidad debido a su estado o si se han agotado las existencias de una pieza importante, EIZO y sus utilizzeranno p distribuidores podrían ofrecerle sustituirlo por un producto con rendimiento equivalente en lugar de repararlo.
  • Page 30 GARANZIA LIMITATA EIZO Corporation (a cui si farà riferimento da qui in poi con “EIZO”) ed i Distributori autorizzati da EIZO (a cui si farà riferimento da qui in poi con “Distributori”) garantiscono, secondo i termini di questa garanzia limitata (a cui si farà...
  • Page 31 Nät skärmen repareras använder EIZO och distributörer reservdelar som uppfyller våra kvalitetsstandarder. Om enheten inte kan repareras på grund av skicket eller att en del inte fi nns i lager kan EIZO och dess leverantörer erbjuda sig att byta ut produkten mot en produkt med likvärdig prestanda istället för att reparera den.
  • Page 32 Компания EIZO и ее дистрибьюторы хранят детали изделия (за исключением деталей внешней конструкции) не более 7 (семи) лет после прекращения его выпуска. В случае ремонта монитора EIZO и Дистрибьюторы будут использовать запчасти, которые соответствуют нашим стандартам QC (контроль качества). Если устройство...
  • Page 33 有限责任保证书 EIZO Corporation（以下简称“EIZO” ）和 EIZO 授权的经销商（以下简称“经销商” ） ，接受并依照本有限责任保证书（以 下简称“保证书” ）之条款， 向从 EIZO 和经销商购买本文中所规定产品（以下简称“产品” ）的原买方（以下称“原买方” ） 提供保证 ： 在保证期内（规定如下） ，如果原买方发现 (i) 按本产品所附使用说明书（以下简称“用户手册” ）所述方式正常 使用本产品过程中， 本产品出现故障或损坏； 或 (ii) 按用户手册所述方式正常使用本产品过程中， 本产品的液晶显示屏 (LCD) 及亮度未能达到用户手册中所述的推荐亮度时，EIZO 和经销商根据其独自的判断免费修理或更换该产品。 本保证期限定为仅按照用户手册（色温为 7500K）所描述的推荐亮度使用本产品时保证其亮度的条件下自购买本产品之日 起的五（5）年（以下简称“保证期限” ） ，亮度的保证期限定为自购买本产品之日起五（5）年。EIZO 和经销商将不向原 买方或任何第三方承担本保证书所规定之外的与本产品有关任何责任或义务。 零件停产七（7）年后，EIZO 及其经销商不再保留或保存产品的任何零件（设计零件除外） 。维修显示器时，EIZO 与经销...
  • Page 34 1st Edition-September, 2016 03V25742A1 Copyright © 2016 EIZO Corporation. All rights reserved. (IM-GX550)
