Connecting/
Using A
Decoder
TV Aerial
Cable
RF Cable (provided)
AV2 (L-2) IN/DECODER
Decoder
TV Receiver
AV1 (L-1) IN/OUT
SYSTEM CONNECTIONS (cont.)
The AV2 (L-2) IN/DECODER connector can be used as an input
terminal for an external decoder (descrambler). Simply connect
a decoder and you can enjoy the variety of programming that is
available through scrambled channels.
SELECT INPUT MODE
1
Set "L-2 SELECT" to "DECODER". (
CONNECT DECODER
2
Connect your recorder's AV2 (L-2) IN/DECODER
connector to the decoder's Euroconnector using a 21-
pin SCART cable.
SET TUNER
3
Perform the procedure as described in "When Receiving
A Scrambled Broadcast" on page 71.
pg. 58)
