Instructions for Use
Important:
Please read this "Instructions for Use", and Installation Manual (on the
CD-ROM) carefully to familiarize yourself with safe and effective usage.
Please retain this manual for future reference.
• The latest "Instruction for Use" is available for download from our web
site: http://www.eizo.com
Gebrauchsanweisung
Wichtig:
Bitte lesen Sie diese „Gebrauchsanweisung" und das separate
Installationshandbuch sorgfältig durch, um sich mit dem sicheren und
sachgemäßen Gebrauch des Produkts vertraut zu machen.
Bewahren Sie dieses Handbuch zum späteren Nachschlagen auf.
• „Gebrauchsanweisung" steht Ihnen auf unserer Website zum Download
zur Verfügung: http://www.eizo.com
Mode d'emploi
Important :
Veuillez lire attentivement ce « Mode d'emploi » ainsi que le Manuel
d'installation (tome séparé) afin de vous familiariser avec ce produit et de
l'utiliser efficacement et en toute sécurité.
Veuillez conserver ce manuel pour référence ultérieure.
• La dernière version du « Mode d'emploi » est à disposition pour
téléchargement sur notre site Web : http://www.eizo.com
设定手册
重要事项： 请仔细阅读本"使用说明书"和"安装手册"（单独卷），熟
悉安全和高效使用。请保留本手册，以备日后参考。
• 最新 "使用说明书"可在我们的网站上下载 ： http://www.eizo.com
Advertisement
Table of Contents
Related Manuals for Eizo RadiForce GX540-CL
Summary of Contents for Eizo RadiForce GX540-CL
-
Page 1: Instructions For Use
• „Gebrauchsanweisung“ steht Ihnen auf unserer Website zum Download zur Verfügung: http://www.eizo.com Mode d’emploi Important : Veuillez lire attentivement ce « Mode d’emploi » ainsi que le Manuel d’installation (tome séparé) afin de vous familiariser avec ce produit et de l’utiliser efficacement et en toute sécurité. Veuillez conserver ce manuel pour référence ultérieure. • La dernière version du « Mode d’emploi » est à disposition pour téléchargement sur notre site Web : http://www.eizo.com 设定手册 重要事项： 请仔细阅读本“使用说明书”和“安装手册”（单独卷），熟 悉安全和高效使用。请保留本手册，以备日后参考。 • 最新 “使用说明书”可在我们的网站上下载 ： http://www.eizo.com... -
Page 2: Cover
Instructions for Use Monochrome LCD monitor... -
Page 3: Safety Symbols
EIZO Corporation. EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifications are subject to change without notice. -
Page 4: Precautions
PRECAUTIONS ● IMPORTANT • This product has been adjusted specifically for use in the region to which it was originally shipped. If the product is used outside the region, it may not operate as specified in the specifications. • To personal safety and proper maintenance, please read carefully this section and the caution statements on the monitor. - Page 5 A unit placed on an inadequate surface may fall and result in injury or equipment damage. If the unit falls, disconnect the power immediately and ask your local EIZO representative for advice. Do not continue using a damaged unit. Using a damaged unit may result in fire or electric shock.
- Page 6 When the unit is dropped, please ask your local EIZO representative for advice. Do not continue using a damaged unit. Using a damaged unit may result in fire or electric shock. When reattaching the tilt stand, please use the same screws and tighten them securely.
- Page 7 CAUTION Handle with care when carrying the unit. Disconnect the power cord and cables when moving the unit. Moving the unit with the cord attached is dangerous. It may result in injury. Carry or place the unit according to the correct specified methods. •...
-
Page 8: Notice For This Monitor
The backlight of the LCD panel has a fixed lifetime. When the screen becomes dark or begins to flicker, please contact your local EIZO representative. Do not press on the panel or edge of the frame strongly, as this may result in display malfunctions, such as interference patterns, etc. -
Page 9: Cleaning
Cleaning Attention • Chemicals such as alcohol and antiseptic solution may cause gloss variation, tarnishing, and fading of the cabinet or panel, and also quality deterioration of the image. • Never use any thinner, benzene, wax, and abrasive cleaner, which may damage the cabinet or panel. Note •... -
Page 10: Table Of Contents
To use the monitor comfortably ......8 CONTENTS ............. 9 Chapter 1 Introduction ........10 1-1. Features ............10 1-2. Package Contents ........11 1-3. EIZO LCD Utility Disk........11 ● Diskcontentsandsoftwareoverview....11 ● UsingRadiCSLE/ScreenManagerPro forMedical ............11 1-4. Controls and Functions ......12 Chapter 2 Setting Up ........ -
Page 11: Chapter 1 Introduction
Chapter 1 Introduction Thank you very much for choosing an EIZO monochrome LCD monitor. 1-1. Features • 21.3 inches • Supports a resolution of 5M pixels (Portrait: 2048 × 2560 dots (H × V)) • Uses high-contrast panel (1200:1). Enables the display of sharp images. -
Page 12: Package Contents
(PP300) • Digitalsignalcable:DVI-D-DVI-D(DualLink) (DD300DL) 1-3. EIZO LCD Utility Disk An “EIZO LCD Utility Disk” (CD-ROM) is supplied with this product. The following table shows the disk contents and the overview of the software programs. ● Disk contents and software overview The disk includes application software programs for adjustment, and Installation Manual. -
Page 13: Controls And Functions
1-4. Controls and Functions Adjustmentmenu 13 1415 1. Presence Sensor Detectsthemovementofapersoninfrontofthemonitor. button SwitchestheCALSwitchmode. Cancelsthesetting/adjustmentandexitstheAdjustmentmenu. button button Providesthemenuselectionaswellastheadjustmentandsettingofafunction. button DisplaystheAdjustmentmenu,determinesanitemonthemenuscreen,andsaves valuesadjusted. button • Turnsthepoweronoroff. • Indicatesthemonitor’soperationstatus. Green:Operating,Orange:Powersavingmode,Off:Mainpower/poweroff 7. Ambient Light Sensor Measurestheenvironmentalillumination. 8. Integrated Front Sensor UsedforcalibrationandGrayscaleCheck. (slide type) 9. Main power switch Turnsthemainpoweronoroff. -
Page 14: Chapter 2 Setting Up
Chapter 2 Setting Up 2-1. Compatible Resolutions The monitor supports the following resolutions. √:Supported DisplayPort vertical Applicable Resolution scan signal Clock Portrait Landscape Portrait Landscape Portrait frequency 720×400 VGATEXT 70Hz √ √ √ √ √ 640×480 60Hz √ √ √ √... -
Page 15: Adjusting The Screen Height And Angle
Digitalconnection (DisplayPort) Signalcable:DisplayPort-DisplayPort (supplied) Digitalconnection (DVI) Signalcable:DVI-D-DVI-D(DualLink) (supplied) Plug the power cord into a power outlet and the power connector on the monitor. Connect the USB cable when using RadiCS LE or ScreenManager Pro for Medical. ConnectingtotheMonitor ConnectingtoaComputer Press to turn on the monitor. The monitor’s power indicator lights up green. -
Page 16: Chapter 3 Troubleshooting
Chapter 3 Troubleshooting If a problem still remains after applying the suggested remedies, contact your local EIZO representative. Problem Possible cause and remedy 1. No picture • Checkwhetherthepowercordisconnectedproperly. • Powerindicatordoesnotlight. • Turnthemainpowerswitchon. • Press . • Turnoffthemainpower,andthenturnitonagainafew minuteslater. • Powerindicatorislightingorangeandgreen. -
Page 17: Error Code Table
● Error code table Error Code Description 0*** • ErrorsthatoccurredduringSelfCalibration 1*** • ErrorsthatoccurredduringGrayscaleCheck *1** • ErrorsthatoccurredduringDICOM *2** • ErrorsthatoccurredduringCAL1 *3** • ErrorsthatoccurredduringCAL2 **10 • Theproductmaximumbrightnessmaybelowerthanthetargetbrightness. • Lowerthetargetbrightness. **11 • Theproductminimumbrightnessmaybehigherthanthetargetbrightness. • Raisethetargetbrightness. **34 • Thesensormaynothavecomeoutduringcalibration,orlightmayhaveenteredthe sensor. • Turnoffthemainpower,waitforafewminutesbeforeturningthepowerbackon,and thenexecuteSelfCalibration/GrayscaleCheckagain. **61 •... -
Page 18: Chapter 4 Specifications
Chapter 4 Specifications LCDPanel Size 21.3-inch(540mm) Type TFTmonochromeLCD,LEDbacklight Surfacetreatment Anti-glare Surfacehardness Viewingangles Horizontal176˚,vertical176˚(CR≥10) Dotpitch 0.165mm Responsetime Black-white-black:Approx.25ms Horizontalscanfrequency 31-135kHz Verticalscanfrequency DVI: 24-61Hz(non-interlace) (VGATEXT:69to71Hz,QSXGA(2048×2560):24 to51Hz) DisplayPort: 49-61Hz(non-interlace) (VGATEXT:69to71Hz,QSXGA(2048×2560):49 to51Hz) Resolution 5Mpixels(Portraitorientation:2048dots×2560lines(H×V)) Max.dotclock 290MHz Displaygrayscales 1,024stepsof16,369steps RecommendedBrightness 500cd/m Displayarea(H×V) 337.9mm(13.30inch)×422.4mm(16.63inch)(Portraitorientation) Powersupply 100-120Vac±10%,50/60Hz1.1-0.9A 200-240Vac±10%,50/60Hz0.6-0.5A Power... -
Page 19: Outside Dimensions
PIVOT 211 (8.3) 18 (0.71) 209.5 (8.2) 245.5 (9.7) HIGHEST POSITION Accessories CalibrationKit EIZO“RadiCSUX1”Ver.4.1.4orlater EIZO“RadiCSVersionUpKit”Ver.4.1.4orlater NetworkQCManagementSoftware EIZO“RadiNETPro”Ver.4.1.4orlater CleaningKit EIZO“ScreenCleaner” For the latest information about the accessories and information about the latest compatible graphics board, refer to our web site. http://www.eizo.com... -
Page 20: Chapter 5 Glossary
Chapter 5 Glossary DDC (Display Data Channel) VESA provides the standardization for the interactive communication of the setting information, etc. between a PC and the monitor. DICOM (Digital Imaging and Communication in Medicine) The DICOM standard was developed by the American College of Radiology and the National Electrical Manufacturer’s Association of the USA. -
Page 21: Appendix
EIZO, the EIZO Logo, ColorEdge, DuraVision, FlexScan, FORIS, RadiCS, RadiForce, RadiNET, Raptor, and ScreenManager are registered trademarks of EIZO Corporation in Japan and other countries. ColorNavigator, EcoView NET, EIZO EasyPIX, EIZO ScreenSlicer, i • Sound, Screen Administrator, and UniColor Pro are trademarks of EIZO Corporation. -
Page 22: Medical Standard
Medical Standard • It shall be assured that the final system is in compliance to IEC60601-1-1 requirement. • Power supplied equipment can emit electromagnetic waves, that could influence, limit or result in malfunction of the monitor. Install the equipment in a controlled environment, where such effects are avoided. -
Page 23: Fcc Declaration Of Conformity
FCC Declaration of Conformity ForU.S.A.,Canada,etc.(rated100-120Vac)Only FCC Declaration of Conformity We, the Responsible Party EIZOInc. 5710WarlandDrive,Cypress,CA90630 Phone:(562)431-5011 declare that the product Tradename:EIZO Model:RadiForceGX540 is in conformity with Part 15 of the FCC Rules. Operation of this product is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 24: Emc Information
EMC Information Essential performance of RadiForce series is to display images and operate functions normally. CAUTION The RadiForce series requires special precautions regarding EMC and need to be installed, put into service and used according to the following information. Do not use any cables other than the cables that provided or specified by us. Using other cables may cause the increase of emission or decrease of immunity. - Page 25 Guidance and manufacturer’s declaration - electromagnetic immunity TheRadiForceseriesisintendedforuseintheelectromagneticenvironmentspecifiedbelow.Thecustomerortheuser oftheRadiForceseriesshouldassurethatitisusedinsuchanenvironment. Immunity test IEC/EN60601 test Compliance level Electromagnetic environment - guidance level ConductedRF 3Vrms 3Vrms PortableandmobileRFcommunications IEC/EN61000-4-6 150kHzto80MHz equipmentshouldbeusednoclosertoanypart oftheRadiForceseries,includingcables,than RadiatedRF 3V/m 3V/m therecommendedseparationdistancecalculated IEC/EN61000-4-3 80MHzto2.5GHz fromtheequationapplicabletothefrequencyof thetransmitter. RecommendedSeparationdistance d=1.2√P d=1.2√P,80MHzto800MHz d=2.3√P,800MHzto2.5GHz Where“P”isthemaximumoutputpowerrating...
- Page 26 Recommended separation distances between portable and mobile RF communications equipment and the RadiForce Series TheRadiForceseriesisintendedforuseinanelectromagneticenvironmentinwhichradiatedRFdisturbances arecontrolled.ThecustomerortheuseroftheRadiForceseriescanhelppreventelectromagneticinterferenceby maintainingaminimumdistancebetweenportableandmobileRFcommunicationsequipment(transmitters)andthe RadiForceseriesasrecommendedbelow,accordingtothemaximumoutputpowerofthecommunicationsequipment. Ratedmaximumoutput Separationdistanceaccordingtofrequencyoftransmitter poweroftransmitter 150kHzto80MHz 80MHzto800MHz 800MHzto2.5GHz d=1.2 √P d=2.3 √P d=1.2√P 0.01 0.12 0.12 0.23 0.38 0.38 0.73 Fortransmittersratedatamaximumoutputpowernotlistedabove,therecommendedseparationdistance“d”in meters(m)canbeestimatedusingtheequationapplicabletothefrequencyofthetransmitter,where“P”isthe maximumoutputpowerratingofthetransmitterinwatts(W)accordingtothetransmittermanufacturer. NOTE1 At80MHzand800MHz,theseparationdistanceforthehigherfrequencyrangeapplies.
-
Page 27: China Measures For Rohs Compliance In Chinarohs
China Measures for RoHS Compliance in ChinaRoHS About the Electronic Information Products Pollution Control Symbol This symbol identifies products regulated by the ‘Measures for the Administration of the Control of Pollution by Electronic Information Products,’ and is applicable to electronic information products for sale in the People’s Republic of China.The number in the circle is the Environmentally Friendly Use Period (EFUP).Compliance with the relevant safety precautions ensures that the product will not cause environmental pollution, bodily harm, or property damage within the specified period of time since the date of manufacture. - Page 28 Phone: +86 512 6252 0100 Fax: +86 512 6252 1508 Siemensallee 84, 76187 Karlsruhe, Germany Phone: +49 721 20321 0 Fax: +49 721 20321 471 http://www.eizo.com 1st Edition-October, 2013 Printed in Japan. 00N0L834A1 Copyright © 2013 EIZO Corporation All rights reserved. (U.M-GX540-4)
