11-26
Maintenance and service
rectly in place.
8. Start and run the engine for more than
five minutes at 2,000 to 3,000 rpm.
9. Stop the engine and wait until the cool-
ant cools down [50 to 60°C (122 to
140°F)]. If there is any loss of coolant, add
coolant to the radiator's filler neck and to
the reserve tank's "FULL" level.
10.Put the radiator cap and reservoir cap
back on and tighten firmly.
Air cleaner element
The air cleaner element functions as a fil-
ter screen. When the element is perforat-
ed or removed, engine wear will be exces-
sive and engine life shortened.
The air cleaner element is a dry type. It is
unnecessary to clean or wash the ele-
ment.
Do not operate the engine with the
air cleaner element removed. The air
cleaner element not only filters in-
take air but also stops flames if the
engine backfires. If the air cleaner
element is not installed when the en-
gine backfires, you could be burned.
Replacing the air cleaner ele-
ment
Non-turbo models
3
1
1) Connector (if equipped)
2) Duct
3) Clamp
1. Unplug the connector (if equipped) that
is attached to the top of the air cleaner
case.
2. Remove the hose that is located at the
bottom of the side surface of the air clean-
er case.
3. Undo the screw and pull the air duct
out of the air cleaner case.
4. Unsnap the two clamps holding the air
cleaner case cover.
0
2
B00426
