- Page 1 Products Solutions Services BA00231P/00/EN/13.13 71118684 Operating Instructions Waterpilot FMX167 Hydrostatic level measurement...
-
Page 2: Table Of Contents
Troubleshooting ....17 Troubleshooting specific to Waterpilot FMX167 with optional Pt100 ..... . . 17 Troubleshooting specific to TMT181 temperature head transmitter . -
Page 3: About This Document
Waterpilot FMX167 About this document About this document Symbols 1.1.1 Safety symbols Symbol Meaning DANGER! DANGER This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in seriousor fatal injury. A0011189-DE WARNING! WARNING This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in seriousor fatal injury. -
Page 4: Registered Trademarks
About this document Waterpilot FMX167 1.1.4 Symbols in graphics Symbol Meaning 1, 2, 3, 4, ... Item numbers A, B, C, D, ... Views Hazardous area Indicates a hazardous area. A0011187 Safe area (non-hazardous area) Indicates a non-hazardous location. A0011188 1.1.5... -
Page 5: Basic Safety Instructions
Basic safety instructions Designated use The Waterpilot FMX167 is a hydrostatic pressure sensor for measuring the level of fresh water, wastewater and salt water. The temperature is measured simultaneously in the case of sensor versions with a Pt100 resistance thermometer. An optional temperature head transmitter converts the Pt100 signal to a 4 to 20 mA signal. -
Page 6: Incoming Acceptance And Product
Incoming acceptance and product identification Waterpilot FMX167 Incoming acceptance and product identification Incoming acceptance • Check the packaging and the contents for damage. • Check the shipment, make sure nothing is missing and that the scope of supply matches your order. -
Page 7: Transport And Storage
The devices comply with the applicable standards and regulations as listed in the EC Declaration of Conformity and thus comply with the legal requirements of the EC Directives. Endress+Hauser confirms the conformity of the device by affixing to it the CE mark. -
Page 8: Mounting
Mounting Waterpilot FMX167 Mounting Mounting requirements OPEN 90° CLOSE 90° Made in Germany, D-79689 Maulburg Waterpilot FMX167 Order Code: Ser.-No.: Messbereich/range: TAG: Vmax: Mat: Dat./Insp.: A0018678 Installation examples, here illustrated with FMX167 with an outer diameter of 22 mm (0.87 in) -
Page 9: Mounting The Waterpilot With A Mounting Clamp
• If the cable is shortened, the filter at the pressure compensation tube has to be reattached. Endress+Hauser offers a cable shortening kit for this purpose, see the documentation SD00552P/00/A6. • Endress+Hauser recommends using twisted, shielded cables for any further wiring. -
Page 10: Mounting With An Extension Cable Mounting
Mounting Waterpilot FMX167 Mounting with an extension cable mounting screw A0018794 Illustrated with thread G 1½". Dimensions in mm (in) Extension cable Cover mounting screw Sealing ring Clamping sleeves Mounting screw adapter Top edge of clamping sleeve Required length of extension cable and probe before assembly After assembly, item 7 is located next to the mounting screw with G 1½"... -
Page 11: Mounting The Terminal Box
Waterpilot FMX167 Mounting Mounting the terminal box The optional ° is mounted with four screws (M4). For the dimensions of the terminal box, please refer to Technical Information TI00351P/00/EN for the Waterpilot, "Mechanical construction" section (see also: www.endress.com Select Country Download ... -
Page 12: Post-Mounting Check
Mounting Waterpilot FMX167 >7 (0.28) mm (in) A0018798 A distance of > 7 mm (> 0.28 in) must be maintained between the terminal strip and the TMT181 temperature head transmitter. Post-mounting check Check that all screws are firmly seated. Endress+Hauser... -
Page 13: Electrical Connection
RD BK FMX167 FMX167 A0018670 A Waterpilot FMX167, versions "7" or "3" for Feature 70 "Additional options" in the order code B Waterpilot FMX167 with Pt100 , versions "1" or "4" for feature 70 "Additional options" in the order code 1 Not for FMX167 with outer diameter 29 mm (1.14 in) - Page 14 The extension cables are shielded for versions with outer diameters of 22 mm (0.87 in) or 42 mm (1.65 in). In the following cases, Endress+Hauser recommends the use of a shielded cable as the cable extension: • For large distances between the end of the extension cable and the display and/or evaluation unit.
- Page 15 Waterpilot FMX167 Electrical connection 5.1.3 Power consumption, current consumption FMX167 FMX167 + Pt100 TMT181 temperature head transmitter Power consumption 0.675 W at 30 V DC 0.675 W at 30 V DC 0.875 W at 35 V DC Max. 22.5 mA Max.
-
Page 16: Measuring Unit Electrical Connection
2 Connection for integrated Pt100 temperature sensor in the FMX167 3 4 to 20 mA (Temperature) 4 4 to 20 mA (Level) 5 Overvoltage protection (OP), e.g. HAW from Endress+Hauser (not for use in hazardous areas) 6 Power supply Post-connection check The following checks must be performed after completing electrical connection of the device: •... -
Page 17: Operability
Endress+Hauser offers comprehensive measuring point solutions with display and/or evaluation units for the Waterpilot and TMT181 temperature head transmitter. Please contact your Endress+Hauser sales representative, if you have any other questions. Contact addresses can be found on the Internet: www.endress.com/ worldwide. -
Page 18: Maintenance
The measuring device must be returned if repairs or a factory calibration are required, or if the wrong measuring device has been ordered or delivered. According to legal regulations, Endress+Hauser, as an ISO-certified company, is required to follow certain procedures when handling returned products that are in contact with medium. To ensure swift, safe and professional device returns, please read the return procedures and conditions on the Endress+Hauser website at: www.services.endress.com/return-material... -
Page 19: Accessories
Waterpilot see also Technical Information TI00351P/00/EN, "Ordering information" section. 10.1 Mounting clamp • Endress+Hauser offers a mounting clamp for easy Waterpilot mounting ( ä 9). • Material: 316L (1.4404 ) and fiberglass reinforced PA (polyamide) • Order number: 52006151 10.2 Terminal box ®... -
Page 20: Tmt181 Temperature Head Transmitter
• Order number: 52008794 10.5 Extension cable mounting screw • Endress+Hauser offers extension cable mounting screws to ease FMX167 mounting and to seal the measuring aperture ( ä 10). • Material: 304 (1.4301) • Order number for extension cable mounting screw: –... -
Page 21: Cable Shortening Kit
The cable shortening kit is not designed for devices with FM/CSA approval. 10.9 Testing adapter for Waterpilot with an outer diameter of 22 mm (0.87 in) and 29 mm (1.14 in) Endress+Hauser offers a testing adapter to ease function-testing of the level probes. ~25 (0.98) M14x1 mm (in) -
Page 22: Index
Mounting the TMT181 temperature head transmitter 11 Nameplate for Waterpilot FMX167 ....6 Overvoltage protection ......16 Post-connection check . - Page 23 Waterpilot FMX167 Endress+Hauser...
- Page 24 71118684 www.addresses.endress.com...
