Page 101: Table Of Contents
..........3-3 Keyless Access System .
Page 102 ..... . . 3-41 Ultrasonic Rear Parking Assist (URPA) ..3-41 Side Blind Zone Alert (SBZA) ....3-44 Lane Departure Warning (LDW) .
Page 103 Leaving children in a vehicle with the keyless access transmitter is dangerous for many reasons, children or others could be badly injured or even killed. They could operate the power windows or other controls or even make the vehicle move. The windows will function with the keyless access transmitter in the vehicle and they could be seriously injured or killed if caught in the path of a closing window.
Page 104: Keyless Access System
Your vehicle has a Keyless Access System with pushbutton start. See Ignition Positions on page 3 26 for information on starting the vehicle. In an emergency, contact Cadillac Roadside Assistance. See Roadside Service on page 8 8. See Radio Frequency Statement on page 8 18 for...
Page 105 If there is a decrease in the RKE operating range, try this: Check the distance. The transmitter may be too far from the vehicle. Stand closer during rainy or snowy weather. Check the location. Other vehicles or objects may be blocking the signal. Take a few steps to the left or right, hold the transmitter higher, and try again.
Page 106 Press once to lock the doors. The light on the front doors comes on and the turn signals flash. is pressed twice, the horn will also sound. See Lights Flash at Lock and Horn Chirps at Lock under Vehicle Personalization on page 3 58 to change the feedback feature.
Page 107 Only keyless access transmitters programmed to this vehicle will work. If a transmitter is lost or stolen, a replacement can be purchased and programmed through your dealer/retailer. The vehicle can be reprogrammed so that lost or stolen transmitters no longer work. Each vehicle can have up to four transmitters programmed to it.
Page 108 8. Remove the transmitter from the transmitter pocket and press twice on each newly programmed transmitter to complete the process. 9. To program additional transmitters, repeat Step 6. Press Acc. on the ignition switch if programming is complete. This procedure requires three ten minutes cycles to complete the programming process.
Page 109 7. The DIC reads WAIT 10 MINUTES and counts down to zero. 8. The DIC displays OFF/ACC TO LEARN again. 9. Press Acc. on the ignition switch. 10. Steps 7, 8 and 9 will be repeated two more times. 11. A beep sounds and the DIC reads READY FOR FOB 1.
Page 110: Remote Vehicle Start
1. Separate the transmitter with a flat, thin object inserted into the slot on the side of the transmitter. 2. Remove the old battery. Do not use a metal object. 3. Insert the new battery, positive side facing down. Replace with a CR2032 or equivalent battery. 4.
Page 111 3. If it is the first remote start since the vehicle has been driven, repeat these steps, while the engine is still running, to extend the engine running time by 10 minutes. Remote start can be extended one time. If the vehicle is left running it will automatically shut off after 10 minutes unless a time extension has been done.
Page 112 The remote start feature will not operate if any of the following occur: The check engine light is displayed. See Check Engine Light under Malfunction Indicator Lamp on page 4 62. The valet lockout switch is on. The keyless access transmitter is in the vehicle. The vehicle's hood is open.
Page 113: Door Locks
Outsiders can easily enter through an unlocked door when you slow down or stop your vehicle. Locking your doors can help prevent this from happening. There are several ways to lock and unlock your vehicle. From the outside: Pull the front door handle. If you have the keyless access transmitter, the vehicle recognizes the transmitter and automatically unlocks the door.
Page 114: Rear Door Security Locks
The vehicle was programmed so when the doors are closed, the ignition is on, and the shift lever is moved out of P (Park), all the doors will lock. The front doors can still be opened from the inside while the doors are locked.
Page 115: Trunk
The vehicle can be programmed to sound the horn three times and unlock the driver's door when all doors are closed and there is a keyless access transmitter inside the interior of the vehicle. When the driver's door is reopened, the key in reminder chime will sound continuously.
Page 116: Keyless Access System Operation
There are three ways to open the trunk lid. Press this button located on the driver's door. The vehicle must be in P (Park) or N (Neutral) and the valet mode turned off. To disable valet mode, see Valet Lockout Switch on page 3 24.
Page 117 If your vehicle has lost battery power, you can still access the trunk by unlocking and lowering the rear seat pass through door and pulling the emergency trunk release handle. To open the door: 1. Pull the rear seat armrest down. 2.
Page 118 Leaving children, helpless adults, or pets in a vehicle with the windows closed is dangerous. They can be overcome by the extreme heat and suffer permanent injuries or even death from heat stroke. Never leave a child, a helpless adult, or a pet alone in a vehicle, especially with the windows closed in warm or hot weather.
Page 119: Power Windows
Leaving children in a vehicle with the keys is dangerous for many reasons, children or others could be badly injured or even killed. They could operate the power windows or other controls or even make the vehicle move. The windows will function and they could be seriously injured or killed if caught in the path of a closing window.
Page 120 Any window can be lowered or raised all the way without holding the switch. Press the front of the window switch to the second position and release to activate the express-down feature. To stop the window, briefly pull up the switch. Lift the front of the switch briefly to activate the express up feature.
Page 121 If express override is activated, the window will not reverse automatically. You or others could be injured and the window could be damaged. Before you use express override, make sure that all people and obstructions are clear of the window path. In an emergency, the anti pinch feature can be overridden in a supervised mode.
Page 122: Theft-Deterrent System
Vehicle theft is big business, especially in some cities. This vehicle has theft-deterrent features, however, they do not make it impossible to steal. Your vehicle has a theft-deterrent alarm system. The security light is located on the instrument panel cluster. If the ignition is off and a door is open, the security light will flash, reminding you to arm the theft-deterrent system.
Page 123 If a door, hood, or the trunk is opened without the keyless access transmitter, the horn will sound for 30 seconds and the lamps will flash for two minutes. The vehicle cannot be started without a keyless access transmitter. The Theft-Deterrent system will not arm if : The key is used to turn the key cylinder to the lock position.
Page 124: Valet Lockout Switch
The valet lockout switch is located inside the glove box. Press to turn the lockout feature off and allow the trunk to be opened with either the keyless access transmitter or the trunk release button located on the driver's door. Press to turn the lockout feature on.
Page 125 If the vehicle does not start and the keyless access transmitter appears to be undamaged, try another keyless access transmitter. Or, place the transmitter in the transmitter pocket. See NO FOBS DETECTED under DIC Warnings and Messages on page 4 76 for additional information.
Page 126: Retained Accessory Power (Rap)
The vehicle has an electronic keyless ignition with pushbutton start. To shift out of P (Park), the vehicle must be running or in ACCESSORY mode and the regular brake pedal must be applied. Press to start the engine with your foot on the brake pedal.
Page 127 To place the transmission in the proper gear: Move the shift lever to P (Park) or N (Neutral). To restart the engine when the vehicle is already moving, use N (Neutral). The keyless access transmitter must be inside the vehicle for the ignition to work. Cell phone chargers can interfere with the operation of the Keyless Access System.
Page 128: Starting The Engine
When the engine starts, let go of the accelerator. If the vehicle starts briefly but then stops again, do the same thing. This clears the extra gasoline from the engine. The vehicle has a Computer-Controlled Cranking System. This feature assists in starting the engine and protects components.
Page 129: Engine Coolant Heater
The engine coolant heater can provide easier starting and better fuel economy during engine warm up in cold weather conditions at or below 18°C (0°F). Vehicles with an engine coolant heater should be plugged in at least four hours before starting. Some models have an internal thermostat in the cord which will prevent engine coolant heater operation at temperatures above 18°C (0°F).
Page 130 There are several different positions for the shift lever. This position locks the rear wheels. It is the best position to use when you start the engine because the vehicle cannot move easily. 3-30 It is dangerous to get out of the vehicle if the shift lever is not fully in P (Park) with the parking brake firmly set.
Page 131 Use this gear to back up. At low vehicle speeds, you can also use R (Reverse) to rock your vehicle back and forth to get out of snow, ice, or sand without damaging the transmission. See If Your Vehicle is Stuck in Sand, Mud, Ice, or Snow on page 5 22 for additional information.
Page 132 Driver Shift Control (DSC) allows you shift an automatic transmission similar to a manual transmission. To use the DSC feature: 1. Move the shift lever to the right from D (Drive) into the DSC area. When in DSC mode, the sport symbol will appear in the Driver Information Center (DIC).
Page 133: Parking Brake
If shifting is prevented for any reason, the selected gear will flash multiple times, indicating that the transmission has not shifted gears. The transmission will allow you to shift to the gear selected and will automatically downshift when the vehicle comes to a stop. This will allow for more power during take-off and passing.
Page 134 It can be dangerous to get out of the vehicle if the shift lever is not fully in P (Park) with the parking brake firmly set. The vehicle can roll. If you have left the engine running, the vehicle can move suddenly.
Page 135 Torque lock is when the weight of the vehicle puts too much force on the parking pawl in the transmission. This happens when parking on a hill and shifting the transmission into P (Park) is not done properly and then it is difficult to shift out of P (Park).
Page 136: Engine Exhaust
Engine exhaust contains Carbon Monoxide (CO) which cannot be seen or smelled. Exposure to CO can cause unconsciousness and even death. Exhaust may enter the vehicle if: The vehicle idles in areas with poor ventilation (parking garages, tunnels, deep snow that may block underbody airflow or tail pipes).
Page 137: Shifting Into Park
smelled. It can cause unconsciousness and even death. Never run the engine in an enclosed area that has no fresh air ventilation. For more information, see Engine Exhaust on page 3 36. It can be dangerous to get out of the vehicle if the automatic transmission shift lever is not fully in P (Park) with the parking brake firmly set.
Page 138: Compass
Press to turn the compass on or off. When the ignition and the compass feature are on, the mirror displays the compass heading after a few seconds. If after few seconds, the display does not show a compass heading (for example, N for North), there may be a strong magnetic field interfering with the compass.
Page 139: Outside Power Mirrors
3. Once the zone number displays, press repeatedly until the correct zone number displays. Stop pressing the button and the mirror returns to normal operation. If C appears in the compass window, the compass may need calibration. See Compass Calibration listed previously. Controls for the outside power mirrors are located on the driver door.
Page 140 This feature assists the driver by improving rear obstacle detection and is useful in viewing the curb when parallel parking. The passenger and/or driver mirror tilts to a preselected position when the vehicle is in R (Reverse). This feature lets the driver view the curb when parallel parking. If further adjustment is needed after the mirror is tilted, the mirror switch may be used.
Page 141: Ultrasonic Rear Parking Assist (Urpa)
For vehicles with the URPA system, it operates at speeds less than 3 mph (5 km/h), and assists the driver with parking and avoiding objects while in R (Reverse). The sensors on the rear bumper are used to detect the distance to an object up to 5 feet (1.5 m) behind the vehicle and at least 10 inches (25.4 cm) off the ground.
Page 142 URPA comes on automatically when the shift lever is moved into R (Reverse). The rear display briefly illuminates to indicate the system is working. URPA operates only at speeds less than 3 mph (5 km/h). If the vehicle is above this speed, the red light on the rear display will flash.
Page 143 If the URPA system will not activate due to a temporary condition a red light will be shown on the rear URPA display when the shift lever is moved into R (Reverse). This occurs under the following conditions: The ultrasonic sensors are not clean. Keep your rear bumper free of mud, dirt, snow, ice and slush.
Page 144: Side Blind Zone Alert (Sbza)
The vehicle may have a Side Blind Zone Alert (SBZA) system. Read this entire section before using the system. SBZA is only a lane changing aid and does not replace driver vision. SBZA does not detect: Vehicles outside the side blind zones which may be rapidly approaching.
Page 145 The SBZA detection zones do not change if the vehicle is towing a trailer. So be extra careful when changing lanes while towing a trailer. When the vehicle is started, both outside mirror displays will briefly come on to indicate that the system is operating.
Page 146 SBZA does not operate when the left or right corners of the rear bumper are covered with mud, dirt, snow, ice, slush, or in heavy rainstorms. For cleaning instructions, see Washing Your Vehicle on page 6 111. If the DIC still displays the SIDE BLIND ZONE SYSTEM UNAVAILABLE message after cleaning the bumper, see your dealer/retailer.
Page 147: Lane Departure Warning (Ldw)
If the vehicle has the LDW system. Read this entire section before using the system. The Lane Departure Warning (LDW) system does not steer the vehicle and is only an aid to help you stay in your driving lane. The LDW system may not: Provide you with enough time to avoid a lane change collision.
Page 148 LDW uses a camera located between the inside rearview mirror and the windshield to detect the lane markings. To turn LDW on or off, press the CONFIG hard key located on the navigation radio, then press . See Configure Menu in the index of the Navigation System manual.
Page 149 message may appear in the DIC to indicate that LDW is not working properly. If this message remains on after continued driving, the system needs service. Take the vehicle to your dealer/retailer. See DIC Warnings and Messages on page 4 76 for more information. This message may appear in the DIC if LDW does not activate due to a temporary condition.
Page 150 Read the instructions completely before attempting to program the transmitter. Because of the steps involved, it may be helpful to have another person available to assist you in programming the transmitter. Be sure to keep the original remote control transmitter for use in other vehicles, as well as, for future programming.
Page 151 2. Locate in the garage, the garage door opener receiver (motor-head unit). Locate the Learn or Smart button. It can usually be found where the hanging antenna wire is attached to the motor-head unit and may be a colored button. Press this button.
Page 152 For questions or help programming the Universal Home Remote System, call 1-866-572-2728 or go to learcar2u.com. Most garage door openers sold before 1996 are Fixed Code units. Programming a garage door opener involves time-sensitive actions, so read the entire procedure before starting.
Page 153 The hand held transmitter can have between eight to 12 dip switches depending on the brand of transmitter. The garage door opener receiver (motor head unit) could also have a row of dip switches that can be used when programming the Universal Home Remote.
Page 154 The panel of switches might not appear exactly as they do in the examples above, but they should be similar. The switch positions on your hand-held transmitter could be labeled, as follows: A switch in the up position could be labeled as Up, +, or On.
Page 155 4. The indicator lights will blink slowly. Enter each switch setting from Step 2 into your vehicle's Universal Home Remote. You will have two and one-half minutes to complete Step 4. Now press one button on the Universal Home Remote for each switch setting as follows: If you wrote Left, press the left button in the vehicle.
Page 156: Glove Box
Press and hold the appropriate button for at least half of a second. The indicator light will come on while the signal is being transmitted. Any of the three buttons can be reprogrammed by repeating the instructions. The programmed buttons should be erased when the vehicle is sold or the lease ends.
Page 157 If the vehicle has a power sunroof, the switches are located on the overhead console. To open or close the sunroof, the ignition must be on or Retained Accessory Power (RAP) must be active. See Retained Accessory Power (RAP) on page 3 26. The express open feature will operate from the closed or partially open position.
Page 158: Programmable Automatic Door Locks
To close the power sunroof, operate the controls according to one of the following: From the open position, press and hold the driver's side sunroof switch forward. The sunshade must be closed manually. From the vent position, press and hold the passenger's side sunroof switch rearward.
Page 159 If your vehicle has the base audio system, the following information explains the vehicle personalization on your vehicle. If your vehicle has the Navigation system, see Personalization in the Index of the Navigation System manual for information on vehicle personalization. If your vehicle has the ability to program additional personalization features, the driver's preferences are recalled by pressing any button on the keyless access...
Page 160 7. Turn the tune/select knob and scroll to PERSONAL SETTINGS MENU, then press the tune/select knob to turn the feature on. A check mark appears after this selection when it is turned on and the entire list of personalization features will appear. 8.
Page 161 3. Press the tune/select knob to turn on the DRIVER GREETING feature. You will see a cursor on the screen. 4. Turn the tune/select knob until you reach the first letter you want; the letter will be highlighted. There is a complete alphabet with both upper and lower case letters and the numbers zero through nine.
Page 162 This feature sounds the horn three times when the driver's door is closed and there is a keyless access transmitter left inside of the vehicle. This will only occur when the vehicle is off. ON (default) To program the vehicle to a different mode: 1.
Page 163 The climate control system will engage when the vehicle is started using the remote start feature. It will be at the same climate control setting that was last used by the driver using that keyless entry transmitter. If this feature is active, the rear defogger will engage when the vehicle is started using the remote start feature.
Page 164 If your vehicle has the optional memory package, you will have this feature. When this feature is turned on, you can recall any previously programmed seat, mirror, and steering column position when the start button on the ignition is pressed. OFF (default) To program the vehicle to a different mode: 1.
Page 165 If your vehicle has the optional memory package, you will have this feature. When this feature is turned on, you can recall any previously programmed exit position for the steering column when the vehicle is off, the shift lever is in P (Park), and the driver's door is opened. OFF (default) To program the vehicle to a different mode: 1.
Page 166 3. Press the tune/select knob to switch back and forth between on and off. When the mode is turned on, a check mark will appear next to the feature name. The mode you selected is now set. You can either exit the programming mode by following the instructions later in this section or program the next feature available on your vehicle.
Page 167 This feature turns on the exterior lamps when the keyless access transmitter is used to unlock the vehicle. The lamps will remain on for about 20 seconds unless a door is opened, the ignition is in ACCESSORY, on, or START, or the keyless access transmitter is used to lock the vehicle.
Page 168 This feature allows you to set the amount of time you want the exterior lamps to remain on after you exit the vehicle. 0:00 seconds (off) 0:05 seconds (default) 0:15 seconds 0:30 seconds 1:30 minutes 2:00 minutes 3:00 minutes 4:00 minutes 3-68 To determine the mode to which the vehicle is programmed or to program the vehicle to a...
Page 169 This feature allows the driver's door to automatically unlock when the ignition is turned off. OFF (default) To program the vehicle to a different mode: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under Entering the Personal Settings Menu. 2.
Page 170 The feature allows the driver's door to automatically unlock when the transmission is shifted into P (Park). OFF (default) To program the vehicle to a different mode: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under Entering the Personal Settings Menu.
Page 171 This feature automatically unlocks the appropriate front door when you approach the vehicle with the keyless access transmitter and pull the respective door handle. See Door Locks on page 3 12 for more information. OFF (default) To program the vehicle to a different mode: 1.
Page 172 This feature delays the locking of the vehicle's doors for eight seconds after a power door lock switch or the lock button on the keyless access transmitter is pressed. The eight second delay occurs after the last door is closed. If the keyless access transmitter is left inside of the vehicle, the doors will not lock.
Page 173 OFF (default) To program the vehicle to a different mode: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under Entering the Personal Settings Menu. 2. Turn the tune/select knob until KEYLESS LOCK DELAY is highlighted. 3. Press the tune/select knob to switch back and forth between on and off.
Page 174 This feature allows you to adjust the volume level of the vehicle's warning chimes. The chime volume cannot be turned off, only adjusted. NORMAL (default) HIGH To program the vehicle to a different mode: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under Entering the Personal Settings Menu.
Page 175 The mode you selected is now set. You can either exit the programming mode by following the instructions later in this section or program the next feature available on your vehicle by pressing the F6 (BACK) button, located on the radio, to return to the PERSONAL SETTINGS MENU.
Page 176 For vehicles with the base audio system, memory features are programmed and recalled through the radio from the DRIVER SELECTION and the DRIVER EXIT SETTINGS submenus. See Entering the Driver Selection Submenu and Entering the Driver Exit Settings Submenu later in this section for more information on recalling and programming the memory settings using the base audio system.
Page 177 The numbers on the back of each keyless access transmitter correspond to DRIVER 1 and DRIVER 2. If you would like to recall or store driver settings for the driver that does not correspond to the number on the back of the keyless access transmitter that you are using: 1.
Page 178 To store driver settings: 1. Adjust your settings for the driver's seat, the outside rearview mirrors, and the steering column to a comfortable driving position. 2. Enter the memory programming mode for your driver settings by following the instructions listed previously under Entering the Driver Selection Submenu.
Page 179 To recall exit settings: 1. Enter the memory programming mode for your exit settings by following the instructions listed previously under Entering the Driver Exit Settings Submenu. 2. From the DRIVER EXIT SETTINGS submenu, turn the tune/select knob to scroll to RECALL EXIT SETTINGS and press in the knob.
Page 180 3-80...
Page 181 ......4-3 Hazard Warning Flashers ..... . . 4-3 Horn .
Page 182 Engine Coolant Temperature Gage ... . 4-61 Tire Pressure Light ......4-62 Malfunction Indicator Lamp .
Page 183: Memory Seat, Mirrors And Steering Wheel
Press this button located on the console, near the shift lever, to make the front and rear turn signal lamps flash on and off. This warns others that you are having trouble. Press again to turn the flashers off. When the hazard warning flashers are on, the turn signals do not work.
Page 184 For vehicles with a heated steering wheel, the button for this feature is located on the steering wheel. Press to turn the heated steering wheel on or off. A light on the button displays when the feature is turned on. The steering wheel takes about three minutes to start heating.
Page 185 The lever returns to its starting position when it is released. If after signaling a turn or lane change the arrow flashes rapidly or does not come on, a signal bulb may be burned out. Have the bulbs replaced. If the bulb is not burned out, check the fuse.
Page 186 If the vehicle has this system, read this entire section before using it. The system operates on a radio frequency subject to Federal Communications Commission (FCC) Rules and with Industry Canada. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1.
Page 187 The Forward Collision Alert (FCA) controls are located on the end of the multifunction lever. Turns the system off. Turns the system on. The Head-Up Display must be on and properly adjusted. If the HUD is not on, FCA will not be enabled and you will not be provided with FCA audible and visual warnings.
Page 188 The alert symbol will flash on the HUD and a warning beep will sound when driver action may be required. The driver warning is active when: You are approaching a vehicle too quickly. You are following a vehicle ahead much too closely.
Page 189 FCA may occasionally provide an unnecessary warning to guard rails, signs, and other stationary objects. This is normal operation, your vehicle does not need service. There are three messages that may appear on the Driver Information Center (DIC). They are CLEAN RADAR, RADAR CRUISE NOT READY and SERVICE RADAR CRUISE.
Page 190 The windshield wiper lever is on the right side of the steering column. Move the lever to select the wiper speed: Single wipe, move to release it. The lever will return to its original position. For several wipes, hold the lever in this position. Turns the windshield wipers off.
Page 191 The windshield washer button is located at the end of the windshield wiper lever on the right side of the steering column. Press and hold to spray windshield washer fluid on the windshield. The washer will spray until the button is released. The wipers will continue to clear the window for about six seconds after the button is released and then stop or return to the preset speed.
Page 192 With cruise control, a speed of about 40 km/h (25 mph) or more can be maintained without keeping your foot on the accelerator. Cruise control does not work at speeds below about 40 km/h (25 mph). If the brakes are applied, the cruise control shuts off. Cruise control can be dangerous where you cannot drive safely at a steady speed.
Page 193 Press to set the speed or to decrease the speed when cruise is already active. Press this button on the steering wheel to cancel cruise control without erasing the set speed from memory. If you leave your cruise control on when you are not using cruise, you might hit a button and go into cruise when you do not want to.
Page 194 There are two ways to go to a higher speed: Use the accelerator pedal to get to the higher speed. Press at the end of the lever, then release the button and the accelerator pedal. The vehicle will cruise at the higher speed. Move the cruise switch from to until the desired speed is reached, and then release the switch.
Page 195 When going downhill, you might have to brake to keep the vehicle's speed down. Applying the brake will turn off the cruise control. If you need to apply the brake due to the grade of the downhill slope, you might not want to attempt to use the cruise control feature.
Page 196 The vehicle's braking during Adaptive Cruise Control is comparable to a person applying moderate pressure to the vehicle's brake pedal. To disengage Adaptive Cruise Control, apply the brake. If no vehicle is in your path, your vehicle will react like traditional cruise control. Adaptive Cruise Control will not apply hard braking or bring the vehicle to a complete stop.
Page 197 On slippery roads, fast changes in tire traction can cause needless wheel spinning, and you could lose control. Do not use cruise control on slippery roads. When weather limits visibility, such as when in fog, rain, or snow conditions, Adaptive Cruise Control performance is limited.
Page 198 If you leave your Adaptive Cruise Control switch on when you are not using cruise, you might hit a button and go into cruise when you do not want to. You could be startled and even lose control. Keep the Adaptive Cruise Control switch off until you want to use cruise control.
Page 199 This symbol appears on the Head-Up Display (HUD) to indicate that Adaptive Cruise Control is active. The number indicates the set speed. See Head-Up Display (HUD) on page 4 38 for more information. Make sure the set speed is visible on the HUD so you know the speed your vehicle will accelerate to if a vehicle is not detected in your path.
Page 200 Press at the end of the lever until the lower speed desired is reached, then release the button. To slow down in small amounts, briefly press Each this is done, the set speed will be 1.6 km/h (1 mph) slower. If the brakes are applied while the Adaptive Cruise Control is at a set speed, this disengages the Adaptive Cruise Control.
Page 201 The range of selectable distances may not be appropriate for all drivers and driving conditions. If you prefer to travel at a following distance farther than Adaptive Cruise Control allows, disengage the system and drive manually. A graphic on the HUD indicates the selected following distance.
Page 202 The vehicle ahead symbol only appears on the HUD when a vehicle ahead is detected in your path. If this symbol does not appear, or disappears briefly, Adaptive Cruise Control will not respond to vehicles you may see ahead. 4-22 When the Adaptive Cruise Control radar is blocked by snow, ice, or dirt, it may not detect a vehicle ahead.
Page 203 Adaptive Cruise Control may not detect and react to stationary or slow moving vehicles or other objects ahead of you. You could crash into an object ahead of you. Do not use Adaptive Cruise Control when approaching stationary or slow moving vehicles or other objects. Adaptive Cruise Control may not detect and react to stationary or slow-moving vehicles or other objects ahead of you.
Page 204 To increase speed to pass a vehicle, use the accelerator pedal. While you are doing this, the system will not automatically apply the brakes. A PEDAL APPLIED ACC OVERRIDE message will appear on the HUD. See Head-Up Display (HUD) on page 4 38 for additional information.
Page 205 When following a vehicle and entering a curve, Adaptive Cruise Control could lose track of the vehicle in your lane and your vehicle could accelerate. When this happens, the vehicle ahead symbol will not appear on the HUD. Adaptive Cruise Control might detect a vehicle that is not in your lane and apply the brakes.
Page 206 Adaptive Cruise Control may lose track of the vehicle ahead and accelerate up to your set speed while entering or on highway exit ramps. You could be startled by this acceleration and even lose control of the vehicle. Disengage Adaptive Cruise Control before entering a highway exit ramp.
Page 207 The set speed memory is erased when the Adaptive Cruise Control switch or the ignition is turned off. There are three messages that may appear on the DIC. They are SERVICE RADAR CRUISE, RADAR CRUISE NOT READY and CLEAN RADAR. These messages will appear to indicate a problem with the Adaptive Cruise Control.
Page 208 Turns the exterior lamps on and off automatically depending upon how much light is outside of the vehicle. The automatic lights may be disabled even if the control is in the AUTO position. To enable automatic lighting do any of the following: Turn the headlamp control from AUTO to off and release the switch.
Page 209 has been turned on, it remains on each time the vehicle is started. Additionally, the IntelliBeam system must be enabled. To enable the System, turn the exterior lamp control to AUTO, with the turn signal/multifunction lever in its starting position. The High-Beam On Light appears on the instrument panel cluster when the high-beams are on.
Page 210 IntelliBeam may not turn off the high-beams if the system cannot detect other vehicle's lamps because of any of the following: The others vehicle's lamp(s) are missing, damaged, obstructed from view, or otherwise undetected. The other vehicle's lamp(s) are covered with dirt, snow and/or road spray.
Page 211 The light sensor is located on the inside of the vehicle at the back of the rearview mirror. Clean the light sensor window, periodically, using glass cleaner on a soft cloth. Gently wipe the sensor window. Do not spray glass cleaner directly on the surface of the sensor window.
Page 212 Daytime Running Lamps (DRL) can make it easier for others to see the front of your vehicle during the day. Fully functional daytime running lamps are required on all vehicles first sold in Canada. The DRL system comes on when the following conditions are met: It is still daylight and the ignition is on.
Page 213 The light sensor for the DRL is located on top of the instrument panel. If the sensor is covered, it will prevent it from sensing light, and the exterior lamps may come on when they are not needed. The fog lamp controls are located on the turn signal/ multifunction lever.
Page 214 ® Twilight Sentinel can turn the lamps on and off for you. A light sensor on top of the instrument panel makes the Twilight Sentinel work, so be sure it is not covered. 4-34 With Twilight Sentinel the following will happen: When it is dark enough outside, the front turn signal lamps (DRL) will go off, and the headlamps and parking lamps will come on.
Page 215 Twilight Sentinel also provides exterior illumination as you leave the vehicle. If Twilight Sentinel has turned on the lamps when you turn off the ignition, the lamps will remain on until: The exterior lamp switch is moved from off to the parking lamp position.
Page 216 The entry lighting system turns on the reading and dome lamps and the backlighting to the exterior lamp control when a door is opened or if you press the remote keyless entry transmitter unlock button. If activated by the transmitter, the lighting will remain active for about 25 seconds.
Page 217 speed. For more battery saving information, see Battery Saver Active Message under DIC Warnings and Messages on page 4 76. The vehicle has Electric Power Management (EPM) that estimates the battery's temperature and state of charge. It then adjusts the voltage for best performance and extended life of the battery.
Page 218: Automatic Transmission Operation
If the HUD image is too bright, or too high in your field of view, it may take you more time to see things you need to see when it is dark outside. Be sure to keep the HUD image dim and placed low in your field of view.
Page 219 The HUD controls are located to the left of the steering wheel on the DIC control panel. Turn the brightness control knob fully counterclockwise to turn the HUD display off. Press to move the HUD display up or down on the windshield. HUD cannot be adjusted side to side.
Page 220 Check to see if: The HUD unit is covered. The brightness is adjusted properly. The HUD display is adjusted to the proper height. Ambient light in the direction the vehicle is facing is low. A fuse is blown. See Fuses and Circuit Breakers on page 6 117.
Page 221 The Speed Advisor can be set to show a speed alert when the vehicle speed exceeds the speed alert limit as set in the DIC menu. Depending on the level of the HUD on the vehicle, your HUD may work like either of the following: The HUD speedometer will turn red when the vehicle speed exceeds the speed alert limit.
Page 222 Accessory power outlets can be used to plug in electrical equipment, such as a cellular telephone. The vehicle has one outlet in front of the center console, one in the center console lid and there may be an additional outlet in the rear of the center console. The vehicle may have a small cap that must be removed to access the accessory power outlet.
Page 223 The vehicle may have an ashtray and cigarette lighter. For vehicles with an ashtray, it is located under the climate control panel on the center console. Press on the door to release the ashtray. The ashtray automatically slides open for use. To empty the ashtray with the ashtray in full open position, locate the release button to the right of the ash receiver and slide it to the right (in the direction of the...
Page 224 The heating, cooling, and ventilation can be controlled for the vehicle with this system. A. Driver and Passenger F. Heated Seat Side Power Buttons G. Fan Control B. Ventilated Seat H. Defrost C. AUTO I. Rear Window Defogger D. Recirculation J.
Page 225 The display can be changed from English to metric units through the Driver Information Center (DIC). See DIC Operation and Displays on page 4 70. entire climate control system on or off. Turn the knob to increase or decrease the temperature inside the vehicle.
Page 226 This mode clears the windows of fog or moisture. Air is directed to the windshield and floor outlets, with some air directed to the side windows and outboard panel outlets. When this mode is selected, the system turns off recirculation and runs the air-conditioning compressor unless the outside temperature is at or below freezing.
Page 227 Press to turn the rear window defogger on or off. The rear window defogger stays on for 10 minutes, before turning off. If the vehicle's speed is above 48 km/h (30 mph), the rear defogger stays on continuously. If turned on again, the defogger only runs for about five minutes before turning off.
Page 228 The climate control system uses the information from these sensors to adjust the temperature, the fan speed and the air delivery, in order to maintain the selected temperature. The system may also supply cooler air to the side of the vehicle facing the sun. Do not cover the sensors or the automatic climate control system will not work properly.
Page 229 The vehicle has a rear climate control system. The base model includes air outlets in the rear of the center console for cooling and under-seat air outlets for heating. The temperature, amount of airflow, and the air delivery mode is controlled automatically by the front climate control system.
Page 230 Your vehicle may be equipped with a passenger compartment air filter. There are two types of filters available. There is a standard dust filter that traps small particles including pollen. There is, also, a dust/odor filter available that traps dust and pollen and uses a charcoal element to help reduce many offensive odors from entering your vehicle.
Page 231 4. Lift the inboard edge of the deflector to release the retention tab. 5. Lift and slide the water deflector toward the inboard side and remove it. 6. The top edge of the filter should be visible. Reach in and lift the filter out , pulling upward and toward the front of the vehicle.
Page 232 The instrument panel cluster is designed to show how the vehicle is running. It shows how fast the vehicle is going, how much fuel is being used and many of the other things needed to drive safely and economically. 4-52...
Page 233 The speedometer shows the speed in both kilometers per hour (km/h) and miles per hour (mph). See DIC Operation and Displays on page 4 70 for more information. The odometer mileage can be checked without the vehicle running. The vehicle's odometer works together with the driver information center.
Page 234 Several seconds after the engine is started, a chime sounds for several seconds to remind the front passenger to buckle their safety belt. The passenger safety belt light, located on the instrument panel, comes on and stays on for several seconds and then flashes for several more.
Page 235 If the airbag readiness light stays on after the vehicle is started or comes on while driving, it means the airbag system might not be working properly. The airbags in the vehicle might not inflate in a crash, or they could even inflate without a crash.
Page 236 Then, after several more seconds, the status indicator will light either ON or OFF, or either the on or off symbol to let you know the status of the right front passenger's frontal airbag. If the word ON or the on symbol is lit on the passenger airbag status indicator, it means that the right front passenger's frontal airbag is enabled (may inflate).
Page 237 If, after several seconds, both status indicator lights remain on, or if there are no lights at all, there may be a problem with the lights or the passenger sensing system. See your dealer/retailer for service. If the airbag readiness light in the instrument panel cluster ever comes on and stays on, it means that something may be wrong with the airbag system.
Page 238 The vehicle's hydraulic brake system is divided into two parts. If one part is not working, the other part can still work and stop the vehicle. For good braking both parts need to be working. If the warning light comes on, there is a brake problem. Have the brake system inspected right away.
Page 239 For vehicles with the Antilock Brake System (ABS), this light comes on briefly when the engine is started. If it does not, have the vehicle serviced by your dealer/retailer. If the system is working normally the indicator light then goes off. If the ABS light stays on, turn the ignition off.
Page 240 The TCS warning light comes on briefly when the engine is started. If it does not, have the vehicle serviced by your dealer/retailer. If the Traction Control System (TCS) warning light comes on and stays on, there may be a problem with the TCS.
Page 241 The engine coolant temperature warning light comes on when the engine is very hot. This light also comes on briefly when the vehicle is started. If the light does not go out or comes on and stays on while driving, there may be a problem with the cooling system.
Page 242 For vehicles with a tire pressure monitoring system, this light comes on briefly when the engine is started. It provides information about tire pressures and the Tire Pressure Monitoring System. This indicates that one or more of the tires is significantly underinflated.
Page 243 This comes on briefly while starting the engine. If it does not come on, have the vehicle serviced by your dealer/retailer. If the check engine light comes on and stays on, while the engine is running, this indicates that there is an OBD II problem and service is required.
Page 244 If the light continues to flash, when it is safe to do so, stop the vehicle. Find a safe place to park the vehicle. Turn off the ignition, wait at least 10 seconds, and restart the engine. If the light is still flashing, follow the previous steps and see your dealer/retailer for service as soon as possible.
Page 245 Some state/provincial and local governments have or might begin programs to inspect the emission control equipment on the vehicle. Failure to pass this inspection could prevent getting a vehicle registration. Here are some things to know to help the vehicle pass an inspection: The vehicle will not pass this inspection if the check engine light is on with the engine running.
Page 246 For vehicles with an oil pressure light, if there is a problem with the oil, the light may stay on after the engine is started, or comes on while driving. This light indicates that oil is not going through the engine quickly enough to keep it lubricated.
Page 247 For information regarding this light and the vehicle's security system, see Theft-Deterrent System on page 3 22. The fog lamp light comes on when the fog lamps are in use. The light goes out when the fog lamps are turned off. See Fog Lamps on page 4 33 for more information.
Page 248 This light comes on when the high-beam headlamps are in use. See Headlamp High/Low-Beam Changer on page 4 5 for more information. The fuel gage shows approximately how much fuel is in the fuel tank. It works only when the engine is on.
Page 249 The Driver Information Center (DIC) gives you the status of many of your vehicle's systems. The DIC is also used to display warning/status messages. All messages will appear in the DIC display located at the bottom of the instrument panel cluster, below the tachometer and speedometer.
Page 250 The Driver Information Center (DIC) has different modes which can be accessed by pressing the four DIC buttons located on the instrument panel, to the left of the steering wheel. If your vehicle does not have a Head-Up Display (HUD), these are the buttons for the DIC.
Page 251 If the vehicle has a HUD, these are the buttons for the DIC. Press the top or bottom of this button to scroll through the available vehicle information displays which include digital speed display, if your vehicle has this feature, fuel range, fuel economy, fuel used, average speed, timer, battery voltage, tire pressure, engine oil life, if your vehicle has this feature, and display units.
Page 252 The following display menu items can be displayed by pressing the information button. If the vehicle has this display, it shows the vehicle's speed digitally in either miles per hour (mph) or kilometers per hour (km/h). This display shows the approximate number of remaining miles (mi) or kilometers (km) you can drive without refilling the fuel tank.
Page 253 This display shows the average speed of the vehicle in miles per hour (mph) or kilometers per hour (km/h). This average is calculated based on the various vehicle speeds recorded since the last reset of this display. To reset AVG MPH, press the reset button. The display will return to zero.
Page 254 This display shows the current battery voltage. If the voltage is in the normal range, the value will display. For example, the display may read 13.2 BATTERY VOLTS. If the voltage is low, the display will have LOW after it. If the voltage is high, the display will have HIGH after it.
Page 255 This display allows you to select between English and metric units of measurement if your vehicle has the uplevel DIC. Press the reset button to switch between English and metric units. This display shows no information. The following display menu items can be displayed by pressing the trip Information button.
Page 256 Messages are displayed on the DIC to notify the driver that the status of the vehicle has changed and that some action may be needed by the driver to correct the condition. Multiple messages may appear one after another. The text messages are the same for both the base audio and Navigation systems unless otherwise indicated.
Page 257 This symbol appears with this message. This message displays when a problem with the charging system has been detected. Have your vehicle serviced by your dealer/retailer. This message displays when the system detects that the battery voltage is dropping beyond a reasonable level.
Page 258 This symbol appears with this message. This message displays when the electrical system is charging less than 10 volts or the battery has been drained. If this message appears immediately after starting the engine, it is possible that the generator can still recharge the battery.
Page 259 This message displays when the pressure in one or more of the vehicle's tires needs to be checked. If a tire pressure message appears on the DIC, stop as soon as you can. Have the tire pressures checked and set to those shown on the Tire Loading Information label.
Page 260 This symbol appears with this message. This message displays when the engine coolant temperature is too hot. Stop and allow the vehicle to idle until it cools down. See Engine Coolant Temperature Warning Light on page 4 61. See Overheated Engine Protection Operating Mode on page 6 34 for information on driving to a safe place in an emergency.
Page 261 destination. The performance may be reduced the next time the vehicle is driven. The vehicle may be driven at a reduced speed while this message is on, but acceleration and speed may be reduced. Anytime this message stays on, take the vehicle to your dealer/ retailer for service as soon as possible.
Page 262 This symbol appears with this message. This message displays when the hood is not closed completely. Make sure that the hood is closed completely. See Hood Release on page 6 12. This message displays when the outside temperature is cold enough to create icy road conditions. Adjust your driving accordingly.
Page 263 This message displays if the vehicle does not detect the presence of a keyless access transmitter when you have attempted to start the vehicle or a vehicle door has just closed. The following conditions may cause this message to appear: Driver-added equipment plugged into the accessory power outlet on the center console is causing interference.
Page 264 This message displays when the keyless access transmitter is not detected inside the vehicle while you are trying to turn the ignition off. Your vehicle may be near a strong radio antenna signal causing the keyless access system to be jammed. The vehicle remains in ACCESSORY until OFF or START has been pressed or 10 minutes has expired.
Page 265 This message displays when you need to press down on the brake pedal while pressing the start button on the electronic keyless ignition when trying to start your vehicle. See Starting the Engine on page 3 27 for more information. This message displays when the Adaptive Cruise Control system is not activating due to a temporary condition.
Page 266 This message displays if there is a problem with the airbag system. Have your vehicle serviced by your dealer/retailer immediately. See Airbag Readiness Light on page 4 54 for more information. This message displays when a problem with the panic brake assist system has been detected.
Page 267 system inspected by your dealer/retailer as soon as ® possible. See StabiliTrak System on page 5 6 or ® Enhanced StabiliTrak on page 5 7 for more information. For vehicles with the Active Steering with Enhanced StabiliTrak option, in some cases when the SERVICE STABILITY SYS message is displayed, a larger degree of steering wheel input at low vehicle speeds and a smaller degree of steering wheel input at higher vehicle...
Page 268 This message displays when the suspension system is not operating properly. Have your vehicle serviced by your dealer/retailer. If your All-Wheel Drive (AWD) vehicle has the Active Steering with Enhanced StabiliTrak option and the suspension system needs service, the Enhanced StabiliTrak system may be operating in the Stability Secure Mode and the STABILITY SECURE MODE message will display.
Page 269 If your vehicle has the Side Blind Zone Alert (SBZA) system, this message displays when the SBZA system has been turned off. See Side Blind Zone Alert (SBZA) on page 3 44 and DIC Operation and Displays on page 4 70 for more information. If your vehicle has the Side Blind Zone Alert (SBZA) system, this message displays when the SBZA system is disabled because the sensor is blocked and cannot...
Page 270 If your All-Wheel Drive (AWD) vehicle has the Active Steering with Enhanced StabiliTrak option, this message displays when the stability control system is in the secure mode. Stability Secure Mode is set automatically when certain system faults or vehicle conditions are detected. When the Stability Secure Mode is activated, the stability control system will not respond to driver requests to change the stability mode until the next ignition cycle or until the vehicle condition...
Page 271 with directional control of the vehicle. Adjust your driving accordingly. See StabiliTrak page 5 6 or Enhanced StabiliTrak more information. This message displays any time StabiliTrak is turned back on using the TC (traction control) on/off button. See Traction Control System (TCS) on page 5 9 for more information.
Page 272 This message displays when the Traction Control System (TCS) is actively limiting wheel spin. Slippery road conditions may exist if this message is displayed, so adjust your driving accordingly. The message stays on for a few seconds after the TCS stops limiting wheel spin.
Page 273 Here are more messages that you can receive on your Driver Information Center (DIC). To acknowledge a message and read another message that may have come on at the same time, press the reset button. ACCESSORY ACTIVE See Ignition Positions on page 3 26. KNOWN FOB See Matching Transmitter(s) to Your Vehicle under Keyless Access System Operation on...
Page 274 Determine which radio the vehicle has and read the following pages to become familiar with its features. Taking your eyes off the road for extended periods could cause a crash resulting in injury or death to you or others. Do not give extended attention to entertainment tasks while driving.
Page 275 To adjust the time: 1. Press ,located on the radio, to enter the main menu. 2. Turn until SET CLOCK displays. 3. Press to select SET CLOCK. 4. Turn to adjust the time. 5. Press to update the time and VEHICLE TIME UPDATED displays.
Page 276 The audio system has RDS features that are available for use only on FM stations that broadcast RDS information. With RDS: Stations can be selected based on programming Stations with traffic announcements can be selected Announcements concerning local and national emergencies can be received.
Page 277 To scan preset stations: 1. Press and hold for more than two seconds until a beep sounds and PSCAN displays. The radio goes to the first preset station, plays for five seconds, then goes to the next preset station. 2. Press and release to search for local stations or stations that are further away for a larger selection.
Page 278 Up to 30 stations (six FM1, six FM2, six AM, six XM1 and six XM2), can be programmed on the six numbered pushbuttons. To program preset stations: 1. Tune to a station and select the equalization, DSP, or PTY (program type) setting if desired. 2.
Page 279 To adjust the bass, midrange, and treble: 1. Press to enter the main menu. 2. Turn until BASS-MID-TREBLE displays. 3. Press to enter the tone settings. 4. Press to scroll through the settings. 5. Turn to increase or to decrease the bass, midrange, or treble.
Page 280 To adjust the balance or fade: 1. Press to enter the main menu. 2. Turn until BALANCE FADER displays. 3. Press to enter the settings. 4. Press to scroll to BALANCE or FADER. 5. Turn to adjust the BALANCE to the right or the left speakers and the FADER to the front or the rear speakers.
Page 281 Displays if the current RDS station has a message. The message can display the artist, song title, call in phone numbers, etc. If the entire message does not display, parts of the message appear every three seconds until the message is completed. MSG disappears from the display once the completed message has displayed.
Page 282 PTY lets the radio search for stations with specific types of music. When this feature is turned on, the PTYs display above the pushbuttons in place of the programmed preset stations. Not all stations support PTYs and the radio may not go to all of the stations with that music type when pressing the pushbutton.
Page 283 Displays when the THEFTLOCK system has been activated. Take the vehicle to your dealer/retailer for service. XM is a satellite radio service that is based in the 48 contiguous United States and 10 Canadian provinces. XM Satellite Radio has a wide variety of programming and commercial-free music, coast-to-coast, and in digital-quality sound.
Page 284 Press to listen to the tracks in a random, rather than sequential order. RANDOM displays. Press again to turn off random play. RANDOM disappears from the display. Press to hear a track over again. REPEAT displays. Press again to turn off repeat play. REPEAT disappears from the display.
Page 285 If the radio is on, the lased CD loaded begins to play automatically. CD displays and the number of the CD and the track number displays. Press to go to the previous CD. Press to go to the next CD. Press to go to the previous track.
Page 286 Radios with the MP3 feature are capable of playing an MP3 CD-R disc. For more information on how to play an MP3 CD-R disc, see Using an MP3 on page 4 108 later in this section. The sound quality of the CD player can be reduced because of: The CD R quality.
Page 287 The air is very humid. If so, wait about an hour and try again. The format of the CD might not be compatible. See Using an MP3 on page 4 108 later in this section. A problem may have occurred while burning the CD.
Page 288 The MP3 player will only play CD-R discs. It can read and play a maximum of: 50 folders. 11 folders in depth 50 playlists 10 sessions 255 files All folders, playlists, sessions and files over the maximum are ignored. When recording an MP3 disc, make sure that: Playlists use an .m3u or .wpl extension.
Page 289 CD's that do not have playlists play the tracks in the following order: 1. The first file in the root directory plays. 2. After all files from the root directory have played, files in the folders play. 3. After playing the last file from the last folder, play restarts with the first file in the root directory.
Page 290 Press to go to the first track in the previous folder. Press and hold F1 to reverse quickly within a track. Release to resume playback. REV and the elapsed time of the track displays. Pressing F1 while in folder random mode goes to the previous folder and plays the tracks in that folder in random order.
Page 291 Single tracks or folders can be repeated. To repeat the current track, press and release F4 RPT until RPT TRCK displays. To repeat the tracks in the current folder, press and release F4 RPT until RPT FLDR displays. To turn repeat off, press and release F4 RPT until NORMAL displays.
Page 292 or any others, can be blocked at a customer's request, by calling 1-800-852-XMXM (9696). The encryption code in the receiver is being updated, and no action is required. This process should take no longer than 30 seconds. The system is functioning correctly, but the vehicle is in a location that is blocking the XM signal.
Page 293 If this message does not clear within a short period of time, the receiver could have a fault. Consult with your dealer/retailer. If this message does not clear within a short period of time, the receiver could have a fault. Consult with your dealer/retailer. For vehicles with a navigation radio system, see the separate Navigation System manual.
Page 294 Use the buttons located on the steering wheel to operate the in vehicle Bluetooth system. See Audio Steering Wheel Controls on page 4 134 for more information. Press to answer incoming calls, to confirm system information, and to start speech recognition.
Page 295 5. The system prompts for a name for the phone. Use a name that best describes the phone. This name will be used to indicate which phone is connected. The system then confirms the name provided. 6. The system responds with <Phone name> has been successfully paired after the pairing process is complete.
Page 296 The system can store up to thirty phone numbers as name tags that are shared between the Bluetooth and OnStar systems. The system uses the following commands to store and retrieve phone numbers: Store Digit Store Directory The store command allows a phone number to be stored without entering the digits individually.
Page 297 3. Say the first digit to be stored. The system will repeat back the digit it heard followed by a tone. Continue entering digits until the number to be stored is complete. If an unwanted number is recognized by the system, say Clear at any time to clear the last number.
Page 298 3. Say the name tag to be deleted. The system responds with Would you like to delete, <name tag>? Please say yes or no . If the name tag is correct, say Yes to delete the name tag. The system responds with OK, deleting <name tag>, returning to the main menu.
Page 299 1. Press and hold for two seconds. The system responds with Ready followed by a tone. 2. Say Digit Dial . The system responds with Digit dial using <phone name>, please say the first digit to dial followed by a tone. 3.
Page 300 1. Press and hold for two seconds. The system responds with Ready followed by a tone. 2. After the tone, say Re dial . The system responds with Re dial using <phone name> and dials the last number called from the connected Bluetooth phone.
Page 301 1. Press . The system responds with Ready followed by a tone. 2. Say Mute Call . The system responds with Call muted . 1. Press . The system responds with Ready followed by a tone. 2. After the tone, say Mute Call . The system responds with Resuming call .
Page 302 The in vehicle Bluetooth system can send numbers and numbers stored as name tags during a call. This is used when calling a menu driven phone system. Account numbers can be programmed into the phonebook for retrieval during menu driven calls. 1.
Page 303 ® The Bluetooth word mark and logos are owned by the ® Bluetooth SIG, Inc. and any use of such marks by General Motors is under license. Other trademarks and trade names are those of their respective owners. See Radio Frequency Statement on page 8 18 for FCC information.
Page 304 Selecting Pass-key allows you to edit the pairing passkey used for your vehicle. The system default device name is Cadillac STS and the pass-key is set to 1234 . It is recommended that you change the default pass-key to a number that you can easily remember.
Page 305 Select to scroll up the list one page at a time. Select to scroll down the list one page at a time. Select to return to the setup screen. Select to display a list of all ® Bluetooth phones that have been registered (connected) to the vehicle.
Page 306 This information on this screen depends on the information received from the phone. Some phones may not support this feature. While in this screen, use the different features to dial or to make a call. Press the AUX hard key to get to the BLUETOOTH PHONE screen.
Page 307 This screen button goes to the phone book screen. From this screen names can be ® stored in the Bluetooth system to be used to dial calls from. This address book is independent of the phone s address book and data cannot be transferred from the ®...
Page 308 This screen allows access to your Bluetooth Book where names and phone numbers are stored. Information in this screen must be entered using the New screen button or by copying and adding the number from the last 10 dialed or received options. This phone book is stored on the Bluetooth Phone book entries can not be transferred to the phone address book.
Page 309 4. A nametag to the entry to work with the voice recognition. Up to 20 nametags can be used for phone book entries in use at a time. 5. After entering the information, touch the OK screen button. To delete a phone book entry: 1.
Page 310 This screen shows either the last 10 calls that have been placed or the last 10 calls received by the ® Bluetooth system. The newest calls are at the top of the list. Scrolls up the list one page at a time. Scrolls up the list one entry at a time.
Page 311 To access the main menu: 1. Press CNFG or to enter the main menu. 2. Turn to scroll through the menu items. The main menu consists of the following menu items: BASS - MID - TREBLE BALANCE - FADER EQ EQUALIZER H/A (HOME/AWAY) PRESETS AUTOSTORE PRESETS CAT CATEGORY...
Page 312 This item allows radio stations based on preset categories to be selected. See Activating Program Type (PTY) Stations under Radio(s) on page 4 95 for more information. This item allows the TA feature to be turned on and off. See TA (Traffic Announcement) under Radio(s) on page 4 95 for more information.
Page 313 3. Press to enter the language settings and then turn to scroll through the following available langauges: ENGLISH GERMAN FRENCH SPANISH JAPANESE 4. Press to set the langauge. 5. Press F6 to exit the display. To return to the original display, repeatedly press F6 or wait for the display to time out.
Page 314 The following submenu displays when this item is selected: RECALL EXIT SETTINGS STORE EXIT SETTINGS For more information on the DRIVER EXIT SETTINGS submenu item, see Recalling Exit Settings and Storing Exit Settings under Memory Seat, Mirrors and Steering Wheel on page 3 75. This item allows the four configurable keys located to the left and right of the audio display to be customized.
Page 315 Some audio controls can be adjusted at the steering wheel. Press to go to the next or previous radio station with a strong signal in the selected band while listening to the radio. Press to go to the next or previous track while a CD is playing, Press to select between AM, FM, XM , or CD.
Page 316 Frequency interference and static can occur during normal radio reception if items such as cell phone chargers, vehicle convenience accessories, and external electronic devices are plugged into the accessory power outlet. If there is interference or static, unplug the item from the accessory power outlet. The range for most AM stations is greater than for FM, especially at night.
Page 317 The AM-FM antenna is integrated with the rear window defogger, located in the rear window. Make sure that the inside surface of the rear window is not scratched and that the lines on the glass are not damaged. If the inside surface is damaged, it could interfere with radio reception.
Page 318 4-138...
Page 319 Defensive Driving ....... 5-2 Drunk Driving ........5-2 Control of a Vehicle .
Page 320 Defensive driving means always expect the unexpected. The first step in driving defensively is to wear your safety belt See Safety Belts: They Are for Everyone on page 2 8. Assume that other road users (pedestrians, bicyclists, and other drivers) are going to be careless and make mistakes.
Page 321 Police records show that almost 40 percent of all motor vehicle-related deaths involve alcohol. In most cases, these deaths are the result of someone who was drinking and driving. In recent years, more than 17,000 annual motor vehicle-related deaths have been associated with the use of alcohol, with about 250,000 people injured.
Page 322 See Brake System Warning Light on page 4 58. Braking action involves perception time and reaction time. Deciding to push the brake pedal is perception time. Actually doing it is reaction time. Average reaction time is about three fourths of a second.
Page 323 This vehicle has the Antilock Brake System (ABS), an advanced electronic braking system that helps prevent a braking skid. When the engine is started and the vehicle begins to drive away, ABS checks itself. A momentary motor or clicking noise might be heard while this test is going on, and it might even be noticed that the brake pedal moves a little.
Page 324 ABS allows the driver to steer and brake at the same time. In many emergencies, steering can help more than even the very best braking. This vehicle has a Brake Assist feature designed to assist the driver in stopping or decreasing vehicle speed in emergency driving conditions.
Page 325 StabiliTrak comes on automatically whenever the vehicle is started. To help assist with directional control of the vehicle, always leave the system on. StabiliTrak can be turned off, however, by using the Traction Control System (TCS)/StabiliTrak button. See Traction Control System (TCS) on page 5 9. If cruise control is being used when StabiliTrak activates, it will automatically disengage.
Page 326 To assist with directional control of the vehicle, always leave the system on. Stability control can be turned off however, by using the TC button. See Traction Control System (TCS) on page 5 9. The STABILITY SYS OFF message will be displayed on the DIC. See DIC Warnings and Messages on page 4 76.
Page 327 Enhanced StabiliTrak can be operated in Touring Mode. It can also be turned off. The TC button is used to change stability control modes (Touring or Off) as well as to turn traction control on or off. See Traction Control System (TCS) on page 5 9.
Page 328 The system may be heard or felt while it is working, but this is normal. This warning light comes on if there is a problem with TCS. See Traction Control System (TCS) Warning Light on page 4 60. When this warning light is on, the system will not limit wheel spin.
Page 329 Vehicles with this feature automatically adjust the ride of the vehicle based on driving conditions. Magnetic Ride Control monitors the suspension system to determine the proper system response. If the controller detects a problem within the system, the DIC will display a SERVICE SUSPENSION SYS message.
Page 330 During some operating conditions, the active steering might deactivate to protect the system from damage. You might notice that the center position of the steering wheel is changed. Unless there is a SERVICE STEERING SYS message, the system will return to normal operation as soon as the condition ceases, usually within a very short period of time.
Page 331 Try to adjust the speed so you can drive through the curve. Maintain a reasonable, steady speed. Wait to accelerate until out of the curve, and then accelerate gently into the straightaway. To help you steer in the direction you want to go, during certain sharp or sudden cornering maneuvers, gear selection is controlled.
Page 332 The vehicle's right wheels can drop off the edge of a road onto the shoulder while driving. If the level of the shoulder is only slightly below the pavement, recovery should be fairly easy. Ease off the accelerator and then, if there is nothing in the way, steer so that the vehicle straddles the edge of the pavement.
Page 333 In a skid, a driver can lose control of the vehicle. Defensive drivers avoid most skids by taking reasonable care suited to existing conditions, and by not overdriving those conditions. But skids are always possible. The three types of skids correspond to the vehicle's three control systems.
Page 334 Night driving is more dangerous than day driving because some drivers are likely to be impaired alcohol or drugs, with night vision problems, or by fatigue. Night driving tips include: Drive defensively. Do not drink and drive. Reduce headlamp glare by adjusting the inside rearview mirror.
Page 335 Wet brakes can cause crashes. They might not work as well in a quick stop and could cause pulling to one side. You could lose control of the vehicle. After driving through a large puddle of water or a car/vehicle wash, lightly apply the brake pedal until the brakes work normally.
Page 336 To prepare your vehicle for a long trip, consider having it serviced by your dealer/retailer before departing. Things to check on your own include: Windshield Washer Fluid: Reservoir full? Windows clean inside and outside? Wiper Blades: In good shape? Fuel, Engine Oil, Other Fluids: All levels checked? Lamps: Do they all work and are lenses clean? Tires: Are treads good? Are tires inflated to recommended pressure?
Page 337 Driving on steep hills or through mountains is different than driving on flat or rolling terrain. Tips for driving in these conditions include: Keep the vehicle serviced and in good shape. Check all fluid levels and brakes, tires, cooling system, and transmission. Going down steep or long hills, shift to a lower gear.
Page 338 Drive carefully when there is snow or ice between the tires and the road, creating less traction or grip. Wet ice can occur at about 0°C (32°F) when freezing rain begins to fall, resulting in even less traction. Avoid driving on wet ice or in freezing rain until roads can be treated with salt or sand.
Page 339 Being stuck in snow can be in a serious situation. Stay with the vehicle unless there is help nearby. If possible, use the Roadside Service on page 8 8. To get help and keep everyone in the vehicle safe: Turn on the Hazard Warning Flashers on page 4 3.
Page 340 To save fuel, run the engine for only short periods as needed to warm the vehicle and then shut the engine off and close the window most of the way to save heat. Repeat this until help arrives but only when you feel really uncomfortable from the cold.
Page 341 Turn the steering wheel left and right to clear the area around the front wheels. Turn off any traction or stability system. Shift back and forth between R (Reverse) and a forward gear, spinning the wheels as little as possible. To prevent transmission wear, wait until the wheels stop spinning before shifting gears.
Page 342 A vehicle specific Tire and Loading Information label is attached to the vehicle's center pillar (B-pillar). With the driver's door open, you will find the label attached below the door lock post 5-24 (striker). The Tire and Loading Information label shows the number of occupant seating positions (A), and the maximum vehicle capacity weight (B) in kilograms and pounds.
Page 343 Locate the statement The combined weight of occupants and cargo should never exceed XXX kg or XXX lbs on your vehicle's placard. Determine the combined weight of the driver and passengers that will be riding in your vehicle. Subtract the combined weight of the driver and passengers from XXX kg or XXX lbs.
Page 344 Vehicle Capacity Weight for Example 1 = Subtract Occupant Weight @ 150 lbs (68 kg) × 2 = Available Occupant and Cargo Weight = 5-26 1,000 lbs (453 kg) 300 lbs (136 kg) 700 lbs (317 kg) Vehicle Capacity 1,000 lbs Weight for (453 kg) Example 2 =...
Page 345 Vehicle Capacity Weight for Example 3 = Subtract Occupant Weight @ 200 lbs (91 kg) × 5 = Available Cargo Weight = Refer to your vehicle's Tire and Loading Information label for specific information about your vehicle's capacity weight and seating positions.
Page 346 rear axles, called the Gross Axle Weight Rating (GAWR). Never exceed the GVWR or the GAWR for either the front or rear axle. Do not load the vehicle any heavier than the Gross Vehicle Weight Rating (GVWR), or either the maximum front or rear Gross Axle Weight Rating (GAWR).
Page 347 Consult your dealer/retailer or a professional towing service if the disabled vehicle needs to be towed. See Roadside Service on page 8 8. To tow the vehicle behind another vehicle for recreational purposes (such as behind a motorhome), see Recreational Vehicle Towing following. Recreational vehicle towing means towing the vehicle behind another vehicle such as behind a motorhome.
Page 348 The vehicle was not designed to be towed with all four wheels on the ground. If the vehicle must be towed, use a dolly. See Dolly Towing later in this section for more information. 5-30 Rear wheel drive vehicles can be towed using a dolly. To tow the vehicle using a dolly, follow these steps: 1.
Page 349 3. Firmly set the parking brake. See Parking Brake on page 3 33. 4. Put the transmission in P (Park). 5. Secure the vehicle to the dolly following the manufacturer's instructions. 6. Use an adequate clamping device designed for towing to ensure that the front wheels are locked into the straight position.
Page 350 Trailering is different than just driving the vehicle by itself. Trailering means changes in handling, acceleration, braking, durability and fuel economy. Successful, safe trailering takes correct equipment, and it has to be used properly. The following information has many time-tested, important trailering tips and safety rules.
Page 351 Three important considerations have to do with weight: The weight of the trailer. The weight of the trailer tongue. The total weight on the vehicle's tires. How heavy can a trailer safely be? It should never weigh more than 1,000 lbs (450 kg). But even that can be too heavy.
Page 352 After loading the trailer, weigh the trailer and then the tongue, separately, to see if the weights are proper. If they are not, adjustments might be made by moving some items around in the trailer. Be sure the vehicle's tires are inflated to the upper limit for cold tires.
Page 353 Does the trailer have its own brakes? Be sure to read and follow the instructions for the trailer brakes so they are installed, adjusted and maintained properly. Because the vehicle has StabiliTrak into the vehicle's hydraulic brake system. If you do, both brake systems will not work well, or at all.
Page 354 Hold the bottom of the steering wheel with one hand. Then, to move the trailer to the left, move that hand to the left. To move the trailer to the right, move your hand to the right. Always back up slowly and, if possible, have someone guide you.
Page 355 Reduce speed and shift to a lower gear before starting down a long or steep downgrade. If the transmission is not shifted down, the brakes might have to be used so much that they would get hot and no longer work well. On a long uphill grade, shift down and reduce the vehicle's speed to around 45 mph (70 km/h) to reduce the possibility of the engine and the transmission...
Page 356 1. Apply and hold the brake pedal while you: Start the engine Shift into a gear Release the parking brake 2. Let up on the brake pedal. 3. Drive slowly until the trailer is clear of the chocks. 4. Stop and have someone pick up and store the chocks.
Page 357: Overheated Engine Protection
..........6-4 Accessories and Modifications .
Page 358 Tire Pressure Monitor System ....6-62 Tire Pressure Monitor Operation ....6-64 Tire Inspection and Rotation .
Page 359 ......6-116 Vehicle Identification Number (VIN) ... 6-116 Service Parts Identification Label .
Page 360 For service and parts needs, visit your dealer/retailer. You will receive genuine GM parts and GM-trained and supported service people. Genuine GM parts have one of these marks: When non dealer/non retailer accessories are added to the vehicle, they can affect vehicle performance and safety, including such things as airbags, braking, stability, ride and handling, emissions systems, aerodynamics, durability, and electronic systems like...
Page 361 Most motor vehicles, including this one, contain and/or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. Engine exhaust, many parts and systems, many fluids, and some component wear by-products contain and/or emit these chemicals.
Page 362 Keep a record with all parts receipts and list the mileage and the date of any service work performed. Things added to the outside of the vehicle can affect the airflow around it. This can cause wind noise and can affect fuel economy and windshield washer performance.
Page 363 If the vehicle has the 3.6L V6 engine (VIN Code V), use regular unleaded gasoline with a posted octane rating of 87 or higher. If the octane rating is less than 87, an audible knocking noise, commonly referred to as spark knock, might be heard when driving.
Page 364 To provide cleaner air, all gasolines in the United States are now required to contain additives that help prevent engine and fuel system deposits from forming, allowing the emission control system to work properly. In most cases, nothing should have to be added to the fuel. However, some gasolines contain only the minimum amount of additive required to meet U.S.
Page 365 To check the fuel availability, ask an auto club, or contact a major oil company that does business in the country where you will be driving. Fuel vapor burns violently and a fuel fire can cause bad injuries. To help avoid injuries to you and others, read and follow all the instructions on the fuel pump island.
Page 366 While refueling, hang the tethered fuel cap from the hook on the fuel door. Fuel can spray out on you if you open the fuel cap too quickly. If you spill fuel and then something ignites it, you could be badly burned. This spray can happen if the tank is nearly full, and is more likely in hot weather.
Page 367 If a fire starts while you are refueling, do not remove the nozzle. Shut off the flow of fuel by shutting off the pump or by notifying the station attendant. Leave the area immediately. Never fill a portable fuel container while it is in the vehicle.
Page 368 An electric fan under the hood can start up and injure you even when the engine is not running. Keep hands, clothing, and tools away from any underhood electric fan. Things that burn can get on hot engine parts and start a fire.
Page 369 2. Then go to the front of the vehicle and find the secondary hood release lever. The lever is located under the front edge of the grille near the center. Push the release lever up and raise the hood. Before closing the hood, be sure all the filler caps are on properly.
Page 370 6-14...
Page 371 After you have removed the sight shields (if equipped) on the 3.6L V6 engine, here is what you will see: A. Underhood Fuse Block. See B. Remote Negative (-) Terminal. See C. Remote Positive (+) Terminal. See D. Battery. See E.
Page 372 6-16...
Page 373 After you have removed the sight shields (if equipped) on the 4.6L V8 engine, here is what you will see: A. Remote Negative (-) Terminal. See B. Remote Positive (+) Terminal. See C. Battery. See D. Passenger Compartment Air Filter. See E.
Page 374 It is a good idea to check the engine oil level at each fuel fill. In order to get an accurate reading, the oil must be warm and the vehicle must be on level ground. The engine oil dipstick handle is a yellow loop. See location of the engine oil dipstick.
Page 375 If the oil is below the cross-hatched area at the tip of the dipstick, add at least one quart/liter of the recommended oil. This section explains what kind of oil to use. For engine oil crankcase capacity, see Add enough oil to put the level somewhere in the proper operating range.
Page 376 Look for three things: GM4718M This vehicle's engine requires a special oil meeting GM Standard GM4718M. Oils meeting this standard may be identified as synthetic. However, not all synthetic oils will meet this GM standard. Use only an oil that meets GM Standard GM4718M.
Page 377 Do not add anything to the oil. The recommended oils with the starburst symbol that meet GM standards are all that is needed for good performance and engine protection. Engine oil system flushes are not recommended and could cause engine damage not covered by the vehicle warranty.
Page 378 The Engine Oil Life System calculates when to change the engine oil and filter based on vehicle use. Whenever the oil is changed, reset the system so it can calculate when the next oil change is required. If a situation occurs where the oil is changed prior to a CHANGE ENGINE OIL SOON message in the DIC being turned on, reset the system.
Page 379 The engine air cleaner/filter is in the engine compartment on the driver's side of the vehicle, near the front. See for more information on locating the air cleaner/filter. Inspect the air cleaner/filter at the Maintenance intervals and replace it at the first oil change after each 80 000 km (50,000 mile) interval.
Page 380 To inspect the air cleaner/filter remove the filter from the vehicle and lightly shake the filter to release loose dust and dirt. If the filter remains caked with dirt, a new filter is required. To inspect or replace the filter in the 3.6L V6 or 4.6L V8 engines, do the following: 1.
Page 381 Operating the engine with the air cleaner/filter off can cause you or others to be burned. The air cleaner not only cleans the air; it helps to stop flames if the engine backfires. Use caution when working on the engine and do not drive with the air cleaner/filter off.
Page 382 The cooling system allows the engine to maintain the correct working temperature. A. Electric Engine Cooling Fan(s) (Out of view) B. Mechanical Engine Cooling Fan (If equipped) (Out of view) C. Coolant Surge Tank and Pressure Cap 6-26 An electric engine cooling fan under the hood can start up even when the engine is not running and can cause injury.
Page 383 Heater and radiator hoses, and other engine parts, can be very hot. Do not touch them. If you do, you can be burned. Do not run the engine if there is a leak. If you run the engine, it could lose all coolant. That could cause an engine fire, and you could be burned.
Page 384 Adding only plain water to the cooling system can be dangerous. Plain water, or some other liquid such as alcohol, can boil before the proper coolant mixture will. The vehicle's coolant warning system is set for the proper coolant mixture. With plain water or the wrong mixture, the engine could get too hot but you would not get the overheat warning.
Page 385 The vehicle must be on a level surface when checking the coolant level. The coolant surge tank and pressure cap are located on the driver's side of the vehicle, toward the rear of the engine compartment. See for more information on location.
Page 386 You can be burned if you spill coolant on hot engine parts. Coolant contains ethylene glycol and it will burn if the engine parts are hot enough. Do not spill coolant on a hot engine. Steam and scalding liquids from a hot cooling system can blow out and burn you badly.
Page 387 2. Then keep turning the pressure cap slowly, and 3. Fill the coolant surge tank with the proper ® remove it. DEX-COOL coolant mixture, to slightly above the FULL COLD/FROID line on the side of the coolant surge tank. 6-31...
Page 388 4. With the coolant surge tank pressure cap off, start the engine and let it run until you can feel the upper radiator hose getting hot. The upper radiator hose is the largest of the hoses which comes out of the radiator, on the passenger side of the vehicle.
Page 389 Steam from an overheated engine can burn you badly, even if you just open the hood. Stay away from the engine if you see or hear steam coming from it. Turn it off and get everyone away from the vehicle until it cools down. Wait until there is no sign of steam or coolant before you open the hood.
Page 390 If the engine coolant temperature gage is no longer in the overheat zone or an overheat warning no longer displays, the vehicle can be driven. Continue to drive the vehicle slow for about 10 minutes. Keep a safe vehicle distance from the car in front of you. If the warning does not come back on, continue to drive normally.
Page 391 for reservoir location. It is not necessary to regularly check power steering fluid unless you suspect there is a leak in the system or you hear an unusual noise. A fluid loss in this system could indicate a problem. Have the system inspected and repaired.
Page 392 When you need windshield washer fluid, be sure to read the manufacturer's instructions before use. If you will be operating your vehicle in an area where the temperature may fall below freezing, use a fluid that has sufficient protection against freezing. The CHECK WASHER FLUID message will appear on the Driver Information Center (DIC) when the fluid level is low.
Page 393 The brake master cylinder reservoir is filled with DOT 3 brake fluid. See reservoir location and access. There are only two reasons why the brake fluid level in the reservoir might go down: The brake fluid level goes down because of normal brake lining wear.
Page 394 DOT 3 brake fluid is recommended. DOT 4 brake fluid is also compatible with the vehicle's brake system parts. However, if DOT 4 fluid is used, it is recommended that the brake hydraulic system be flushed and refilled with new DOT 4 fluid at a regular maintenance service every two years.
Page 395 The brake wear warning sound means that soon the brakes will not work well. That could lead to an accident. When the brake wear warning sound is heard, have the vehicle serviced. Some driving conditions or climates can cause a brake squeal when the brakes are first applied or lightly applied.
Page 396 Refer to the replacement number on the original battery label when a new battery is needed. See location. Battery posts, terminals, and related accessories contain lead and lead compounds, chemicals known to the State of California to cause cancer and reproductive harm. Wash hands after handling.
Page 397 1. Check the other vehicle. It must have a 12-volt battery with a negative ground system. 2. Get the vehicles close enough so the jumper cables can reach, but be sure the vehicles are not touching each other. If they are, it could cause a ground connection you do not want.
Page 398 Your vehicle has a remote negative ( ) ground location, as shown in the illustration. It is located on the passenger side front shock tower. See You should always use this remote ground location, instead of the terminal on the battery. 6-42 An electric fan can start up even when the engine is not running and can injure you.
Page 399 Using an open flame near a battery can cause battery gas to explode. People have been hurt doing this, and some have been blinded. Use a flashlight if you need more light. Be sure the battery has enough water. You do not need to add water to the battery installed in your new vehicle.
Page 400 6. Connect the red positive (+) cable to the positive (+) terminal of the dead battery. Use a remote positive (+) terminal if the vehicle has one. 7. Do not let the other end touch metal. Connect it to the positive (+) terminal of the good battery. Use a remote positive (+) terminal if the vehicle has one.
Page 401 A. Heavy, Unpainted Metal Engine Part or Remote Negative ( ) Terminal B. Good Battery or Remote Positive (+) and Remote Negative ( ) Terminals C. Dead Battery or Remote Positive (+) Terminal To disconnect the jumper cables from both vehicles, do the following: 1.
Page 402 A. Drain Plug B. Fill Plug To get an accurate reading, the vehicle should be on a level surface. 6-46 If the level is below the bottom of the filler plug hole, located on the transfer case, you'll need to add some lubricant.
Page 403 To get an accurate reading, the vehicle should be on a level surface. If the level is below the bottom of the filler plug hole, located on the rear axle, you'll need to add some lubricant. Add enough lubricant to raise the level to the bottom of the filler plug hole.
Page 404 A. Drain Plug B. Filler Plug To get an accurate reading, the vehicle should be on a level surface. If the level is below the bottom of the filler plug hole, located on the front axle, you may need to add some lubricant.
Page 405 For the proper type of replacement bulbs, see For any bulb changing procedure not listed in this section, contact your dealer/retailer. The low beam high intensity discharge lighting system operates at a very high voltage. If you try to service any of the system components, you could be seriously injured.
Page 406 To replace a back-up lamp bulb: 1. Open the trunk. See 2. Pull out the push pins holding down the top portion of the cloth cover. 3. Fold the cover down slightly and locate the lamp assembly. 6-50 4. Turn the socket counterclockwise and pull it straight out to remove it from the lamp assembly.
Page 407 Windshield wiper blades should be inspected for wear or cracking. See It's a good idea to clean or replace the wiper blade assembly on a regular basis or when worn. For proper windshield wiper blade length and type, see To replace the wiper blade assembly, do the following: 1.
Page 408 Your new vehicle comes with high-quality tires made by a leading tire manufacturer. If you ever have questions about your tire warranty and where to obtain service, see your vehicle Warranty booklet for details. Poorly maintained and improperly used tires are dangerous. Overloading your tires can cause overheating as a result of too much flexing.
Page 409 If your vehicle has 255/45ZR18 size tires, they are classified as low profile performance tires. These tires are designed for very responsive driving on wet or dry pavement. You may also notice more road noise with low profile performance tires and that they tend to wear faster.
Page 410 Useful information about a tire is molded into its sidewall. The examples below show a typical passenger vehicle tire and a compact spare tire sidewall. 6-54 The tire size is a combination of letters and numbers used to define a particular tire's width, height, aspect ratio, construction type, and service description.
Page 411 The type of cord and number of plies in the sidewall and under the tread. manufacturers are required to grade tires based on three performance factors: treadwear, traction, and temperature resistance. For more information Maximum load that can be carried and the maximum pressure needed to support that load.
Page 412 The type of cord and number of plies in the sidewall and under the tread. The letters and numbers following the DOT (Department of Transportation) code is the Tire Identification Number (TIN). The TIN shows the manufacturer and plant code, tire size, and date the tire was manufactured.
Page 413 The three digit number indicates the tire section width in millimeters from sidewall to sidewall. A two digit number that indicates the tire height to width measurements. For example, if the tire size aspect ratio is 60, as shown in item C of the illustration, it would mean that the tire's sidewall is 60 percent as high as it is wide.
Page 414 The amount of air pressure in a tire, measured in pounds per square inch (psi) or kilopascals (kPa) before a tire has built up heat from driving. See The weight of a motor vehicle with standard and optional equipment including the maximum capacity of fuel, oil, and coolant, but without passengers and cargo.
Page 415 Designated seating positions. asymmetrical tire that has a particular side that faces outward when mounted on a vehicle. The side of the tire that contains a whitewall, bears white lettering, or bears manufacturer, brand, and/or model name molding that is higher or deeper than the same moldings on the other sidewall of the tire.
Page 416 an individual tire due to curb weight, accessory weight, occupant weight, and cargo weight. A label permanently attached to a vehicle showing the vehicle's capacity weight and the original equipment tire size and recommended inflation pressure. See Tire and Loading Information Label under Tires need the correct amount of air pressure to operate effectively.
Page 417 Check your tires once a month or more. Do not forget to check the compact spare tire, if your vehicle has one. The compact spare should be at 60 psi (420 kPa). For additional information regarding the compact spare tire, see Use a good quality pocket-type gage to check tire pressure.
Page 418 Driving at high speeds, 160 km/h (100 mph) or higher, puts an additional strain on tires. Sustained high-speed driving causes excessive heat build up and can cause sudden tire failure. You could have a crash and you or others could be killed.
Page 419 Accordingly, when the low tire pressure telltale illuminates, you should stop and check your tires as soon as possible, and inflate them to the proper pressure. Driving on a significantly under inflated tire causes the tire to overheat and can lead to tire failure. Under inflation also reduces fuel efficiency and tire tread life, and may affect the vehicle's handling and stopping ability.
Page 420 This vehicle may have a Tire Pressure Monitor System (TPMS). The TPMS is designed to warn the driver when a low tire pressure condition exists. TPMS sensors are mounted onto each tire and wheel assembly, excluding the spare tire and wheel assembly, if the vehicle has one.
Page 421 Factory-installed Tire Inflator Kits use a GM approved liquid tire sealant. Using non-approved tire sealants could damage the TPMS sensors. See regarding the inflator kit materials and instructions. The TPMS will not function properly if one or more of the TPMS sensors are missing or inoperable. When the system detects a malfunction, the low tire warning light flashes for about one minute and then stays on for the remainder of the ignition cycle.
Page 422 Each TPMS sensor has a unique identification code. Any time you replace one or more of the TPMS sensors or rotate your vehicle's tires, the identification codes will need to be matched to the new tire/wheel position. The sensors are matched to the tire/wheel positions in the following order: driver side front tire, passenger side front tire, passenger side rear tire, and driver side rear tire using a TPMS diagnostic tool.
Page 423 10. After hearing the confirming single horn chirp for the driver side rear tire, a double horn chirp will sound to signal the tire matching mode is no longer active. Press the push button ignition switch to Acc. 11. Set all four tires to the recommended air pressure level as indicated on the tire and loading information label.
Page 424 When rotating P235/50R17 size tires or 255/45ZR18 size tires, always use the correct rotation pattern shown here. If the vehicle has a compact spare tire, do not include the compact spare tire in the tire rotation. After the tires have been rotated, adjust the front and rear inflation pressures as shown on the Tire and Loading Information label.
Page 425 Various factors, such as maintenance, temperatures, driving speeds, vehicle loading, and road conditions influence when you need new tires. One way to tell when it is time for new tires is to check the treadwear indicators, which will appear when your tires have only 1/16 inch (1.6 mm) or less of tread remaining.
Page 426 GM has developed and matched specific tires for your vehicle. The original equipment tires installed on your vehicle, when it was new, were designed to meet General Motors Tire Performance Criteria Specification (TPC Spec) system rating. If you need replacement tires, GM strongly recommends that you get tires with the same TPC Spec rating.
Page 427 Mixing tires could cause you to lose control while driving. If you mix tires of different sizes (other than those originally installed on your vehicle), brands, or types (radial and bias-belted tires), the vehicle may not handle properly, and you could have a crash.
Page 428 Your vehicle's original equipment tires are listed on the Tire and Loading Information label. information about the Tire and Loading Information label and its location on your vehicle. If you add wheels or tires that are a different size than your original equipment wheels and tires, this may affect the way your vehicle performs, including its braking, ride and handling characteristics, stability, and...
Page 429 Quality grades can be found where applicable on the tire sidewall between tread shoulder and maximum section width. For example: The following information relates to the system developed by the United States National Highway Traffic Safety Administration (NHTSA), which grades tires by treadwear, traction, and temperature performance.
Page 430 The temperature grades are A (the highest), B, and C, representing the tire's resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel. Sustained high temperature can cause the material of the tire to degenerate and reduce tire life, and excessive temperature can lead to sudden tire failure.
Page 431 If you need to replace any of your wheels, wheel bolts, wheel nuts, or Tire Pressure Monitor System (TPMS) sensors, replace them only with new GM original equipment parts. This way, you will be sure to have the right wheel, wheel bolts, wheel nuts, and TPMS sensors for your vehicle.
Page 432 If your vehicle has P255/45R17, P255/45ZR18, or 255/45ZR18 size tires, do not use tire chains, as there is not enough clearance. Tire chains used on a vehicle without the proper amount of clearance can cause damage to the brakes, suspension, or other vehicle parts. The area damaged by the tire chains could cause you to lose control of the vehicle and you or others may be injured in a crash.
Page 433 A rear blowout, particularly on a curve, acts much like a skid and may require the same correction you would use in a skid. In any rear blowout, remove your foot from the accelerator pedal. Get the vehicle under control by steering the way you want the vehicle to go. It may be very bumpy and noisy, but you can still steer.
Page 434 If the vehicle has the tire sealant and compressor kit shown above, see the operating instructions that follow. 6-78 If the vehicle has the tire sealant and compressor kit shown above, follow the operating instructions under Tire Sealant and Compressor Kit (With Selector Switch).
Page 435 Idling a vehicle in an enclosed area with poor ventilation is dangerous. Engine exhaust may enter the vehicle. Engine exhaust contains Carbon Monoxide (CO) which cannot be seen or smelled. It can cause unconsciousness and even death. Never run the engine in an enclosed area that has no fresh air ventilation.
Page 436 Read and follow all of the tire sealant and compressor kit instructions. The kit includes: A. Air Compressor E. Pressure Gage B. Tire Sealant Canister F. Air Only Hose (Black) C. Power Plug G. Sealant/Air Hose (Clear) D. On/Off Button 6-80 Read and follow the safe handling instructions on the label adhered to the sealant canister.
Page 437 When using the tire sealant and compressor kit during cold temperatures, warm the kit in a heated environment for 5 minutes. This will help to inflate the tire faster. Always do a safety check first. See . Do not remove any objects that have penetrated the tire.
Page 438 6. Plug the power plug (C) into the accessory power outlet in the vehicle. Unplug all items from other accessory power outlets. See If the vehicle has an accessory power outlet, do not use the cigarette lighter. If the vehicle only has a cigarette lighter, use the cigarette lighter.
Page 439 11. Unplug the power plug (C) from the accessory power outlet in the vehicle. 12. Turn the sealant/air hose (F) counterclockwise to remove it from the tire valve stem. 13. Replace the tire valve stem cap. 14. Replace the sealant/air hose (F), and the power plug (C) back in their original location.
Page 440 To use the air compressor to inflate a tire with air only and not sealant: 6-84 Always do a safety check first. See 1. Remove the tire sealant and compressor kit from its storage location. See 2. Unlock the air only hose (F) from the sealant canister (B) by pulling up on the lever.
Page 441 8. Plug the power plug (C) into the accessory power outlet in the vehicle. Unplug all items from other accessory power outlets. See If the vehicle has an accessory power outlet, do not use the cigarette lighter. If the vehicle only has a cigarette lighter, use the cigarette lighter.
Page 442 To remove the sealant canister: 1. Unlock the air only hose (F) from the sealant canister (B) by pulling up on the lever. 2. Pull the air only hose (F) from the sealant canister (B). 3. Unwrap the sealant/air hose (F) from the compressor (A).
Page 443 To install a new sealant canister: 1. Align the sealant/air hose (F) with the slot in the air compressor. 2. Push the sealant canister (B) down and turn it clockwise. 3. Wrap the sealant/air hose (F) around the air compressor channel to stow it in its original location.
Page 444 If the vehicle has the tire sealant and compressor kit shown above, follow the operating instructions under Tire Sealant and Compressor Kit (Without Selector Switch). 6-88 Idling a vehicle in an enclosed area with poor ventilation is dangerous. Engine exhaust may enter the vehicle.
Page 445 Storing the tire sealant and compressor kit or other equipment in the passenger compartment of the vehicle could cause injury. In a sudden stop or collision, loose equipment could strike someone. Store the tire sealant and compressor kit in its original location.
Page 446 Read and follow the safe handling instructions on the label adhered to the sealant canister. Check the tire sealant expiration date on the sealant canister. The sealant canister should be replaced before its expiration date. Replacement sealant canisters are available at your local dealer/retailer. See Removal and Installation of the Sealant Canister following.
Page 447 Always do a safety check first. See . Do not remove any objects that have penetrated the tire. 1. Remove the tire sealant and compressor kit from its storage location. See 2. Unwrap the sealant/air hose (F) and the power plug (H).
Page 448 10. Inflate the tire to the recommended inflation pressure using the pressure gage (C). The recommended inflation pressure can be found on the Tire and Loading Information label. The pressure gage (C) may read higher than the actual tire pressure while the compressor is on. Turn the compressor off to get an accurate pressure reading.
Page 449 19. Stop at a safe location and check the tire pressure. Refer to Steps 1 through 11 under Using the Tire Sealant and Compressor Kit without Sealant to Inflate a Tire (Not Punctured). If the tire pressure has fallen more than 10 psi (68 kPa) below the recommended inflation pressure, stop driving the vehicle.
Page 450 3. Place the kit on the ground. 4. Remove the tire valve stem cap from the flat tire by turning it counterclockwise. 5. Attach the air only hose (G) onto the tire valve stem by turning it clockwise until it is tight. 6.
Page 451 14. Replace the air only hose (G) and the power plug (H) and cord back in its original location. 15. Place the equipment in the original storage location in the vehicle. The tire sealant and compressor kit has an accessory adapter located in a compartment on the bottom of its housing that may be used to inflate air mattresses, balls, etc.
Page 452 The tire sealant and compressor kit is located in the trunk. 1. Open the trunk. See 2. Remove the retainer that holds the tire sealant and compressor kit in place. 3. Remove the tire sealant and compressor kit from the foam container. To store the tire sealant and compressor kit, reverse the steps.
Page 453 To be even more certain the vehicle will not move, you should put blocks at the front and rear of the tire farthest away from the one being changed. That would be the tire, on the other side, at the opposite end of the vehicle.
Page 454 The equipment you will need is located in the trunk. To access to the compact spare tire and jacking equipment: 1. Open the trunk. See information. 2. Remove the compact spare tire cover. 6-98 for more 3. Pull the stow rod (A) to remove it. 4.
Page 455 The tools you will be using include the jack (A) and the wheel wrench (B). 1. Do a safety check before proceeding. See information. 2. Loosen all of the wheel nuts, but do not remove them yet, using the wheel wrench. Turn the handle about 180 degrees, then flip the handle back to the starting position.
Page 456 3. Find the vehicle's jacking location using the diagram above and corresponding V shaped notches located in the plastic molding on the vehicle's frame. The notches in the plastic molding are marked with a triangle shape. 4. Attach the wheel wrench to the jack. 6-100 Getting under a vehicle when it is jacked up is dangerous.
Page 457 Lifting a vehicle and getting under it to do maintenance or repairs is dangerous without the appropriate safety equipment and training. If a jack is provided with the vehicle, it is designed only for changing a flat tire. If it is used for anything else, you or others could be badly injured or killed if the vehicle slips off the jack.
Page 458 8. Raise the vehicle by turning the wheel wrench clockwise. Raise the vehicle far enough off the ground for the compact spare tire to fit under the vehicle. 6-102 9. Remove all the wheel nuts and the flat tire. Rust or dirt on a wheel, or on the parts to which it is fastened, can make wheel nuts become loose after time.
Page 459 to the vehicle. In an emergency, use a cloth or a paper towel to do this; but be sure to use a scraper or wire brush later, if needed, to get all the rust or dirt off. See Never use oil or grease on bolts or nuts because the nuts might come loose.
Page 460 Wheel nuts that are improperly or incorrectly tightened can cause the wheels to become loose or come off. The wheel nuts should be tightened with a torque wrench to the proper torque specification after replacing. Follow the torque specification supplied by the aftermarket manufacturer when using accessory locking wheel nuts.
Page 461 15. Tighten the wheel nuts firmly in a crisscross sequence as shown. Storing a jack, a tire, or other equipment in the passenger compartment of the vehicle could cause injury. In a sudden stop or collision, loose equipment could strike someone. Store all these in the proper place.
Page 462 Use the following diagram as a guide for storing the compact spare tire and tools in the trunk: A. Compact Spare Tire E. Jack Container Package Cover (With Wheel Wrench and Jack) B. Stow Rod Cap F. Compact Spare Tire C.
Page 463 Driving with more than one compact spare tire at a time could result in loss of braking and handling. This could lead to a crash and you or others could be injured. Use only one compact spare tire at a time. Although the compact spare tire was fully inflated when the vehicle was new, it can lose air after a time.
Page 464 The vehicle's interior will continue to look its best if it is cleaned often. Although not always visible, dust and dirt can accumulate on the upholstery. Dirt can damage carpet, fabric, leather, and plastic surfaces. Regular vacuuming is recommended to remove particles from the upholstery.
Page 465 Do not clean the vehicle using: A knife or any other sharp object to remove a soil from any interior surface. A stiff brush. It can cause damage to the vehicle's interior surfaces. Heavy pressure or aggressive rubbing with a cleaning cloth.
Page 466 If any of the soil remains, a commercial fabric cleaner or spot lifter may be necessary. When a commercial upholstery cleaner or spot lifter is to be used, test a small hidden area for colorfastness first. If the locally cleaned area gives any impression that a ring formation may result, clean the entire surface.
Page 467 Use a clean cloth moistened in warm, soapy water (use mild dish washing soap). Dry the wood immediately with a clean cloth. Vacuum around a speaker cover gently, so that the speaker will not be damaged. Clean spots with just water and mild soap.
Page 468 Rinse the vehicle well, before washing and after to remove all cleaning agents completely. If they are allowed to dry on the surface, they could stain. Dry the finish with a soft, clean chamois or an all-cotton towel to avoid surface scratches and water spotting. High pressure car washes may cause water to enter the vehicle.
Page 469 If necessary, use non-abrasive cleaners that are marked safe for painted surfaces to remove foreign matter. Exterior painted surfaces are subject to aging, weather and chemical fallout that can take their toll over a period of years. To help keep the paint finish looking new, keep the vehicle garaged or covered whenever possible.
Page 470 The vehicle may have either aluminum or chrome-plated wheels. Keep the wheels clean using a soft clean cloth with mild soap and water. Rinse with clean water. After rinsing thoroughly, dry with a soft clean towel. A wax may then be applied.
Page 471 To clean the tires, use a stiff brush with tire cleaner. If the vehicle is damaged and requires sheet metal repair or replacement, make sure the body repair shop applies anti-corrosion material to parts repaired or replaced to restore corrosion protection. Original manufacturer replacement parts will provide the corrosion protection while maintaining the vehicle warranty.
Page 472 This legal identifier is in the front corner of the instrument panel, on the driver side. It can be seen through the windshield from outside. The VIN also appears on the Vehicle Certification and Service Parts labels and certificates of title and registration.
Page 473 The vehicle has an airbag system. Before attempting to add anything electrical to the vehicle, see The headlamp wiring is protected by fuses in the fuse block. An electrical overload will cause the lamps to turn off. If this happens, have the headlamp wiring checked right away.
Page 474 6-118...
Page 475 The underhood fuse block is located in the front of the engine compartment on the passenger side of the vehicle. See for more information on location and removal procedure for the front compartment underhood sights shields. To access the fuses, push in the tabs located on each side of the fuse block cover, then lift the cover off.
Page 476 Easy Key Module (EKM), Instrument EKM/I/P MDL Panel Module (I/P MDL) Even Ignition Coils, Even Fuel EVEN COILS Injectors FOG LAMP Front Fog Lamps FRT PWR Front Accessory Power Outlet OUTLET FUEL COOL Fuel Cooling HORN Horn Heated Headlamp Washer, Air WASH/AQS Quality Sensor Heads-Up Display, Steering Column...
Page 477 Instrument Panel Module-Voltage V/CHK Check Wipe/Wash Module Assembly WPR SW/VICS Rain Sensor, Wiper Switch A/C CMPRSR Air Conditioning Compressor Clutch CLTCH Accessory, Rain Sensor, Headlamp ACCY Washer Relay Coil, Windshield Wiper/Washer Module Brake Vacuum Pump VAC PUMP FAN S/P Cooling Fan Series/Parallel FOG LAMP Fog Lamps FRT BLWR...
Page 478 To remove the rear seat cushion, do the following: 1. Pull up on the front of the cushion to release the front hooks. 2. Pull the cushion up and out toward the front of the vehicle. 6-122 To reinstall the rear seat cushion, do the following:...
Page 479 A safety belt that is not properly routed through the seat cushion or is twisted will not provide the protection needed in a crash. If the safety belt has not been routed through the seat cushion at all, it will not be there to work for the next passenger. The person sitting in that position could be badly injured.
Page 480 The vehicle may not have all the fuses listed below. 6-124...
Page 481 Amplifier SPARE Spare Theft Sensors, Auto Shifter, Power THEFT/SHFT Sounder Magnetic Ride Control Module MRTD MDL (Option) REAR DR MDL Rear Door Modules Electronic Level Control, Exhaust ELC EXH Solenoid (Option) Driver Door Module, Front Door SubWoofers (Option) Infotainment (Export Only), TV/VICS/SCM Supervisory Control Module (Option) REAR HTD/...
Page 482 SPARE Spare Electronic Level Control, ELC CMPRSR Compressor (Option) Left Rear Taillamp, Position Lamps LT POS (Option) Right Rear Taillamp, Position Lamps RT POS (Option) Ignition 3 Rear Taillamps, Position Lamps STDBY LAMP (Option) TRUNK RELSE Trunk Release Motor Reverse Lamps, Rear Parking Aid, BCK/UP LAMP Inside Rearview Mirror 6-126...
Page 483 6-127...
Page 484 Sensing and Diagnostic Monitor, Automatic Occupant Sensor, AIRBAG/IGN Passenger Supplemental Inflatable Restraint CNSTR/VENT Canister Vent Solenoid SPARE Spare Front Passenger Door Module, Right FRT PDM Power Subwoofer FUEL PUMP Fuel Pump HTD STR Heated Steering Wheel RF HTD/ Front Passenger Heated Seat, SEAT/XM S-Band Antenna...
Page 485 SPARE Spare FUEL PUMP Fuel Pump INT LAMP Interior Lamps REAR DEFOG Rear Defogger REAR/FOG Rear Fog Lamps (Option) RUN/CRNK Ignition 1 SPARE Spare STOP LAMP Stop Lamp WINDOW Power Window Motors Circuit MTRS Breaker TRUNK DIODE Trunk Release Splice Pack (Blue) 6-129...
Page 486 The following approximate capacities are given in English and metric conversions. See for more information. Air Conditioning Refrigerant R134a Brake Fluid Capacities Cooling System 3.6L V6 Engine 4.6L V8 Engine Engine Oil with Filter 3.6L V6 Engines 4.6L V8 Engine Fuel Tank 6-130 For the air conditioning system refrigerant charge...
Page 487 Transmission Fluid (Pan Removal and Filter Replacement) 6-Speed Automatic Wheel Nut Torque All capacities are approximate. When adding, be sure to fill to the approximate level as recommended in this manual. Recheck the fluid level after filling. 3.6L SIDI V6 Engine 4.6L DOHC V8 Engine 6.3 L Automatic...
Page 488 6-132...
Page 523: Appearance Care
Accessories and Modifications ..... . .6-4 Accessory Power ........3-26 Accessory Power Outlets .
Page 524: Automatic Transmission
Audio System ........4-94 Audio Steering Wheel Controls .
Page 525: Child Restraints
Carbon Monoxide Engine Exhaust ........3-36 Trunk .
Page 526: Drive Systems
Convenience Net ........3-56 Coolant Engine ..........6-27 Engine Temperature Gage .
Page 527: Electrical System
EDR ..........8-17 Electrical Equipment, Add-On .
Page 528: Fuel Economy
Fuel ..........6-6 Additives .
Page 529: Instrument Panel
Heater Engine Coolant ........3-29 High-Speed Operation, Tires ..... . 6-62 Highbeam On Light .
Page 530: Lockout Protection
Lights (cont.) Engine Coolant Temperature Warning ... . 4-61 Flash-to-Pass ........4-9 Fog Lamps .
Page 531: New Vehicle Break-In
Navigation System, Privacy ......8-18 Navigation/Radio System, see Navigation Manual ......... . 4-113 Net, Convenience .
Page 532: Rearview Mirrors
Phone ..........4-123 ®...
Page 533: Running The Vehicle While Parked
Replacement Parts Maintenance ........7-11 Reporting Safety Defects Canadian Government .
Page 534: Sun Visors
Service ..........6-4 Accessories and Modifications .
Page 535 Tires ..........6-52 Aluminum or Chrome-Plated Wheels, Cleaning .
Page 536: Vehicle Identification
Valet Lockout Switch ......3-24 Vehicle Control ..........5-3 Loading .
