- Page 1 M M o o d d e e l l S S R R 1 1 0 0 0 0 0 0 O O w w n n e e r r ’ ’ s s G G u u i i d d e e...
-
Page 2: Limited Lifetime Consumer Warranty
Warranty shall be limited to the repair or replacement of the product, at the sole discretion of Clarion. If it becomes necessary to send the product or any defective part to Clarion, the product must be shipped in its original carton or equivalent carton, fully insured, with shipping charges prepaid. - Page 3 ALSO HAVE THE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE. Should you have any difficulties with the performance of this product during warranty, please call: 1-800-GO-CLARION or visit your local Ungo Pro Security dealer. You may also contact the National Service Manager at the following address below for additional service help you may need.
-
Page 4: Table Of Contents
table of contents limited lifetime consumer warranty .......i standard remote configuration ........3 what is included . - Page 5 diagnostics ..........22 arming diagnostics .
-
Page 6: Standard Remote Configuration
standard remote configuration controls the Arm and Panic On/Off function. controls the Disarm and Panic Off function. controls Silent Arm/Disarm and Auxiliary channel 2 output. controls the Remote Engine Start function. pressed together control the Timer mode. pressed together control Turbo/Short Run. pressed together control channel 4 output. -
Page 7: What Is Included
what is included A control module A receiver/antenna Two four-button remotes A two-stage shock sensor A six-tone programmable siren A blue status LED indicator light A push-button override switch A shut-down toggle switch important information Congratulations on the purchase of your combination remote engine start alarm system. -
Page 8: Fcc/Id Notice
fcc/id notice This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesirable operation. Changes or modifications not expressly approved by the party responsi- ble for compliance could void the user's authority to operate this device. -
Page 9: Standard Configuration
standard configuration Button The arming and panic functions are controlled by pressing this button for one second. Button The disarming function is controlled by pressing this button for one second. Button Silent arm/disarm and an optional auxiliary function are controlled by this button. -
Page 10: Using Your System
Buttons An optional auxiliary convenience or expansion function that you have added to your system can be activated by pressing these buttons simultaneously. The auxiliary output controls __________________________. Buttons The remote engine start timer mode is controlled by pressing these but- tons simultaneously. - Page 11 enclosed or partially enclosed area or when having the vehicle serviced, the remote engine start system must be disabled using the installed toggle switch. It is the user's sole responsi- bility to properly handle and keep out of reach from children all remotes to assure that the system does not unintentionally remote engine start the vehicle.
-
Page 12: Active Arming
when performing the Neutral Safety Shutdown Circuit test, the remote engine start unit has not been properly installed. The remote engine start module must be removed or the installer must properly reinstall the remote engine start system so that the vehicle does not start in gear. All installations must be performed by an authorized dealer. -
Page 13: Passive Arming
passive arming The system can be programmed to arm itself automatically (called pas- sive arming). If the system is programmed for passive arming, it will automatically arm 30 seconds after the ignition is turned off and the system detects that you have left the vehicle by opening and closing a door. -
Page 14: Remote Sensor Bypass
armed, while still providing instant response (even if the door is immediately closed). Turning on the ignition key will trip the same progressive re- sponse as opening a door. The optional starter kill prevents the vehicle’s starter from cranking. remote sensor bypass Remote Sensor Bypass allows you to select which of the system's inputs or sensors will be active and which will be bypassed when the system is armed. -
Page 15: Arming While Driving
n n o o t t e e : : Multi-Level Security Arming only applies to a single arming cycle. Once the system is disarmed and then re- armed, all the zones will be active again. arming while driving Your security system can be armed while driving the vehicle! Simply press on the remote for two seconds while the vehicle is running. -
Page 16: Silence Alarm Without Disarm
silence alarm without disarm This feature makes it possible to silence and reset the system while it is triggering, without disarming the system. If the system is triggered and the siren has been sounding for longer than six seconds, pressing on the remote will stop the trigger and return the unit to the armed state. -
Page 17: Silent Mode
To disarm the security system, turn the ignition to the ON posi- tion. Press the override switch the preset number of times (one to five times) within 15 seconds. After five seconds, the system will disarm. If the system does not disarm, you may have waited too long;... -
Page 18: Panic Mode
panic mode If you are threatened in or near your vehicle, you can attract attention by triggering the system with your remote. Just press onds, and you will enter panic mode. The siren will sound and the park- ing lights will flash for the programmed siren duration. To stop panic mode at any time, press override mode You can prevent your security system from automatically arming and... -
Page 19: Remote Engine Start
Press The status LED will light solidly if you are entering override mode, and it will go out if you are exiting override mode. remote engine start This feature allows you to remotely start and run your vehicle for a pro- grammable period of time. - Page 20 i i m m p p o o r r t t a a n n t t ! ! It is unsafe to operate a vehicle’s motor in a garage or other closed off area. Breathing the exhaust from the vehicle is hazardous to your health.
-
Page 21: Override Take-Over
override take-over The override take-over feature allows the vehicle to remain running after the key has been removed from the ignition. This feature is useful for occasions when you wish to exit and lock the vehicle for short peri- ods of time, but would like to leave the motor running and the climate controls on. -
Page 22: Short-Run/Turbo
short-run/turbo Short run turbo mode keeps the engine running after arriving at you destination for a programmable period of 1, 3, 5 or 10 minutes. This allows the system’s timer to conveniently cool down the turbo after you have left the vehicle. To activate: Park the vehicle and set parking brake. -
Page 23: Safety Features
If shut down with the remote start button will remain in timer mode. The system will start every 3 hours until canceled by the brake, hood, or neutral safety shut-down wires. i i m m p p o o r r t t a a n n t t ! ! Timer Mode should be used only in open areas. Never start and run the vehicle in an enclosed space such as a garage or carport. -
Page 24: Disabling The Remote Engine Start System
disabling the remote engine start system This feature allows your system's remote engine start unit to be tem- porarily disabled to prevent the vehicle from being remote started acci- dentally. This feature is useful if the vehicle is being serviced or stored in an enclosed area. -
Page 25: False Alarm Prevention Circuitry
false alarm prevention circuitry Your system has false alarm prevention circuitry. It prevents annoying repetitive trigger sequences due to faulty door pin switches or environ- mental conditions such as thunder, jackhammers, airport noise, etc. Example If the alarm triggers three times within a 60-minute period and each time the same sensor or switch triggers the alarm, false alarm preven- tion circuitry will interpret those triggers as false alarms. -
Page 26: Diagnostics
diagnostics The microprocessor at the heart of your system is constantly monitoring all of the switches and sensors connected to it. It is designed to detect any faulty switches and sensors and prevents them from disabling the entire system. The microprocessor will also record and report any trig- gers that occurred during your absence. -
Page 27: System Status Chirps
security system was triggered in your absence. If five chirps are heard when disarming the system, a zone was triggered so many times that the false alarm prevention circuitry has bypassed that zone. In either case, the status LED will indicate which zone was involved (see Table of Zones section). -
Page 28: Interpreting Zone Diagnostics
ZONE (Number of DESCRIPTION LED Flashes) Trunk Pin Instant trigger - a heavier impact detected by the shock sensor Door switch trigger Instant trigger - for optional sensors Ignition trigger Hood Pin interpreting zone diagnostics Warning responses are not reported by arming or disarming diagnos- tics. -
Page 29: Anti-Code Grabbing
anti-code grabbing The receiver and remotes use a mathematical formula called an algo- rithm to change their code each time the remote is used. This technol- ogy has been developed to increase the security of the unit. The control unit knows what the next codes should be. This helps to keep the remote “in sync”... -
Page 30: Power-Up
program many of the system settings. The programmer makes it possi- ble to program different settings for each remote that is used with the system. Then, whenever a specific remote is used, the system will recall the settings assigned to that remote. Individual recognition lets up to four users of the system have different settings that meet their specif- ic needs. -
Page 31: Power Saver Mode
power saver mode Your system will automatically enter Power Saver Mode while armed or in override mode, after a period of time in which no operation has been performed. This lowers the current draw on the vehicle's battery. Power Saver Mode takes over under the following conditions: Power Saver when the system is armed: After the system has been armed for 24 hours the LED will flash at half its normal rate, decreasing the system's current draw. - Page 32 Arming/disarming siren chirps on or off. The ignition controlled door lock feature on or off: When this feature is programmed on, the doors will lock three seconds after the ignition is turned on, and unlock when the ignition is turned off. If your installer is programming the security system with the Pro Security Programmer, ignition lock and unlock are independent features that can be programmed separately.
- Page 33 n n o o t t e e : : When the system passively arms after one hour, the entry point that has been left open, and anything connected to the same zone, is bypassed and cannot trigger the sys- tem.
-
Page 34: Security & Convenience Expansions
n n o o t t e e : : This feature will only function if the Starter Kill relay has been installed. Siren tones and chirp volume. The output of the siren consists of six different tones in sequence. Any of these tones can be eliminated by a dealer, resulting in a unique, easily identifiable siren sound. - Page 35 Audio Sensor: Metal on glass, glass cracking, and breaking glass produce distinctive acoustic signatures. The audio sensor uses a microphone to pick up sounds, then analyzes them with proprietary acoustic software to determine if the glass has been struck. Backup Battery: This keeps the system armed, triggers the alarm and keeps the starter interrupt active if main battery is disconnected.
-
Page 36: Glossary Of Terms
glossary of terms Control Unit: The “brain” of your system. Usually hidden underneath the dash area of the vehicle. The control unit houses the microproces- sor which monitors your vehicle and controls all system functions. Fault-Proof Starter Interrupt: An automatic switch controlled by your system that prevents the vehicle’s starter from cranking whenever the system is armed. - Page 37 Override Switch: A small push button mounted at a discretionary location inside the vehicle. It is used to override the starter interrupt when a remote is lost or damaged, or to enter or exit override mode. Warning Zone Response: Lighter impacts to the vehicle will generate the Warning Zone response.
-
Page 38: Quick Reference Guide
QUICK REFERENCE GUIDE Arming To arm, press the parking lights will flash once. Arming while driving To arm the system while driving, press is running. The system will chirp once and then once more to indicate that the ignition is on. Disarming To disarm, press flash twice. - Page 40 Get Started Get Protected Ungo Pro Security 661 W. Redondo Beach Blvd. Gardena, Ca. 90247 800-GO-CLARION © 2003 Directed Electronics, Inc. GSR1000 11-03...
