Summary of Contents for Barco Graphics 9200

  • Page 1 All manuals and user guides at all-guides.com GRAPHICS 9200 R9001320 OWNER'S MANUAL...
  • Page 2 All manuals and user guides at all-guides.com...
  • Page 3 All manuals and user guides at all-guides.com BARCO PROJECTION SYSTEMS GRAPHICS 9200 R9001320 OWNER'S MANUAL Date : Rev : Art. No. : 030798 R5975947...
  • Page 4 The use of shielded cables is required to comply within the limits of Part15 of FCC rules and EN55022. BARCO n.v./Projection Systems Noordlaan 5 B-8520 Kuurne Belgium Tel : +32/56/368211 Fax : +32/56/351651 E-mail : sales.bps@barco.com Visite Barco at the web : http://www.barco.com Printed in Belgium...
  • Page 5 All manuals and user guides at all-guides.com Table of Contents TABLE OF CONTENTS...
  • Page 6 All manuals and user guides at all-guides.com Table of Contents...

  • Page 7: Unpacking And Dimensions

    All manuals and user guides at all-guides.com Unpacking and Dimensions UNPACKING AND DIMENSIONS Unpacking Pull To open Warning : To prevent overheating of the projector as table mounted, always remove the wooden board and turn in the 3 supporting feet to allow air circulation via the built-in dust filter at the bottom.

  • Page 8: Battery Installation In The Rcu

    All manuals and user guides at all-guides.com Unpacking and Dimensions Battery installation in the RCU. Note : projector address has to be programmed on the RCU before using the RCU (see chapter 'Controlling'). 3 1 0 a .D R W...
  • Page 9 All manuals and user guides at all-guides.com Installation Guidelines INSTALLATION GUIDELINES Installation guidelines * Environment * What about ambient light ? * Which screen type? T p…rr Ðvq ‡u For more information about screens, contact your local screen supplier. * What image size? How big should the image be?
  • Page 10 All manuals and user guides at all-guides.com Installation Guidelines * Where to install the projector? Inputs and computer video format input compatibility : Definitions of the Abbreviation on drawings • • • • • • • • • Lens type selection. C eiling O p tica l a xis p ro je ctio n len s CD = B - A...

  • Page 11: Location And Functions Of Control

    All manuals and user guides at all-guides.com Location and Functions of Control LOCATION AND FUNCTIONS OF CONTROL Front Panel Terminology ÃÃ!"ÃW T h i s d e v i c e c o m p li e s w it h P art 1 5 o f t h e F C C ru l e s . O p e ra t i o n i s s u b je c t to f o ll o w i n g t w o c on d i t i o n s : ÃÃ(ÃÃÃÃÃ#Ã6 (1 ) T h i s d ev ic e m a y n ot c a u s e h a rm f u l i n t e rf e r en c e...
  • Page 12 &2/25 TEXT PAUSE %5,*+71(66 SHARPN TINT BRIGHTN &2175$67 &2175$67 PHASE COLOR 3 2a Terminology Barco Key FREEZ ADJ. ENTER EXIT Control disc Key '+' and '-' keys STBY PAUSE Help : Digit buttons Picture controls '+' and '-' keys PHASE...

  • Page 13: Installation & Setup

    All manuals and user guides at all-guides.com Installation Set Up INSTALLATION SET UP 5HDU&HLOLQJ ) URQW& HLOLQJ 5HDU7DEOH )URQW7DEOH ADJUST ENTER ENTER ADJUSTMENT MODE ENTER INSTALLATION EXIT or ADJUST ENTER INSTALLATION ENTER CONFIGURATION EXIT ADJUST CONFIGURATION ENTER FRONT/TABLE ENTER EXIT ADJUST...
  • Page 14 All manuals and user guides at all-guides.com Installation Set Up...

  • Page 15: Power (Mains) Cord Connection

    All manuals and user guides at all-guides.com Connections CONNECTIONS Power (mains) cord connection T h i s d e vic e co m p lie s w it h P a r t 1 5 o f th e F C C r u le s . O p e ra t io n is s u b je c t to fo ll o w in g t w o c o n d itio n s : ( 1 ) T h is d e vi ce m a y n o t c a u se h a r m f u l in te r fe r e n c e Fuses...

  • Page 16: Switching Off

    All manuals and user guides at all-guides.com Connections Lamp Run Time Lamp run time Lamp run time is 1000 hours. Operating the lamp longer than 1000 hours may damage 980 hours the projector. Please replace the lamp. WARNING Warning : Using a lamp for more than 1000 hours is dangerous, the lamp could explode.

  • Page 17: Video/S-Video Input Module

    All manuals and user guides at all-guides.com Connections Video/S-video input module VID EO AU D IO S-VID EO WD9@ P TWD9@P ÃDI QVU PR OJEC TOR MODE : DIAGNOSTICS GREEN - OPERATION CODE IR-RECEIVER IR-ACKNOWLEDGED C O MM UN IC ATIO N POR T RED - STAND BY RS232 OUT R S 232 IN...

  • Page 18: Rgb Analog Input Module

    All manuals and user guides at all-guides.com Connections RGB Analog Input Module. PROJECTOR M ODE : GREE N - OPER ATION DIAGNOSTICS CODE IR-RECEIVER IR-ACKNOWLEDGED CO M M UN IC ATIO N PO R T RED - STAN DBY RS232 OUT R S 232 IN (800-PE R IPH ERA LS) R EMO TE...
  • Page 19 All manuals and user guides at all-guides.com Connections System Settings ENTER ADJUSTMENT MODE ENTER INSTALLATION ENTER INPUT SLOTS RGB-SS [CV] RGB-SS [CS or HS&VS] RGB-SOG Component Input Module. 8P H QP I@ IUÃWD9@ PÃDIQ VU PROJEC TOR MO DE : DIAGNOSTICS G REEN - O PERATION CODE...

  • Page 20: Rgb3S/Rg3Sb Input Module

    All manuals and user guides at all-guides.com Connections Straps on module level : Ay‚h‡vtÂ…Á‚Ãsy‚h‡vtÃvƒˆ‡ Non-Floating Floating T’pÆryrp‡v‚ T ’  p   Ã` T r ƒ h …h ‡r Æ ’  p U …vyr‰ryÃT’p I ‚ … € h yÃT ’  p RGB3S/RG3sB Input Module.

  • Page 21: Connecting A Computer, E.g. Ibm Pc (Or Compatible), Apple Macintosh To The Rs 232 Input Of The Projector

    All manuals and user guides at all-guides.com Connections Straps on module level : E ' ÃT ’  p Æ r yr p ‡v‚ T rƒ h …h ‡r Æ ’ p T ’  p   Ãt …r r E &...
  • Page 22 All manuals and user guides at all-guides.com Connections Connecting a RCVDS 05 to the projector. Connecting a VS05 to the projector Connecting an IR Remote Receiver 800 to the projector.

  • Page 23: Projector Address

    All manuals and user guides at all-guides.com Controlling CONTROLLING IR sensor IR sensor How to Use the RCU? T h i s d e v i c e c o mp l i e s w i t h Pa r t 1 5 o f t h e FC C r u l e s .

  • Page 24: How To Display A Projector Address

    All manuals and user guides at all-guides.com Controlling How to Display a Projector Address? ADDRESS How to Program an Address into the RCU? PROJECTOR ADDRESS ADDRESS Picture Controls with Direct Access. Brightness Control BRIGHTNESS 'brightness' Contrast Control Color Saturation Tint Control Sharpness Control.

  • Page 25: Start Up Of The Adjustment Mode

    All manuals and user guides at all-guides.com Start up of the Adjustment Mode START UP OF THE ADJUSTMENT MODE Adjustment Mode ADJUST ENTER ADJUSTMENT MODE ENTER EXIT ADJUST Installation Random Access Service PASSWORD ENTER PASSWORD Error EXIT 0 0 0 0...
  • Page 26 All manuals and user guides at all-guides.com Start up of the Adjustment Mode...

  • Page 27: Starting Up The Random Access Adjustment Mode

    All manuals and user guides at all-guides.com Random Access Adjustment Mode RANDOM ACCESS ADJUSTMENT MODE Starting up the Random Access Adjustment Mode ADJUSTMENT MODE ENTER File Service...
  • Page 28 All manuals and user guides at all-guides.com Random Access Adjustment Mode File Service ENTER RANDOM ACCESS ADJUSTMENT MODE ENTER EXIT ADJUST FILE SERVICE Load File FILE SERVICE ENTER LOAD FILE ENTER ENTER CONFIRM LOAD FILE ENTER ENTER EXIT Edit File FILE SERVICE EDIT ENTER...
  • Page 29 All manuals and user guides at all-guides.com Random Access Adjustment Mode EDIT FILE xga.s30 ENTER ENTER ENTER How to find the correct values for the displayed item? "Horizontal Total Pixels" "Active Pixels" "Horizontal Start "Horizontal Period" "Vertical Total Lines" "Active Lines" Vertical start Interlaced [On] or [Off] Read AMDS...
  • Page 30 All manuals and user guides at all-guides.com Random Access Adjustment Mode Options Source Number EDIT FILE OPTIONS Clamp Position ENTER Clamp Width Field Polarity Inverted Example for clamp position [trailing] ENTER Vertical Refresh [sync/async] Sync pulse Clamp pulse Clamp width Vertical Sync Polarity CONFIRM EDIT FILE...
  • Page 31 All manuals and user guides at all-guides.com Random Access Adjustment Mode Rename ENTER FILE SERVICE ENTER RENAME FILE RENAME FILE ENTER EXIT Copy FILE SERVICE ENTER ENTER COPY FILE COPY FILE ENTER EXIT...
  • Page 32 All manuals and user guides at all-guides.com Random Access Adjustment Mode Delete FILE SERVICE ENTER ENTER DELETE FILE ENTER CONFIRM EXIT DELETE FILE File Options ENTER FILE SERVICE FILE OPTIONS Picture Tuning ENTER RANDOM ACCESS ADJUSTMENT MODE PICTURE TUNING...

  • Page 33: Sync Slow/Fast

    All manuals and user guides at all-guides.com Random Access Adjustment Mode Sync slow/fast PICTURE TUNING SYNC [FAST] ENTER Still Video PICTURE TUNING STILL VIDEO [ON] Color Temperature PICTURE TUNING ENTER COLOR TEMPARATURE COLOR TEMPERATURE CUSTUM COLOR BALANCE GAIN RED...
  • Page 34 All manuals and user guides at all-guides.com Random Access Adjustment Mode Gamma PICTURE TUNING GAMMA GAMMA = 2.2 Geometry RANDOM ACCESS ADJUSTMENT MODE ENTER GEOMETRY ENTER ENTER Shift GEOMETRY ENTER GEOMETRY Size ENTER Fixed sides Horizontal size adjustment Vertical size adjustment Example for table mount configuration...

  • Page 35: Side Keystone

    All manuals and user guides at all-guides.com Random Access Adjustment Mode Side Keystone GEOMETRY Blanking GEOMETRY BLANKING Top blanking Right blanking Left blanking Bottom blanking...
  • Page 36 All manuals and user guides at all-guides.com Random Access Adjustment Mode Adjustment of the blanking on the top of the image BLANKING Adjustment of the blanking on the bottom of the image Correct by pushing the control disc up or down Adjustment of the blanking on the left side Adjustment of the blanking on the right side Correct by pushing the control disc to the right or to the left...

  • Page 37: Installation Mode

    All manuals and user guides at all-guides.com Installation Mode INSTALLATION MODE Starting up the Installation Mode ADJUSTMENT MODE Select a path from below : ENTER RANDOM ACCESS ENTER INSTALLATION EXIT SERVICE Source 01 INSTALLATION INPUT SLOTS CONVERGENCE CONFIGURATION INTERNAL PATTERNS Select with then <ENTER>...
  • Page 38 All manuals and user guides at all-guides.com Installation Mode Convergence INSTALLATION "Convergence" INPUT SLOTS ENTER CONVERGENCE CONFIGURATION OSD COLOR INTERNAL PATTERNS Select with Select with Select with Select with then <ENTER> then <ENTER> then <ENTER> then <ENTER> CONVERGENCE <EXIT> to return. <EXIT>...
  • Page 39 All manuals and user guides at all-guides.com Installation Mode EXIT Convergence Red on green convergence. Red on green ENTER CONVERGENCE GREEN BLUE ON GREEN RED ON GREEN HATCH Select with then <ENTER> <EXIT> to return. EXIT Convergence EXIT Convergence 5975957 BARCOGRAPHICS 9200 221297...
  • Page 40 All manuals and user guides at all-guides.com Installation Mode Blue on green convergence. Blue on green ENTER CONVERGENCE GREEN BLUE ON GREEN RED ON GREEN HATCH Select with then <ENTER> <EXIT> to return. Hatch ENTER ENTER EXIT Configuration ENTER INSTALLATION INPUT SLOTS For more information, see Projector configuration in chapter 4 : CONVERGENCE...

  • Page 41: Starting Up The Service Mode

    Starting up the Service Mode Starting up the Service Mode ADJUSTMENT MODE ENTER ENTER SERVICE ENTER ENTER ENTER ENTER EXIT EXIT SERVICE SERVICE BARCO CHANGE PASSWORD CHANGE LANGUAGE GRAPHICS 9200 SERVICE CHANGE PROJ. ADDRESS CHANGE BAUDRATE PC RESET LAMP RUN TIME LAMP RUNTIME HISTORY...
  • Page 42 All manuals and user guides at all-guides.com Service Mode SERVICE PANEL ADJUSTMENT PRESET INPUT BALANCE RED COARSE SERVICE I2C DIAGNOSIS 60 Hz TRACKING Identification Identification ENTER SERVICE Identification type software version Proj. Address Installation Baud rate Projector Run Time Projector Serial number...

  • Page 43: Change Password

    All manuals and user guides at all-guides.com Service Mode Change Password How to enable or disable the password function ? This device complies with Part 15 of the FCC rules. Operation ÃÃ!" ÃW is subject to following two conditions : (1) This device may not cause harmful interference ÃÃ(ÃÃÃÃÃ# Ã6 (2) This device must accept any interference received...

  • Page 44: Change Language

    All manuals and user guides at all-guides.com Service Mode How to change the password ? SERVICE ENTER ENTER EXIT ADJUST CHANGE PASSWORD Change Language SERVICE CHANGE LANGUAGE Change Projector Address SERVICE CHANGE PROJ. ADDRESS Change Baudrate PC SERVICE ENTER...

  • Page 45: Lamp Power

    All manuals and user guides at all-guides.com Service Mode CHANGE BAUDRATE PC ENTER Reset Lamp Runtime SERVICE ENTER EXIT WARNING ----------------------------------------------------- RISK OF ELECTRICAL SHOCK _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ Lamp Run Time History SERVICE ENTER...
  • Page 46 All manuals and user guides at all-guides.com Service Mode Panel Adjustments SERVICE PANEL ADJUSTMENTS Changing these settings may seriously affect the perform- ance of the projector. ENTER WARNING Preset Input Balance SERVICE ENTER PRESET INPUT BALANCE PRESET INPUT BALANCE EXIT 60 Hz Tracking SERVICE 60 Hz Tracking...

  • Page 47: Standard Source Set Up Files

    All manuals and user guides at all-guides.com Appendix A : Standard Source Set Up Files STANDARD SOURCE SET UP FILES Name : FVERT Hz : FHOR kHz : FPIX MHz : PTOT : PACT : LTOT : LACT :...
  • Page 48 All manuals and user guides at all-guides.com Appendix A : Standard Source Set Up Files...

  • Page 49: Focusing The Lens

    All manuals and user guides at all-guides.com Lenses LENSES Focusing the lens Lens Cleaning Procedure Cleaning procedure for HD(1.5-3:1) lens and HD(3-5.3:1) lens. FIRST lightly DO NOT DO NOT DO NOT use an aerosol. moisten the cloth or tissue Cleaning procedure for the other HD lens...
  • Page 50 All manuals and user guides at all-guides.com Lenses Lenses Lens formulas to calculate the projector distance.

  • Page 51: Projector Without Any 800 Peripheral Connected

    All manuals and user guides at all-guides.com Source Numbers 90 - 99 SOURCE NUMBERS 80 - 89 AND 90 - 99 Projector without any 800 peripheral connected. Projector with a 800 peripheral connected. Source numbers 90 - 99.
  • Page 52 All manuals and user guides at all-guides.com Source Numbers 90 - 99 Source numbers 81 - 84...
  • Page 53 All manuals and user guides at all-guides.com 5&8 5&8 DI Q V UÃTP V S 8 @T DI Q V UÃTP V S 8@T 352-(&725 352-(&725 DIQVUÃTP V S8@T DIQVUÃTP V S8@T 5&9'6 5&9'6...
