Audio Controls; Storage Device Controls And Features - HP Visualize c100 Service Handbook

Product Information
System Unit Front Panel Controls

Audio Controls

Next to the system LEDs are the following audio con-
trols:
Headset Jack
Volume Control
Mic Jack
Mute Button
The volume control, headset jack, and microphone
jack features of the CD-ROM are supported through
applications only.
For more information on the features and electrical
specifications, see the section called "Security Loop,"
later in this chapter.

Storage Device Controls and Features

The C Class workstations allow up to two of the fol-
lowing internal storage devices: CD-ROM drive, DDS
tape drive, or floppy drive. The following sections
describe the controls and features of these devices.
NOTICES: You may not have two of the same type of device.
For example, you can have a CD-ROM device and
a floppy device, but not two CD-ROMs.
Due to space limitations, a DDS-format tape drive
and a CD-ROM drive cannot both be mounted in
the system at the same time.
8
Accommodates mini-head-
phones with a 3.5 mm diameter
miniature stereo plug.
Adjusts the audio output volume
to the headset or lineout.
Accommodates microphones
with a 3.5 mm diameter minia-
ture stereo plug.
Turns off the audio output to line
out and speaker only.
