19" LCD / 8 CHANNEL DVR
COMBO WITH 160GB HDD
& 4 CAMERAS
Overview - Remote
Viewing
MODEL:
SG19LD804-161
www.lorexcctv.com
©
Copyright
2007 LOREX Technology Inc.

Advertisement

Table of Contents
loading

Related Manuals for Lorex SG19LD804-161

Summary of Contents for Lorex SG19LD804-161

  • Page 1 19” LCD / 8 CHANNEL DVR COMBO WITH 160GB HDD & 4 CAMERAS Overview - Remote Viewing MODEL: SG19LD804-161 www.lorexcctv.com © Copyright 2007 LOREX Technology Inc.

  • Page 2: Table Of Contents

    Network - Router Port Forwarding ....................7 19” System - DDNS SETUP ......................8 Lorex NetViewer Software - Connection Manager ..............9 Lorex NetViewer Software - Remote Connection ..............11 If you have any additional questions or technical issues, please contact the Sentinel CCTV Help desk for further assistance at 1-888-425-6739 (Option 1 - 1) or mail your questions to support@strategicvista.com...

  • Page 3: Setting Up Remote Viewing

    (for remote viewing outside your network) Network Setup / Remote Access Overview The SG19LD804-161 Observation System can be remotely controlled using your existing network and the Lorex NetViewer software. 1. Connect the Observation System to the Router using the supplied Ethernet Cable. Power the Observation System on.

  • Page 4: 19" System - Ip & Mac Address

    Setting up Remote Viewing 19” System - IP & MAC Address The IP & MAC Addresses are IP Address necessary for DDNS Setup (for remote access to the Observation System). MAC Address To Locate the System information, Press the ENTER button on the Front Panel or Remote Control while viewing the Cameras.

  • Page 5: Network - Setting Up Your Ddns Account

    Network - Setting Up Your DDNS Account Lorex offers a free DDNS service for use with your System. A DDNS account allows you to set up a web site address that points back to your Local Network. The following outlines how to set up your free DNS account.
  • Page 6 ________________________________________________________ * Domain Name: __________________________________________________________ Password: __________________________________________________________ * Only the first part of the Domain Name is required for setup on the SG19LD804-161 System. If the full Domain sent is tomsmith.strategicvis- ta.net, the unit only requires that only tomsmith be entered.

  • Page 7: Network - Router Port Forwarding

    Setting up Remote Viewing Network - Router Port Forwarding You will need to enable port forwarding on your Router to allow for external communications with your Observation System for ports: • TCP/IP PORT 6100 • WEB PORT 80 Computers, Observation Systems, and other devices inside your network can only communicate directly with each other within the internal network.

  • Page 8: 19" System - Ddns Setup

    Status first - wait for the SUCCESS MESSAGE (as long as the information is correct). Select OK to save the settings. NOTE: Once all Network settings are configured, the System can be accessed using the Lorex Client Software. Refer to Page 8 for Connection Manager details.

  • Page 9: Lorex Netviewer Software - Connection Manager

    Setting up Remote Viewing Lorex NetViewer Software - Connection Manager The Connection Manager contains the setup information to allow the user to remotely connect to the Observation System. Adding a Group Group - Right click on ‘Site’ to add a New Group.
  • Page 10 Setting up Remote Viewing Adding a Site (Individual Unit Configuration) DVR Information - Enter the information specific to the unit (refer to page 30 for setup instructions): • Name - Enter a name for the unit. • IP / Domain Name - Enter the IP address or Domain Name for the System.

  • Page 11: Lorex Netviewer Software - Remote Connection

    Setting up Remote Viewing Lorex NetViewer Software - Remote Connection Once the site setup profile has been created, a connection can then be made to the Observation System: 1. Select the Site profile from the Dropdown List. 2. Press the CONNECT button.
  • Page 12 It’s all on the web Product Information Specification Sheets User Manuals Software Upgrades Quick Start Guides Firmware Upgrades VISIT www.lorexcctv.com wwwlorexcctv.com Lorex Technology International Inc.
