Endress+Hauser LPGmass Modbus RS485 Operating Instructions Manual
Coriolis flowmeter
Hide thumbs
Also See for LPGmass Modbus RS485:
- Operating instructions manual (140 pages) ,
- Operating instructions manual (80 pages) ,
- Operating instructions manual (84 pages)
Related Manuals for Endress+Hauser LPGmass Modbus RS485
Summary of Contents for Endress+Hauser LPGmass Modbus RS485
- Page 1 BA01316D/06/EN/01.16 Products Solutions Services 71311937 Valid as of version 01.03.zz (Device firmware) Operating Instructions LPGmass Modbus RS485 Coriolis flowmeter...
- Page 2 • The manufacturer reserves the right to modify technical data without prior notice. Your Endress+Hauser Sales Center will supply you with current information and updates to these instructions. Endress+Hauser...
-
Page 3: Table Of Contents
Mounting position ....18 10.2 Establishing a connection via FieldCare ..40 10.3 Setting the operating language ... . 40 Endress+Hauser... - Page 4 10.5.1 Calculated values ....48 13.3 Endress+Hauser services ....70 10.5.2 Carrying out a sensor adjustment .
-
Page 5: Document Information
LPGmass Modbus RS485 Document information Document information Document function These Operating Instructions contain all the information that is required in various phases of the life cycle of the device: from product identification, incoming acceptance and storage, to mounting, connection, operation and commissioning through to troubleshooting, maintenance and disposal. -
Page 6: Symbols For Certain Types Of Information
• The W@M Device Viewer : Enter the serial number from the nameplate (www.endress.com/deviceviewer) • The Endress+Hauser Operations App: Enter the serial number from the nameplate or scan the 2-D matrix code (QR code) on the nameplate. For a detailed list of the individual documents along with the documentation code →... -
Page 7: Standard Documentation
LPGmass Modbus RS485 Document information 1.3.1 Standard documentation Document type Purpose and content of the document Technical Information Planning aid for your device The document contains all the technical data on the device and provides an overview of the accessories and other products that can be ordered for the device. -
Page 8: Basic Safety Instructions
Keep within the specified pressure and temperature range. Verification for borderline cases: ‣ For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of fluid-wetted materials, but does not accept any Endress+Hauser... -
Page 9: Workplace Safety
It meets general safety standards and legal requirements. It also complies with the EU directives listed in the device-specific EU Declaration of Conformity. Endress+Hauser confirms this by affixing the CE mark to the device. - Page 10 Basic safety instructions LPGmass Modbus RS485 IT security measures in line with operators' security standards and designed to provide additional protection for the device and device data transfer must be implemented by the operators themselves. Endress+Hauser...
-
Page 11: Product Description
LPGmass Modbus RS485 Product description Product description The device consists of a transmitter and a sensor. If a device is ordered with Modbus RS485 intrinsically safe, the Safety Barrier Promass 100 is part of the scope of supply and must be implemented to operate the device. -
Page 12: Incoming Acceptance And Product
A0029318 • If one of the conditions is not satisfied, contact your Endress+Hauser Sales Center. • Depending on the device version, the CD-ROM might not be part of the delivery! The Technical Documentation is available via the Internet or via the Endress+Hauser Operations App, see the "Product identification"... -
Page 13: Product Identification
• Enter the serial number from the nameplates into the Endress+Hauser Operations App or scan the 2-D matrix code (QR code) on the nameplate with the Endress+Hauser Operations App: all the information for the measuring device is displayed. For an overview of the scope of the associated Technical Documentation, refer to the following: •... -
Page 14: Sensor Nameplate
Incoming acceptance and product identification LPGmass Modbus RS485 4.2.2 Sensor nameplate 3 4 5 6 Order code: Ser. no.: Ext. ord. cd.: Size: Ptest = Material: 0044 Patents Date: 322541-0000 13 14 A0013907 3 Example of a sensor nameplate... -
Page 15: Promass 100 Safety Barrier - Nameplate
LPGmass Modbus RS485 Incoming acceptance and product identification 4.2.3 Promass 100 safety barrier - nameplate Safe area NON intrinsically safe circuit (grey terminals) Promass 100 Safety Barrier Intrinsically safe circuits (blue terminals) HAZARDOUS area A0017854 4 Example of a Safety Barrier Promass 100 nameplate Non-hazardous area or zone 2/div. -
Page 16: Storage And Transport
Storage and transport LPGmass Modbus RS485 Storage and transport Storage conditions Observe the following notes for storage: • Store in the original packaging to ensure protection from shock. • Do not remove protective covers or protective caps installed on process connections. -
Page 17: Measuring Devices With Lifting Lugs
LPGmass Modbus RS485 Storage and transport 5.2.2 Measuring devices with lifting lugs CAUTION Special transportation instructions for devices with lifting lugs ‣ Only use the lifting lugs fitted on the device or flanges to transport the device. ‣ The device must always be secured at two lifting lugs at least. -
Page 18: Installation
Installation LPGmass Modbus RS485 Installation Installation conditions No special measures such as supports are necessary. External forces are absorbed by the construction of the device. 6.1.1 Mounting position Mounting location A0028772 To prevent measuring errors arising from accumulation of gas bubbles in the measuring tube, avoid the following mounting locations in the pipe: •... -
Page 19: Requirements From Environment And Process
LPGmass Modbus RS485 Installation If a sensor is installed horizontally with a curved measuring tube, match the position of the sensor to the fluid properties. A0028774 5 Orientation of sensor with curved measuring tube Avoid this orientation for fluids with entrained solids: Risk of solids accumulating. -
Page 20: Special Mounting Instructions
Installation LPGmass Modbus RS485 For this reason, the following mounting locations are recommended: • At the lowest point in a vertical pipe • Downstream from pumps (no danger of vacuum) A0028777 Vibrations The high oscillation frequency of the measuring tubes ensures that the correct operation of the measuring system is not influenced by plant vibrations. -
Page 21: Post-Installation Check
LPGmass Modbus RS485 Installation 2. Install the measuring device or turn the transmitter housing so that the cable entries do not point upwards. A0029263 Post-installation check Is the device undamaged (visual inspection)? Does the measuring device conform to the measuring point specifications? For example: •... -
Page 22: Electrical Connection
Electrical connection LPGmass Modbus RS485 Electrical connection NOTICE The measuring device does not have an internal circuit breaker. ‣ For this reason, assign the measuring device a switch or power-circuit breaker so that the power supply line can be easily disconnected from the mains. - Page 23 LPGmass Modbus RS485 Electrical connection Connecting cable between Safety Barrier Promass 100 and measuring device Cable type Shielded twisted-pair cable with 2x2 wires. When grounding the cable shield, observe the grounding concept of the plant. Maximum cable resistance 2.5 Ω, one side Comply with the maximum cable resistance specifications to ensure the operational reliability of the measuring device.
-
Page 24: Terminal Assignment
Electrical connection LPGmass Modbus RS485 7.1.3 Terminal assignment Transmitter Modbus RS485 connection version For use in the intrinsically safe area. Connection via Safety Barrier Promass 100. Order code for "Output", option M Connection methods available Order code for Possible options for order code Power "Housing"... -
Page 25: Preparing The Measuring Device
LPGmass Modbus RS485 Electrical connection Safety Barrier Promass 100 Power Modbus supply RS485 Safe area Power Lift panel for bus termination Communication Safety Barrier Promass 100 Hazardous area Power Modbus supply RS485 A0030220 7 Safety Barrier Promass 100 with terminals Non-hazardous area and Zone 2/Div. -
Page 26: Connecting The Transmitter
Electrical connection LPGmass Modbus RS485 7.2.1 Connecting the transmitter A0030221 8 Housing versions and connection versions Housing version: compact, aluminum coated Cable entry for signal transmission Cable entry for supply voltage 3 mm 10 (0.4) A0030223 9 Device versions with connection example. Engineering unit mm (in) Cable 1. -
Page 27: Connecting The Safety Barrier Promass 100
LPGmass Modbus RS485 Electrical connection 7. Enable the terminating resistor if applicable → 28. WARNING Housing degree of protection may be voided due to insufficient sealing of the housing. ‣ Screw in the screw without using any lubricant. The threads on the cover are coated with a dry lubricant. -
Page 28: Special Connection Instructions
Electrical connection LPGmass Modbus RS485 Special connection instructions 7.3.1 Connection examples Modbus RS485 Modbus RS485 intrinsically safe L- L+ A0028766 11 Connection example for Modbus RS485 intrinsically safe Control system (e.g. PLC) Cable shield, observe cable specifications Safety Barrier Promass 100... -
Page 29: Ensuring The Degree Of Protection
LPGmass Modbus RS485 Electrical connection If the transmitter is used in the intrinsically safe area 220 Ω A0030217 12 Terminating resistor can be enabled via DIP switch in the Safety Barrier Promass 100 Ensuring the degree of protection The measuring device fulfills all the requirements for the IP66/67 degree of protection, Type 4X enclosure. - Page 30 Electrical connection LPGmass Modbus RS485 • Does the supply voltage match the specifications on the transmitter nameplate → 76? • For device version with Modbus RS485 intrinsically safe: does the supply voltage match the specifications on the nameplate of the Safety Barrier Promass 100 → 76? Is the terminal assignment →...
-
Page 31: Operation Options
LPGmass Modbus RS485 Operation options Operation options Overview of operating options A0017760 Computer with "FieldCare" or "DeviceCare" operating tool via Commubox FXA291 and service interface Control system (e.g. PLC) Endress+Hauser... -
Page 32: Structure And Function Of The Operating Menu
Operation options LPGmass Modbus RS485 Structure and function of the operating menu 8.2.1 Structure of the operating menu For an overview of the operating menu for experts: "Description of Device Parameters" document supplied with the device→ 85 Operating menu for operators and maintenances... -
Page 33: Operating Philosophy
LPGmass Modbus RS485 Operation options 8.2.2 Operating philosophy The individual parts of the operating menu are assigned to certain user roles (operator, maintenance etc.). Each user role contains typical tasks within the device lifecycle. Menu/parameter User role and tasks Content/meaning... -
Page 34: Fieldcare
FieldCare Function scope FDT-based plant asset management tool from Endress+Hauser. It can configure all smart field devices in a system and helps you manage them. By using the status information, it is also a simple but effective way of checking their status and condition. -
Page 35: Devicecare
DeviceCare Function scope Tool to connect and configure Endress+Hauser field devices. The fastest way to configure Endress+Hauser field devices is with the dedicated "DeviceCare" tool. Together with the device type managers (DTMs) it presents a convenient, comprehensive solution. For details, see Innovation Brochure IN01047S Source for device description files See information →... -
Page 36: System Integration
System integration LPGmass Modbus RS485 System integration Overview of device description files 9.1.1 Current version data for the device Firmware version 01.03.zz • On the title page of the Operating instructions • On the transmitter nameplate • Firmware version Diagnostics → Device information → Firmware... -
Page 37: Register Information
LPGmass Modbus RS485 System integration Code Name Description Application Write single Master writes a new value to one Write only 1 device parameter registers Modbus register of the measuring Example: reset totalizer device. Use function code 16 to write multiple registers with just 1 telegram. - Page 38 System integration LPGmass Modbus RS485 Structure of the Modbus data map The Modbus data map consists of two data sets: • Scan list: Configuration area The device parameters to be grouped are defined in a list in that their Modbus RS485 register addresses are entered in the list.
- Page 39 LPGmass Modbus RS485 System integration Data area Device parameter value Modbus RS485 Data type* Access** register Value of scan list register 0 5051 Integer/float Read/write Value of scan list register 1 5053 Integer/float Read/write Value of scan list register ...
-
Page 40: Commissioning
Commissioning LPGmass Modbus RS485 Commissioning 10.1 Function check Before commissioning the measuring device: ‣ Make sure that the post-installation and post-connection checks have been performed. • "Post-installation check" checklist → 21 • "Post-connection check" checklist → 29 10.2 Establishing a connection via FieldCare •... -
Page 41: Setting The System Units
LPGmass Modbus RS485 Commissioning Parameter overview with brief description Parameter Description User entry Factory setting Device tag Enter the name for the measuring point. Max. 32 characters such as LPGmass letters, numbers or special characters (e.g. @, %, /). 10.4.2 Setting the system units In the System units submenu the units of all the measured values can be set. - Page 42 Commissioning LPGmass Modbus RS485 Parameter Description Selection Factory setting Volume flow unit Select volume flow unit. Unit choose list Country-specific: • l/min Result • gal/min (us) The selected unit applies for: • Output • Low flow cut off • Simulation process variable Volume unit Select volume unit.
-
Page 43: Selecting And Setting The Medium
LPGmass Modbus RS485 Commissioning 10.4.3 Selecting and setting the medium The Select medium wizard submenu contains parameters that must be configured in order to select and set the medium. Navigation "Setup" menu → Medium selection ‣ Medium selection Select medium →... -
Page 44: Configuring The Communication
Commissioning LPGmass Modbus RS485 Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Select medium – Select medium type. • Liquid Liquid • Gas Select gas type The Gas option is selected in Select measured gas type. - Page 45 LPGmass Modbus RS485 Commissioning Navigation "Setup" menu → Communication ‣ Communication → 45 Bus address → 45 Baudrate Data transfer mode → 45 Parity → 45 Byte order → 45 Failure mode → 45...
-
Page 46: Configuring The Low Flow Cut Off
Commissioning LPGmass Modbus RS485 10.4.5 Configuring the low flow cut off The Low flow cut off submenu contains the parameters that must be set in order to configure the low flow cut off. Navigation "Setup" menu → Low flow cut off ‣... -
Page 47: Configuring The Partial Filled Pipe
LPGmass Modbus RS485 Commissioning 10.4.6 Configuring the partial filled pipe detection The Partially filled pipe detection submenu contains parameters that have to be set for configuring empty pipe detection. Navigation "Setup" menu → Partially filled pipe detection ‣ Partially filled pipe detection →... -
Page 48: Advanced Settings
Commissioning LPGmass Modbus RS485 10.5 Advanced settings The Advanced setup submenu together with its submenus contains parameters for specific settings. The number of submenus can vary depending on the device version, e.g. viscosity is available only with the Promass I. -
Page 49: Carrying Out A Sensor Adjustment
LPGmass Modbus RS485 Commissioning Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting interface / User entry Corrected volume flow calculation – Select reference density for • Fixed reference Calculated reference calculating the corrected density density volume flow. • Calculated reference density •... -
Page 50: Configuring The Totalizer
Commissioning LPGmass Modbus RS485 Zero point adjustment All measuring devices are calibrated in accordance with state-of-the-art technology. Calibration takes place under reference conditions → 77. Therefore, a zero point adjustment in the field is generally not required. Experience shows that zero point adjustment is advisable only in special cases: •... -
Page 51: Using Parameters For Device Administration
LPGmass Modbus RS485 Commissioning Parameter overview with brief description Parameter Prerequisite Description Selection Factory setting Assign process variable – Select process variable for • Off Mass flow totalizer. • Mass flow • Volume flow • Corrected volume flow Mass unit The Mass flow option is Select mass unit. -
Page 52: Protecting Settings From Unauthorized
Commissioning LPGmass Modbus RS485 Navigation "Diagnostics" menu → Simulation ‣ Simulation → 52 Assign simulation process variable → 52 Value process variable Simulation device alarm → 52 Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting... - Page 53 LPGmass Modbus RS485 Commissioning 2. Depending on the housing version, unscrew or open the housing cover. A0030224 Setting the write protection switch on the main electronics module to the On position enables hardware write protection. Setting the write protection switch on the main electronics module to the Off position (factory setting) disables hardware write protection.
-
Page 54: Operation
Operation LPGmass Modbus RS485 Operation 11.1 Reading the device locking status Device active write protection: Locking status parameter Navigation "Operation" menu → Locking status Function scope of "Locking status" parameter Options Description Hardware locked The locking switch (DIP switch) for locking the hardware is activated on the main electronic module. -
Page 55: Totalizer" Submenu
LPGmass Modbus RS485 Operation Volume flow → 55 Corrected volume flow → 55 Density → 55 Reference density → 55 Temperature → 55 → 55 Pressure value Parameter overview with brief description Parameter Description... -
Page 56: Adapting The Measuring Device To The Process
Operation LPGmass Modbus RS485 Navigation "Diagnostics" menu → Measured values → Totalizer ‣ Totalizer → 56 Totalizer value 1 to n → 56 Totalizer overflow 1 to n Parameter overview with brief description Parameter Prerequisite Description User interface... -
Page 57: Function Scope Of The "Control Totalizer" Parameter
LPGmass Modbus RS485 Operation Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Control Totalizer One of the following options is Control totalizer value. • Totalize Totalize selected in the Assign process • Reset + hold variable parameter •... -
Page 58: Diagnostics And Troubleshooting
Diagnostics and troubleshooting LPGmass Modbus RS485 Diagnostics and troubleshooting 12.1 General troubleshooting For output signals Error Possible causes Solution Green power LED on the main Supply voltage does not match the Apply the correct supply voltage electronics module of the value indicated on the nameplate. -
Page 59: Safety Barrier Promass 100
LPGmass Modbus RS485 Diagnostics and troubleshooting Color Meaning Supply voltage Supply voltage is off or too low Green Supply voltage is ok Alarm Device status is ok Flashing red A device error of diagnostic behavior "Warning" has occurred • A device error of diagnostic behavior "Alarm" has occurred •... -
Page 60: Design, Description
Diagnostics and troubleshooting LPGmass Modbus RS485 Xxxxxx/…/…/ Device name: Xxxxxxx Mass flow: kg/h 12.34 Device tag: Xxxxxxx Volume flow: 12.34 m /h ³ Status signal: Function check (C) Xxxxxx Diagnostics 1: C485 Simu... Remedy information: Deactivate... Failure (F) Access status tooling:... -
Page 61: Calling Up Remedy Information
LPGmass Modbus RS485 Diagnostics and troubleshooting Diagnostic information Diagnostic code Status signal Diagnostic number Short text ↓ ↓ ↓ Example Process limit A0013958 3-digit number 12.3.2 Calling up remedy information Remedy information is provided for every diagnostic event to ensure that problems can be rectified quickly: •... -
Page 62: Adapting The Diagnostic Information
Diagnostics and troubleshooting LPGmass Modbus RS485 Parameter overview with brief description Parameters Description Selection Factory setting Failure mode Select measured value • NaN value NaN value output behavior when a • Last valid value diagnostic message occurs NaN º not a number via Modbus communication. - Page 63 LPGmass Modbus RS485 Diagnostics and troubleshooting Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Memory content 1. Restart device Alarm 2. Contact service Sensor signal 1. Check or change main Alarm electronics 2.
-
Page 64: Pending Diagnostic Events
Diagnostics and troubleshooting LPGmass Modbus RS485 Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Electronic temperature too Reduce ambient temperature Warning high Electronic temperature too Increase ambient temperature Warning Process temperature too... -
Page 65: Diagnostic List
LPGmass Modbus RS485 Diagnostics and troubleshooting Operating time from restart → 65 Operating time → 65 Parameter overview with brief description Parameter Prerequisite Description User interface Actual diagnostics A diagnostic event has occurred. Shows the current occured diagnostic... -
Page 66: Filtering The Event Logbook
Diagnostics and troubleshooting LPGmass Modbus RS485 In addition to the operation time of its occurrence and possible troubleshooting measures, each event is also assigned a symbol that indicates whether the event has occurred or has ended: • Diagnostic event – : Occurrence of the event –... -
Page 67: 12.10 Resetting The Measuring Device
LPGmass Modbus RS485 Diagnostics and troubleshooting Info number Info name I1451 Monitoring on I1457 Failed:Measured error verification I1459 Failed: I/O module verification I1460 Failed: Sensor integrity verification I1461 Failed: Sensor verification I1462 Failed:Sensor electronic module verific. 12.10 Resetting the measuring device Using theDevice reset parameter (→... - Page 68 Diagnostics and troubleshooting LPGmass Modbus RS485 Extended order code 2 → 68 Extended order code 3 → 68 ENP version → 68 Parameter overview with brief description Parameter Description User interface Factory setting Device tag Shows name of measuring point.
-
Page 69: 12.12 Firmware History
"Manufacturer' s information" document. The manufacturer' s information is available: • In the Download Area of the Endress+Hauser web site: www.endress.com → Downloads • Specify the following details: –... -
Page 70: Maintenance
13.2 Measuring and test equipment Endress+Hauser offers a wide variety of measuring and test equipment, such as W@M or device tests. Your Endress+Hauser Sales Center can provide detailed information on the services. -
Page 71: Repairs
• The measuring devices have a modular design. • Spare parts are grouped into logical kits with the associated Installation Instructions. • Repairs are carried out by Endress+Hauser Service or by appropriately trained customers. • Certified devices can only be converted to other certified devices by Endress+Hauser Service or at the factory. -
Page 72: Disposal
Repairs LPGmass Modbus RS485 14.5 Disposal 14.5.1 Removing the measuring device 1. Switch off the device. WARNING Danger to persons from process conditions. ‣ Beware of hazardous process conditions such as pressure in the measuring device, high temperatures or aggressive fluids. -
Page 73: Accessories
Various accessories, which can be ordered with the device or subsequently from Endress +Hauser, are available for the device. Detailed information on the order code in question is available from your local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com. -
Page 74: Technical Data
Technical data LPGmass Modbus RS485 Technical data 16.1 Application The measuring device is suitable for flow measurement of liquids and gases only. Depending on the version ordered, the measuring device can also measure potentially explosive, flammable, poisonous and oxidizing media. -
Page 75: Output
LPGmass Modbus RS485 Technical data Recommended measuring range "Flow limit" section → 81 Operable flow range Over 1000 : 1. Flow rates above the preset full scale value do not override the electronics unit, with the result that the totalizer values are registered correctly. -
Page 76: Power Supply
Technical data LPGmass Modbus RS485 Function codes • 03: Read holding register • 04: Read input register • 06: Write single registers • 08: Diagnostics • 16: Write multiple registers • 23: Read/write multiple registers Broadcast messages Supported by the following function codes: •... -
Page 77: Performance Characteristics
LPGmass Modbus RS485 Technical data Current consumption Transmitter Maximum Maximum Order code for "Output" Current consumption switch-on current Option M: Modbus RS485, for use in intrinsically safe 145 mA 16 A (< 0.4 ms) areas Safety Barrier Promass 100 Maximum Maximum Order code for "Output"... - Page 78 Technical data LPGmass Modbus RS485 Mass flow ±0.2 % o.r. Volume flow ±0.3 % o.r. Density ±20 kg/m³ (±0.02 SGU) Temperature ±0.5 °C ± 0.005 · T °C (±0.9 °F ± 0.003 · (T – 32) °F) Zero point stability...
-
Page 79: Design Fundamentals
LPGmass Modbus RS485 Technical data The outputs have the following base accuracy specifications. Repeatability o.r. = of reading; 1 g/cm = 1 kg/l; T = medium temperature Base repeatability Mass flow ±0.10 % % o.r. Volume flow ±0.15 % % o.r. -
Page 80: Installation
Technical data LPGmass Modbus RS485 Calculation of the maximum repeatability as a function of the flow rate Flow rate Maximum repeatability in % o.r. ⋅ ½ ZeroPoint ⋅ ³ BaseRepeat A0021340 A0021335 ⋅ ½ ZeroPoint ZeroPoint ⋅ ⋅ ⋅ <... -
Page 81: Process
LPGmass Modbus RS485 Technical data Vibration resistance • Vibration, sinusoidal according to IEC 60068-2-6 – 2 to 8.4 Hz, 3.5 mm peak – 8.4 to 2 000 Hz, 1 g peak • Vibration broad-band random, according to IEC 60068-2-64 – 10 to 200 Hz, 0.003 g –... - Page 82 Technical data LPGmass Modbus RS485 Weight All values (weight) refer to devices with EN/DIN PN 40 flanges. Weight in SI units Weight [kg] [mm] 10.4 15.5 Weight in US units Weight [lbs] [in] ³⁄₈ ½ 1 ½ Safety Barrier Promass 100 49 g (1.73 ounce)
-
Page 83: 16.11 Operability
LPGmass Modbus RS485 Technical data Order code for "Housing", option A "Compact, coated aluminum" The various cable entries are suitable for hazardous and non-hazardous areas. Cable entry/cable gland Material Cable gland M20 × 1.5 Nickel-plated brass Adapter for cable entry with internal thread G ½"... -
Page 84: 16.12 Certificates And Approvals
EU Directives. These are listed in the corresponding EU Declaration of Conformity along with the standards applied. Endress+Hauser confirms successful testing of the device by affixing to it the CE mark. C-Tick symbol The measuring system meets the EMC requirements of the "Australian Communications and Media Authority (ACMA)". -
Page 85: 16.14 Supplementary Documentation
• The W@M Device Viewer : Enter the serial number from the nameplate (www.endress.com/deviceviewer) • The Endress+Hauser Operations App: Enter the serial number from the nameplate or scan the 2-D matrix code (QR code) on the nameplate. Standard documentation... -
Page 86: Index
Enabling write protection ..... 52 see Electrical connection Endress+Hauser services Connection preparations ..... . 25 Maintenance . - Page 87 Operation ....... . . 54 Design ....... . . 11 Endress+Hauser...
- Page 88 Supply voltage ......76 Return ........71 Endress+Hauser...
- Page 89 Via write protection switch ....52 Write protection switch ..... . . 52 Endress+Hauser...
