2.4 GHz WIRELESS
VIDEO SECURITY SYSTEM
Please read this manual thoroughly before operating this system
This product broadcasts over public airwaves and its
video and audio signals may be intercepted without your
consent.

OPERATING INSTRUCTIONS

Rev 03/01-1

Advertisement

Table of Contents
loading

Related Manuals for Lorex SG6130

Summary of Contents for Lorex SG6130

  • Page 1: Operating Instructions

    2.4 GHz WIRELESS VIDEO SECURITY SYSTEM Please read this manual thoroughly before operating this system This product broadcasts over public airwaves and its video and audio signals may be intercepted without your consent. OPERATING INSTRUCTIONS Rev 03/01-1...

  • Page 2: Fcc Class B Notice

    SPECIFICATIONS WIRELESS CAMERA Image sensor B&W or Color CMOS Lens F2.0/f 3.7mm, 92°wide-angle lens Picture element 510 x 492 (Color), 320X240 (B&W) Scanning system 2:1 interlace Battery Life (assume 1300mAH) 3 Hours (Color); 4-5 Hours (B&W) Current Consumption 300mA typ. (color); 230mA typ (with LED)- Scanning frequency 15.734 KHz(H) 59.9Hz(V) ,EIA Sync.

  • Page 3: Troubleshooting

    TROUBLE SHOOTING If the system does not function properly, check the following points before contact the service center. Causes and remedies Problems Camera - AC adapter not plugged in No power - Power switch not turned (no picture/sound) - AC adapter not plugged in Poor reception - Power switch not turned - Strong spot light in the...

  • Page 4: Optional Accessories

    OPTIONAL ACCESSORIES The following optional accessories are available to add to your existing system Accessory Camera - Used to view other camera locations (Available in B&W and Color) Accessory Receiver - Used to connect and view picture on a T.V. Accessory Transmitter - Used to turn a wired camera into a wireless device Time Lapse VCR - Used to record key events.

  • Page 5: System Operation

    SYSTEM OPERATION AUTO MODE VIEWING OPTIONS This system is preset to Manual mode, with a dwell mode of 2 seconds. In Auto mode, the LED light will be ON. To manually view a specific camera location, press the Auto/Manual button. Press the Ch. Select key to view the desired camera location. Press the Auto/Manual button to return to the Auto Mode feature.
  • Page 6 SYSTEM OPERATION USING SYSTEM WITH MORE THAN ONE CAMERA The receiver will automatically do a self diagnostics when it is powered up. If everything is OK, the four LED Channel LED indicator lights will turn on for one cycle. This video security system allows you to view up to four different camera locations.
  • Page 7 INSTALLATION OF RECEIVER CONNECTION OF RECEIVER TO A VCR RECEIVER TV REAR ELECTRICAL OUTLET Ensure the Power Switch on the Receiver and Camera are turned OFF NOTE NOTE before proceeding following steps. 1. Connect one end of the RCA cables to the Audio/Video jacks at the back of the Receiver.

  • Page 8: Installation Of The Receiver

    INSTALLATION OF THE RECEIVER CONNECTION OF RECEIVER TO TELEVISION USING RCA CABLES 1. Place the wireless receiver near your television (or monitor) 2. Connect the supplied 9V 500 mA AC adapter to the DC IN jack at the rear of the receiver and plug it into an electrical outlet.

  • Page 9: Wireless Camera - Installation

    INSTALLATION OF RECEIVER CONNECTION OF RECEIVER TO TELVISION USING COAXIAL CABLE You can connect this system either using the supplied RCA or coaxial cables. 1. Place the wireless receiver near your television (or monitor) 2. Connect the supplied 9V 500 mA DC adapter to the DC IN jack at the back of the receiver and plug it into an electrical outlet.
