prompted to. The USB-C™ port supplies power to the laptop then even when the monitor
is in standby mode.
2. Go to System > MST > ON. Note the OSD menu can be launched and configured only
when input signal is detected.
3. Connect the second monitor to the first one using a DP cable as illustrated.
4. Follow Step 3 to connect the third and the fourth monitors if desired.
5. Power on the laptop and the monitors. On all the connected monitors, check the
configurations as described in Step 2.
6. On you laptop, decide the way you want the content to be displayed on the connected
monitors: Duplicate, Extend, or Projector only. Additional software (purchased
separately) may be used to manage the display. Refer to the manual of the purchased
software for more information.
If you keep the KVM connection and wish to enable MST function at the same time, see
with KVM and MST at the same time on page 37
Supported resolution
To perform MST, a limited number of connected monitors is required to ensure image quality.
The following information shows the image resolution available to each monitor.
Configu-
ration
1 2560 x 1440 (60Hz)
2 2560 x 1440 (60Hz)
3 2560 x 1440 (60Hz)
4
Make sure the graphic card on your computer supports DP 1.4 for MST. Please also be noted that the supported
number of monitors for connection may vary by graphic card. To find out the capability of your graphic card,
check its specifications or contact its manufacturer.

Working with HDR technology

The information regarding HDR-compatible devices and content in this document is most up-to-date at the time
of publication. For the latest information, contact your device manufacturer and content provider.
To enable HDR function, you need to have a compatible player and content.
1. Make sure a FHD/4K HDR player is ready. Players with the following names and resolutions
are supported. Note that the 4K content on a FHD monitor get resized and is displayed at
1920 x 1080.
Commonly used names for
FHD/4K
(may vary by manufacturer)
38 How to adjust your monitor
st
1 monitor
(PD2506Q or a com-
(PD2506Q)
patible BenQ monitor)
2560 x 1440 (60Hz)
2560 x 1440 (60Hz)
1920 x 1080
(60Hz)
FHD, 4K, 4K Ultra HD, UHD, UHD 4K, Ultra HD, 2160p
for more information.
nd
2 monitor
(PD2506Q or a com-
patible BenQ monitor)
1920 x 1080
(60Hz)
1920 x 1080
(60Hz)
Scenario C: Working
rd
3 monitor
(PD2506Q or a com-
patible BenQ monitor)
N/A
1920 x 1080
(60Hz)
1920 x 1080
(60Hz)
1920 x 1080
(60Hz)
th
4 monitor
N/A
N/A
1920 x 1080
(60Hz)
1920 x 1080
(60Hz)
