Section 16. ZONE PROGRAMMING
PROGRAM TOOL?
0 = NO, 1 = YES
00 INPUT S/N:
A
X X X–X X X X
00 INPUT S/N:
A123-4567
While in program mode, press 56 to enter Zone Programming
Menu Mode.
Refer to the zone assignment table for
programming form .
This is an interactive menu mode that is used to program zone
numbers, zone types, partition numbers, alarm and report codes, and
to identify the type of loop input device. This mode can also be used
for "enrolling" 5800 series transmitter ID codes and for entering
Alpha descriptors for zones (we recommend entering descriptors in
menu mode 82).
NOTE: If using wireless transmitters, there are two methods for
enrolling the transmitter serial numbers. The first method is by using
*56 Zone Programming mode (described below). The second method is
by using *83 Sequential mode. Note that the *83 Sequential mode
requires that all zone information first be entered using *56 Zone
Programming mode.
Program Tool: The Zone Programming and Sequential Modes allow
you to use a 5803 or 5804 button-type transmitter as a "program
tool." The upper left-hand and right-hand buttons of the tool duplicate
the [*] and [#] keypad programming functions. The advantage of
using a program tool is that it enables remote enrollment. You can
move to the physical location of the transmitter to be enrolled, press
the upper left-hand button of the program tool, and then trip the
intended transmitter. The transmitter that you use as the program
tool can also be used as a transmitter in the system. If you plan to use
an existing transmitter, it must first be enrolled into the system as its
associated zones. You may then program it as the tool.
After entering 56, the following prompts are displayed:
If the system has been set up to use wireless transmitters, and a
program tool has been entered, skip to the zone number prompt. If no
program tool has been entered, the following prompt will appear:
If a program tool (5803/5804) is being used, enter "1." If not using a
tool, enter "0" and skip to the zone number prompt.
0
If "1" is entered, the system will prompt for the serial number of the
L
transmitter being used as the program tool. You can enter the serial
number using one of the following methods:
a) Enter the 7-digit serial number for the transmitter
or
b) Press any button on the transmitter. The keypad should beep twice
and display the serial number of the tool.
In this example, the serial number is A123-4567. Once entered, you
L
can use the 5803/5804 program tool to ready the system for enrolling
3
a transmitter's serial number by first pressing the upper left-hand
button of the program tool, then activating the desired transmitter
(see procedure at the "LEARN S/N?" prompt).
To back up to the ÒPROGRAM TOOL ?Ò prompt, press the [#] key on
the keypad.
The serial number for the program tool will only remain in
the system until the programming mode is exited. (Entering
97 will not delete the tool.)
Press [ ] to continue.
–57–
(*56 Menu Mode)
*
56 on the separate
