Page 1
INSTRUCTION MANUAL 17” B&W QUAD OBSERVATION SYSTEM WITH FOUR CAMERAS SG7864R BEFORE OPERATING THIS SYSTEM, PLEASE READ THIS MANUAL THROUGHLY AND RETAIN IT FOR FUTURE REFERENCE...
Page 2
Thank you for purchasing the LOREX 17” B&W Quad Observation System with Real Time Quad Processor. LOREX is committed to providing our customers with a high quality, reliable security product that customers have come to expect from us. To learn more about this system and to learn about our complete range of accessory products, please visit our website at: www.strategicvista.com...
NOTE This equipment has been certified and found to comply with the limits regulated by FCC, EMC and LVD. Therefore, it is designed to provide reasonable protection against interference and will not cause interference with other appliance usage. However, it is imperative that user follows this manual's guidelines to avoid improper usage which may result in damage to the unit, electrical shock and fire hazard or injury.
10.TECHNICAL SPECIFICATIONS ----------------------------------------------------------- 11. OPTIONAL ACCESSORIES ---------------------------------------------------------------- 12. APPENDIX - A CONNECTING MONITOR TO A VCR-------------------------------- 14. APPENDIX - B CONNECTING TO A LOREX TIME LAPSE VCR FOR ALARM REC.--------------- 15. APPENDIX - C CONNECTING TO A LOREX TIME LAPSE VCR FOR NORMAL REC.---------------...
GENERAL PRECAUTIONS: Servicing Read Instructions Do not attempt to service this product yourself All of the safety and operating instructions should as opening or removing covers may expose be read and understood before the product is used. you to voltage or other hazards. Refer all Retain Instructions servicing to qualified service personnel The safety and operating instructions should be...
CAUTIONS: 1. All the warnings and instructions of this manual should be followed 2. Remove the plug from the outlet before cleaning. Do not use liquid aerosol detergents. Use water damped cloth for cleaning 3. Do not use this unit in very humid and wet places 4.
MONITOR CONTROLS - FRONT PANEL: 1. Power Switch - Pressing this switch will turn power ON to the monitor. Pressing it again will turn the power OFF. The master power switch, which controls the monitor is located at the back of the unit. 2.
Page 9
5. MENU BUTTON – The monitor has a number of programmable features available by using the Menu option. To enter the Menu selection, press the MENU button. The main menu as identified will appear. MAIN MENU TITLE SET SEQUENCE SCAN DWELL TIME ALARM RESET TIME TIME/DATE EXIT...
Page 10
ALARM MODE - This function will enable the monitor to automatically bring the trouble location to Full screen when a PIR Motion sensor camera detects movement. The letters AL will appear At the top right corner of the screen and the camera location where the alarm has taken place Will appear in the top left hand corner.
FREEZE ON/OFF SELECTION - This function will enable the monitor to automatically bring the trouble location to full screen when a PIR Motion sensor camera detects movement. The letters AL will appear at the top right corner of the screen and the camera location where the alarm has taken place will appear in the top left hand corner.
MONITOR CONTROLS - BACK PANEL: 6 Pin Din Camera Inputs - Channel 1-4 camera inputs (for camera switch 6 pin din camera inputs) Video Input Receives video signal from VCR and other recording devices Audio Input Receives audio signal from VCR or other recording devices Audio Output Transmits audio signal from the monitor Video Output Transmits video signal from the monitor AC Input - This Cord is used to connect the supplied power cord from the monitor to an...
STANDARD B&W CAMERA : Camera Lens - Delivers high quality image by using a 1/3” CCD Image Sensor Infra Red LED’s Illuminators which allow user to ‘See In the Dark’ Microphone – Picks up sound around the camera Camera Inputs - Connects cable to monitor Speaker –...
MONITOR CONNECTIONS : 1. Camera 1 input Connect one end of the supplied 65ft cable to the first wired camera and the other end to the camera 1 input 2. Camera 2 input Connect one end of the supplied 65ft cable to the first wired camera, the other end to camera 2 input 3.
OPTIONAL ACCESSORIES: The following accessories are available to add to your existing system. CABLE TIME LAPSE RECORDER Extends viewing length from 24 Hour Real Time or 960 Hour Camera to monitor. Available Time Lapse VCR. Records key In 65, 100 and 250 ft lengths events SUNSHADE HOUSING DIGITAL MONITORING SYSTEM...
APPENDIX - A CONNECTING MONITOR TO A VCR : BACK SIDE OF THE NORMAL VCR BACK SIDE OF THE LOREX 17” QUAD OBSERVATION SYSTEM NOTE: PLEASE MAKE SURE YOUR VCR IS IN A/V (AUDIO/VIDEO) MODE BEFORE PROCEEDING WITH RECORDING. STILL...
This warranty is invalidated if other than Lorex accessories are or have been used in or in connection with the Product or in any modification or repair is made to the Product be other than a service depot authorized by Lorex.
CARE AND MAINTENANCE: Please follow the following instructions to ensure proper care and maintenance of this system Keep your monitor and camera dry. If it gets wet, wipe it dry immediately. Use and store your unit in normal temperature environment. Extreme temperatures can shorten the life of the electronic devices.
