Endress+Hauser Gammapilot FMG50 Operating Instructions Manual
  1. Manuals
  2. Brands
  3. Endress+Hauser Manuals
  4. Measuring Instruments
  5. Gammapilot FMG50
  6. Operating instructions manual

Endress+Hauser Gammapilot FMG50 Operating Instructions Manual

Radiometric measurement
Hide thumbs Also See for Gammapilot FMG50:
Table of Contents

Advertisement

Quick Links

BA01966F/00/EN/03.21
71536311
2021-08-16
Products
Operating Instructions
Gammapilot FMG50
Radiometric measurement
Solutions
Services

Advertisement

Table of Contents
loading

Related Manuals for Endress+Hauser Gammapilot FMG50

Summary of Contents for Endress+Hauser Gammapilot FMG50

  • Page 1 Products Solutions Services BA01966F/00/EN/03.21 71536311 2021-08-16 Operating Instructions Gammapilot FMG50 Radiometric measurement...

  • Page 2: Cascade Mode With More Than

    Gammapilot FMG50 Order code: XXXXX-XXXXXX Ser. no.: XXXXXXXXXXXX Ext. ord. cd.: XXX.XXXX.XX Serial number www.endress.com/deviceviewer Endress+Hauser Operations App A0023555 Endress+Hauser...
  • Page 3 Contents of these Operating Instructions These Operating Instructions describe how to install and commission the radiometric compact transmitter Gammapilot FMG50. All of the functions that are necessary for standard measuring tasks are included. In addition, the Gammapilot FMG50 provides many additional functions for optimizing the measuring point and for converting the measured value.

  • Page 5: Table Of Contents

    Gammapilot FMG50 Table of contents Table of contents 4.2.5 Installation conditions for density About this document ....8 measurement ....24 Document function .
  • Page 6 Battery disposal ....94 Overview of the operating menu ... 82 Contact addresses at Endress+Hauser ..95 Diagnostics and troubleshooting . . . 83 Accessories .
  • Page 7 11.2.12 Memograph M, RSG45 ..104 11.2.13 Collimator (sensor side) for Gammapilot FMG50 ... . 104 Certificates and approvals ..105 12.1 Functional safety .

  • Page 8: About This Document

    About this document Gammapilot FMG50 About this document Document function These Operating Instructions provide all of the information that is required in various phases of the life cycle of the device including: • Product identification • Incoming acceptance • Storage •...

  • Page 9: Documentation

    For an overview of the scope of the associated Technical Documentation, refer to the following: • W@M Device Viewer (www.endress.com/deviceviewer): Enter the serial number from nameplate • Endress+Hauser Operations App: Enter the serial number from the nameplate or scan the 2D matrix code (QR code) on the nameplate 1.3.1 Technical Information (TI)

  • Page 10: Safety Instructions (Xa)

    Android, Google Play and the Google Play logo are trademarks of Google Inc. Bluetooth® The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Endress+Hauser is under license. Other trademarks and trade names are those of their respective owners. Endress+Hauser...

  • Page 11: Basic Safety Instructions

    The Gammapilot FMG50 is a compact transmitter for non-contact level, point level, density and concentration measurement. The detector is up to 3 m (9.84 ft) in length. The Gammapilot FMG50 is certified according to IEC 61508 for safety-related operation up to SIL 2/3.

  • Page 12: Hazardous Area

    Radiation protection The Gammapilot FMG50 is used in conjunction with a radioactive source, contained in a source container. The Gammapilot FMG50 does not emit any radioactive radiation. When handling radioactive sources, the following instructions must be observed: 2.5.1...

  • Page 13: Workplace Safety

    Gammapilot FMG50 Basic safety instructions Shielding Ensure the best possible shielding between the radiation source and yourself and all other persons. Effective shielding is provided by source containers (FQG60, FQG61/ FQG62,FQG63, FQG66) and all high-density materials (lead, iron, concrete etc.).

  • Page 14: Ce Mark

    The measuring system meets the legal requirements of the applicable EU Directives. These are listed in the corresponding EU Declaration of Conformity along with the standards applied. Endress+Hauser confirms successful testing of the device by affixing to it the CE mark. 2.8.2 EAC conformity The measuring system meets the legal requirements of the applicable EAC guidelines.

  • Page 15: Product Description

    Gammapilot FMG50 Product description Product description Product design 3.1.1 Components of the FMG50 A0037983  1 A: Gammapilot FMG50 Housing Potential equalization terminal Locking screw Detector pipe Measuring range marking Endress+Hauser...

  • Page 16: Nameplates

    ), reference to documentation Date of manufacture: year-month and 2-D matrix code (QR code) Scope of delivery • Ordered version of the device (including Brief Operating Instructions) • Endress+Hauser operating program on DVD (optional) • Accessories as ordered Accompanying documentation 3.4.1...

  • Page 17: Description Of Device Functions

    Product description 3.4.2 Description of Device Functions The Description of Device Functions document contains a detailed description of all the functions of the Gammapilot FMG50 and applies for all communication versions. Available for download at "www.de.endress.com". GP01141F 3.4.3 Safety instructions Additional safety instructions (XA, ZE, ZD) are supplied with certified device versions.

  • Page 18: Mounting

    ‣ Enter the serial number from the nameplate into the Endress+Hauser Operations App or use the Endress+Hauser Operations App to scan the 2-D matrix code (QR Code) provided on the nameplate  All the information about the measuring device and the scope of the associated Technical Documentation are displayed.

  • Page 19: Installation Conditions

    Gammapilot FMG50. Observe the measuring range marks of the device. • The source container and the Gammapilot FMG50 should be mounted as close to the vessel as possible. Any access to the beam must be blocked to ensure that it is not possible to reach into this area.

  • Page 20: Dimensions, Weights

    Mounting Gammapilot FMG50 3. Tighten the locking screw with 0.7 Nm  0.7 Nm A0042093 Depending on the application, the cable gland may have to point downwards. The cable gland and dummy plug can be swapped for this purpose. Tighten the cable gland with maximum 3.75 Nm.
  • Page 21 Gammapilot FMG50 Mounting • Version PVT 400 : • Total length A: 790 mm (31.10 in) • Total weight: 13.26 kg (29.23 lb) • Measuring range length B: 400 mm (16 in) • Distance C: 41 mm (1.61 in) • Version PVT 800 : •...

  • Page 22: Installation Conditions For Level Measurement

    Installation conditions for level measurement Conditions • The Gammapilot FMG50 is mounted vertically for level measurements. • To facilitate installation and commissioning, the Gammapilot FMG50 can be configured and ordered with an additional support (order feature 620, option Q4: "Retaining bracket").

  • Page 23: Installation Conditions For Point Level Detection

    Mounting Examples A0037715 Vertical cylinder; the Gammapilot FMG50 is mounted vertically with the detector head pointing either downwards or upwards, the gamma radiation is aligned to the measuring range. Correct: Gammapilot FMG50 mounted outside the tank insulation Incorrect: Gammapilot FMG50 mounted inside the tank insulation...

  • Page 24: Installation Conditions For Density Measurement

    • If only horizontal pipes are accessible, the path of the beam should also be arranged horizontally to minimize the influence of air bubbles and deposits. • The Endress+Hauser clamping device or an equivalent clamping device should be used to fasten the source container and the Gammapilot FMG50 to the measuring pipe.

  • Page 25: Installation Conditions For Interface Measurement

    When a radiation source is used in an immersion tube, the radiation can be aligned with the measuring range of the Gammapilot FMG50 using a collimator on the immersion tube. Measuring system arrangement...

  • Page 26: Installation Conditions For Concentration Measurement

    • The Endress+Hauser FHG51 clamping device or an equivalent clamping device should be used to fasten the source container and the Gammapilot FMG50 to the measuring pipe. The clamping device itself must be installed in such a way as to withstand the weight of the source container and the Gammapilot FMG50 under all anticipated operating conditions.

  • Page 27: Installation Conditions For Concentration Measurement With Radiating Media

    Installation conditions for flow measurement Measurement of mass flow (liquids) The density signal determined by the Gammapilot FMG50 is transmitted to the Promag 55S. The Promag 55S measures the volume flow; the Promag can determine a mass flow in connection with the calculated density value.

  • Page 28: Post-Installation Check

    Measurement of mass flow (solids) Bulk solids applications on conveyor belts and conveyor screws. The source container is positioned above the conveyor belt and the Gammapilot FMG50 below the conveyor belt. The radiation is attenuated by the medium on the conveyor belt.

  • Page 29: Electrical Connection

    Gammapilot FMG50 Electrical connection Electrical connection Connection compartment A0038877 Connection compartment 4 to 20 mA HART connection Connection of the device with HART communication, power source and 4 to 20 mA display A0028908  4 Block diagram of HART connection...

  • Page 30: Terminal Assignment

    Electrical connection Gammapilot FMG50 Terminal assignment A0038895  5 Connection terminals and ground terminal in the connection compartment Internal ground terminal (to ground the cable shield) Negative terminal Positive terminal • Non-Ex: supply voltage: 14 to 35 VDC • Ex-i: supply voltage: 14 to 30 VDC...

  • Page 31: Overvoltage Protection (Optional)

    Gammapilot FMG50 Electrical connection A0038024 Ground terminal for connecting the potential matching line CAUTION ‣ Please refer to the separate documentation on applications in hazardous areas for the safety instructions For optimum electromagnetic compatibility, the potential matching line should be as short as possible and at least 2.5 mm...

  • Page 32: Connection Of Devices With Harting Plug Han7D

    Electrical connection Gammapilot FMG50 5.8.2 Connection of devices with Harting plug Han7D – + – Han7D – A0019990 Electrical connection for devices with Harting plug Han7D View of the plug-in connection on the device Material: CuZn, contacts for plug-in jack and connector are gold-plated...

  • Page 33: Fmg50 With Ria15

    Alternatively available as an accessory, for details see Technical Information TI01043K and Operating Instructions BA01170K CAUTION ‣ Pay attention to the Safety Instructions (XAs) when using the Gammapilot FMG50 with the remote indicator RIA15 in hazardous environments: • XA01028R • XA01464K •...

  • Page 34: Connection Of The Hart Device And Ria15 With Backlighting

    Electrical connection Gammapilot FMG50 5.9.2 Connection of the HART device and RIA15 with backlighting A0019568  7 Block diagram of HART device with RIA15 process indicator with light Device with HART communication Power supply HART resistor 5.9.3 FMG50, RIA15 with installed HART communication resistor...

  • Page 35: Wiring

    Gammapilot FMG50 Electrical connection Connection of the HART communication resistor module, RIA15 with backlighting A0020840  9 Block diagram of HART device, RIA15 with light, HART communication resistor module HART communication resistor module Device with HART communication Power supply 5.10...

  • Page 36: Wiring Examples

    Electrical connection Gammapilot FMG50 5.11 Wiring examples 5.11.1 Point level measurement The output signal is linear between free and covered adjustment (e.g. 4 to 20 mA) and can be evaluated in the control system. If a relay output is needed, the following Endress +Hauser process transmitters can be used: •...
  • Page 37 Gammapilot FMG50 Electrical connection A0040224  10 Connection diagram: for two FMG50 units connected to one RMA42 RMA42 Sample settings for cascade mode ‣ FMG50 settings:  All FMG50 units used in cascade must be adjusted individually. For example via the "Commissioning"...

  • Page 38: Fmg50 Units

    Electrical connection Gammapilot FMG50 For more information, see: BA00287R 5.11.3 Cascade mode with more than 2 FMG50 units Level measurement: FMG50 with Memograph M RSG45 Conditions requiring several FMG50 units: • Large measuring ranges • Special tank geometry More than two FMG50 units (maximum 20) can be interconnected and powered via one Memograph M RSG45.
  • Page 39 Gammapilot FMG50 Electrical connection 2. Configure the HART variable PV (Primary Value) as "Level"  PV (level) is not relevant for the calculation 3. Configure the HART variable SV (Secondary Value) as "Pulse rate"  SV (pulse rate) is relevant for the calculation 4.

  • Page 40: Sil Applications For Gammapilot In Connection With Rma42

    Gammapilot FMG50 5.11.5 SIL applications for Gammapilot in connection with RMA42 The Gammapilot FMG50 meets the requirements of SIL2/3 as per IEC 61508, see: FY01007F The RMA42 meets SIL2 as per IEC 61508:2010 (Edition 2.0), see the Functional Safety Manual: SD00025R 5.12...

  • Page 41: Operation

    Transmitter 6.1.2 Operation via FieldCare/DeviceCare FieldCare/DeviceCare is an Endress+Hauser asset management tool based on FDT technology. With FieldCare/DeviceCare you can configure all Endress+Hauser devices as well as devices from other manufacturers that support the FDT standard. Hardware and software requirements can be found on the Internet: www.de.endress.com ->...

  • Page 42: Alternative Operation Options

    DIP switch for locking and unlocking the measuring device 6.2.2 Operation via the service interface DeviceCare/FieldCare via service interface (CDI) A0038834  13 DeviceCare/FieldCare via service interface (CDI) Computer with DeviceCare/FieldCare operating tool Commubox FXA291 Service interface (CDI) of the measuring device (= Endress+Hauser Common Data Interface) Endress+Hauser...

  • Page 43: Operation Via Ria15

    Gammapilot FMG50 Operation 6.2.3 Operation via RIA15 A0017719  14 Display and operating elements of the process indicator Symbol: operating menu disabled Symbol: error Symbol: warning Symbol: HART communication active Operating keys 14-segment display for unit/TAG Bar graph with indicators for under range and over range 5-digit 7-segment display for measured value, digit height 17 mm (0.67 in)

  • Page 44: Heartbeat Verification/Monitoring

    Operation Gammapilot FMG50 A0039243  15 Display with Bluetooth module A flashing Bluetooth symbol indicates that a Bluetooth connection is available Bluetooth communication with the device is possible with a supply voltage of 14 V or higher. The background lighting of the display is only guaranteed with a supply voltage ≥...

  • Page 45: Locking/Unlocking Configuration

    Gammapilot FMG50 Operation Locking/unlocking configuration 6.3.1 Software locking Locking via password in FieldCare / DeviceCare / SmartBlue App Access to the configuration of the FMG50 can be locked by assigning a password. The "User role" is set to "Maintainer" in the as-delivered state. The device can be fully configured in the "Maintainer"...
  • Page 46 Operation Gammapilot FMG50 The following types of reset can be selected: • Restart device A soft reset is performed here. The device software performs all the diagnostics that would also be performed by a hard reset by switching the device on/off.

  • Page 47: Commissioning

    A Wizard is available in FieldCare, DeviceCare and the SmartBlue App to guide you through the initial commissioning process. FieldCare and DeviceCare are available for download. You need to register in the Endress+Hauser software portal to download the application. https://www.software-products.endress.com SmartBlue enables operation via Bluetooth.

  • Page 48: Device Identification

    7.2.2 Device identification The user guidance starts with the general configuration of the tag name and some HART parameter settings. A0042162 A0042163 7.2.3 Measurement settings After this, the general "measurement settings" of the Gammapilot FMG50 can then be made: Endress+Hauser...
  • Page 49 Gammapilot FMG50 Commissioning A0042164 The first settings page of the "measurement settings" is displayed for all operating modes. The following configuration options are available: • General settings • Configuration of the reference time • Selection of the isotope used (depends on the operating mode) •...
  • Page 50 If a gamma modulator FHG65 is used for interference radiation suppression, "modulated" must be selected for the beam type. If the Gammapilot FMG50 is used without the gamma modulator FHG65, the default option "not modulated" is left as is.

  • Page 51: Calibration

    Commissioning WARNING ‣ If the incorrect beam type or isotope is selected, the Gammapilot FMG50 will output an incorrect measured value. This would be a dangerous undetected failure. It is not permitted to change the setting in the operating menu.
  • Page 52 Commissioning Gammapilot FMG50 The correlation between the current output and the calibration values is always linear in the point level operating mode. In this sense, this operating mode is the same as the Level operating mode with the "linear" type of linearization.
  • Page 53 5. The settings for the current output are then made in the "Output settings" step Level calibration Depends on the operating mode selected. For a level measurement, the Gammapilot FMG50 requires at least two other calibration points in addition to the background calibration: • Empty calibration •...
  • Page 54 Commissioning Gammapilot FMG50 L (%) 100% 1000 A0040241  18 Example of a linearization curve for level measurements (consisting of 6 value pairs) Level Normalized pulse rate The type of linearization has already been selected in the "Measurement settings" section The behavior of the "linear"...
  • Page 55 Gammapilot FMG50 Commissioning 2. Empty calibration level: the radiation is switched on and the beam path is completely free.  If these conditions are met, empty calibration can be started. A0042169 The empty calibration can be performed by pressing the "Start empty calibration"...
  • Page 56 Commissioning Gammapilot FMG50 4. If a customized table has been selected for the linearization, the following input screen appears:  A0042174 The procedure varies depending on the type of table that is selected. • For the "Normalized pulse rate" table type, see the description for "Normalized pulse rate"...
  • Page 57 The linearization table is not used as long as "Disable" is selected. The linearization table can also be entered manually in the linearization module. This is started by selecting the "Linearization" button: The Endress+Hauser Applicator is available online at www.endress.com Endress+Hauser...
  • Page 58 Commissioning Gammapilot FMG50 A0042194 The normalized pulse rate and the customer value can be entered directly in table form in this module. The linearization table must be activated by selecting "Activate table" -> "Enable" Semi-automatic A0042195 During semi-automatic linearization, the device measures the pulse rate for every linearization point.
  • Page 59 Gammapilot FMG50 Commissioning Edit table: the index of the linearization point is entered in this field (1-32 points) Customer input value: measured pulse rate for the linearization point Customer value: level in unit of length, volume unit or %. Activate table: the "Enable" option must first be selected before the linearization table is used.
  • Page 60 A0042200 Pulse rate ρ Density Once the calibration points have been entered, the Gammapilot FMG50 calculates the reference pulse rate I and the absorption coefficient µ parameters on its own. One-point calibration A one-point calibration can be performed if a multi-point calibration is not possible. This means that apart from the background calibration only one additional calibration point is used.
  • Page 61 Gammapilot FMG50 Commissioning The type of calibration has already been selected in the "Measurement settings" section The Gammapilot FMG50 does not have a Wizard for recalibration. Nevertheless, a recalibration can be performed easily. See "Density recalibration for multi-point calibration" Beam path length The length of the beam path in the medium to be measured is specified here.
  • Page 62 Commissioning Gammapilot FMG50 2. With this calibration point, the density of the product is entered in the "Density value of calibration point" field.  This establishes the reference between the determined pulse rate and the density of the product. TIP: it is recommended to take a sample of the medium during the integration and determine its density subsequently (e.g.
  • Page 63 CAUTION: in the "Density" operating mode, it is essential to assign the lower limit value (4 mA) and the upper limit value (20 mA) of the current output to the density. The following message is displayed following a successful calibration: The Endress+Hauser Applicator is available online at www.endress.com Endress+Hauser...
  • Page 64 Maximum pulse rate ρ Maximum density, water Once the calibration points have been entered, the Gammapilot FMG50 calculates the interface layer in % on its own. Here, 0% corresponds to the minimum density and 100% to the maximum density. The settings for the current output are then made in the "Output settings" step Beam path length The length of the beam path in the medium to be measured is specified here.
  • Page 65 Gammapilot FMG50 Commissioning If the beam passes through the pipe at an angle of 90°, this value corresponds to the internal pipe diameter. If the beam passes through the pipe at an angle of 30° in order to increase the sensitivity of the measurement, the length of the beam path corresponds to twice the internal pipe diameter.
  • Page 66 Commissioning Gammapilot FMG50 The settings for the current output are then made in the "Output settings" step Concentration In concentration measurements, linearization defines the correlation between the measured density and the concentration. The concentration measurement is therefore a density measurement with subsequent linearization.
  • Page 67 Gammapilot FMG50 Commissioning 2. Perform linearization  A0042219 The individual linearization values are entered via the input screen or via a separate linearization module. The linearization table consists of up to 32 "density value : concentration (%)" value pairs. 3. The table values can be sorted as monotonically decreasing using the "Table mode ->...
  • Page 68 6. The settings for the current output are then made in the "Output settings" step Concentration of radiating media For concentration measurement in radiating media (e.g.: K40), the Gammapilot FMG50 requires at least two other calibration points in addition to the background calibration: •...
  • Page 69 Gammapilot FMG50 Commissioning 2. Selection: start with a high concentration of the radiating medium or start with a low concentration of the radiating medium  Start calibration -> the calibration can be stopped once the pulse rate has stabilized. A0042222 3.
  • Page 70 Commissioning Gammapilot FMG50 The procedure varies depending on the type of table that is selected. • For the "Normalized pulse rate" type of table • For the "Semi-automatic" type of table Normalized pulse rate A0042183 2431 1000 1935 1283 Normalized pulse rate Note that the normalized pulse rate is entered in the linearization table.
  • Page 71 Gammapilot FMG50 Commissioning Linearization table conditions • The table can consist of up to 32 "concentration - linearized value" pairs. • The table must decrease monotonically • The first value in the table must correspond to the minimum concentration • The last value in the table must correspond to the maximum concentration The table values can be sorted as monotonically increasing using the "Table mode ->...
  • Page 72 Commissioning Gammapilot FMG50 Semi-automatic A0042195 During semi-automatic linearization, the device measures the concentration for every table point. The associated linearized value is entered manually. The individual linearization values are entered via the input screen. The linearization table consists of up to 32 "measured pulse rate : concentration"...
  • Page 73 Gammapilot FMG50 Commissioning Please note the following if using the linearization module with linearization tables recorded semi-automatically: The module assumes pulse rates are normalized and automatically switches the internal measurement calculation to normalized values if the module is used. This falsifies the assignment between the output value and the measured value.

  • Page 74: Slave Mode

    The slave mode can be used if the measured raw pulse rate is to be processed by a downstream evaluation unit (e.g. a controller) and not by the Gammapilot FMG50. In this operating mode, the Gammapilot FMG50 transmits the raw pulse rate in cnt/ 125 ms as the primary value.

  • Page 75: Commissioning Via Smartblue App

    Gammapilot FMG50 Commissioning Commissioning via SmartBlue App 7.3.1 Requirements Device requirements Commissioning via SmartBlue is only possible if the device has a Bluetooth module. SmartBlue system requirements SmartBlue is available as a download from the Google Play Store for Android devices and from the iTunes Store for iOS devices.

  • Page 76: Level Basic Calibration

    Commissioning Gammapilot FMG50 Zero/I Alarm Span/II Display A0039285 Operating key for empty calibration (function I) Operating key for full calibration (function II) DIP switch for alarm current (SW-defined / Min alarm) DIP switch for locking and unlocking the measuring device •...

  • Page 77: Commissioning Of Density Compensation With Rsg45 (Gamma Computer)

    Gammapilot FMG50 Commissioning Commissioning of density compensation with RSG45 (gamma computer) Level measurement: FMG50 with Memograph M RSG45 and gas density information. In the vessel containing the medium to be measured, the gas phase is above the medium. The gas phase also absorbs gamma radiation in the process, albeit to a much lesser degree than the medium.
  • Page 78 Commissioning Gammapilot FMG50 Configuring RSG45 Setting or deleting the limit values 1. Navigate to limit values: "Setup -> Extended setup -> Application -> Limit values"  2. Enter the limit values • FMG50 (density measurement), channel 1 • Cnts_density_min: Pulse rate (pulses per second, cnt/s) of the FMG50 (density) at atmospheric conditions (environment) •...

  • Page 79: Scenario 2: Density Compensation Via Fmg50 Gas Density Measurement

    Gammapilot FMG50 Commissioning 2. Enter value pairs in the linearization table. A value pair consists of a percentage value and the associated pulse rate (pulses per second, cnt/s).  The linearized measured value is shown as a percentage. The linearization table consists of up to 32 value pairs.
  • Page 80 Commissioning Gammapilot FMG50 Configuring RSG45 Setting or deleting the limit values 1. Navigate to limit values: "Setup -> Extended setup -> Application -> Limit values"  2. Enter the limit values • FMG50 (density measurement), channel 1 • Cnts_density_min: pulse rate (pulses per second, cnt/s) of the FMG50 (density) at atmospheric conditions (environment) •...
  • Page 81 Gammapilot FMG50 Commissioning 2. Enter value pairs in the linearization table. A value pair consists of a percentage value and the associated pulse rate (pulses per second, cnt/s).  The linearized measured value is shown as a percentage. The linearization table consists of up to 32 value pairs.

  • Page 82: Operation And Settings Via Ria15

    7.7.2 Hardware locking The Gammapilot FMG50 can be locked and unlocked via a switch on the main unit. Hardware locking can only be unlocked via the main unit (flip the switch). It is not possible to unlock the hardware by communication.

  • Page 83: Diagnostics And Troubleshooting

    Gammapilot FMG50 Diagnostics and troubleshooting Diagnostics and troubleshooting System error messages 8.1.1 Error signal Errors occurring during commissioning or operation are signaled in the following way: • Error symbol, display color, error code and error description on the display and operating module.

  • Page 84: Error - Smartblue Operation

    Diagnostics and troubleshooting Gammapilot FMG50 Fault Possible causes Solution Pulse rate too high with empty Activity too high Attenuate radiation, e.g. by mounting vessel a steel plate in front of the source container; or replace radiation source External radiation sources present Shield off if possible;...

  • Page 85: Diagnostic Event

    Gammapilot FMG50 Diagnostics and troubleshooting Diagnostic event 8.4.1 Diagnostic event in the operating tool If a diagnostic event is present in the device, the status signal appears in the top left status area of the operating tool along with the corresponding symbol for the event level in accordance with NAMUR NE 107: •...
  • Page 86 Diagnostics and troubleshooting Gammapilot FMG50 Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Memory content 1. Restart device Warning inconsistent 2. Contact service Electronic failure Maintenance required! Warning 1. Do not perform reset 2.

  • Page 87: Displaying The Diagnostic Events

    Gammapilot FMG50 Diagnostics and troubleshooting Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Gammagraphy detected Gammagraphy detected Warning Evaluation plateau curve Evaluation plateau curve Warning Diagnostic behavior can be changed. 8.4.3 Displaying the diagnostic events Actual diagnostics The menu contains the "Actual diagnostics"...

  • Page 88: Reaction To Detected Gammagraphy Radiation

    Diagnostics and troubleshooting Gammapilot FMG50 A0040223  24 Influence of gammagraphy on radiometric measurements Interference radiation 8.6.2 Reaction to detected gammagraphy radiation If the gammagraphy criterion "gammagraphy limit" is met, the device output adopts a value defined by the user (Gammagraphy detection parameter). Furthermore, a warning is also signaled.

  • Page 89: Gammagraphy Settings

    Gammapilot FMG50 Diagnostics and troubleshooting 8.6.4 Gammagraphy settings Gammagraphy detection can be configured under: Application -> Sensor -> Gammagraphy detection 8.6.5 Gammagraphy detection parameter Gammagraphy detection can be switched on and off with this parameter. In addition, the event class can be defined according to NE107 Gammagraphy detection ->...

  • Page 90: Gammagraphy Limit Parameter

    Diagnostics and troubleshooting Gammapilot FMG50 8.6.7 Gammagraphy limit parameter Gammagraphy radiation is detected if the pulse rate at the detector exceeds the maximum gammagraphy limit value. This value is determined using the maximum pulse rate from the calibration (generally "upper range value") and the configured gammagraphy sensitivity.

  • Page 91: Real-Time Clock And Decay Compensation

    Real-time clock and decay compensation 8.8.1 General principles For decay compensation, the Gammapilot FMG50 contains a real-time clock, which is generally powered by the terminal voltage. This clock is backed up by a battery to bridge voltage interruptions. The battery must have a sufficient remaining capacity to ensure the clock works correctly and continues to keep the correct date if power is interrupted.

  • Page 92: Behavior In The Event Of Low Terminal Voltage

    Diagnostics and troubleshooting Gammapilot FMG50 WARNING ‣ If the incorrect time is set, this falsifies the result of the decay compensation. This could result in a dangerous failure that cannot be diagnosed in the device. Behavior in the event of low terminal voltage 8.9.1...

  • Page 93: Maintenance And Repair

    Repair 9.2.1 Repair concept Under the Endress+Hauser repair concept, devices have a modular design and repairs can be carried out by Endress+Hauser Service or by properly trained customers. Spare parts are grouped into logical kits with the associated replacement instructions.

  • Page 94: Historom

    The parameters are saved in the HistoROM. After replacing the transmitter electronics, remove the HistoROM and insert it into the new replacement part. Please contact the Endress+Hauser Service Department if the HistoROM is lost or defective. Spare parts Enter the serial number into W@M Device Viewer (www.endress.com/deviceviewer).

  • Page 95: Contact Addresses At Endress+Hauser

    Gammapilot FMG50 Maintenance and repair Contact addresses at Endress+Hauser Contact addresses are available at www.endress.com/worldwide or from your local Endress +Hauser branch office. Endress+Hauser...

  • Page 96: Accessories

    Accessories Gammapilot FMG50 Accessories 10.1 Commubox FXA195 HART For intrinsically safe HART communication with FieldCare/DeviceCare via the USB interface. For details refer to TI00404F 10.2 Field Xpert SFX350, SFX370, SMT70 Compact, flexible and robust industrial handheld terminal for remote operation and measured value interrogation of HART devices.

  • Page 97: Mounting Device

    Gammapilot FMG50 Accessories 10.3 Mounting device (for level and point level measurement) 10.3.1 Mounting the retaining bracket Reference dimension A is used to define the mounting location of the retaining bracket depending on the measuring range. A0040283  26 A defines the distance between the device flange and the start of the measuring range. Distance A depends on the material of the scintillator (PVT or Nal).
  • Page 98 Accessories Gammapilot FMG50 Dimensions of mounting clamps 6 Nm A0042084  28 Dimensions of mounting clamp Distance A • For electronics pipe: 210 mm (8.27 in) • For detector pipe: 198 mm (7.8 in) CAUTION Max. torque for the screws of the retainers: ‣...
  • Page 99 Gammapilot FMG50 Accessories Dimensions of pole mount 106 (4.17) 56 (2.2) 88 (3.46) A0040266  30 øA: 40 to 65 mm (1.57 to 2.56 in) Dimensions of retaining bracket 88 (3.46) 30 (1.18) 175 (6.89) 135 (5.31) 153 (6.02) A0040030 ...

  • Page 100: Use

    (see Figure C). Do not use the enclosed mounting clamps for a horizontal pipe. The fixing bracket supplied can be used for FMG50. ‣ To prevent damage to the detector pipe of the Gammapilot FMG50, the maximum torque that can be applied to tighten the retainer screws is 6 Nm (4.42 lbf ft). 10.4 Clamping device for density measurement FHG51 10.4.1...

  • Page 101: Fhg51-A#1

    Gammapilot FMG50 Accessories 10.4.2 FHG51-A#1PA For pipes with diameter 50 to 200 mm (2 to 8 in) with protective guard. SD02533F 10.4.3 FHG51-B#1 For pipes with diameter 200 to 420 mm (8 to 16.5 in). SD02544F 10.4.4 FHG51-B#1PB For pipes with diameter 200 to 420 mm (8 to 16.5 in) with protective guard.

  • Page 102: Hart Communication Resistor

    Accessories Gammapilot FMG50 10.5.1 HART communication resistor 54 (2.13) 31 (1.22) A0020858  33 Dimensions of HART communication resistor, engineering unit: mm (in) A communication resistor is required for HART communication. If this is not already present (e.g. in the power supply RMA42, RN221N, RNS221, ...), it can be ordered with the device via the product structure, feature 620 "Accessory enclosed": option R6...

  • Page 103: Technical Data

    SD02533F (clamping device for density measurement with protective guard) SD02534F (clamping device for density measurement with protective guard) SD02543F (clamping device for density measurement) SD02544F (clamping device for density measurement) 11.2.7 Mounting device for Gammapilot FMG50 SD02454F 11.2.8 Heat shield for Gammapilot FMG50 SD02472F...

  • Page 104: Weather Protection Cover For Dual-Compartment Housing

    Technical data Gammapilot FMG50 11.2.9 Weather protection cover for dual-compartment housing SD02424F 11.2.10 VU101 Bluetooth® display SD02402F 11.2.11 Process indicator RIA15 TI01043K 11.2.12 Memograph M, RSG45 TI01180R 11.2.13 Collimator (sensor side) for Gammapilot FMG50 Under development Endress+Hauser...

  • Page 105: Certificates And Approvals

    Gammapilot FMG50 Certificates and approvals Certificates and approvals The availability of approvals and certificates can be called up daily via the Product Configurator. 12.1 Functional safety SIL 2/3 according to IEC 61508, see: "Functional Safety Manual" FY01007F 12.2 Heartbeat Monitoring + Verification...

  • Page 106: Ce Mark

    Certificates and approvals Gammapilot FMG50 12.6 CE mark The measuring system meets the legal requirements of the EU Directives. Endress+Hauser confirms that the device has been successfully tested by applying the CE mark. 12.7 Approval for EAC 12.8 Overfill prevention...
  • Page 108 *71536311* 71536311 www.addresses.endress.com...
