- Page 1 2.4 GHz Wireless B&W Video Security System with 1 camera Instruction Manual English Version1.0 MODEL: SG6331P www.lorexinternational.com Copyright © 2006 Lorex Technology Inc.
- Page 2 CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Explanation of two Symbols The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage“...
-
Page 3: Safety Instructions
SAFETY INSTRUCTIONS IMPORTANT SAFEGUARDS All the safety and operating instructions should be read before the Appliance is operated and retained for future reference. 1. HEED WARNINGS - All warnings on the appliance and in the operating instructions should be adhered to. 2. -
Page 4: Table Of Contents
TABLE OF CONTENTS INTRODUCTION & FEATURES……………………………………… SYSTEM INCLUDES………………………………………………….. CONTROLS AND FUNCTIONS Monitor …...….……………………..……... Camera ...….……………...……….……...…… INSTALLATION Camera ...……………….…... Monitor ...………... SYSTEM OPERATION Additional camera connection……………………………………. Auto Scanning……………………………………………………… Auto & Manual Viewing Options…………………………………. Selectable Dwell Settings………………………………………… Connecting The Monitor To A VCR ……...………………..……. OPTIONAL ACCESSORIES ... -
Page 5: Introduction & Features
INTRODUCTION: Thank you for purchasing the 2.4 GHz Wireless B&W Video System. This is an ideal solution for monitoring your business or home, or for safeguarding your valuables. The package contains a 5.5” B&W Monitor, and 1 wireless B&W camera. The system allows you to automatically scan between locations with the convenience of connecting up to 4 cameras (additional cameras sold separately). -
Page 6: System Includes
SYSTEM INCLUDES: 5.5” – 2.4 GHz B&W Monitor Owner’s Manual 1 - 2.4 GHz B&W Wireless Camera with camera stand & screws Also includes: 1 – 9V DC 500mA Adapter (Camera) with battery option (4 “AA”, not included) 1 – 13.8V DC 1000mA Adapter (Monitor) with battery option (10 “C”, not included) 1 –... -
Page 7: Monitor
MONITOR CONTROLS – FRONT & BACK PANEL MONITOR FRONT VIEW Location of Receiver Monitor controls 1. 2.4GHz Antenna - High gain dipole patch antenna receives audio and video signal from the camera. 2. CRT - 5.5” Diagonal Screen 3. Brightness Control – Allows you to adjust the brightness of the picture 4. -
Page 8: Camera
CAMERA CONTROLS Front/Side View 1. Microphone – Built-in condenser microphone provides listen-in audio capability from camera to monitor 2. Lens – B&W CMOS Image Sensor 3. 6 Infrared LED’s – Enhances the picture quality in low light conditions 4. Channel Selector Switch – Slide switch for channels 1-4 5. -
Page 9: Installation Camera
CAMERA INSTALLATION NOTE Ensure the power switch on the monitor and camera are set to the OFF position before proceeding with the following steps. 1. Attach the stand base to the wall or ceiling where you want to install the camera. -
Page 10: Monitor
MONITOR INSTALLATION 1. Connect the supplied 13.8V AC adapter to the DC INPUT JACK at the rear of the receiver monitor and plug it into an electrical outlet. BATTERY CASE & COMPARTMENT Remove the battery case by unscrewing the bolt at the bottom of the monitor and sliding the battery case out. -
Page 11: Additional Camera Connection
OPERATION Camera (1) Connect the power adapter to the camera power input and ensure the camera is turned “ON”. Ensure the camera is set to channel 1. Monitor (1) Connect the supplied power adaptor to the power input of the monitor. (2) Use the channel selection switch button and ensure the monitor is set to the same channel as the camera to view the picture. -
Page 12: Auto Scanning
AUTO & MANUAL VIEWING OPTIONS This system is preset to Manual mode. In Auto mode, the LED light will be ON. To manually view a specific camera location, set the Auto/Manual button to Manual. Then press the channel selector button to navigate between Channels 1-4. -
Page 13: Connecting The Monitor To A Vcr
CONNECTING THE MONITOR TO A VCR FOR RECORDING Monitor AC Adapter Connections for recording Connect the supplied audio/video cable from the back of the monitor to the Audio/Video In of the VCR. Please Note: To record, you must select the A/V or AUX channel on your VCR. -
Page 14: Optional Accessories
Picture rolls and jumps -Adjust antenna direction or scrambled picture FOR MORE INFORMATION www.lorexinternational.com Lorex / Sylvania / Home Sentinel Causes and remedies Camera Monitor - AC adapter not plugged in - Power switch not turned on - Monitor not turned on... -
Page 15: Technical Specifications
TECHNICAL SPECIFICATIONS Camera Image sensor Lens Picture Elements Scanning system Scanning frequency Sync. system Resolution Min. illuminations Video Output Gamma characteristics Auto Iris Microphone Transmitting frequency Modulation RF out level Video Output level Antenna Dimensions Battery Option Operating temperature Power source Monitor Screen Size Receiving frequency... -
Page 16: Care & Maintenance
CARE AND MAINTENANCE: Please follow these instructions to ensure proper care and maintenance of this system Keep your monitor and camera dry. If it gets wet, wipe it dry immediately. Use and store your unit in normal temperature environment. Extreme temperatures can shorten the life of the electronic devices. - Page 17 Quick Start Guides V I S I T w w w . l o r e x i n t e r n a t i o n a l . c o m Lorex Technology Inc. Specification Sheets Software Upgrades Firmware Upgrades www.lorexinternational.com...
