Instructions for Use
■ User's Manual
Important
Please read this User's Manual carefully to familiarize yourself with safe and effective
usage. Please retain this manual for future reference.
Wichtig
Lesen Sie die dieses Benutzerhandbuch aufmerksam durch, um sich mit der sicheren
und effizienten Bedienung vertraut zu machen. Bewahren Sie dieses Handbuch zum
späteren Nachschlagen auf.
Important
Veuillez lire attentivement ce Manuel d'utilisation afin de vous familiariser avec ce
produit et de l'utiliser efficacement et en toute sécurité. Veuillez conserver ce manuel
pour référence ultérieure.
重要
ご使用前には必ずこの取扱説明書をよくお読みになり、正しくお使いください。
この取扱説明書は大切に保管してください。
Advertisement
Table of Contents
Related Manuals for Eizo RadiForce GS320-CL
Summary of Contents for Eizo RadiForce GS320-CL
- Page 1 Instructions for Use ■ User’s Manual Important Please read this User’s Manual carefully to familiarize yourself with safe and effective usage. Please retain this manual for future reference. Wichtig Lesen Sie die dieses Benutzerhandbuch aufmerksam durch, um sich mit der sicheren und effizienten Bedienung vertraut zu machen.
- Page 2 Note Use the attached specified cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class B digital device. - AC Cord...
- Page 3 Instructions for Use User’s Manual Monochrome LCD Monitor It shall be assured that the final system is in compliance to IEC60601-1-1 requirements.
- Page 4 EIZO Corporation. EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information.
-
Page 5: Table Of Contents
English TABLE OF CONTENTS PRECAUTIONS ..................4 1. INTRODUCTION ..................9 1-1. Features ......................9 1-2. Package Contents..................9 1-3. Controls & Connectors ................10 2. INSTALLATION ..................12 2-1. Before Connecting ..................12 2-2. Cable Connection ..................12 2-3. Environmental Settings ................15 3. ADJUSTMET & SETTINGS ..............17 3-1. -
Page 6: Precautions
English PRECAUTIONS IMPORTANT! • This product has been adjusted specifically for use in the region to which it was originally shipped. If operated outside the region to which it was originally shipped, the product may not perform as stated in the specifications. •... - Page 7 English WARNING If the unit begins to emit smoke, smells like something is burning, or makes strange noises, disconnect all power connections immediately and contact your dealer for advice. Attempting to use a malfunctioning unit may result in fire, electric shock, or equipment damage.
- Page 8 English WARNING To disconnect the power cord, grasp the plug firmly and pull. Tugging on the cord may damage and result in fire or electric shock. The equipment must be connected to a grounded main outlet. Not doing so may result in fire or electric shock. Use the correct voltage.
- Page 9 English CAUTION Handle with care when carrying the unit. Disconnect the power cord and cables when moving the unit. Moving the unit with the cord attached is dangerous. It may result in injury. Carry or place the unit according to the correct specified methods. When handing the unit, grip the bottom of the unit firmly with both hands ensuring the panel faces outward before lifting.
- Page 10 English Notice for this monitor This product is intended to be used in displaying and viewing digital images for diagnosis of X-ray or MRI, etc. by trained medical practitioners. The device is not specified for digital mammography system. This product has been adjusted specifically for use in the region to which it was originally shipped.
-
Page 11: Introduction
• USB (Universal Serial Bus) hub support (p. 25) • Utility software “ScreenManager Pro for Medical”, which enables control of the monitor from a Windows PC with a mouse or keyboard (refer to the EIZO LCD Utility Disk). • Monitor stand adjustable for different heights •... -
Page 12: Controls & Connectors
English 1-3. Controls & Connectors Front ® ScreenManager main menu CAL Switch menu Control Panel (1) MODE Mode Switch Enter Switch Directing Switches (Left, Down, Up, Right) Power Switch Power Indicator Green Operational Orange Power saving Flashing orange slowly Power off (Main power is on) Main Power off When the monitor is oriented in the landscape position, these switches can be changed to Up, Left, Right, and Down (p. - Page 13 English Side / Rear DVI-D connector USB upstream port (x 1) USB downstream ports (x 2) Power connector (10) Security lock slot (11) Main Power Switch (12) Monitor stand with adjustable height (detachable) Allows for connection of a security cable. This lock supports Kensington’s MicroSaver security system.
-
Page 14: Installation
English 2. INSTALLATION 2-1. Before Connecting Before connecting your monitor to the PC, change the display screen settings resolution (p. 36) and frequency in accordance with the charts below. NOTE • When your computer and monitor support VESA DDC, the appropriate resolution and the refresh rate are set just by plugging your display into the computer without any manual settings. - Page 15 English Connect the signal cable to the DVI-D input connector on the rear of the monitor and to the video output connector on the PC. After connecting, secure the cable connectors with the attached screw-in fasteners. Signal cable FD-C39 Power cord Signal Cable Connector on PC Signal cable (FD-C39)
- Page 16 English Connect the other end of the power cord to a power outlet. WARNING Use the enclosed power cord and connect to the standard power outlet of your country. Be sure to remain within the rated voltage of the power cord. Not doing so may result in fire or electric shock.
-
Page 17: Environmental Settings
English 2-3. Environmental Settings The monitor may need to be set in some environment. If you install it for the first time or change environment, set the monitor. • Set the signal corresponding to make a connection for non monochrome signal only specifications. - Page 18 English Monitor Orientation Display Example Landscape Select this option when using the Landscape orientation. Portrait (SW) Select this option when using the Portrait orientation. Graphics board utility software is used to rotate the display image 90 degrees. Portrait (HW) Select this option when using the Portrait orientation. The monitor function is used to rotate the display image 90 degrees.
-
Page 19: Adjustmet & Settings
English 3. ADJUSTMET & SETTINGS 3-1. How to use the ScreenManager Screen adjustments and settings can be performed with the ScreenManager (OSD) and switches of the monitor. Mode Switch Power Switch ScreenManager Menu Directing Switches CAL Switch menu Left, Down, Up, Right Enter Switch Adjustment Startup... -
Page 20: Screenmanager Menu
English 3-2. ScreenManager menu Using ScreenManager menu controls the screen adjustment and settings. Refer to the “Explanation” column in the following table for each detailed functions. Functions The following table shows all the ScreenManager’s adjustment and setting menus. Main menu Sub menu Explanation Setup... - Page 21 English How to use the ScreenManager ScreenManager menu [Entering the ScreenManager] Touch the enter switch. [Making adjustments and settings] (1) Select the desired submenu icon with the directing switches and touch the enter switch. (2) Select the desired setting icon with the directing switches and touch the enter switch. (3) Make any required adjustments with the directing switches and touch the enter switch.
- Page 22 English Mode Preset Function <Setup>-<Mode Preset> When CAL Switch mode is selected, the computer can be forced to display only specified modes. Use this function when the display modes are restricted or when the display should not be changed needlessly. [How to set] (1) Select <Mode Preset>...
- Page 23 English Off Timer <Others>-<Off Timer> The off timer function causes the monitor to turn off automatically after a predetermined amount of time has lapsed. This function was created to reduce the afterimages particular to LCD monitors, which appear when the screen is left on for long periods without use.
-
Page 24: Cal Switch Function
English 3-3. CAL Switch Function The most suitable display mode is available by switching the mode switch on the control panel. The <Brightness> settings can be adjusted on the CAL Switch menu. CAL Switch Modes Mode Description 1-DICOM Select this option to display images in the DICOM mode (see p. 36). -
Page 25: Adjustment Lock Function
English 3-4. Adjustment Lock Function Use the “Adjustment Lock” function to prevent any accidental changes. • Display, adjustment, and setting of the ScreenManager Locked functions • Brightness adjustments to the CAL Switch mode • Selection of the CAL Switch mode with the mode switch Unlocked function [How to lock] (1) Turn off the monitor power by touching the power switch. -
Page 26: Brightness Adjustment & Image Adjustment
English 4. BRIGHTNESS ADJUSTMENT & IMAGE ADJUSTMENT 4-1. Brightness Adjustment The brightness of the entire screen can be set to a desired level. [How to adjust] (1) Select <Brightness> in the ScreenManager <Mode> menu. (2) Make adjustments with the Left and Right directing switches. The Left directing switch makes the screen darker, and the Right directing switch makes it brighter. -
Page 27: Making Use Of Usb (Universal Serial Bus)
• PC equipped with USB ports or another USB hub connected to the USB compliant PC • Windows 2000/XP/Vista/7/8 // Mac OS 8.5.1 or later • EIZO USB Cable (MD-C93) NOTE • The USB hub function may not work properly depending on the PC, OS or peripherals. - Page 28 ScreenManager Pro for Medical (for Windows) For further details about the “ScreenManager Pro for Medical (for Windows)”, refer to the EIZO LCD Utility Disk. 5. MAKING USE OF USB (Universal Serial Bus)
-
Page 29: How To Attach The Optional Arm
An optional arm (or an optional stand) can be attached by removing the stand section. Please refer to our web site for the corresponding optional arm (or optional stand). http://www.eizo.com NOTE • When attaching an arm or stand, follow the instructions of their user's manual. -
Page 30: Troubleshooting
English 7. TROUBLESHOOTING If a problem persists even after applying the remedies suggested below, contact an EIZO dealer. • No picture problems → See No.1 ~ No.2 • Imaging problems → See No.3 ~ No.6 • Other problems → See No.7 ~ No.9 •... - Page 31 • Make sure the air vents are not blocked. • Make sure high temperature equipment is not located nearby. Contact an EIZO dealer when the power switch fails to restart the monitor even after its location is moved. NOTE Do not block the ventilation slots on the cabinet and do not install the monitor in a closed space.
- Page 32 Try connecting the peripheral to another USB operate. downstream port. If the problem is solved by doing this, contact an EIZO dealer. (For details, refer to the manual of the PC.) Try executing the following method. - Restarting the PC...
-
Page 33: Cleaning
English 8. CLEANING Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime. NOTE • Chemicals such as alcohol and antiseptic solution may cause gloss variation, tarnishing, and fading of the cabinet or panel, and also quality deterioration of the image. -
Page 34: Specifications
English 9. SPECIFICATIONS LCD Panel Size 54 cm (21.3 inch), TFT Monochrome LCD panel Response Time 34ms Surface treatment Anti-Glare, Hard Coating (GX320-CL/GS320-CL) Surface treatment Hard Coating (GS320-CLG) Surface hardness Panel Surface treatment Anti-Reflection Protector Surface hardness 2H or higher (GX320-CL) Visible reflectance 1.5% or less... - Page 35 English Classification of Equipment Type of protection against electric shock: Class I EMC class: EN60601-1-2:2007 Group 1 Class B Classification of medical device (MDD 93/42/EEC): Class I Mode of operation : Continuous IP Class : IPX0 GX320-CL Dimensions With stand 376 mm (W) x 522.5 mm ∼...
- Page 36 *These functions cannot be initialized with a reset function (p.18). For information about setting these functions, refer to p. 15. Optional Calibration Kit EIZO “RadiCS UX1 ”Ver.2.5.0 or later Network QC EIZO “RadiNET Pro” Ver.2.5.0 or later Management Software Cleaning kit EIZO “ScreenCleaner”...
- Page 37 English Pin Assignment DVI-D Connector 1 2 3 4 5 6 7 8 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 Pin No. Signal Pin No. Signal Pin No. Signal TMDS Data2- TMDS Data1- TMDS Data0- TMDS Data2+ TMDS Data1+...
-
Page 38: Glossary
English 10. GLOSSARY DICOM (Digital Imaging and Communication in Medicine) The DICOM standard was developed by the American College of Radiology and the National Electrical Manufacturer's Association of the USA. A DICOM-compatible device connection enables the transfer of medical images and information. - Page 39 Este producto debe desecharse y reciclarse según la legislación del país para reducir el impacto medioambiental. Cuando desee deshacerse de este producto, póngase en contacto con un distribuidor o una filial de su país. Encontrará las direcciones de contacto en el sitio web de EIZO que se indica a continuación. http://www.eizo.com Informazioni sul riciclaggio Per lo smaltimento e il riciclaggio del presente prodotto, attenersi alle normative vigenti nel proprio paese per ridurre l’impatto ambientale.
