Graphics Configuration Restrictions
The system supports only four graphics displays at a
time. A "display" is a video output port or connector.
For example, the Dual Visualize Enhanced Graphics
Card (A4451A) is a dual display card. It has two exter-
nal video connectors so it accounts for two of the max-
imum of four displays. If you installed two of these
cards they would account for the maximum of four
displays supported by the system.
The built-in graphics adapter accounts for one graph-
ics display (graphics(0)). If four displays are installed
in the option slots, the built-in graphics adapter is
automatically disabled.
NOTICE: The A4077A Color Graphics Card and A4078A Dual Color
Graphics Card are not supported in the Model C160L.
The Model C160l only supports the A4211A HP Visualize48
graphics adapter. It does not support the A4244A HP
Visualize48 graphics adapter.
Optional graphics adapters may only be installed
in option slots 1 and 2 since only these 2 slots
support GSC boards.
NOTE: The Model C200 and C240 systems do not have a built-in
graphics card, but use an optional graphics card.
