CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Explanation of two Symbols The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage“...
SAFETY INSTRUCTIONS IMPORTANT SAFEGUARDS All the safety and operating instructions should be read before the system is operated, and retained for future reference. 1. HEED WARNINGS - All warnings on the appliance and in the operating instructions should be adhered to. 2.
TABLE OF CONTENTS PAGE INTRODUCTION & FEATURES……………………………………… SYSTEM INCLUDES………………………………………………….. CONTROLS AND FUNCTIONS Wireless Camera…..……..….……………………..……... Wireless Receiver...……......……….……...…… INSTALLATION OF WIRELESS CAMERA…………………………. INSTALLATION OF WIRELESS RECEIVER Operation with TV (Using RCA Cables)..……………….…..Operation with TV (Using Coaxial Cable) ....…..……..SYSTEM OPERATION Multiple Cameras / Auto Scanning………………………………… Auto/Manual Options / Selectable Settings………………………...
INTRODUCTION: Thank you for purchasing the 2.4 GHz Wireless Color Camera & Receiver System. This system turns your TV into a Video Security System, providing instant protection in your home or office. Avoid the hassle of running wires. This system is easy to install and operate for immediate applications.
INSTALLATION OF CAMERA OPTION #1 – Permanent Wall Mount STEP 1: Wall To 9V Power Camera mounted Adapter 1. Attach the stand base to the wall or ceiling where you want to install the camera. Locate a wall stud or ceiling, and secure the bracket using the three supplied screws.
INSTALLATION OF RECEIVER CONNECTING THE RECEIVER TO A TV STEP 2: You have two options to connect the Receiver: A) Using RCA Cables (see below), or B) Coaxial Cables, please refer to page 7 of this manual. Television Back of Receiver Electrical Outlet Ensure the Power Switch on the Receiver is turned OFF before NOTE...
Page 11
INSTALLATION OF RECEIVER CONNECTING A RECEIVER TO A TV USING COAXIAL CABLES Television Back of Receiver Electrical Outlet Audio Video Coaxial Cable (75 ohm) Ensure the Power Switch on the receiver is turned OFF prior to NOTE proceeding with the following steps. 1.
SYSTEM OPERATION CONNECTING MORE CAMERAS TO YOUR SYSTEM (MAX. OF 4) The receiver will automatically do a self diagnostic when it is powered up to determine how many cameras are connected. It will detect which channels are receiving a video signal. To purchase additional wireless cameras, please visit www.lorexcctv.com When connecting additional cameras to this system, ensure the camera is set to a different channel.
SYSTEM OPERATION AUTO AND MANUAL VIEWING OPTIONS This system is preset to the Manual mode. In Auto mode, the LED light will turn ON. To manually view a specific camera location, set the system to Manual and press the Ch. Select key to view the desired camera location. Auto Mode is used when more than 1 camera is connected to the system.
TROUBLESHOOTING If the system does not function properly, check the following points before contacting the service center. Causes & Remedies Problems Camera Receiver/Transmitter No power - AC adapter not plugged in - AC adapter not plugged in (no picture/sound) - Power not turned ON (press - Power switch not turned on and hold the Channel button - TV or Monitor not turned on...
CARE AND MAINTENANCE: Please follow these instructions to ensure proper care and maintenance of this system Keep your monitor and camera dry. If it gets wet, wipe it dry immediately. Use and store your unit in normal temperature environment. Extreme temperatures can shorten the life of the electronic devices.
Page 17
It’s all on the web Product Information Specification Sheets User Manuals Software Upgrades Quick Start Guides Firmware Upgrades V I S I T w w w . l o r e x c c t v . c o m www.lorexcctv.com Strategic Vista International Inc.
