Touchpanel Media Centers
2 Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17 Tilt Series
Crestron Isys i/O
TPMC-15 & TPMC-17 Series Functional Summary
24 Bit non-palette graphics
Fast graphics performance: imported photographs, drawings, and icons
Two scalable video windows (up to full screen), enable the
simultaneous display of any two full-motion video or RGB computer
images (RGB on QM versions only)
Two balanced video inputs can receive component, composite, and
S-video inputs; supports NTSC/PAL formats from any Crestron CAT5
balanced video source (CH versions only)
Two QM inputs can receive audio, microphone, NTSC/PAL composite
video, S-video, component video and non-interlaced RGB computer
signals over Crescat-QM (or equivalent) cable (QM versions only)
Built-in time-base correction for stable video & graphics
Balanced input for audio that can be connected to a Crestron
CNX-BIPAD8 or any Crestron CAT5 balanced audio source (CH
versions only)
Balanced output for microphone audio that can be connected to a
Crestron CNX-BIPAD8 or any Crestron CAT5 balanced audio device
(CH versions only)
QM output at native touchpanel resolution act as transmitter for
connection to a QM receiver or switcher (QM versions only)
Built-in microphone & two speakers (half duplex intercom capable)
Built-in mixer mixes PC audio with selected audio input to speakers
Stereo headphone jack
Auto compensation automatically recalls microphone EQ settings,
source compensation settings and peak and boost preset values of
multiple QM origination points when acting as an endpoint (QM
versions only)
Stores and transmits audio parameters for recall by a QM receiver when
acting as a QM origination point (QM versions only)
Two USB ports for connecting with USB peripherals
One RS-232 port for project upload, firmware upgrade, and diagnostics
Two PCMCIA card slots for further expansion including installation of
wireless network card
One 10BaseT/100BaseT Ethernet port
Up to 4,000 digital and 4,000 analog signals; up to 4000 serial signals
Support for downloadable fonts – proportional* and non-proportional
Foreign language text
Display can be tilted between 45 and 90 degrees for optimum viewing
* Proportional fonts: the width of each character differs with the character shape, for example, the letter M
is wider than the letter I. All characters in non-proportional fonts are spaced equally.
QM versions feature two QM inputs that can receive audio, microphone, NTSC/PAL
composite video, S-video, component video (including interlaced and progressive
scan HDTV), and non-interlaced RGB computer signals from any of Crestron's
MediaManager line of FlipTop Boxes, Wall Plates, or Distribution Centers. The QM
versions also have a QM output for connection to a QM receiver or switcher.
CH versions feature two balanced video inputs for receiving component, S-video,
and NTSC/PAL composite sources, including HDTV signals from a Crestron
CNX-PVID device (or similar Crestron CAT5 video source) and one balanced audio
input for receiving audio signals from a Crestron CNX-BIPAD8 (or similar Crestron
™
