KA01078F/00/EN/19.22-00
71565958
2022-04-05
Products
Brief Operating Instructions
Levelflex FMP53
HART
Guided wave radar
These Instructions are Brief Operating Instructions; they are
not a substitute for the Operating Instructions pertaining to
the device.
Detailed information about the device can be found in the
Operating Instructions and the other documentation:
Available for all device versions via:
• Internet:
www.endress.com/deviceviewer
• Smart phone/tablet: Endress+Hauser Operations App
Solutions
Services

Advertisement

Table of Contents
loading

Summary of Contents for Endress+Hauser HART Levelflex FMP53

  • Page 1 Operating Instructions pertaining to the device. Detailed information about the device can be found in the Operating Instructions and the other documentation: Available for all device versions via: • Internet: www.endress.com/deviceviewer • Smart phone/tablet: Endress+Hauser Operations App...
  • Page 2: Associated Documentation

    Order code: XXXXX-XXXXXX Ser. no.: XXXXXXXXXXXX Ext. ord. cd.: XXX.XXXX.XX Serial number www.endress.com/deviceviewer Endress+Hauser Operations App A0023555 About this document Symbols 2.1.1 Safety symbols DANGER This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in serious or fatal injury.
  • Page 3 Symbols for certain types of information and graphics  Permitted Procedures, processes or actions that are permitted  Forbidden Procedures, processes or actions that are forbidden  Tip Indicates additional information Reference to documentation Reference to graphic Notice or individual step to be observed Endress+Hauser...
  • Page 4: Basic Safety Instructions

    ‣ Measured process variables: level ‣ Calculable process variables: volume or mass in any shape of vessel (calculated from the level by the linearization functionality) Endress+Hauser...
  • Page 5: Workplace Safety

    The manufacturer is not liable for damage caused by improper or non-intended use. Verification for borderline cases: ‣ For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of fluid-wetted materials, but does not accept any warranty or liability.
  • Page 6: Product Safety

    • Are the goods undamaged? • Do the nameplate data match the ordering information on the delivery note? • If required (see nameplate): are the Safety Instructions (XA) provided? If one of these conditions is not met, please contact your Endress+Hauser sales office. Endress+Hauser...
  • Page 7: Product Identification

    ‣ Enter the serial number from the nameplate in the Endress+Hauser Operations app or scan the 2-D matrix code on the nameplate with the camera  All of the information on the measuring device and on the scope of the technical documentation pertaining to the device is displayed.
  • Page 8: Mounting Requirements

    • Distance (B) between rod probes and internal fittings (4): > 300 mm (12 in) • When using more than one Levelflex: Minimum distance between the sensor axes: 100 mm (3.94 in) • Distance (C) from the end of the probe to the bottom of the vessel: > 10 mm (0.4 in) Endress+Hauser...
  • Page 9: Mounting The Device

    Loosen the screw of the securing clamp of the electronics compartment cover using an Allen key (3 mm) and turn the clamp 90 ° counterclockwise. Unscrew the electronics compartment cover and check the cover seal; replace it if necessary. Endress+Hauser...
  • Page 10: Electrical Connection

    Turn the securing clamp 90 ° in the clockwise direction and, using an Allen key (3 mm), tighten the screw of the securing clamp on the electronics compartment cover with 2.5 Nm. Electrical connection Connecting requirements 6.1.1 Terminal assignment Endress+Hauser...
  • Page 11 Active barrier for power supply (e.g. RN221N); observe terminal voltage Resistor for HART communication (≥ 250 Ω); observe maximum load Connection for Commubox FXA195 or FieldXpert SFX350/SFX370 (via VIATOR Bluetooth modem) Analog display unit; observe maximum load Cable screen; observe cable specification Measuring device Endress+Hauser...
  • Page 12 Active barrier for power supply (e.g. RN221N); observe terminal voltage Resistor for HART communication (≥ 250 Ω); observe maximum load Connection for Commubox FXA195 or FieldXpert SFX350/SFX370 (via VIATOR Bluetooth modem) Analog display unit; observe maximum load Cable screen; observe cable specification Measuring device Switch output (open collector) Endress+Hauser...
  • Page 13 Connection for Commubox FXA195 or FieldXpert SFX350/SFX370 (via VIATOR Bluetooth modem) Analog display unit; observe maximum load Cable screen; observe cable specification Measuring device Analog display unit; observe maximum load Active barrier for power supply (e.g. RN221N), current output 2; observe terminal voltage Endress+Hauser...
  • Page 14 Resistor for HART communication (≥ 250 Ω); observe maximum load Connection for Commubox FXA195 or FieldXpert SFX350/SFX370 (via VIATOR Bluetooth modem) Analog display unit; observe maximum load Cable screen; observe cable specification Measuring device Supply voltage; observe terminal voltage, observe cable specification Endress+Hauser...
  • Page 15 (flange or threaded connection) or to the external ground terminal. An easily accessible power switch must be installed in the proximity of the device. The power switch must be marked as a disconnector for the device (IEC/EN61010). Endress+Hauser...
  • Page 16 Device plug In the case of the device versions with a plug, the housing does not need to be opened to connect the signal cable. A0011175  12 Pin assignment of M12 plug Signal + Not assigned Signal - Ground Endress+Hauser...
  • Page 17 Levelflex FMP53 HART Electrical connection A0011176  13 Pin assignment of 7/8" plug Signal - Signal + Not assigned Shielding Endress+Hauser...
  • Page 18 If the Bluetooth module is used, the minimum supply voltage increases by 2 V. At ambient temperatures T ≤ -30 °C, a terminal voltage U ≥ 16 V is required to start the device with the minimum failure current (3.6 mA). Endress+Hauser...
  • Page 19 At ambient temperatures T ≤ -30 °C, a terminal voltage U ≥ 16 V is required to start the device with the minimum failure current (3.6 mA). If the Bluetooth module is used, the minimum supply voltage increases by 2 V. Endress+Hauser...
  • Page 20 If the Bluetooth module is used, the minimum supply voltage increases by 2 V. Integrated polarity reversal protection Permitted residual ripple < 1 V with f = 0 to 100 Hz Permitted residual ripple < 10 mV with f = 100 to 10000 Hz Endress+Hauser...
  • Page 21: Connecting The Device

    Loosen the screw of the securing clamp of the connection compartment cover using an Allen key (3 mm) and turn the clamp 90 ° counterclockwise. Unscrew the connection compartment cover and check the cover seal; replace it if necessary. Endress+Hauser...
  • Page 22 The electrical connection of device versions without an integrated overvoltage protection is via plug-in spring-force terminals. Rigid conductors or flexible conductors with ferrules can be inserted directly into the terminal without using the lever, and create a contact automatically. Endress+Hauser...
  • Page 23: Operation Options

    2.5 Nm. Operation options The device can be operated as follows: • Operation via operating menu (display) • DeviceCare and Fieldcare, see Operating Instructions • SmartBlue (app), Bluetooth (optional), see Operating Instructions Endress+Hauser...
  • Page 24: Structure And Function Of The Operating Menu

    Visualization of a parameter (here: parameter with picklist) 3.1 Header containing parameter name and error symbol (if an error is active) 3.2 Picklist;  marks the current parameter value. Input matrix for numbers Input matrix for alphanumeric and special characters Endress+Hauser...
  • Page 25 • If present, opens the help text for the function of the parameter. • In a text and numeric editor: Pressing the key briefly: • Opens the selected group. • Carries out the selected action. • Carries out the selected action. Endress+Hauser...
  • Page 26 When you call up the "Expert" menu, you are always asked for an access code. If a customer-specific access code has not been defined, "0000" must be entered. 7.2.1 Opening the context menu Using the context menu, the user can call up the following menus quickly and directly from the operational display: Endress+Hauser...
  • Page 27: Switching On The Device

    8.1.1 Disabling write protection If the device is write-protected, write protection must first be disabled. See the Operating Instructions of the device for this purpose: BA01002F (FMP53, HART) Setting the operating language Factory setting: English or ordered local language Endress+Hauser...
  • Page 28 Main menu 0104-1 Display language English Operation Setup Display language 0104-1 English à Deutsch Español Français Display language 0104-1 à English Deutsch Español Français Hauptmenü 0104-1 Sprache Deutsch Betrieb Setup A0029420  18 Taking the example of the local display Endress+Hauser...
  • Page 29: Device Configuration

     Specify the diameter of the bypass or stilling well. Setup → Medium group  Specify the medium group (Others or Water based (DC >= 4)) Setup → Empty calibration  Specify the empty distance E (distance from the reference point R to the 0% mark). Endress+Hauser...
  • Page 30 10. Setup → Signal quality  Displays the signal quality of the analyzed level echo (for verification purposes). 11. Setup → Mapping  →  Confirm distance  Compare the distance displayed with the actual value to start recording an interference echo map. Endress+Hauser...
  • Page 32 *71565958* 71565958 www.addresses.endress.com...
