W ü r t h w e i n
ARCADIS Orbic
Installation and Start-up
System
3D Reconstruction
Print No.:
SPR2-320.814.02.01.02
Replaces: n.a.
SP
2005
© Siemens AG
The reproduction, transmission or use
of this document or its contents is not
permitted
without
express
authority. Offenders will be liable for
damages. All rights, including rights
created by patent grant or registration
of a utility model or design, are
reserved.
English
Doc. Gen. Date: 01.05
written

Advertisement

Table of Contents
loading

Related Manuals for Siemens ARCADIS Orbic

Summary of Contents for Siemens ARCADIS Orbic

  • Page 1 W ü r t h w e i n ARCADIS Orbic Installation and Start-up System 3D Reconstruction 2005 © Siemens AG The reproduction, transmission or use of this document or its contents is not permitted without express written authority. Offenders will be liable for damages.
  • Page 2 Assemblers and other persons who are not employed by or otherwise directly affiliated with or authorized by Siemens or one of its affiliates are directed to contact one of the local offices of Siemens or one of its affiliates before attempting installation or service pro- cedures.

  • Page 3: Table Of Contents

    6 _______ 3D Reconstruction Upgrade Part 4 ________________________________ 45 Checking C-arm movement for ARCADIS Orbic 3D ......45 The next step .

  • Page 4: Notes And Symbols

    General Notes and symbols 1General Emphasized texts in technical documentation have the following meaning: Fig. 1: Safety notes ARCADIS Orbic SPR2-320.814.02.01.02 Siemens AG Page 4 of 46 01.05 CS SD 24 Medical Solutions...

  • Page 5: Safety Information

    ARCADIS Orbic 3D. • This document describes the individual steps required to install the 3D option in the in- stalled base - in this case the ARCADIS Orbic 3D. WARNING Danger of possibly fatal physical injury and property damage! Noncompliance can lead to death, physical injury or property dam- age.
  • Page 6 Avoid any skin contact with blood or other excreta! The preventive measures against infectious diseases specified in ARTD-002.731.37... must be strictly observed at all times! ARCADIS Orbic SPR2-320.814.02.01.02 Siemens AG Page 6 of 46 01.05 CS SD 24...
  • Page 7 Low kV and mA values, short radiation time. Release radiation as briefly as possible. Checks requiring the release of radiation are identified by the radiation warning symbol. Siemens AG SPR2-320.814.02.01.02 ARCADIS Orbic Page 7 of 46 Medical Solutions 01.05 CS SD 24...
  • Page 8 To prevent burns, switch off the system power sup- ply before contacting any parts or components and let the system cool off for at least 5 minutes before resum- ing work. ARCADIS Orbic SPR2-320.814.02.01.02 Siemens AG Page 8 of 46 01.05...
  • Page 9 Perform the corresponding work with special care and attentiveness. Wear work gloves if necessary. Siemens AG SPR2-320.814.02.01.02 ARCADIS Orbic Page 9 of 46 Medical Solutions 01.05 CS SD 24...

  • Page 10: Tools, Measuring Equipment And Auxiliary Devices

    75 51 620 Drill with right/left spiral (clockwise/counterclockwise) n.a. Threader 96 60 093 DMM Fluke 8060A 97 02 101 Y4290 3D reconstruction upgrade kit 80 81 403 ARCADIS Orbic SPR2-320.814.02.01.02 Siemens AG Page 10 of 46 01.05 CS SD 24 Medical Solutions...

  • Page 11: Check List Prior To Installing The 3D Option

    A room suitable for the installation is available. The tools to be provided by the R.U. are available. All auxiliary service tools to be provided by the R.U. are available. Siemens AG SPR2-320.814.02.01.02 ARCADIS Orbic Page 11 of 46 Medical Solutions 01.05 CS SD 24...

  • Page 12: Actions Required Prior To Installing The 3D Option

    General Actions required prior to installing the 3D option Not OK Functional check of the ARCADIS Orbic 3D in accordance with the operating manual Testing as part of the IQ quick test: - The "Checking the ADR characteristics" chapter - The "Resolution" chapter - The "Image interference"...

  • Page 13: Covers

    Actions Covers 2Actions • Proceed as follows after the ARCADIS Orbic 3D has been moved to the respective room and the brake has been enabled. Cover of the X-ray unit • Remove the cover and reattach it after installing the 3D option.

  • Page 14: Centering Disk, Item No. 71 40 580

    • Remove the countersunk screws prior to mounting the centering disk. • Attach the centering disk at the cable module (see (Fig. 2 / p. 14)). ARCADIS Orbic SPR2-320.814.02.01.02 Siemens AG Page 14 of 46 01.05 CS SD 24 Medical Solutions...

  • Page 15: C-Arm

    Attach the cam using 2 countersunk screws M 4 x 8 (Fig. 8 / p. 18). • Repeat these steps on the other side of the C-arm. Fig. 3: C-arm _ starting position Siemens AG SPR2-320.814.02.01.02 ARCADIS Orbic Page 15 of 46 Medical Solutions 01.05 CS SD 24...
  • Page 16 3D Reconstruction Upgrade Part 1 Fig. 4: Mark distance Fig. 5: Mark hole ARCADIS Orbic SPR2-320.814.02.01.02 Siemens AG Page 16 of 46 01.05 CS SD 24 Medical Solutions...
  • Page 17 3D Reconstruction Upgrade Part 1 Fig. 6: Drill Fig. 7: Cutting the threads Siemens AG SPR2-320.814.02.01.02 ARCADIS Orbic Page 17 of 46 Medical Solutions 01.05 CS SD 24...
  • Page 18 If these guidelines are not observed, minor to moderate injury, es- pecially to the hands, can occur. Observe the safety notes concerning the C-arm carbon fiber structure. Fig. 8: Attaching the cam ARCADIS Orbic SPR2-320.814.02.01.02 Siemens AG Page 18 of 46 01.05 CS SD 24...

  • Page 19: Limit Switches

    3D Reconstruction Upgrade Part 1 Limit switches Fig. 9: Attaching both limit switches Fig. 10: Limit switch in switching position Siemens AG SPR2-320.814.02.01.02 ARCADIS Orbic Page 19 of 46 Medical Solutions 01.05 CS SD 24...

  • Page 20: Setting The Limit Switches

    20). Fig. 11: Limit switch with cabling Fig. 12: Setting the limit switch Setting the limit switches • Manually move the C-arm into the end position. ARCADIS Orbic SPR2-320.814.02.01.02 Siemens AG Page 20 of 46 01.05 CS SD 24 Medical Solutions...
  • Page 21 Test the functioning of the limit switches by moving the C-arm into the +95° und -95° or- bital positions. • Check these settings at least twice. Siemens AG SPR2-320.814.02.01.02 ARCADIS Orbic Page 21 of 46 Medical Solutions 01.05 CS SD 24...

  • Page 22: Installing The System Electronics For 3D Reconstruction 71 39 921

    Move the lifting column into the top position. • Remove the 4 upper mounting screws of D1, leave the washers on D1 (Fig. 14 / p. 22). ARCADIS Orbic SPR2-320.814.02.01.02 Siemens AG Page 22 of 46 01.05 CS SD 24...
  • Page 23 • Place D200 on the hexagonal bolts. • Attach D200 with the contact washers and nuts (Fig. 16 / p. 24). Fig. 15: Mounted bolt Siemens AG SPR2-320.814.02.01.02 ARCADIS Orbic Page 23 of 46 Medical Solutions 01.05 CS SD 24...
  • Page 24 3D Reconstruction Upgrade Part 1 Fig. 16: Installed 3D reconstruction system electronics D200 ARCADIS Orbic SPR2-320.814.02.01.02 Siemens AG Page 24 of 46 01.05 CS SD 24 Medical Solutions...

  • Page 25: Cable No. 3, Item Number N.a

    27). Retighten the shielding on PC board D30. Cable no. 3, item number n.a. • Connect plug D30.X5 on D30 and plug-in location D200.X215 on D200. Siemens AG SPR2-320.814.02.01.02 ARCADIS Orbic Page 25 of 46 Medical Solutions 01.05 CS SD 24...

  • Page 26: Cable No. 4, Item Number N.a

    Connect cable no 1. to plug D30.X4 on D30 and to plug D200.X214 on D200. Cable no. 6, item number n.a. • Connect cable no. 6 to plug D200.X220 on D200 and to D10.X12 on PC board D10. ARCADIS Orbic SPR2-320.814.02.01.02 Siemens AG Page 26 of 46 01.05...
  • Page 27 3D Reconstruction Upgrade Part 1 Fig. 18: Shielding connection D200 Siemens AG SPR2-320.814.02.01.02 ARCADIS Orbic Page 27 of 46 Medical Solutions 01.05 CS SD 24...

  • Page 28: Orbital Drive Cable Set, Item No. 71 39 970

    - Insert plug D10.X10 into plug-in-location D10.X10 on PC board D10. - Insert plug D200.X116 into plug-in-location D200.X116 on PC board D200. - Insert plug D200.X221 into plug-in-location D200.x221 on PC board D200. ARCADIS Orbic SPR2-320.814.02.01.02 Siemens AG Page 28 of 46 01.05...

  • Page 29: Installation Usb/Can Converter

    Secure the USB/CAN converter (see (Fig. 21 / p. 29)) with cable ties (see (Fig. 22 / p. 30)) Fig. 20: Covers Fig. 21: Kit Siemens AG SPR2-320.814.02.01.02 ARCADIS Orbic Page 29 of 46 Medical Solutions 01.05 CS SD 24...
  • Page 30 3D Reconstruction Upgrade Part 1 Fig. 22: Plug_1 • Connect the USB plug of the USB/CAN converter to the PC (see (1/Fig. 23 / p. 31)). ARCADIS Orbic SPR2-320.814.02.01.02 Siemens AG Page 30 of 46 01.05 CS SD 24 Medical Solutions...
  • Page 31 Fig. 24: Plug_3 • Connect the CAN plug (see Fig. 21) to the USB/CAN converter (1/Fig. 20). • Close all covers of the monitor trolley. Siemens AG SPR2-320.814.02.01.02 ARCADIS Orbic Page 31 of 46 Medical Solutions 01.05 CS SD 24...

  • Page 32: Orbital Drive

    3D Reconstruction Upgrade Part 2 Orbital drive 43D Reconstruction Upgrade Part 2 Fig. 25: Screws removed Fig. 26: Attached motor unit ARCADIS Orbic SPR2-320.814.02.01.02 Siemens AG Page 32 of 46 01.05 CS SD 24 Medical Solutions...

  • Page 33: Coupling Unit

    32). • Attach the motor using 2 countersunk Allen screws M 8 x 40 (Fig. 26 / p. 32). Coupling unit Fig. 28: Centering disk Siemens AG SPR2-320.814.02.01.02 ARCADIS Orbic Page 33 of 46 Medical Solutions 01.05 CS SD 24...
  • Page 34 Press the coupling unit against the centering disk and attach it to the left and right using the two threaded pins (Fig. 29 / p. 34). Fig. 30: Lateral bracket ARCADIS Orbic SPR2-320.814.02.01.02 Siemens AG Page 34 of 46 01.05...
  • Page 35 (Fig. 30 / p. 34) on both sides (Fig. 31 / p. 35), first on top and then on the side; use big washers. Fig. 32: Toothed belt Siemens AG SPR2-320.814.02.01.02 ARCADIS Orbic Page 35 of 46 Medical Solutions 01.05 CS SD 24...
  • Page 36 Tighten the belt. On the opposite side of the belt tightener, it should be possible to press the belt down approx. 2 - 3 mm with your thumb (Fig. 33 / p. 36). Fig. 34: Belt pulley ARCADIS Orbic SPR2-320.814.02.01.02 Siemens AG Page 36 of 46 01.05...
  • Page 37 Once the potentiometer is in this position, turn it fully clockwise twice. • Secure the belt pulley with the Allen screw (Fig. 34 / p. 36). Siemens AG SPR2-320.814.02.01.02 ARCADIS Orbic Page 37 of 46 Medical Solutions 01.05 CS SD 24...

  • Page 38: Angulation Measurement

    3D Reconstruction Upgrade Part 2 Angulation measurement Fig. 36: Mounting screw Fig. 37: Square bar in cable module ARCADIS Orbic SPR2-320.814.02.01.02 Siemens AG Page 38 of 46 01.05 CS SD 24 Medical Solutions...
  • Page 39 40). Ensure that the markings (black lines) on the two gear wheels match exactly (Fig. 40 / p. 40). • Secure cables with cable ties. Siemens AG SPR2-320.814.02.01.02 ARCADIS Orbic Page 39 of 46 Medical Solutions 01.05 CS SD 24...
  • Page 40 Connect the angulation plug of the cable of the angulation part to the X4 plug of the or- bital drive cable set. • Connect the limit switch plug of the limit switch cable to the limit switch plug of the orbit- al drive. ARCADIS Orbic SPR2-320.814.02.01.02 Siemens AG Page 40 of 46 01.05...
  • Page 41 (Fig. 45 / p. 43). • Connect cables 1 through 4 to terminal blocks 1 through 4 ((Fig. 44 / p. 42) (Fig. 46 / p. 43)). Siemens AG SPR2-320.814.02.01.02 ARCADIS Orbic Page 41 of 46 Medical Solutions 01.05 CS SD 24...
  • Page 42 Fig. 44: Connecting the terminal block • Clamp the red cable of the coupling unit to terminal block 3. • Clamp the blue cable of the coupling unit to terminal block 4. ARCADIS Orbic SPR2-320.814.02.01.02 Siemens AG Page 42 of 46 01.05...
  • Page 43 3D Reconstruction Upgrade Part 3 53D Reconstruction Upgrade Part 3 Fig. 45: Labels_1 Fig. 46: Label_3 Siemens AG SPR2-320.814.02.01.02 ARCADIS Orbic Page 43 of 46 Medical Solutions 01.05 CS SD 24...
  • Page 44 43). Also affix the second safety label to the cable module cover on the opposite side of the other label. • Affix the 3D label to the ARCADIS Orbic C-arm (see (1/Fig. 46 / p. 43)) and the monitor trolley (see (1/Fig.

  • Page 45: Checking C-Arm Movement For Arcadis Orbic 3D

    "normal" C-arm movement. If not, verify that connector M3.X1 for the brake assembly is inserted correctly. If yes, the LEDs in both keys light up. The next step Continue with ARCADIS Orbic Start-up Instructions SPR2-320.815.02... and Image Qual- ity Assurance Test SPR2-320.820.02.. . Perform a complete functional check.
  • Page 46 Changes to the Previous Version 7Changes to the Previous Version n.a., new version ARCADIS Orbic SPR2-320.814.02.01.02 Siemens AG Page 46 of 46 01.05 CS SD 24 Medical Solutions...
