2.5.2 Wiring Examples
The following illustrate how to connect power to single and dual power supplies.
Figure 2.7
RUGGEDCOM RSG2100
Installation Manual, 11/2022, C79000-G8976-1040-20
#6 Ring Lug
3
Figure 2.6 Chassis Ground Connection
DANGER
Electrocution hazard – risk of death, serious personal injury and/or damage
to the device
Make sure the supplied terminal block cover is always installed before the
device is powered.
Install the terminal block cover.
Single AC Power Supply
Installing the Device
2.5.2 Wiring Examples
