System Unit Rear Panel Connectors

System Unit Rear Panel Connectors
This section describes the following connectors on the
system unit's rear panel:
•
•
•
•
•
•
•
•
•
To maintain emissions compliance, verify that
NOTICE:
all cables are fully seated and properly
fastened.
Figure 6 shows the locations of the connectors on the
system unit's rear panel.
14
Security loop
Audio connectors
Keyboard and mouse connectors
HP parallel (Centronics) I/O connector
802.3 network connectors
Serial I/O connectors
SCSI connectors (including Fast, Wide SCSI and
single-ended SCSI)
TOC (Transfer of Control) button
Power cord connector
