Battery. See Changing the 12V Battery (page 326).
H
Air filter assembly. See Changing the Engine Air Filter (page 326).
ENGINE OIL
ENGINE OIL DIPSTICK OVERVIEW
E270482
A
Minimum.
B
Nominal.
C
Maximum.
CHECKING THE ENGINE OIL LEVEL
1.
Make sure that your vehicle is on level
ground.
2. Check the oil level before starting the
engine, or switch the engine off after
warming up and wait 10 minutes for
the oil to drain into the oil pan.
3. Remove the dipstick and wipe it with
a clean, lint-free cloth.
4. Reinstall the dipstick and make sure it
is fully seated.
5. Remove the dipstick again to check the
oil level.
Note: If the oil level is between the
maximum and minimum marks, the oil level
is acceptable. Do not add oil.
2021 Bronco (TG1) Canada/United States of America, enUSA, Edition date: 202101, First-Printing
Maintenance
6. If the oil level is at the minimum mark,
immediately add oil.
7.
Reinstall the dipstick. Make sure it is
fully seated.
Note: The oil consumption of new engines
reaches its normal level after approximately
3,000 mi (5,000 km).
ADDING ENGINE OIL
WARNING: Do not remove the filler
cap when the engine is running.
WARNING: Do not add engine oil
when the engine is hot. Failure to follow
this instruction could result in personal
injury.
Do not use supplemental engine oil
additives because they are unnecessary
and could lead to engine damage that the
vehicle warranty may not cover.
1.
Clean the area surrounding the engine
oil filler cap before you remove it.
2. Remove the engine oil filler cap.
3. Add engine oil that meets our
specifications. See Capacities and
Specifications (page 393).
4. Reinstall the engine oil filler cap. Turn
it clockwise until you feel a strong
resistance.
Note: Do not add oil further than the
maximum mark. Oil levels above the
maximum mark may cause engine damage.
Note: Immediately soak up any oil spillage
with an absorbent cloth.
321
