Endress+Hauser Micropilot M FMR230 Operating Instructions Manual

Level-radar
Hide thumbs Also See for Micropilot M FMR230:
Table of Contents

Advertisement

Quick Links

Operating Instructions

Micropilot M FMR230
Level-Radar
BA00228F/00/EN/13.11
71139433
Valid as of software version:
01.04.00

Advertisement

Table of Contents
loading

Related Manuals for Endress+Hauser Micropilot M FMR230

Summary of Contents for Endress+Hauser Micropilot M FMR230

  • Page 1: Operating Instructions

    Operating Instructions Micropilot M FMR230 Level-Radar BA00228F/00/EN/13.11 71139433 Valid as of software version: 01.04.00...
  • Page 2 Brief operating instructions Micropilot M FMR230 FOUNDATION Fieldbus Brief operating instructions Micropilot M FMR230, FMR231 - Brief operating instructions KA159F/00/a2/08.06 52006292 Contrast: measured value dist./ meas value Group selection basic setup tank shape medium process empty full pipe dist./ check...

  • Page 3: Table Of Contents

    Post-installation check ..... . 26 Contact addresses of Endress+Hauser ... 81 Wiring .

  • Page 4: Safety Instructions

    Safety instructions Micropilot M FMR230 FOUNDATION Fieldbus Safety instructions Designated use The Micropilot M is a compact radar level transmitter for the continuous, contactless measurement of liquids, pastes and sludge. The device can also be freely mounted outside closed metal vessels because of its operating frequency of about 6 GHz and a maximum radiated pulsed energy of 1 mW (average power output 1 μW).

  • Page 5: Notes On Safety Conventions And Symbols

    Micropilot M FMR230 FOUNDATION Fieldbus Safety instructions Notes on safety conventions and symbols In order to highlight safety-relevant or alternative operating procedures in the manual, the following conventions have been used, each indicated by a corresponding symbol in the margin.

  • Page 6: Identification

    Identification Micropilot M FMR230 FOUNDATION Fieldbus Identification Device designation 2.1.1 Nameplate The following technical data are given on the instrument nameplate: ENDRESS+HAUSER Order Code: Ser.-No.: if modification see sep. label Dat./Insp.: Typenschild-FMxxxx-xx Information on the nameplate of the Micropilot M...
  • Page 7 Micropilot M FMR230 FOUNDATION Fieldbus Identification 2.1.2 Ordering structure This overview does not mark options which are mutually exclusive. Approval A Non-hazardous area Non-hazardous area, WHG ATEX II 1/2G EEx ia IIC T6, IECEx Zone 0/1 ATEX II 1/2G EEx ia IIC T6, XA, IECEx Zone 0/1, Note safety instruction (XA) (electrostatic charging)!
  • Page 8 Identification Micropilot M FMR230 FOUNDATION Fieldbus Process Connection 10K 150A RF, 316Ti flange JIS B2220 10K 200A RF, 316Ti flange JIS B2220 10K 250A RF, 316Ti flange JIS B2220 Tri-Clamp ISO2852 DN70-76.1 (3"), 316Ti 6" 150lbs FF, AlloyC4, purge flange ANSI B16.5 NUS Special version, TSP-no.

  • Page 9: Scope Of Delivery

    The device complies with the applicable standards and regulations as listed in the EC declaration of conformity and thus complies with the statutory requirements of the EC directives. Endress+Hauser confirms the successful testing of the device by affixing to it the CE mark.

  • Page 10: Mounting

    Mounting Micropilot M FMR230 FOUNDATION Fieldbus Mounting Quick installation guide Observe orientation when installing! Installation in tank (free space): Mark on process connector facing the nearest tank wall! Turn housing The housing can be turned 350° mark at instrument flange...

  • Page 11: Incoming Acceptance, Transport, Storage

    Micropilot M FMR230 FOUNDATION Fieldbus Mounting Incoming acceptance, transport, storage 3.2.1 Incoming acceptance Check the packing and contents for any signs of damage. Check the shipment, make sure nothing is missing and that the scope of supply matches your order.

  • Page 12: Installation Conditions

    Mounting Micropilot M FMR230 FOUNDATION Fieldbus Installation conditions 3.3.1 Dimensions Housing dimensions 65 (2.56) 78 (3.07) max. 110 (4.33) ENDRESS+HAUSER F12 housing (Aluminium) 85 (3.35) mm (in) L00-F12xxxx-06-00-00-en-001 65 (2.56) max. 100 (4.33) 94 (3.7) 78 (3.07) ENDRESS+HAUSER T12 housing (Aluminium) 85 (3.35)
  • Page 13 Micropilot M FMR230 FOUNDATION Fieldbus Mounting Process connection, type of antenna F12 / T12 / F23 housing R = reference point of measurement Group 30 / Code L Group 30 / Code M High temperature version Ext. temperature version ø60 ø60...
  • Page 14 Mounting Micropilot M FMR230 FOUNDATION Fieldbus 3.3.2 Engineering hints Orientation • Recommended distance (1) wall – outer edge of nozzle: ~1/6 of tank diameter. Nevertheless the device should not be installed closer than 30 cm (11.8 in) to the tankwall.
  • Page 15 Micropilot M FMR230 FOUNDATION Fieldbus Mounting Measurement in a plastic tank If the outer wall of the tank is made of a non-conductive material (e.g. GRP), microwaves can also be reflected off interfering installations outside the signal beam (e.g. metallic pipes (1), ladders (2), grates (3), …).
  • Page 16 Mounting Micropilot M FMR230 FOUNDATION Fieldbus Measuring conditions Note! • In case of boiling surfaces, bubbling or tendency for foaming, use FMR230 or FMR231. Depending on its consistence, foam can either absorb microwaves or reflect them off the foam surface. Measurement is possible under certain conditions.
  • Page 17 Micropilot M FMR230 FOUNDATION Fieldbus Mounting Measuring range The usable measuring range depends on the size of the antenna, the reflectivity of the medium, the mounting location and eventual interference reflections. The maximum configurable range is: • 20 m (66 ft) The following tables describe the groups of media as well as the achievable measuring range as a function of application and media group.

  • Page 18: Installation Instructions

    Mounting Micropilot M FMR230 FOUNDATION Fieldbus Installation instructions 3.4.1 Mounting kit In addition to the tool needed for flange mounting, you will require the following tool: • 4 mm (0.16 in) Allen wrench for turning the housing or mounting an FAR10 antenna extension.
  • Page 19 Micropilot M FMR230 FOUNDATION Fieldbus Mounting Antenna extension FAR10 When mounting an antenna extension, please note the following points: FMR230 • The antenna extension has to be selected such that the horn extends below the nozzle. • If the horn diameter is greater than the ≥...
  • Page 20 Mounting Micropilot M FMR230 FOUNDATION Fieldbus Special extensions • If the antenna has to be mounted on a sloping FMR230 or vertical vessel wall, an extension with a 45° respectively 90° bend is available. • The smallest possible radius R for the bend is 300 mm (11.8 in).
  • Page 21 Micropilot M FMR230 FOUNDATION Fieldbus Mounting Installation with heat insulation high temperature version (type of antenna M) extended temperature version (type of antenna L) tank insulation tank insulation max. 280°C (536°F) max. 400°C (752°F) L00-FMR230xx-17-00-00-en-019 • To avoid the electronics heating up as a result of heat radiation or convection, the FMR230 must be incorporated into the tank insulation at high process temperature (≥...
  • Page 22 Mounting Micropilot M FMR230 FOUNDATION Fieldbus 3.4.3 Installation in stilling well Optimum mounting position marker at instrument flange or threaded boss 1½” BSPT (R 1½”), G 1½" (FMR 244) DN50 DN80…150 1½ NPT ANSI 2” ANSI 3…6” L00-FMR230xx-17-00-00-en-006 Standard installation For installations in a stilling well, follow the engineering hints (→...
  • Page 23 Micropilot M FMR230 FOUNDATION Fieldbus Mounting Examples for the construction of stilling wells Micropilot M FMR230 marker e.g. welding neck flange DIN 2633 stilling well 100 % with slots hole <1/10 pipe-ø, < 1/10 pipe-ø single sided or drilled through...
  • Page 24 Mounting Micropilot M FMR230 FOUNDATION Fieldbus 3.4.4 Installation in bypass Optimum mounting position L00-FMR230xx-17-00-00-en-007 Standard installation For installations in a bypass, follow the engineering hints (→ ä 14) and note the following points: • Marker is aligned perpendicular (90°) to tank connectors.
  • Page 25 Micropilot M FMR230 FOUNDATION Fieldbus Mounting Example for the construction of a bypass Micropilot M FMR230, FMR240, FMR244 - 80 (3"), FMR245 marker e.g. welding neck flange DIN 2633 full bore ball valve 100% Diameter of the connection pipes as small as possible...

  • Page 26: Post-Installation Check

    Mounting Micropilot M FMR230 FOUNDATION Fieldbus 3.4.5 Turn housing After mounting, the housing can be turned 350° in order to simplify access to the display and the terminal compartment. Proceed as follows to turn the housing to the required position: •...

  • Page 27: Wiring

    Micropilot M FMR230 FOUNDATION Fieldbus Wiring Wiring Quick wiring guide Wiring in F12/F23 housing " Before connection please note the following: ● Foundation Fieldbus devices are marked on the nameplate (1). The voltage is determined by the Caution! ENDRESS+HAUSER Made in Germany...
  • Page 28 Wiring Micropilot M FMR230 FOUNDATION Fieldbus Wiring in T12 housing " Before connection please note the following: ENDRESS+HAUSER ● Foundation Fieldbus devices are marked on the nameplate (1). Made in Germany MICROPILOT M D-79689 Maulburg Order Code: FMR2xx-14EALJAA2A The voltage is determined by the Foundation Fieldbus standard Caution! Ser.-No.:...
  • Page 29 Micropilot M FMR230 FOUNDATION Fieldbus Wiring Wiring with FOUNDATION Fieldbus connector Before connection please note the following: " ● FOUNDATION Fieldbus devices are marked on the ENDRESS+HAUSER Made in Germany MICROPILOT M D-79689 Maulburg nameplate (1). The voltage is determined by the...

  • Page 30: Connecting The Measuring Unit

    Wiring Micropilot M FMR230 FOUNDATION Fieldbus Connecting the measuring unit Supply voltage The following values are the voltages across the terminals directly at the instrument: Supply voltage 9 V to 30 V (Ex) 9 V to 32 V (non Ex) max.

  • Page 31: Recommended Connection

    Micropilot M FMR230 FOUNDATION Fieldbus Wiring Recommended connection For maximum EMC protection please observe the following points: • The external ground terminal on the transmitter must be connected to ground. • The continuity of the cable screening between tapping points must be ensured.

  • Page 32: Operation

    Operation Micropilot M FMR230 FOUNDATION Fieldbus Operation This chapter gives an overview of the different operating options for the device. The different methods of parameter access are described and the preconditions for each method are stated. The meaning of the parameters is not described in this chapter. Instead, refer to: •...

  • Page 33: Remote Operation

    Micropilot M FMR230 FOUNDATION Fieldbus Operation 5.1.1 On-site operation Options for on-site operation • Display and operating module • Endress+Hauser operating software "FieldCare" Parameter access by on-site operation The following parameters can be accessed by on-site operation: • Parameters of the device specific blocks (Sensor Block, Diagnostic Block, Display Block) •...

  • Page 34: Operation With The Display And Operating Module

    Operation Micropilot M FMR230 FOUNDATION Fieldbus Operation with the display and operating module (liquid crystal display) Orde Orde Ser.- Ser.- r Cod r Cod No.: No.: sber sber eich eich surin surin g rang g rang U 16... U 16...
  • Page 35 Micropilot M FMR230 FOUNDATION Fieldbus Operation 5.2.1 Display Liquid crystal display (LCD): Four lines with 20 characters each. Display contrast adjustable through key combination. Headline Position indicator ENDRESS + HAUSER Symbol Main value Bargraph Unit – Selection list Function groups -> Functions HOME F000 F001 F002 F003 F004 ...
  • Page 36 Operation Micropilot M FMR230 FOUNDATION Fieldbus 5.2.3 Function of the keys Key(s) Meaning Navigate upwards in the selection list. Edit numeric value within a function. Navigate downwards in the selection list. Edit numeric value within a function. Navigate to the left within a function group.

  • Page 37: The Operating Menu

    Micropilot M FMR230 FOUNDATION Fieldbus Operation 5.2.4 The operating menu General structure of the operating menu The operating menu is made up of two levels: • Function groups (00, 01, 03, …, 0C, 0D): The individual operating options of the instrument are split up roughly into different function groups.
  • Page 38 Operation Micropilot M FMR230 FOUNDATION Fieldbus Navigation within the menu ENDRESS + HAUSER – >3 s Return to basic setup tank shape medium property Group Selection dome ceiling unknown safety settings horizontal cyl DC: < 1.9 bypass DC: 1.9 ... 4...

  • Page 39: Operation With The Endress+Hauser Operating Program

    FieldCare is an Endress+Hauser asset management tool based on FDT technology. With FieldCare, you can configure all Endress+Hauser devices as well as devices from other manufacturers that support the FDT standard. Hardware and software requirements you can find on the inernet: www.endress.com ➞...
  • Page 40 Operation Micropilot M FMR230 FOUNDATION Fieldbus Signal analysis via envelope curve MicropilotM-en-306 Tank linearisation MicropilotM-en-307 Endress+Hauser...

  • Page 41: Operation With A Foundation Fieldbus Configuration Program

    Micropilot M FMR230 FOUNDATION Fieldbus Operation Operation with a FOUNDATION Fieldbus configuration program 5.4.1 FOUNDATION Fieldbus configuration programs The user can obtain special configuration and operating programs offered by different manufacturers for use in configuration. These can be used for configuring both the FOUNDATION Fieldbus functions and all the device-specific parameters.
  • Page 42 A FOUNDATION Fieldbus configuration tool offers two types of parameter representation: • Representation by parameter name Examples: "PAROPERATIONCODE", "PARRESET" • Representation by parameter label (identical to the labels on the display module and in an Endress+Hauser operation tool) Examples: "unlock parameter", "reset" Endress+Hauser...

  • Page 43: Operation With The Field Communicator

    Micropilot M FMR230 FOUNDATION Fieldbus Operation Operation with the Field Communicator 375, 475 5.5.1 Connection The handheld terminal is directly connected to the FOUNDATION Fieldbus communication line. An additonal communication resistor is not required. 5.5.2 Device Descriptions Make sure you have loaded the valid Device Description files (DDs). DDs can be downloaded from the internet at "www.fieldcommunicator.com".
  • Page 44 Operation Micropilot M FMR230 FOUNDATION Fieldbus 5.5.4 Example basic setup dsdmdm df das. asdas fa asas la. tank shape: dome ceiling Fieldbus Live Device List Number of Devices found = 1 dome ceiling Address horizontal cyl. bypass E+H_MICROPILOT_M_XXXXXXX 247 stilling well...

  • Page 45: Commissioning

    • "Resetting the device", → ä 47 • "Commissioning by the display and operatig module", → ä 49 • "Basic Setup with the Endress+Hauser operating program", → ä 59 • "Commissioning with a FOUNDATION Fieldbus configuration tool", → ä 62 •...
  • Page 46 Commissioning Micropilot M FMR230 FOUNDATION Fieldbus 6.2.2 Key combination (display and operating module) Locking Press S, O and F simultaneously. Unlocking If you try to change a parameter, the following appears: L00-fmrxf0a4-20-00-00-de-001 Press S, O and F simultaneously. The "unlock parameter" (0A4) function appears.

  • Page 47: Resetting The Device

    Micropilot M FMR230 FOUNDATION Fieldbus Commissioning Resetting the device It is advisable to reset the device parameters before the commissioning if you want to use a device with an unknown history. 6.3.1 Resetting the parameters of the FOUNDATION Fieldbus func-...
  • Page 48 – "inactive": deactivates the tank map but does not delete it. It can be re-activated when required. – "active": activates the tank map. Resetting the tank map with an Endress+Hauser operating program In the function group "extended calibr." select the "cust. tank map" (055) function. Select the required option ("reset", "inactive" or "active") Resetting the tank map with a FOUNDATION Fieldbus configuration tool In the Sensor Block select the parameter PARCUSTTANKMAP (cust tank map).

  • Page 49: Commissioning By The Display And Operatig Module

    Micropilot M FMR230 FOUNDATION Fieldbus Commissioning Commissioning by the display and operatig module 6.4.1 Power up instrument After switching on the supply voltage, the instrument is first initialised. L00-fmp-fxxx-20-00-00-en-003 Then the following appear for approximately five seconds: • Device type •...
  • Page 50 Commissioning Micropilot M FMR230 FOUNDATION Fieldbus 6.4.2 Application parameters Function "tank shape" (002) ⇒ ENDRESS + HAUSER – This function is used to select the tank shape. Selection: • dome ceiling • horizontal cyl • bypass • stilling well • flat ceiling •...
  • Page 51 Micropilot M FMR230 FOUNDATION Fieldbus Commissioning Function "process cond." (004) ⇒ ENDRESS + HAUSER – This function is used to select the process conditions. Selection: • standard • calm surface • turb. surface • agitator • fast change • test: no filter...
  • Page 52 Commissioning Micropilot M FMR230 FOUNDATION Fieldbus Function "empty calibr." (005) ⇒ ENDRESS + HAUSER – This function is used to enter the distance from the flange (reference point of the measurement) to the minimum level (=zero). L00-FMR2xxxx-14-00-06-en-008 " Caution! For dish bottoms or conical outlets, the zero point should be no lower than the point at which the radar beam hits the bottom of the tank.
  • Page 53 Micropilot M FMR230 FOUNDATION Fieldbus Commissioning Function "pipe diameter" (007) ⇒ ENDRESS + HAUSER – This function is used to enter the pipe diameter of the stilling well or bypass pipe. 100% 100% ø ø L00-FMR2xxxx-14-00-00-en-011 Microwaves propagate more slowly in pipes than in free space. This effect depends on the inside diameter of the pipe and is automatically taken into account by the Micropilot.
  • Page 54 Commissioning Micropilot M FMR230 FOUNDATION Fieldbus Function "check distance" (051) ⇒ ENDRESS + HAUSER – This function triggers the mapping of interference echoes. To do so, the measured distance must be compared with the actual distance to the product surface. The following options are available for...
  • Page 55 Micropilot M FMR230 FOUNDATION Fieldbus Commissioning Function "range of mapping" (052) ⇒ ENDRESS + HAUSER – This function displays the suggested range of mapping. The reference point is always the reference point of the measurement. This value can be edited by the operator.
  • Page 56 Commissioning Micropilot M FMR230 FOUNDATION Fieldbus 6.4.3 Envelope curve mit device display After the basic setup, an evaluation of the measurement with the aid of the envelope curve ("envelope curve" (0E) function group) is recommended. Function "plot settings" (0E1) ⇒...
  • Page 57 Micropilot M FMR230 FOUNDATION Fieldbus Commissioning Function "envelope curve display" (0E3) The envelope curve is displayed in this function. You can use it to obtain the following information: quality of evaluated echo full calibr. evaluated echo is marked empty calibr.
  • Page 58 Commissioning Micropilot M FMR230 FOUNDATION Fieldbus Move mode Then press to switch to Move mode. Either is displayed. • shifts the curve to the right. • shifts the curve to the left. L00-FMxxxxxx-07-00-00-yy-008 Vertical Zoom mode Press once more to switch to Vertical Zoom mode.

  • Page 59: Basic Setup With The Endress+Hauser Operating Program

    Micropilot M FMR230 FOUNDATION Fieldbus Commissioning Basic Setup with the Endress+Hauser operating program To carry out the basic setup with the operating program, proceed as follows: • Start the operating program and establish a connection. • Select the "basic setup" function group in the navigation window.
  • Page 60 Commissioning Micropilot M FMR230 FOUNDATION Fieldbus Basic Setup step 2/4: • Enter the application parameters: – Tank shape – Medium property – Process cond. MicropilotM-en-302 Basic Setup step 3/4: If "dome ceiling", "horizontal cyl", "..." is selected in the "tank shape" function, the following display appears on the screen: •...
  • Page 61 Micropilot M FMR230 FOUNDATION Fieldbus Commissioning Basic Setup step 4/4: • This step starts the tank mapping • The measured distance and the current measured value are always displayed in the header MicropilotM-en-304 6.5.1 Signal analysis via envelope curve After the basic setup, an evaluation of the measurement using the envelope curve is recommended.

  • Page 62: Commissioning With A Foundation Fieldbus Configuration Tool

    Commissioning Micropilot M FMR230 FOUNDATION Fieldbus Commissioning with a FOUNDATION Fieldbus configuration tool Note! For commissioning of the device with a FOUNDATION Fieldbus configuration tool you need to know the DEVICE_ID, which consists of the following parts: Device_ID = 452B48100F-XXXXXXXX...
  • Page 63 Micropilot M FMR230 FOUNDATION Fieldbus Commissioning 6.6.2 Parametrization of the Resource Block (Start Index: 400) Enter the desired block name (optional). Factory setting: RESOURCE_XXXXXXXX Opern the Resource Block On delivery, write protection is disabled so that you can access the write parameters via FOUNDATION Fieldbus.
  • Page 64 – by the display and operating module (→ ä 56) – by an Endress+Hauser operating program (→ ä 61) In the FOUNDATION Fieldbus configuration tool you can select from two types of parameter display: - parameter names (e.g. "PARTANKSHAPE") - label texts (e.g.
  • Page 65 Micropilot M FMR230 FOUNDATION Fieldbus Commissioning 6.6.4 Parametrization of the Analog Input Blocks Micropilot M has two Analog Input Blocks that can be assigned to the various process variables. The following descripiton provides an example for the Analog Input Block 1 (Start Index 500).

  • Page 66: Commissioning With The Field Communicator 375, 475

    Commissioning Micropilot M FMR230 FOUNDATION Fieldbus 6.6.5 Connection of the function blocks A concluding overall system configuration is essential so that the operating mode of the Analog Input Block can be set to AUTO and so that the field device is integrated into the system application.

  • Page 67: Maintenance

    Repairs The Endress+Hauser repair concept assumes that the measuring devices have a modular design and that customers are able to undertake repairs themselves (→ ä 80, "Spare Parts"). Please contact Endress+Hauser Service for further information on service and spare parts.

  • Page 68: Accessories

    L00-FMR2xxxx-00-00-06-en-001 Commubox FXA291 The Commubox FXA291 connects Endress+Hauser field instruments with CDI interface (= Endress+Hauser Common Data Interface) to the USB interface of a personal computer or a notebook. For details refer to TI00405C/07/EN. Note! For the instrument you need the "ToF Adapter FXA291" as an additional accessory.

  • Page 69: Antenna Extension Far10

    Micropilot M FMR230 FOUNDATION Fieldbus Accessories Antenna extension FAR10 8.4.1 Dimensions instrument horn material 316L/1.4404 mm (in) L00-FMRxxxxx-00-00-06-en-002 8.4.2 Ordering information: Material 316L 316L + EN10204-3.1 material, NACE MR0175 (316l wetted parts) inspection certificate 2.4600 / Alloy B2 2.4610 / Alloy C4 Special version, TSP-no.

  • Page 70: Remote Display Fhx40

    Accessories Micropilot M FMR230 FOUNDATION Fieldbus Remote display FHX40 Wall-mounting Pipe-mounting (without mounting bracket) (mounting bracket and plate supplied optionally, s. product structure) Separate housing FHX40 (IP 65) Micropilot M (4.8) Levelflex M Prosonic M O rd O rd S er...

  • Page 71: Trouble-Shooting

    Micropilot M FMR230 FOUNDATION Fieldbus Trouble-shooting Trouble-shooting Trouble-shooting instructions Micropilot M FMR 2xx -Trouble Shooting Check voltage and Not ok Instrument does compare it with the Connect the Instrument works? Ready not respond specifications on the correct voltage nameplate. Check the polarity...

  • Page 72: System Error Messages

    • Device display: error symbol in the "measured value" (000) function • Device display or Endress+Hauser operating program: in the "diagnostics" (0A) function group in the "present error" (0A0) function Only the highest priority error is displayed; in the case of multiple errors, you can scroll between the different error messages by pressing O or S.

  • Page 73: Error Codes

    Micropilot M FMR230 FOUNDATION Fieldbus Trouble-shooting 9.2.3 Types of error Type of error Symbol Meaning The output signal assumes a value which can be set using the "output on alarm" (010) function: • MAX: 110% Alarm (A) • MIN: -10% •...
  • Page 74 Trouble-shooting Micropilot M FMR230 FOUNDATION Fieldbus Code Description Possible cause Remedy A164 electronics defect hardware problem reset; if alarm prevails after reset, exchange electronics A171 electronics defect hardware problem reset; if alarm prevails after reset, exchange electronics A231 sensor 1 defect...
  • Page 75 Micropilot M FMR230 FOUNDATION Fieldbus Trouble-shooting 9.2.5 Influence of the error codes on the output signal The following table describes the influence of the error codes on the status of the cyclic output values as well as on the parameters BLOCK_ERR and XD_ERROR in the Sensor Block.

  • Page 76: Application Errors

    Trouble-shooting Micropilot M FMR230 FOUNDATION Fieldbus Application errors Error Output Possible cause Remedy A warning or alarm Depending on the configuration See table of error messa- 1. See table of error messages ges (→ ä 72) (→ ä 72) has occurred →...
  • Page 77 Micropilot M FMR230 FOUNDATION Fieldbus Trouble-shooting Error Output Possible cause Remedy → If the surface is not Signal is weakened by 1. Carry out tank mapping basic calm (e.g. filling, the rough surface – the setup emptying, agitator interference echoes are 100% 2.

  • Page 78: Orientation Of The Micropilot

    Trouble-shooting Micropilot M FMR230 FOUNDATION Fieldbus Orientation of the Micropilot For orientation a marker is found on the flange or threaded boss of the Micropilot. During installation this must be oriented as follows (→ ä 10): • In tanks: to the vessel wall •...
  • Page 79 Micropilot M FMR230 FOUNDATION Fieldbus Trouble-shooting echo: highest value echo tank bottom L00-FMRxxxxx-19-00-00-en-004 Vessel empty, no interference echo false echo: smallest value false echo echo tank bottom L00-FMRxxxxx-19-00-00-en-005 Vessel empty, interference echo obtained Fix the flange or threaded boss in this position. If necessary, replace the seal.

  • Page 80: Spare Parts

    Trouble-shooting Micropilot M FMR230 FOUNDATION Fieldbus Spare Parts An overview of the spare parts for your device is available in the internet at www.endress.com. To obtain information on the spare parts, proceed as follows: Go to "www.endress.com" and select your country.

  • Page 81: Return

    Micropilot M FMR230 FOUNDATION Fieldbus Trouble-shooting Return The following procedures must be carried out before a transmitter is sent to Endress+Hauser e.g. for repair or calibration: • Remove all residue which may be present. Pay special attention to the gasket grooves and crevices where fluid may be present.

  • Page 82: Technical Data

    Technical data Micropilot M FMR230 FOUNDATION Fieldbus Technical data 10.1 Additional technical data 10.1.1 Input Measured variable The measured variable is the distance between a reference point and a reflective surface (i.e. medium surface). The level is calculated based on the tank height entered.
  • Page 83 Micropilot M FMR230 FOUNDATION Fieldbus Technical data 10.1.3 Data of the FOUNDATION Fieldbus interface Basic Data Device Type 100F (hex) Device Revision 04 (hex) DD Revision 01 (hex) CFF Revision 01 (hex) ITK Version 4.61 ITK-Certification Driver-No. IT035500 Link Master (LAS) cabable Link Master / Basic Device yes;...
  • Page 84 Technical data Micropilot M FMR230 FOUNDATION Fieldbus Function Blocks Block Content Execution time Functionality Resource Block The Resource Block contains all the data that uniquely iden- enhanced tifies the field device. It is an electronic version of a name- plate of the device.
  • Page 85 Micropilot M FMR230 FOUNDATION Fieldbus Technical data 10.1.4 Auxiliary energy Terminals Cable cross-section: 0,5 to 2,5 mm² (20 to 14 AWG) Cable entry • Cable gland M20x1.5 (recommended cable diameter 6 to 10 mm (0.24 to 0.39 in)) • Cable entry G½ or ½ NPT •...
  • Page 86 Technical data Micropilot M FMR230 FOUNDATION Fieldbus 10.1.5 Performance characteristics Reference operating • temperature = +20 °C ±5 °C (+68 °F ±41 °F) conditions • pressure = 1013 mbar abs. ±20 mbar (15 psi ±0.29 psi) • relative humidity (air) = 65 % ±20 % •...
  • Page 87 Micropilot M FMR230 FOUNDATION Fieldbus Technical data 10.1.6 Operating conditions: Environment Ambient temperature range Ambient temperature for the transmitter: -40 °C to +80 °C (-40 °F to +176 °F) or -50 °C to +80 °C (-58 °F to +176 °F). The functionality of the LCD display may be limited for temperatures Ta <...
  • Page 88 Technical data Micropilot M FMR230 FOUNDATION Fieldbus 10.1.7 Operating conditions: Process Process temperature range / Note! Process pressure limits The specified range may be reduced by the selected process connection. The pressure rating (PN) specified on the flanges refers to a reference temperature of 20 °C (68 °F), for ASME flanges to 100 °F.
  • Page 89 Micropilot M FMR230 FOUNDATION Fieldbus Technical data 10.1.8 Mechanical construction Weight • F12/T12 housing: approx 6 kg (13.23 lbs) + weight of flange • F23 housing: approx 9.4 kg (20.73 lbs) + weight of flange Material Materials of T12 and F12 housing (seawater-resistant, powder-coated)
  • Page 90 Technical data Micropilot M FMR230 FOUNDATION Fieldbus Materials of F23 housing (corrosion-resistant) F23 housing 316L (1.4404/1.4435) L00-x12xxxx-16-00-00-en-001 Pos. Part Material Housing body: 1.4404; Sensor neck: 1.4435; F23 housing earth connection block: 1.4435 Cover 1.4404 Sealing Fa. SHS: EPDM 70pW FKN...
  • Page 91 Micropilot M FMR230 FOUNDATION Fieldbus Technical data Material Ext. temperature version High temperature version 3" Tri-Clamp (in contact with process) ISO 2852 Standard antenna Antenna extension L00-FMR230xx-16-00-00-en-003 Pos. Part Material Horn antenna 316L (1.4404) Hastelloy Screw Hastelloy Spring washer Flange 316L (1.4404/1.4435)
  • Page 92 Technical data Micropilot M FMR230 FOUNDATION Fieldbus 10.1.9 Certificates and approvals CE approval The measuring system meets the legal requirements of the EC-guidelines. Endress+Hauser confirms the instrument passing the required tests by attaching the CE-mark. RF approvals R&TTE, FCC Overspill protection German WHG, see ZE00244F/00/DE.
  • Page 93 Micropilot M FMR230 FOUNDATION Fieldbus Technical data Ex approval Correlation of safety instructions (XA, XC) and certificates (ZD, ZE) to the instrument: Feature Non-hazardous area Non-hazardous area, WHG ATEX II 3G Ex nA II T6 ATEX II 1/2G Ex ia IIC T6, ATEX II 3D...
  • Page 94 Technical data Micropilot M FMR230 FOUNDATION Fieldbus 10.1.10 Supplementary Documentation Supplementary This supplementary documentation can be found on our product pages on www.endress.com: Documentation • Technical Information (TI00345F/00/EN) • Operating Instructions "Description of instrument functions" (BA00221F/00/EN) • Safety Manual "Functional Safety Manual" (SD00150F/00/EN).
  • Page 95 Micropilot M FMR230 FOUNDATION Fieldbus Technical data Endress+Hauser...

  • Page 96: Appendix

    Appendix Micropilot M FMR230 FOUNDATION Fieldbus Appendix 11.1 Operating menu basic setup tank shape medium cond. process cond. empty calibr. full calibr. dome ceiling unknown standard enter value enter value horizontal cyl. DK: < 1.9 calm surface DK: 1.9 … 4 turb.
  • Page 97 Micropilot M FMR230 FOUNDATION Fieldbus Appendix dist./meas.value check distance range of mapping start mapping dist./meas.value distance = ok input of D and L dist. too small mapping range are displayed D and L manual are displayed dist. unknown dist. too big safety distance in safety dist.

  • Page 98: Block Model Of The Micropilot M

    Appendix Micropilot M FMR230 FOUNDATION Fieldbus 11.2 Block model of the Micropilot M The Micropilot M contains the follwoing blocks: • Resource Block (RB2) see Operating Instructions BA013S/04/EN: "FOUNDATION Fieldbus - Overview" • Sensor Block (TBRL) contains the parameters relevant to the measurement •...

  • Page 99: Resource Block

    Micropilot M FMR230 FOUNDATION Fieldbus Appendix 11.3 Resource block The resource block contains the parameters used to describe physical resources of the device. It has no linkable inputs or outputs. 11.3.1 Operation The resource block is opened by a click on the resource line.

  • Page 100: Sensor Block

    Appendix Micropilot M FMR230 FOUNDATION Fieldbus 11.4 Sensor block The Sensor block contains the parameters required to calibrate the device. These parameters can also be addressed by using the display module. The calibration of the device is described, → ä 45.
  • Page 101 Micropilot M FMR230 FOUNDATION Fieldbus Appendix 11.4.5 Methods The FOUNDATION Fieldbus specification provides for the use of so-called methods to simplify the operation of the device. A method is an interactive sequence of steps that must be followed in order to obtain a particular function from the device.
  • Page 102 Appendix Micropilot M FMR230 FOUNDATION Fieldbus Parameter Position rel. Variable Name Size Type Access Storage Changeable Indicator Index [bytes] Class in Mode table no. PARTABLENUMBER Unsigned8 non-vol. Auto, OOS input level PARINPUTLEVELHALFAUTOMATIC FloatingPoint dynamic Auto, OOS input level PARINPUTLEVELMANUAL FloatingPoint...

  • Page 103: Diagnostic Block

    Micropilot M FMR230 FOUNDATION Fieldbus Appendix 11.5 Diagnostic Block 11.5.1 Operation The diagnostic block contains the error messages of the instrument. These parameters can also be addressed by using the display module. The diagnostic block is opened by clicking on the "diagnostic"...

  • Page 104: Display Block

    Appendix Micropilot M FMR230 FOUNDATION Fieldbus 11.6 Display Block 11.6.1 Operation The display block contains the parameters required to parametrise the display module (which is contained in the remote display and operating unit FHX40). These parameters can also be addressed by using the display module.

  • Page 105: Analog Input Block

    Micropilot M FMR230 FOUNDATION Fieldbus Appendix 11.7 Analog input block The analog input block conditons the signal output by the Sensor block andoutputs signal to the PCL or other function blocks. L00-FMR2xxxx-05-00-00-en-008 11.7.1 Operation The resource block is opened by a click on the resource line.
  • Page 106 Appendix Micropilot M FMR230 FOUNDATION Fieldbus 11.7.3 Output values Parameter Description Either the primary/secondary Sensor block value used to execute the block or a process value associated with it. Comprises value and status. The primary value output as a result of executing the analog input block. Comprises value and status.
  • Page 107 Micropilot M FMR230 FOUNDATION Fieldbus Appendix 11.7.5 Output response parameters Parameter Description LOW_CUT Not relevant to level measurement! Determines a threshold for square root linearization below which the output value is set to zero. PV_FTIME Sets the time constant for the output value.

  • Page 108: List Of Start Indices

    Appendix Micropilot M FMR230 FOUNDATION Fieldbus 11.7.9 Simulation The SIMULATE parameter allows the Sensor block output value to be simulated, provided simulation has also been enabled at the device DIP switch. The simulation must be enabled, a value and/or status entered and the block must be in AUTO mode. During simulation the Sensor output value is substituted by the simulated value.

  • Page 109: Patents

    Micropilot M FMR230 FOUNDATION Fieldbus Appendix 11.9 Patents This product may be protected by at least one of the following patents. Further patents are pending. • US 5,387,918 i EP 0 535 196 • US 5,689,265 i EP 0 626 063 •...
  • Page 110 Appendix Micropilot M FMR230 FOUNDATION Fieldbus Endress+Hauser...
  • Page 111 Micropilot M FMR230 FOUNDATION Fieldbus Appendix Endress+Hauser...

  • Page 112: Index

    Micropilot M FMR230 FOUNDATION Fieldbus Index Index accessories ........68 key assignment .
  • Page 113 Micropilot M FMR230 FOUNDATION Fieldbus Index vessel / silo........60 warning .
  • Page 114 Micropilot M FMR230 FOUNDATION Fieldbus Index Endress+Hauser...
  • Page 115 Erklärung zur Kontamination und Reinigung Please reference the Return Authorization Number (RA#), obtained from Endress+Hauser, on all paperwork and mark the RA# clearly on the outside of the box. If this procedure is not followed, it may result in the refusal of the package at our facility.
  • Page 116 www.endress.com/worldwide BA00228F/00/EN/13.11 71139433 71139433 CCS/FM+SGML 9.0 ProMoDo...
