Summary of Contents for Barco G62-W9

  • Page 1 User guide ENABLING BRIGHT OUTCOMES...
  • Page 3 Barco. If the purchaser or a third party carries out modifications or repairs on goods delivered by Barco, or if the goods are handled incorrectly, in particular if the systems are operated incorrectly or if, after the transfer of risks, the goods are subject to influences not agreed upon in the contract, all guarantee claims of the purchaser will be rendered invalid.

  • Page 5: Table Of Contents

    Table of contents 1 Safety ........................................... 9 General considerations ................................10 Important safety instructions..............................12 Product Safety Labels ..................................15 Risk Group 3 Safety ..................................16 1.4.1 General considerations............................16 1.4.2 High Brightness precautions: Hazard Distance ..................17 1.4.3 HD for fully enclosed projection systems.......................19 Regulatory......................................20 2 Product overview ....................................21 Main unit.......................................22 3 Input &...
  • Page 6 Geometry Correction..................................46 Multi-Projection ....................................48 Test Pattern ......................................49 7.10 Freeze Screen ....................................50 7.11 Reset........................................50 8 User control — Image menu...............................51 Color Mode ......................................52 Brightness ......................................52 Contrast........................................52 Saturation......................................52 Tint...........................................52 Sharpness......................................52 Gamma.........................................53 White Balance....................................53 Advanced Color ....................................53 8.10 Advanced Image .....................................55 8.11 Save to User ......................................57 8.12 Apply to User .....................................57 8.13...
  • Page 7 12.2 LED indication chart ..................................77 A Specifications ......................................79 Specifications for G62-W9.................................80 Specifications for G62-W11...............................81 Specifications for G62-W14 ..............................83 Dimensions of the G62 ................................84 Ceiling mount ....................................85 Compatibility modes..................................86 EDID table......................................90 B Regulatory information..................................93 Product compliance..................................94 China RoHS compliance................................95 Taiwan RoHS compliance ................................96 Turkey RoHS compliance................................97...
  • Page 8 R5914653 /05...

  • Page 9: Safety

    Ensure that you understand and follow all safety guidelines, safety instructions and warnings mentioned in this chapter before installing the G62 projector. Clarification of the term “G62 ” used in this document When referring in this document to the term “G62 ” means that the content is applicable for following Barco products: •...

  • Page 10: General Considerations

    • Before operating this equipment please read this manual thoroughly and retain it for future reference. • Installation and preliminary adjustments should be performed by qualified Barco personnel or by authorized Barco service dealers. • All warnings on the projector and in the documentation manuals should be adhered to.
  • Page 11 HIGH BRIGHTNESS PROJECTORS) in performing a task, and of measures to minimize the potential risk to themselves or other persons. Only Barco authorized SERVICE PERSONNEL, knowledgeable of such risks, are allowed to perform service functions inside the product enclosure. The term USER and OPERATOR refers to any person other than SERVICE PERSONNEL.

  • Page 12: Important Safety Instructions

    Safety 1.2 Important safety instructions To prevent the risk of electrical shock • This product should be operated from a mono phase AC power source. • This apparatus must be grounded (earthed) via the supplied 3 conductor AC power cable. If none of the supplied power cables are the correct one, consult your dealer.
  • Page 13 Do not place flammable or combustible materials near the projector! • Barco large screen projection products are designed and manufactured to meet the most stringent safety regulations. This projector radiates heat on its external surfaces and from ventilation ducts during normal operation, which is both normal and safe.
  • Page 14 Replacement parts: When replacement parts are required, be sure the service technician has used original Barco replacement parts or authorized replacement parts which have the same characteristics as the Barco original part. Unauthorized substitutions may result in degraded performance and reliability, fire, electric shock or other hazards.

  • Page 15: Product Safety Labels

    If the product exhibits a distinct change in performance, indicating a need for service. Safety Data Sheets for Hazardous Chemicals For safe handling information on chemical products, consult the Safety Data Sheet (SDS). SDSs are available upon request via safetydatasheets@barco.com. 1.3 Product Safety Labels Light beam related safety labels...

  • Page 16: Risk Group 3 Safety

    Do not open or disassemble the projector as this may cause damage by the exposure of laser radiation. FOR PROFESSIONAL USE ONLY means installation can only be carried out by Barco AUTHORIZED PERSONNEL familiar with potential hazards associated with high intensity light beams.

  • Page 17: High Brightness Precautions: Hazard Distance

    Safety 1.4.2 High Brightness precautions: Hazard Distance Hazard Distance (HD) is the distance measured from the projection lens at which the intensity or the energy per surface unit becomes lower than the applicable exposure limit on the cornea or on the skin.
  • Page 18 The LIP shall be installed by Barco or by a trained and Barco-authorized installer or shall only be transferred to laser light show variance holders. This is applicable for dealers and distributors since they may need to install the LIP (demo install) and/or they transfer (sell, rent, lease) the LIP.

  • Page 19: Hd For Fully Enclosed Projection Systems

    Safety 1.4.3 HD for fully enclosed projection systems Hazard Distance (HD) is the distance measured from the projection lens at which the intensity or the energy per surface unit becomes lower than the applicable exposure limit on the cornea or on the skin.

  • Page 20: Regulatory

    Safety 1.5 Regulatory UK Compliance This product is fit for use in the UK. Authorised Representative: Barco UK Ltd Address: Building 329, Doncastle Road Bracknell RG12 8PE, Berkshire, United Kingdom L’information des consommateurs sur la règle de tri REPRISE À DÉPOSER À...

  • Page 21: Product Overview

    Product overview Main unit ............................22 R5914653 /05...

  • Page 22: Main Unit

    Product overview 2.1 Main unit Component locations Image 2–1 Remote receiver (Front) Projection lens DVI-D DC 12V HDBaseT HDMI OUT HDMI-2 IN HDMI-1 IN 3G-SDI IN 3D SYNC 3D SYNC RS232 REMOTE ETHERNET MENU EXIT INPUT LENS FOCUS ENTER Image 2–2 LED Status Indicator Control panel Input/Output (I/O) Panel...
  • Page 23 Product overview Airflow Image 2–3 R5914653 /05...
  • Page 24 Product overview R5914653 /05...

  • Page 25: Input & Communication

    Input & Communication Input/Output (I/O) Panel ........................26 Control panel..........................26 R5914653 /05...

  • Page 26: Input/Output (I/O) Panel

    Input & Communication 3.1 Input/Output (I/O) Panel Input and output ports location DVI-D DC 12V HDBaseT HDMI OUT HDMI-2 IN HDMI-1 IN 3G-SDI IN 3D SYNC 3D SYNC RS232 REMOTE ETHERNET Image 3–1 DC 12V connector Wired remote connector HDBaseT connector Network connector RJ45 HDMI out connector USB Type A connector...
  • Page 27 Input & Communication Button Function ENTER Confirm the settings. INPUT Select an input source. ZOOM Adjust the image size. FOCUS Adjust the image focus. LEFT Navigate left through the menu. Navigate up through the menu. DOWN Navigate down through the menu. RIGHT Navigate right through the menu.
  • Page 28 Input & Communication R5914653 /05...

  • Page 29: Remote Control Unit (Rcu)

    Remote Control Unit (RCU) RCU battery installation ........................30 Overview of the RCU ........................31 Projector Address (ID)........................31 Using the RCU ..........................32 R5914653 /05...

  • Page 30: Rcu Battery Installation

    Remote Control Unit (RCU) 4.1 RCU battery installation How to install the batteries of the Remote Control Unit Remove the cover by sliding it in the direction indicated by the arrow Insert two new AAA batteries (observe the polarity). Replace the cover. Image 4–1 Notes for the Remote Control Unit •...

  • Page 31: Overview Of The Rcu

    Remote Control Unit (RCU) 4.2 Overview of the RCU Button identification Button location Button Function Turn the projector on. Standby Turn the projector off. Number Input numbers (0-9) Info Display information on the source image. Set the projector address. Auto Automatically synchronize the projector to an input source.

  • Page 32: Using The Rcu

    Remote Control Unit (RCU) to the same number. The default ID code of the RCU (also known as the broadcast address) is 00. This specific address allows the RCU to control all projectors within its effective range. How to set the projector address on the RCU Keep ID Key pressed in.
  • Page 33 Remote Control Unit (RCU) Image 4–2 R5914653 /05...
  • Page 34 Remote Control Unit (RCU) R5914653 /05...

  • Page 35: Powering On/Off The Projector

    Powering On/Off the projector Powering On the projector ......................36 Powering Off the Projector......................36 This chapter assumes that the power cord and (all) signal cables are securely connected. For detailed instructions see installation manual. R5914653 /05...

  • Page 36: Powering On The Projector

    Powering On/Off the projector 5.1 Powering On the projector How to power On the projector Power on the AC switch (1) and wait until the power button on the control panel is solid red. Image 5–1 Turn on the projector by pressing the POWER button (2) on the control panel or the ON key (3) on the remote control.
  • Page 37 Powering On/Off the projector MENU EXIT INPUT LENS FOCUS ENTER Image 5–4 Press the POWER button or OFF key again to confirm, otherwise the message disappears after 5 seconds and the projector remains on. CAUTION: Don’t turn on the projector immediately after entering Standby mode. R5914653 /05...
  • Page 38 Powering On/Off the projector R5914653 /05...

  • Page 39: User Controls

    User controls On-Screen Display Menus......................40 R5914653 /05...

  • Page 40: On-Screen Display Menus

    User controls 6.1 On-Screen Display Menus About OSD The projector has On-Screen Display (OSD) menus that allow you to make image adjustments and change a variety of settings. Follow the steps below to use the OSD menu to configure the projector settings. How to operate To open the OSD menu, press Menu key on the control panel or remote control.

  • Page 41: User Controls - Installation

    User controls — Installation Lens ............................43 Orientation ...........................43 Aspect Ratio..........................44 Scale ............................44 Signal ............................44 Edge Mask...........................46 Geometry Correction ........................46 Multi-Projection ..........................48 Test Pattern..........................49 7.10 Freeze Screen..........................50 7.11 Reset............................50 R5914653 /05...
  • Page 42 User controls — Installation Overview INSTALLATION Lens Orientation Aspect Ratio Auto Scale Signal Edge Mask Geometric Correction Multi-Projection Test Pattern Freeze Screen Reset Enter Select Adjust Return Image 7–1 R5914653 /05...

  • Page 43: Lens

    User controls — Installation 7.1 Lens About lens settings Configure the lens settings to adjust the image quality and position. Focus Adjust the focus of the image. Zoom Adjust the size of the projected image. Lens Shift Adjust the lens position to shift the projected area. CAUTION: For UST lens mounted in its support, do not execute any lens movements when the UST lens is fixed in the Lens Support.

  • Page 44: Aspect Ratio

    User controls — Installation 7.3 Aspect Ratio Possible aspect ratios Set the aspect ratio of the projected image. The available options are: • Auto (default) • • 16:9 • 16:10 • Letter boxing • Native Select Auto to display the detected image size. 7.4 Scale About scale Digitally scale the image size and position to fit onto the actual projection surface.
  • Page 45 User controls — Installation • First Input: Select a signal as the first input source. Once the selected source is activated, the OSD menu lists out the signal’s Resolution, Horz Refresh (horizontal refresh rate), and Color Space. • Second Input: Select a signal as the second input source. Once the selected source is activated, the OSD menu lists out the signal’s Resolution, Horz Refresh (horizontal refresh rate), and Color Space •...

  • Page 46: Edge Mask

    User controls — Installation • Backup input source (HDMI1/ HDMI2 / HDBaseT / DVI Case 2: different input source (without splitter) Image 7–5 • 2 input sources, HDMI1 and HDMI2 • When Backup Input Status is active, auto switch to HDMI2 seamlessly when HDMI1 is lost. •...
  • Page 47 User controls — Installation Image 7–6 V. Keystone : Adjust the top and bottom side of the projected image to make it an even rectangle. It is used for the images with unequal top and bottom sides. Image 7–7 • Pincushion: Pincushion function is used to adjust the image with barrel or pincushion distortion.

  • Page 48: Multi-Projection

    User controls — Installation Advanced Warp Configure advanced warp settings. • Grid Points: Set the grid points of warp pattern. • Warp Inner: Enable or disable warp inner control. Note: the warp inner does not support 2x2 grid points. • Warp Sharpness: When the grid lines are warped from straight into curve, the grid lines will be distorted and become jagged.

  • Page 49: Test Pattern

    User controls — Installation Remote Code Set the remote code for each remote control to have it matching with the projector. 3D Setup Configure the 3D settings for each projector when performing 3D warp and blend. Light Source Settings Configure the light source settings for the projectors to have their brightness level matching with each other. Color Mode Set the projectors to the same color mode.

  • Page 50: Freeze Screen

    User controls — Installation 7.10 Freeze Screen About freeze screen Select to pause the display screen despite any change in the source device. 7.11 Reset About reset Reset all the installation settings to factory default values. R5914653 /05...

  • Page 51: User Control - Image Menu

    User control — Image menu Color Mode ..........................52 Brightness............................52 Contrast............................52 Saturation ............................52 Tint ..............................52 Sharpness ...........................52 Gamma ............................53 White Balance ..........................53 Advanced Color..........................53 8.10 Advanced Image ..........................55 8.11 Save to User ..........................57 8.12 Apply to User ..........................57 8.13 Reset............................57 R5914653 /05...

  • Page 52: Color Mode

    User control — Image menu 8.1 Color Mode About color mode There are a number of color modes that are preset for different types of images. • Presentation: Best for displaying presentation slides in a bright room. • Bright: Best for the installations requiring high brightness images. •...

  • Page 53: Gamma

    User control — Image menu 8.7 Gamma About gamma Adjust the gamma levels of the image. The available options are: • 1.8, • 2.0, • Standard 2.2, • 2.4, • 2.6, • Graphic, • Video, • CRT(Vivid), • Enhanced (default), •...
  • Page 54 User control — Image menu • RGB (16 - 235), • REC709, • REC601 Wall Color Set the wall color of the projector to achieve best color performance for a specific wall. The available options are: • Off (default), • Blackboard, •...

  • Page 55: Advanced Image

    User control — Image menu 8.10 Advanced Image About advanced image Configure advanced image settings to correctly project specific image formats for more complicated applications. Dynamic Contrast Set up the Dynamic Contrast to maximizing the contrast for dark content. • Dynamic Black: Enable the function to automatically adjust the contrast ratio for video sources.
  • Page 56 User control — Image menu PIP / PBP PIP/PBP (picture in picture/picture by picture) allows simultaneously displaying two images from two input sources. • PIP/PBP: Select the appropriate PIP/PBP mode or disable the function. Off: Disable PIP/PBP mode. PIP: Display one input source on the main screen and the other input source in an inset window. PBP: Display two images of the same size on the screen.

  • Page 57: Save To User

    User control — Image menu PIP/BPB HDMI-1 HDMI-2 DVI-D 3G-SDI HDBaseT Matrix DVI-D — 3G-SDI — HDBaseT — • Sub Brightness: Adjust the luminous brightness of the sub image to adapt to different ambient light. • Sub Contrast: Adjust the contrast ratio of the sub image. •...
  • Page 58 User control — Image menu R5914653 /05...

  • Page 59: User Controls - Communication Menu

    User controls — Communication menu Projector ID..........................60 Remote Setup ..........................60 Network Setup..........................60 Control............................61 Using the web control center ......................62 Using RS232 command by Telnet ....................63 Baud Rate............................63 Reset............................64 R5914653 /05...

  • Page 60: Projector Id

    User controls — Communication menu 9.1 Projector ID About projector ID Assign an remote code for the projector from 00 to 99. Use this code as the projector ID when controlling the projector by RS232, HDBaseT, Telnet or other control methods. 9.2 Remote Setup About remote setup Configure the settings of the Infra-Red (IR) remote control.

  • Page 61: Control

    User controls — Communication menu • DHCP: Turn on DHCP to automatically acquire IP address, subnet mask, gateway, and DNS. • IP Address: Assign the projector’s IP address. • Subnet Mask: Assign the projector’s subnet mask. • Gateway: Assign the projector’s gateway. •...

  • Page 62: Using The Web Control Center

    User controls — Communication menu Telnet Control the projector using RS232 commands though Telnet connection (port 3023). HTTP Control the projector with web browser (port 80). Reset Reset the function settings to default factory values. – Crestron is a registered trademark of Crestron Electronics, Inc. of the United States. –...

  • Page 63: Using Rs232 Command By Telnet

    User controls — Communication menu Directly connect the projector to a computer When a network is not available to you, connect the projector to you computer directly using a RJ-45 cable, and configure the network settings manually. Assign IP address to the projector •...

  • Page 64: Reset

    User controls — Communication menu • 9600 • 19200 • 38400 • 57600 • 115200 (default) 9.8 Reset About reset Reset all the communication settings to factory default values. R5914653 /05...

  • Page 65: System Menu

    System menu 10.1 Language ............................66 10.2 Date and Time..........................66 10.3 On Screen Display........................67 10.4 Logo Setup ..........................67 10.5 Schedule .............................67 10.6 Standby Mode ..........................70 10.7 Power Settings ..........................70 10.8 Light Source Settings........................70 10.9 Shutter............................70 10.10 Security ............................71 10.11 Backlight............................71 10.12 High Altitude..........................71 10.13 12V Trigger ..........................72 10.14 User Data ............................72 10.15 Reset............................72...

  • Page 66: Language

    System menu 10.1 Language About language Select a language for the OSD menu. The available languages are: • English, • Simplified Chinese, • French, • German, • Italian, • Japanese, • Korean, • Russian, • Spanish, • Portuguese, • Indonesian, •...

  • Page 67: On Screen Display

    System menu 10.3 On Screen Display About on screen display Set up the on screen display menus. Menu Location Select the menu location from Top Left, Top Right, Center, Bottom Left, and Bottom Right. Menu Transparency Set the menu transparency level. Menu Timer Set the length of time the menu displays on the screen.
  • Page 68 System menu Schedule Date and Time 2019/11/06 14:00 Schedule Mode View Today Monday Monday Power On + Tuesday Wednesday Thursday Friday Saturday Sunday Special Dates 2019/11/12 + Reset Schedule Enter Select Return Enter Exit Image 10–1 Date and Time Check or adjust the date and time for the projector. Schedule Mode Enable or disable the schedule function.
  • Page 69 System menu • Event 01-08 / Event 09-16: Select an event record number, and set up the schedule details. Time: Set the time for the event. Function: Set the function. The available functions are Power Settings, Input Source, Light Source Mode, and Shutter.

  • Page 70: Standby Mode

    System menu 10.6 Standby Mode About standby mode Setup the projector standby mode. • Standby Mode: Minimum power consumption (0.5 Watt) which does not allow network controlling. • Network Standby Mode: Low power consumption (< 2 Watt) which allows the LAN module to enter sleep mode and supports to be woken by Wake on LAN (WoL).

  • Page 71: Security

    System menu Fade-In This function allows the fading in effect when turning off shutter. The time for the fading effect can be adjusted from 0.5s to 5s. Fade-Out This function allows the fading out effect when turning on shutter. The time for the fading effect can be adjusted from 0.5s to 5s.

  • Page 72: Trigger

    System menu 10.13 12V Trigger About 12V trigger When enabled, the projector screen is automatically raised or lowered when the projector is turned on or off. This function only works when the projector is connected to an electrical projector screen. 10.14 User Data About user data User can save the projector settings as user data and reload the settings later.

  • Page 73: Information Menu

    Information menu 11.1 Projector information and status.....................74 R5914653 /05...

  • Page 74: Projector Information And Status

    Information menu 11.1 Projector information and status Overview View the projector information about its status and settings. The projector information is read only. • Projector Model Name Serial Number Total Projector Hours • System Status Standby Mode Light Source Mode Light Source Hours Temperature •...

  • Page 75: Troubleshooting

    Troubleshooting 12.1 Projector Problems ........................76 12.2 LED indication chart........................77 If you experience a problem with your projector, please refer to the following information. If a problem persists, please contact your local re-seller or service center. R5914653 /05...

  • Page 76: Projector Problems

    Troubleshooting 12.1 Projector Problems No image appears on-screen • Check if all the cables and the AC power are correctly connected. For more details, refer to the installation manual. • Check if the pins of the connectors are not crooked or broken. •...

  • Page 77: Led Indication Chart

    Troubleshooting Image is reversed • To reverse the image, enable rear projection by selecting “Installation > Orientation > Direction > Rear Projection” from the OSD menu. The projector stops responding to all controls • If possible, turn off the projector, then unplug the power cord and wait at least 60 seconds before reconnecting power.
  • Page 78 Troubleshooting Light LED Status LED AV Mute LED Message Orange Orange Orange Green Green Green Projector Steady Flash- Steady communication Firmware upgrade Flash- Flash- Error Steady (Over temperature) Error Flash- (Fan failure) Power key of the keypad is in steady red light when the projector enters standby mode. R5914653 /05...

  • Page 79: A Specifications

    Specifications Specifications for G62-W9......................80 Specifications for G62-W11 ......................81 Specifications for G62-W14 ......................83 Dimensions of the G62 .........................84 Ceiling mount ..........................85 Compatibility modes ........................86 EDID table ...........................90 R5914653 /05...

  • Page 80: Specifications For G62-W9

    Specifications A.1 Specifications for G62-W9 Overview Projector type Single chip DLP laser phosphor projector Technology 0.67" Resolution 1,920 x 1,200 (WUXGA) Brightness 8,000 ANSI lumens 8,900 center lumens 9,500 ISO lumens Contrast ratio 1,200:1 sequential; 6,000:1 dynamic; Extreme black: 750,000:1...

  • Page 81: Specifications For G62-W11

    Specifications Power requirements 100-240V / 50-60Hz Power consumption 625W nominal, 750W maximum BTU per hour 2,133 BTU/h nominal; 2,252 BTU/h maximum Standby power less than 0.5W Noise level (typical at 25°C/ 36dB(A) - 40dB(A) depending on the used mode 77°F) Operating temperature 0 - 40 °C (sea level) Storage temperature...
  • Page 82 Specifications Color correction CLO (constant light output) Light source Laser phosphor Light source lifetime Up to 20,000hrs Light source warranty 20.000hrs or 3 years, whatever comes first Sealed DLP™ core Optical dowser laser dimming Orientation 360° rotation, no restrictions DMX 512 Active stereoscopic 3D Image processing Embedded warp &...

  • Page 83: Specifications For G62-W14

    Specifications Standard accessories Power cord, wireless remote control Certifications CE, FCC Class A, cTUVUS, CCC, EAC, KCC, RCM, BIS, BSMI Warranty Limited 3 years parts and labor A.3 Specifications for G62-W14 Overview Projector type Single chip DLP laser phosphor projector Technology 0.67"...

  • Page 84: Dimensions Of The G62

    Specifications Software tools Projector Toolset Control IR, RS232, RJ45, 3.5mm phone jack for wired remote Network connection 10/100 Ethernet, RJ45 Output 1 x HDMI Out / 1 x 3D SYNC Out / 1 x DC 12V Out Power requirements 100-240V / 50-60Hz Power consumption 1020W nominal, 1200W maximum BTU per hour...

  • Page 85: Ceiling Mount

    Specifications Rear view Image A–2 Dimensions given in millimeters. Top view 484.0 529.0 509.0 Image A–3 Dimensions given in millimeters. Left view Image A–4 Dimensions given in millimeters. A.5 Ceiling mount About ceiling mount CAUTION: Be sure to use the correct screw size. Screw Length will vary depending on the thickness of the mounting plate.

  • Page 86: Compatibility Modes

    Specifications CAUTION: Be sure to keep at least 30 mm gap between the ceiling and the bottom of the projector. Projector mounting holes 280.0 140.0 100.0 100.0 310.0 310.0 99.0 99.0 4 - M6 x1.0P L10 280.0 Image A–5 Dimensions given in millimeters. A.6 Compatibility modes Timing table Signal...
  • Page 87 Specifications Signal Signal Format V sync (Hz) Resolution HDMI1/2 HDBaseT 3G-SDI type 848x480 1024x768 SXGA 1152x864 1152x870 WXGA 1280x768 WXGA 1280x800 SXGA 1280x960 1280x1024 WXGA 1360x768 1366x768 SXGA+ 1400x1050 WXGA+ 1440x900 1440x900 1440x900 WXGA++ 1600x900 UXGA 1600x1200 1600x1200 WSXGA+ 1680x1050 WSXGA RB 1920X1200RB NTSC...
  • Page 88 Specifications Signal Signal Format V sync (Hz) Resolution HDMI1/2 HDBaseT 3G-SDI type 720p 1280x720 59,94 1080p 1920x1080 23,98 29,97 59,94 Manda- Frame Packing 1920x1080 23,98 tory 3D 1080p Frame Packing 1280x720 720p 59,94 Side by Side 1920x1080 1080i 50,94 Side by Side 1920x1080 23,98 1080p...
  • Page 89 Specifications Signal Signal Format V sync (Hz) Resolution HDMI1/2 HDBaseT 3G-SDI type HDTV 1080i 1080i Ycb- Cr422 10bit 59.94 HDTV 1080p 1080p Ycb- 23.98 Cr422 10bit 29.97 HDTV 1080sF 1080sF Ycb- Cr422 10bit 29.97 3GA-SDI HDTV 1080p 1080p Ycb- Cr422 10bit 59.94 3GB-SDI HDTV 1080p...

  • Page 90: Edid Table

    Specifications A.7 EDID table Established timing Standard timing Detail timing 720x400@70Hz 1024x768 @120Hz 1920x1200@59Hz 720x400@88Hz 1280x800@75Hz 1920x1080@60Hz 640x480@60Hz 1280x1024@60Hz 640x480@60Hz 640x480 @67Hz 1360x765 @60Hz 720x480 @60Hz 640x480 @72Hz 800x600 @120Hz 1280x720 @60Hz 640x480 @75Hz 1400x1050 @60Hz 1920x1080i @60Hz 800x600 @56Hz 1600x1200 @60Hz 720x480i @60Hz 800x600 @60Hz...
  • Page 91 Specifications Established timing Standard timing Detail timing 1024x768 @75Hz 1440x480 @60Hz 1280x1024 @75Hz 1920x1080 @25Hz 1152x870 @75Hz 1280x720 @120Hz 1920x1080 @120Hz 3840x2160 @24Hz 3840x2160 @25Hz 3840x2160 @30Hz 4096x2160 @24Hz 4096x2160 @25Hz 4096x2160 @30Hz HDMI 2.0 Established timing Standard timing Detail timing 720x400@70Hz 1024x768@120Hz 1920x1200@59Hz...
  • Page 92 Specifications Established timing Standard timing Detail timing 3840x2160@50Hz 3840x2160@60Hz R5914653 /05...

  • Page 93: B Regulatory Information

    Regulatory information Product compliance ........................94 China RoHS compliance .......................95 Taiwan RoHS compliance......................96 Turkey RoHS compliance......................97 Disposal information ........................97 Contact information........................98 Download Product Manual ......................98 R5914653 /05...

  • Page 94: Product Compliance

    Regulatory information B.1 Product compliance UK Compliance This product is fit for use in the UK. Authorised Representative: Barco UK Ltd Address: Building 329, Doncastle Road Bracknell RG12 8PE, Berkshire, United Kingdom EurAsian Conformity (EAC) This product complies with the Safety of Low-Voltage Equipment (LVE Technical Regulation 004/...

  • Page 95: China Rohs Compliance

    Electronic Products” (Also called RoHS of Chinese Mainland), the table below lists the names and contents of toxic and/or hazardous substances that Barco’s product may contain. The RoHS of Chinese Mainland is included in the MCV standard of the Ministry of Information Industry of China, in the section “Limit Requirements of toxic substances in Electronic Information Products”.

  • Page 96: Taiwan Rohs Compliance

    Chinese Mainland, marked with the Environmental Friendly Use Period (EFUP) logo. The number inside the EFUP logo that Barco uses (please refer to the photo) is based on the “General guidelines of environment-friendly use period of electronic information products”...

  • Page 97: Turkey Rohs Compliance

    備考3.〝—〞係指該項限用物質為排除項目。 Note 3：The “—” indicates that the restricted substance corresponds to the exemption. 備註: 此RoHS表格適用於以下產品型號: G62-W9, G62-W11, G62-W14 Hint: This RoHS table is suitable for following models: G62-W9, G62-W11, G62-W14 B.4 Turkey RoHS compliance Turkey RoHS compliance Türkiye Cumhuriyeti: AEEE Yönetmeliğine Uygundur.

  • Page 98: Contact Information

    Registered office address: President Kennedypark 35, 8500 Kortrijk, Belgium Contact address: Beneluxpark 21, 8500 Kortrijk, Belgium Importers contact information To find your local importer, contact Barco directly or one of Barco's regional offices via the contact information given on Barco's web site, www.barco.com. B.7 Download Product Manual Download Product Manual Product manuals and documentation are available online at www.barco.com/td.

  • Page 99: Index

    Index Numbers/Symbols Date 66 12V trigger 72 Dimensions 84 Disposal 97 Battery 98 Download Product manual 98 Advanced color 53 Advanced image 55 Apply to user 57 Aspect ratio 44 Edge mask 46 EDIT table 90 Electrical shock 12 Backlight 71 Enclosed projection 19 Environmental information Battery...
  • Page 100 Index High altitude 71 High Brightness precautions 17 On screen display 67 On/Off 35 Orientation 43 OSD 40 ID 31 Overview 31 Image menu 51 Advanced color 53 Advanced image 55 Apply to user 57 Personal injury 12 Brightness 52 Power 35 Color mode 52 Power Off 36...
  • Page 101 Index High altitude 71 Light source settings 70 Power settings 70 Reset 72 Service 72 Shutter 70 Standby mode 70 User data 72 Security Schedule menu Security 71 Service 72 Sharpness 52 Shutter 70 Signal 44 Specifications 79 G62 W11 81 G62 W9 80 G62-W14 83 Standby mode 70...
  • Page 102 Index R5914653 /05...
  • Page 104 R5914653 /05 | 2022-08-22 www.barco.com...

This manual is also suitable for:

G62 seriesG62-w11G62-w14
