  • Page 1 ® ® Invacare Tracer SX5 Wheelchair User Manual This manual MUST be given to the user of the product. BEFORE using this product, read this manual and save for future reference.
  • Page 2 © 2016 Invacare Corporation. All rights reserved. Republication, duplication or modification in whole or in part is prohibited without prior written per- mission from Invacare. Trademarks are identified by ™ and ®. All trademarks are owned by or licensed to Invacare Corporation or its subsidiaries unless otherwise noted.

  • Page 3: Table Of Contents

    Raising/Lowering Elevating Legrest Assembly ....................................36 Using Flip-Back Armrest............................................. 37 Installing Anti-Tippers ............................................38 Removing/Installing Rear Wheels - Quick Release Axle Only ..............................40 Installing the Optional Wheel Lock Extension Handle ................................42 Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...
  • Page 4 Adjusting Patient Operated Wheel Locks ..................................... 50 Adjusting the Clamp-On Wheel Locks......................................51 Adjusting Footplate Height ..........................................53 Adjusting Armrest Height ..........................................55 Adjusting Anti-Tippers............................................56 Adjusting Quick-Release Axle........................................... 58 TROUBLESHOOTING/MAINTENANCE Troubleshooting..............................................59 Maintenance ................................................60 Invacare® Tracer® SX5 Wheelchair Part No. 1110550...
  • Page 5 Installing/Replacing Six/Eight Inch Front Casters/Forks ................................77 Adjusting Forks..............................................78 Replacing Front Casters ............................................. 78 Changing Seat-to-Floor Height ......................................... 79 10 OPTIONS Installing Amputee Bracket..........................................83 Installing Crutch and Cane Carrier........................................85 Installing the Seat Positioning Strap ......................................... 86 Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...

  • Page 6: General

    Caution indicates a potentially hazardous situation which, if not avoided, may result in property damage or minor injury or both. IMPORTANT Indicates a hazardous situation that could result in damage to property if it is not avoided. Gives useful tips, recommendations and information for efficient, trouble-free use.  Invacare® Tracer® SX5 Wheelchair Part No. 1110550...

  • Page 7: Limited Warranty

    (seat, back and armrests of the arm assembly) and remaining components of this product when purchased new and unused to be free from defects in materials and workmanship for a period of thirteen (13) months from date of purchase from Invacare or a dealer, with a copy of the seller’s invoice required for coverage under this warranty.

  • Page 8: Safety

    Use of non-Invacare accessories may result in serious injury or damage. Invacare products are specifically designed and manufactured for use in conjunction with Invacare accessories. Accessories designed by other manufacturers have not been tested by Invacare and are not recommended for use with Invacare products.

  • Page 9: Intended Use

    DO NOT smoke while using this wheelchair. NOTICE THE INFORMATION CONTAINED IN THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. Check all parts for shipping damage and test before using. In case of damage, DO NOT use. Contact Invacare/Carrier for further instruction. Intended Use The intended use for the manual (mechanical) wheelchair is to provide mobility to persons who may be restricted to a sitting position.

  • Page 10: Wear And Tear Items

    Normal wear and tear items and components include but are not limited to: all upholstery items including seat and back upholstery, arm and calf pads, cushions, wheels, tires and casters. Invacare reserves the right to ask for any item back that has an alleged defect in workmanship. See Warranty policy shipped with the product for specific warranty information.

  • Page 11: Operating Information

    If the wheelchair is exposed to extreme temperature (above 100°F or below 32°F), high humidity and/or becomes wet, prior to use, ensure that the handgrips DO NOT twist on the handle. Otherwise, damage or injury may occur. Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...
  • Page 12 ALWAYS wear your seat positioning strap. Inasmuch as the seat positioning strap is an option on this wheelchair (you may order with or without the seat positioning strap), Invacare strongly recommends ordering the seat positioning strap as an additional safeguard for the wheelchair user. The seat positioning strap is a positioning strap only. It is not designed for use as a safety device withstanding high stress loads such as auto or aircraft safety belts.
  • Page 13 Seat-to-floor angle of 0° or 3°: If so equipped, anti-tippers MUST be attached at all times. Inasmuch as the anti-tippers are an option for 0° or 3° on this wheelchair (you may order with or without the anti-tippers), Invacare strongly recommends ordering the anti-tippers as a safeguard for the wheelchair user.
  • Page 14 It is Invacare’s position that users of wheelchairs should be transferred into appropriate seating in vehicles for transportation and use be made of the restraints made available by the auto industry. Invacare cannot and does not recommend any wheelchair transportation systems.
  • Page 15 WARNING Invacare does not recommend the use of its wheelchairs as a weight training apparatus. Invacare wheelchairs have not been designed or tested as a seat for any kind of weight training. If occupant uses said wheelchair as a weight training apparatus, Invacare shall not be liable for bodily injury or damage to the wheelchair and the warranty is void.
  • Page 16   •   WHEEL POSITION seat-to-floor angle. These adjustments must be performed by a qualified technician.      ANTI-TIPPERS •      • USER CONDITION Invacare® Tracer® SX5 Wheelchair Part No. 1110550...

  • Page 17: Safety/Handling Of Wheelchairs

    Use this information only as a basic guide. The techniques that are discussed on the following pages have been used successfully by many. Individual wheelchair users often develop skills to deal with daily living activities that may differ from those described in this manual. Invacare recognizes and encourages each individual to try what works best for him/her in overcoming architectural obstacles that they may encounter.
  • Page 18 DO NOT move beyond the center of gravity. Virtually all activities which involve movement in the wheelchair have an effect on the center of gravity. Invacare recommends using seat/chest positioning straps for additional safety while involved in activities that shift your weight.
  • Page 19 Coping With Everyday Obstacles Coping with the irritation of everyday obstacles can be alleviated somewhat by learning how to manage your wheelchair. Keep in mind your center of gravity to maintain stability and balance. Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...
  • Page 20 Roll the wheelchair forward and slowly lower the front of the wheelchair in one continuous movement onto the sidewalk. Push the wheelchair forward until the rear wheels roll up and over the Step Tube curb. FIGURE 2 Method 1 - Wheelchair With Step Tubes Invacare® Tracer® SX5 Wheelchair Part No. 1110550...
  • Page 21 Extreme caution is advised when it is necessary to move an occupied or unoccupied wheelchair up or down the stairs. Invacare recommends that, if possible, the user be removed from the wheelchair prior to moving. Invacare recommends using two assistants and making thorough preparations. Make sure to use only secure, non-detachable parts for hand-held supports.
  • Page 22 The wheelchair should not be lowered until the last stair has been negotiated and the wheelchair has been rolled away from the stairway. If necessary, rotate the anti-tippers so the wheels are facing down. FIGURE 4 Stairways Invacare® Tracer® SX5 Wheelchair Part No. 1110550...
  • Page 23 Shift body weight into seat with transfer. During independent transfer, little or no seat platform will be beneath you. Use a transfer board if at all possible. FIGURE 5 Transferring To and From Other Seats Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...

  • Page 24: Overview

    No. 1091554 Documentation can be obtained at: • www.invacare.com • ph (440) 329-6000 • One Invacare Way, Elyria OH 44035-2125 WARNING Do not operate without the anti- tip tubes installed. AVERTISSEMENT NE PAS utiliser sans d’abord avoir installé...

  • Page 25: Component Identification

    3 OVERVIEW Component Identification Back Upholstery Seat Upholstery Rear Wheel Wheelchair Frame Handrim Rear Wheel Axle Wheel Lock Front Caster Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...

  • Page 26: Specifications

    1/4 inch to the measurements listed above. These heights can vary +/- ¼-inch due to tire wear and manufacturing tolerances. ** Weights based on 18 x 16 inch wheelchair without front riggings. Weights will vary depending on how wheelchair is equipped. Invacare® Tracer® SX5 Wheelchair Part No. 1110550...

  • Page 27: Safety Inspection

    Inspect the back cane hand grips for wear/looseness/deterioration. ❑ Ensure seat positioning strap buckle latches. Verify hardware that attaches strap to frame is secure and undamaged. Replace if necessary. ❑ Inspect tires for flat spots and wear. Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...
  • Page 28 Clean upholstery with mild soap and water or spray disinfectant using a sponge. DO NOT use bleach or wash in a washing machine. ❑ Clean upholstery and armrests with mild soap and water. ❑ Check that all labels are present and legible. Replace if necessary. Invacare® Tracer® SX5 Wheelchair Part No. 1110550...
  • Page 29 Inspect back cane hand grips for wear/looseness/deterioration. ❑ Adjust front casters/forks bearing system if wheel wobbles noticeably or binds to a stop. ❑ Ensure wheel bearings are clean and free of moisture. ❑ Check headtube locknuts for tightness. Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...
  • Page 30 Ensure wheel bearings are clean and free of moisture. ❑ Inspect casters for cracks and wear. ❑ Clean upholstery and armrests with mild soap and water. ❑ Check that all labels are present and legible. Replace if necessary. Invacare® Tracer® SX5 Wheelchair Part No. 1110550...

  • Page 31: Operation

    DO NOT sit or transfer into the wheelchair unless it is fully open and the seat frame rails are fully seated into the side frame H-blocks. Invacare recommends that a non-folding device be installed to keep the wheelchair from being folded when left unoccupied in a public place.
  • Page 32 While holding the spreader bar, pull out handle until the release pin is out of the handle of the back cane. Drop the spreader bar to one side. Swing footrest/legrest in locked position to the front of the wheelchair. Pivot footplates upward to vertical position. Invacare® Tracer® SX5 Wheelchair Part No. 1110550...
  • Page 33 Continue to close the wheelchair by grasping the armrest furthest from you and pulling the armrest towards you. WARNING DO NOT allow upholstery to hang between the cross braces. Place excess seat upholstery over the armrest. Spreader Bar Detent Pin FIGURE 2 Folding Wheelchair Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...

  • Page 34: Using Patient Operated Wheel Locks

    Unlocked Position Wheel Lock Unlocked Position Wheel Lock Locked Position Locked Position FIGURE 3 Using Patient Operated Wheel Locks Invacare® Tracer® SX5 Wheelchair Part No. 1110550...

  • Page 35: Installing/Removing Front Riggings

     Swingaway footrest shown Removing Push the front rigging release lever inward. FIGURE 4 Installing/Removing Front Riggings Rotate swingaway front rigging assembly outward. Lift the swingaway front rigging assembly off the hinge pins. Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...

  • Page 36: Raising/Lowering Elevating Legrest Assembly

    To lower the elevating legrest, perform the following: Support user leg with one hand. Support Tube Push release lever downward with other hand. FIGURE 5 Raising/Lowering Elevating Legrest Assembly Gently, lower user leg down and rest against the legrest. Invacare® Tracer® SX5 Wheelchair Part No. 1110550...

  • Page 37: Using Flip-Back Armrest

    Ensure armrest is securely locked into arm socket and armrest release button locks into place before using. If not properly aligned, rotate the insert using a flat screwdriver to align the mounting holes. FIGURE 6 Using Flip-Back Armrest Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...

  • Page 38: Installing Anti-Tippers

    Seat-to-floor angle of 0° or 3°: If so equipped, anti-tippers MUST be attached at all times. Inasmuch as the anti-tippers are an option for 0° or 3° on this wheelchair (you may order with or without the anti-tippers), Invacare strongly recommends ordering the anti-tippers as a safeguard for the wheelchair user.
  • Page 39 2 inch clearance between the bottom of the anti-tipper wheels and the ground/floor MUST be maintained at all times. If the distance between the bottom of anti-tipper wheels and the ground/floor is not 1 to 2 inches, adjust anti-tippers. Refer to Adjusting Anti-Tippers on page 56. Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...

  • Page 40: Removing/Installing Rear Wheels - Quick Release Axle Only

    Repeat STEPS 1-2 for the opposite rear wheel. To reinstall the rear wheel onto the wheelchair, reverse STEPS 1-3.  Make sure axle spacer is between rear wheel and wheelchair frame if wheelchair is equipped with conventional arms. Invacare® Tracer® SX5 Wheelchair Part No. 1110550...
  • Page 41 The detent balls MUST be protruding past the inside of the rear wheel axle bushing for a positive lock (Detail "A"). Keep detent balls clean. Invacare recommends inserting quick-release axles with the detent pin to the inside of the wheelchair to prevent accidental release during contact activities.

  • Page 42: Installing The Optional Wheel Lock Extension Handle

    Install the extension handle over the wheel lock handle (Detail “B”). Detail “B” Detail “A” Wheel Lock Rubber Tip Extension Handle Wheel Lock Handle Wheel Lock Handle Wheel Lock Wheel Lock FIGURE 9 Installing the Optional Wheel Lock Extension Handle Invacare® Tracer® SX5 Wheelchair Part No. 1110550...
  • Page 43 Make sure to use proper body mechanics (use your legs) or seek assistance if necessary to avoid injury. ALWAYS engage both wheel locks while reclining or inclining (reverse recline) the wheelchair. Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...
  • Page 44 10. When the back reaches the desired angle, slowly let go of the release levers. 11. To return the back to the full upright position, reverse the STEPS 7-10 keeping in mind proper body mechanics. Invacare® Tracer® SX5 Wheelchair Part No. 1110550...
  • Page 45 6 RECLINER OPERATION Handle Reclined Position Upright Position Release Levers Wheelchair Wheelchair Release Levers Level Level Surface Surface FIGURE 1 Recliner Operation Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...

  • Page 46: Replacing The Headrest Pillow

    Pressing firmly, attach the fastening strips of the new/existing headrest pillow to the fastening strips on the back of the headrest upholstery. Headrest Upholstery Fastening Strips Strap Strap Headrest Pillow FIGURE 2 Replacing the Headrest Pillow Invacare® Tracer® SX5 Wheelchair Part No. 1110550...

  • Page 47: Removing/Installing The Spreader Bar

    Release Button Lock Tube Ensure the release button fully protrudes out of the hole in the back cane handle. FIGURE 3 Removing/Installing the Spreader Bar Repeat STEPS 1-3 on opposite end of spreader bar. Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...

  • Page 48: Removing And Installing Fixed Height Armrest

    Lock rear armrest by turning the armrest release lever towards the back of the wheelchair. Ensure armrest is locked securely in the arm sockets by gently lifting up. If not locked, repeat STEPS 1-3. Invacare® Tracer® SX5 Wheelchair Part No. 1110550...

  • Page 49: Using The Clamp-On Wheel Locks

    Ensure the wheelchair is not moving before engaging the wheel locks. To engage, push the wheel lock handle forward. Disengage the wheel locks by reversing STEP 2. FIGURE 5 Using the Clamp-On Wheel Locks Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...

  • Page 50: Adjustment

    Loosen the bolt and locknut that secure the wheel lock assembly to the wheelchair frame. Reposition the wheel lock so that when engaged, the wheel lock shoe embeds the tire inch ( inch for pneumatic tires) and holds the wheelchair. Invacare® Tracer® SX5 Wheelchair Part No. 1110550...

  • Page 51: Adjusting The Clamp-On Wheel Locks

    Loosen the bolt and locknut that secure the wheel lock to the wheelchair frame. Reposition the wheel lock so that when engaged, the wheel lock shoe embeds the tire inch ( inch for pneumatic tires) and holds the occupied wheelchair in place when pushed. Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...
  • Page 52 Lock Wheel WARNING Shoe Lock If wheel locks DO NOT hold the occupied Tire wheelchair in place contact a qualified technician. Rear Wheel FIGURE 2 Adjusting the Clamp-On Wheel Locks Invacare® Tracer® SX5 Wheelchair Part No. 1110550...

  • Page 53: Adjusting Footplate Height

    Repeat this procedure for the other footplate, if necessary. Cam Lock Lever Reinstall the swingaway front rigging assembly. Refer to Installing/Removing Front Riggings on page 35.  Swingaway footrest shown FIGURE 3 Adjusting Footplate Height - Spring Button Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...
  • Page 54 Hole Button Head Screw Adjustment Hole Threaded Rivet Footplate Cam Lock Lever Assembly Footplate Assembly Inside of Swingaway Front Rigging Outside of Swingaway Front Rigging FIGURE 4 Adjusting Footplate Height - Bolt-In-Place Invacare® Tracer® SX5 Wheelchair Part No. 1110550...

  • Page 55: Adjusting Armrest Height

    Lock the armrest by pressing the height adjustment lever into the down (vertical) position when the desired armrest height is achieved. Repeat STEPS 1-3 for other armrest. Unlocked (Horizontal) FIGURE 5 Adjusting Armrest Height Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...

  • Page 56: Adjusting Anti-Tippers

    Seat-to-floor angle of 0° or 3°: If so equipped, anti-tippers MUST be attached at all times. Inasmuch as the anti-tippers are an option for 0° or 3° on this wheelchair (you may order with or without the anti-tippers), Invacare strongly recommends ordering the anti-tippers as a safeguard for the wheelchair user.
  • Page 57 2 inches. to 2 inch Clearance If the 1 to 2 inch distance cannot be achieved, a different model FIGURE 6 Adjusting Anti-Tippers may be required. Contact an Invacare dealer or qualified technician. Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...

  • Page 58: Adjusting Quick-Release Axle

    (Conventional Arms Only) Keep detent balls clean. FIGURE 7 Adjusting Quick-Release Axle Reinstall rear wheel onto the wheelchair. Refer to Removing/Installing Rear Wheels - Quick Release Axle Only on page 40. Invacare® Tracer® SX5 Wheelchair Part No. 1110550...

  • Page 59: Troubleshooting/Maintenance

    Wheels Performance Flutter Rattles Chair Check tires for correct and equal pressure. Check for loose nuts and bolts. Check caster headtube angle. Check that rear wheels are equally spaced away from seat frame. Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...

  • Page 60: Maintenance

    Replacing/Repairing Rear Wheel Tire/Tube on page 61 or Replacing/Repairing Caster Tire/Tube on page 61. The rear wheels, casters and tires should be checked periodically for cracks and wear, and should be replaced by a qualified technician if damaged. Invacare® Tracer® SX5 Wheelchair Part No. 1110550...
  • Page 61 10. Hand grips should be checked monthly for wear/looseness/deterioration. Clean if desired. Replace if looseness or deterioration is found. Replacing/Repairing Rear Wheel Tire/Tube WARNING Replacement of solid urethane tires is not recommended. If the solid urethane tire needs repaired, Invacare recommends replacing the complete wheel assembly. Replacement of rear wheel tube must be performed by a qualified technician.
  • Page 62 For any service requirements beyond these procedures contact Invacare. For a list of parts or part numbers contact your dealer/Invacare. DO NOT return product without first contacting your dealer/Invacare for shipping and packing instructions. If necessary, contact Invacare for a list of dealers.

  • Page 63: Replacing Heel Loop

    Install the mounting screw, spacer and locknut to secure the heel loop to the footplate. Tighten until the spacer is secure. Insert the lower footrest assembly into the upper footrest assembly to desired height. Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...
  • Page 64 Footplate Tube Cam Lock Assembly Adjustment Lever Inside of Holes Swingaway Adjustment Hole Front Rigging Cam Lock Footplate Assembly Lever Footplate Outside of Swingaway Locknut Footplate Assembly Front Rigging FIGURE 1 Replacing Heel Loop Invacare® Tracer® SX5 Wheelchair Part No. 1110550...

  • Page 65: Replacing The Flip-Back Armrest

    Armrest Rear Armrest Release Button Armrest Tube (Front or Back of the Rear Tube Armrest Front Tube) Hex Screw Armrest Front Tube Inside of Arm Socket Chair Spacer FIGURE 2 Replacing the Flip-Back Armrest Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...

  • Page 66: Installing/Removing The Back Canes

    Inside of Wheelchair Frame Install the locknut onto the hex screw. Secure the hex screw to prevent it from backing out and torque the locknut to 60-80 inch pounds. FIGURE 3 Replacing the Flip-Back Armrest Invacare® Tracer® SX5 Wheelchair Part No. 1110550...

  • Page 67: Replacing Seat Upholstery

    Securely tighten the new back upholstery to the back canes with the phillips screws and washers.The following chart determines the number of mounting screws for each seat depth. Mounting Screws Washers FIGURE 5 Adjusting Seat Depth Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...

  • Page 68: Replacing The Headrest/Back Upholstery - Recliner Frame Style

    Secure new back upholstery to back canes with the existing twelve FIGURE 6 Replacing the Headrest/Back Upholstery - Recliner mounting screws. Securely tighten. Frame Style Reengage spreader bar. Refer to Removing/Installing the Spreader Bar on page 47. Invacare® Tracer® SX5 Wheelchair Part No. 1110550...

  • Page 69: Adjusting Seat Depth

    Refer to Replacing Seat Upholstery on page 67. Seat Extension Tube Install plug buttons into the ends of the seat extension spacers. FIGURE 7 Adjusting Seat Depth Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...

  • Page 70: Adjusting The Seat Width

    Detail "B" for hardware orientation. Repeat for opposite crossbrace. Securely tighten. Install the new back and seat upholstery onto the wheelchair. Refer to Adjusting Seat Depth on page 67 and Replacing Seat Upholstery on page 67. Invacare® Tracer® SX5 Wheelchair Part No. 1110550...
  • Page 71 14 INCH 14 inch 18 INCH DO NOT USE 16 INCH 18 inch 16 inch 18 INCH DO NOT USE 20 INCH 20 inch 22 INCH 22 inch FIGURE 8 Adjusting the Seat Width Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...
  • Page 72 (STEPS 2,7) Crossbrace Button Screw Saddle Button Screw (STEPS 3,8) (STEPS 3,8) (STEPS 2,7) Crossbrace Locknut Wheelchair Saddle (STEPS 3,8) Frame (STEPS 3,8) See Detail “A” See Detail “B” FIGURE 9 Adjusting the Seat Width Invacare® Tracer® SX5 Wheelchair Part No. 1110550...
  • Page 73 DETAIL “A” DETAIL “B” Coved Washers Wheelchair Frame Washer Washer Coved Washer Washer Locknut Crossbrace Washer Saddle Crossbraces Coved Washers Hex Screw DETAIL “B” - CROSSBRACE HARDWARE (STEPS 4,5) FIGURE 10 Adjusting the Seat Width Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...

  • Page 74: Removing/Installing Rear Wheels - Permanent Axles

    1-2 and torque locknut to 40 ft.-lbs. with Removable Adjust wheel locks. Refer to Adjusting Patient Operated Wheel Arms ONLY) Hex Screw Locks on page 50. FIGURE 11 Removing/Installing Rear Wheels - Permanent Axles - Non-Recliner Frame Style Invacare® Tracer® SX5 Wheelchair Part No. 1110550...
  • Page 75 Torque locknut to 40 in-lbs. Spacer Adjust wheel locks. Refer to Adjusting the Clamp-On Wheel Locks on page 51. Removing/Installing Rear Wheels - Permanent FIGURE 12 Axles - Recliner Frame Style Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...

  • Page 76: Replacing Rear Wheel Handrim

    Reinstall rear wheel to the wheelchair. Refer to Removing/Installing Rear Wheels - Quick Release Axle Only on page 40 or FIGURE 13 Replacing Rear Wheel Handrim Removing/Installing Rear Wheels - Permanent Axles on page 74. Invacare® Tracer® SX5 Wheelchair Part No. 1110550...

  • Page 77: Installing/Replacing Six/Eight Inch Front Casters/Forks

    Slide the new fork assembly into the caster headtube. Reassemble by reversing STEPS 1-3. FIGURE 14 Installing/Replacing Six/Eight Inch Front Casters/Forks Repeat STEPS 1-5 for the opposite fork assembly. Adjust the forks. Refer to Adjusting Forks on page 78. Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...

  • Page 78: Adjusting Forks

    Front Caster  Washers are only used with 8 inch casters with precision bearings. FIGURE 15 Replacing Front Casters To reinstall the new front caster onto the fork, reverse step 1. Invacare® Tracer® SX5 Wheelchair Part No. 1110550...

  • Page 79: Changing Seat-To-Floor Height

    Reinstall the rear wheels onto the wheelchair in the mounting position indicated in the chart. Refer to Removing/Installing Rear Wheels - Quick Release Axle Only on page 40 or Removing/Installing Rear Wheels - Permanent Axles on page 74. Adjust anti-tippers according to new seat-to-floor height. Refer to Adjusting Anti-Tippers on page 56. Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...
  • Page 80 BOTTOM 20 inch BOTTOM BOTTOM 24 inch BOTTOM Rear Wheel Mounting 6 or 8-Inch Fork Positions - Adult/Hemi Mounting Positions Frame Style Bottom Middle Bottom FIGURE 16 Changing Seat-to-Floor Height - Non-Recliner Frame Style Invacare® Tracer® SX5 Wheelchair Part No. 1110550...
  • Page 81 SEAT-TO-FLOOR FRONT CASTER REAR REAR WHEEL HEIGHT (IN MOUNTING WHEEL SIZE MOUNTING INCHES) POSITION POSITION 20 inch Middle MIDDLE 22 inch Bottom BOTTOM 24 inch FIGURE 17 Changing Seat-to-Floor Height - Recliner Frame Style Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...

  • Page 82: Options

    For any service requirements beyond these procedures contact Invacare. For a list of parts or part numbers contact your dealer/Invacare. DO NOT return product without first contacting your dealer/Invacare for shipping and packing instructions. If necessary, contact Invacare for a list of dealers.

  • Page 83: Installing Amputee Bracket

    Make sure the axle spacer is pointing towards the outside of the wheelchair. Install the two hex screws and locknuts that secure the amputee bracket to the wheelchair. Install the rear wheels onto the wheelchair. Refer to Removing/Installing Rear Wheels on page 52. Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...
  • Page 84 Left Right Adult Right Adult Left Axle Spacer Toward Axle Spacer Toward Outside of Wheelchair Outside of Wheelchair Rear View of Amputee Bracket Hex Screws Hemi Left Hemi Right FIGURE 1 Installing Amputee Bracket Invacare® Tracer® SX5 Wheelchair Part No. 1110550...

  • Page 85: Installing Crutch And Cane Carrier

    Reinstall the back upholstery screw and washer and secure the Locknut strap to the wheelchair. FIGURE 2 Installing Crutch and Cane Carrier The base cleans easily with any chrome or glass cleaner. The strap can be cleaned with mild soap and water. Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...

  • Page 86: Installing The Seat Positioning Strap

    ALWAYS wear your positioning strap. Inasmuch as the Seat Positioning Strap is an option on this wheelchair (You may order with or without the seat restraint), Invacare strongly recommends ordering the Seat Positioning Strap as an additional safeguard for the wheelchair user.
  • Page 87 NOTES NOTES Part No. 1110550 Invacare® Tracer® SX5 Wheelchair...
