Clarion UNGO ProSecurity SR5000 Owner's Manual

Clarion corporation of america owner's manual sr5000
Hide thumbs Also See for UNGO ProSecurity SR5000:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual
M M o o d d e e l l S S R R 5 5 0 0 0 0 0 0
O O w w n n e e r r ' ' s s G G u u i i d d e e

Advertisement

Table of Contents
loading

Related Manuals for Clarion UNGO ProSecurity SR5000

Summary of Contents for Clarion UNGO ProSecurity SR5000

  • Page 1 M M o o d d e e l l S S R R 5 5 0 0 0 0 0 0 O O w w n n e e r r ’ ’ s s G G u u i i d d e e...

  • Page 2: L L I I M M I I T T E E D D L L I I F F E E T T I I M M E E C C O O N N S S U U M M E E R R W W A A R R R R A A N N T T Y Y

    Warranty shall be limited to the repair or replacement of the product, at the sole discre- tion of Clarion. If it becomes necessary to send the product or any defective part to Clarion, the product must be shipped in its original carton or equivalent carton, fully insured, with shipping charges prepaid.
  • Page 3 ALSO HAVE THE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE. Should you have any difficulties with the performance of this product during warranty, please call: 1-800-GO-CLARION or visit your local Ungo Pro Security dealer. You may also contact the National Service Manager at the following address below for additional service help you may need.

  • Page 4: Table Of Contents

    t t a a b b l l e e o o f f c c o o n n t t e e n n t t s s l l i i m m i i t t e e d d l l i i f f e e t t i i m m e e c c o o n n s s u u m m e e r r w w a a r r r r a a n n t t y y ..i i t t r r a a n n s s c c e e i i v v e e r r d d i i a a g g r r a a m m .
  • Page 5 t t r r a a n n s s c c e e i i v v e e r r d d i i a a g g r r a a m m...
  • Page 6 s s t t a a n n d d a a r r d d t t r r a a n n s s c c e e i i v v e e r r c c o o n n f f i i g g u u r r a a t t i i o o n n s s Vehicle Interior Temperature Indicator Numeric Display AM/PM Indicator...
  • Page 7 w w h h a a t t i i s s i i n n c c l l u u d d e e d d Control module A.S.K. Receiver One four-button two-way transceiver One four-button remote Two-stage shock sensor Six-tone programmable siren Red status LED indicator light Push-button override switch...

  • Page 8: Warning! Safety First

    warning! safety first The following safety warnings must be observed at all times: warning! THIS SYSTEM PROVIDES REMOTE NOTI- FICATION OF SECURITY SYSTEM TRIGGER EVENTS. CONTACT POLICE OR SECURITY PER- SONNEL IMMEDIATELY. NEVER CONFRONT A CAR THIEF OR VANDAL. Due to the complexity of this system, installation of this product must only be performed by an authorized dealer.
  • Page 9 Use of this product in other than a fuel injected automatic transmission vehicle is contrary to its intended mode of operation may result in property damage, personal injury, or death. (1) Never remotely start the vehicle with the vehicle in gear, and (2) Never remotely start the vehicle with the keys in the ignition.

  • Page 10: System Maintenance

    O O R R P P E E R R S S O O N N A A L L I I N N J J U U R R Y Y . . Y Y O O U U M M U U S S T T I I M M M M E E D D I I A A T T E E L L Y Y C C E E A A S S E E T T H H E E U U S S E E O O F F T T H H E E U U N N I I T T A A N N D D S S E E E E K K T T H H E E A A S S S S I I S S T T A A N N C C E E O O F F A A N N A A U U T T H H O O R R I I Z Z E E D D D D E E A A L L E E R R T T O O R R E E P P A A I I R R...

  • Page 11: Fcc/Id Notice

    fcc/id notice This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesirable operation.

  • Page 12: A A N N T T I I - - C C O O D D E E G G R R A A B B B B I I N N G

    Button The System Disarm/Unlock and the capability to silence the alarm without disarming. These functions are controlled by pressing this button for one second. Button Channel 2 output is controlled by pressing this button for three seconds. Hold the button down continuously while accessing Channel 2 output. Button The panic feature is controlled by pressing this button for two seconds.

  • Page 13: Standard Icon Configurations

    Buttons When pressed simultaneously these buttons display the internal temperature of the vehicle on the LCD. Buttons The numeric display toggles between the time of the day and the alarm clock when these buttons are pressed simultaneously. Buttons Press these buttons simultaneously to activate the parking timer. Each additional press will toggle through the available options (10 min., 20 min., 30 min., 1 hour, 1.5 hours, 2 hours, and off ).
  • Page 14 Icon The AM/PM icon indicates the time before or after noon. Icon The alarm clock mode icon indicates that the alarm clock mode is active. Icon The timer function icon flashes during timed functions including parking timer. Icon The transmit range indicator icon stays visible as long as the system is within operating range.
  • Page 15 Icon This icon has no function. Icon No function. Icon The full trigger shock sensor icon indicates that the shock sensor has been triggered by a hard shock. Icons The hood/trunk open or trigger icon illuminates when the hood or trunk trigger has been activated or the hood or trunk is open, and bypasses those zones until it is closed.
  • Page 16 Icon The remote engine start safety shut down icon indicates the vehicle may be in gear or other unsafe condition inhibiting remote start operation. Icon The battery level icon indicates the level of power remaining in the battery. Icon No function. Icon The silent arm/disarm icon appears when the system has been armed or disarmed in the silent mode.

  • Page 17: Function Button Configurations

    function button configurations F F u u n n c c t t i i o o n n Lamp On (10 sec) Power-Saver Mode* Beep/Vibrate Mode Time Adjust Mode (hour)** Time Adjust Mode (min)** Alarm Clock Set Mode (hour)** Alarm Clock Set Mode (min)** Alarm Clock Music...
  • Page 18 Timer Count Down 7 Times*** Adjust Mode (min)** Timer Count 8 Times*** Down Ending Melody Selection 1** RS Timer Count 9 Times*** Down Mode (on/off )* Remote Start On 10 times*** Melody Selection 2 10 Min Parking Count Down Mode 20 Min Parking Count Down Mode 30 Min Parking...

  • Page 19: System Signal Paging Features

    *** Be sure to hold down for five seconds prior to entering timer clock adjust mode operation. **** Press once to have the alarm clock on. Press twice to have the alarm clock off. r r e e m m o o t t e e o o p p e e r r a a t t i i o o n n The 554 remote start system operates at 434 MHz and incorpo- rates an A.S.K.

  • Page 20: Active Arming

    Page Recognition Mode The transceiver will leave a zone icon illuminated when it has received a triggered response and will wait for violation recogni- tion. To clear the LCD information and alarm page alerts, turn the ignition on and then off u u s s i i n n g g y y o o u u r r s s y y s s t t e e m m active arming Press...

  • Page 21: Passive Arming

    passive arming The system can be programmed to arm automatically. This is called passive arming. In passive arming mode the system will arm itself 30 seconds after the user exits the vehicle and closes all protected entry points. Passive arming sequence 1.

  • Page 22: Vehicle Protection

    vehicle protection Following are descriptions of the many ways this system protects the vehicle. Included are descriptions of the types of alarm pages and how to interpret them. D D o o o o r r L L o o c c k k s s ( ( i i f f a a v v a a i i l l a a b b l l e e ) ) - The system will automatically lock the vehicle doors when armed.

  • Page 23: Warning Response Description

    warning response description A warning Response consists of an alarm page along with the responses described below. S S h h o o c c k k S S e e n n s s o o r r - Light impacts to the vehicle will flash the vehicle lights and chirp the siren for a few seconds.
  • Page 24 D D o o o o r r T T r r i i g g g g e e r r - If a door is opened the siren will chirp for three seconds, then the siren will sound and the lights will flash for the programmed duration and report Zone 3.

  • Page 25: Arming/Disarming While Driving

    arming/disarming while driving The alarm system can operate while the vehicle is being driven for added safety when driving through areas of questionable security. The alarm will only respond to the door trigger inputs and the starter kill will be activated. Arming while driving Press for two seconds while the vehicle is running.

  • Page 26: Remote Sensor Bypass

    remote sensor bypass Remote Sensor Bypass allows you to select which of the system's inputs or sensors will be active and which will be bypassed when the system is armed. (See Table of Zones section of this guide.) Pressing (only in standard configuration) again within five seconds of arming the system will activate the Remote Sensor Bypass feature.

  • Page 27: Disarming

    note: Remote Sensor Bypass only applies to a single arm- ing cycle. Once the system is disarmed and then re- armed, all the zones will be active again. disarming Press to disarm the system. The vehicle’s lights will flash twice, the doors will unlock, the siren will chirp twice and the status LED will turn off.

  • Page 28: Disarming Without A Transceiver (Emergency Override)

    Pressing any button to clear the transceiver page and the first six seconds will stop the trigger response and disarm the system. The six second timer is there for your convenience in case the system was accidentally triggered. disarming without a transceiver (emergency override) If your transceiver is lost or damaged, you can manually disarm your vehicle security system.

  • Page 29: Silent Arm/Disarm

    important! The override switch can be programmed to respond to 1-5 presses for the disarm function. You must check with the installer to verify the programming for your individual unit. silent arm/disarm To temporarily turn off the arm or disarm chirps, use silent arm/disarm.

  • Page 30: Panic Mode

    panic mode If you are threatened in or near your vehicle, you can attract attention by triggering the system with your transceiver. Just press for two seconds, and you will enter panic mode. The siren will sound and the parking lights will flash. To stop panic mode press on the transceiver again.

  • Page 31: Remote Engine Start

    The status LED will light solidly if you are entering override mode, and it will go out if you are exiting override mode. The transceiver will not generate a page notification when entering or exiting override mode using the override switch. To enter or exit override mode using the transceiver: 1.
  • Page 32 important! (1) Never remote start your vehicle when the keys are in the ignition, except when performing Override Take-Over, and (2) Never start the vehicle if it is not in either PARK or NEUTRAL. To remote start the vehicle: 1. Simultaneously press one second.
  • Page 33 important! It is unsafe to operate a vehicle’s motor in a garage or other closed off area. Breathing the exhaust from the vehicle is hazardous to your health. Never acti- vate the remote engine start in an enclosed space. When you are ready to drive the vehicle: 1.

  • Page 34: Override Take-Over

    override take-over The Override Take-Over feature allows the vehicle to remain running after the key has been removed from the ignition. This feature is useful for occasions when you wish to exit and lock the vehicle for short periods of time, but would like to leave the motor running and the climate controls on.

  • Page 35: Temperature Check Mode

    Then press to advance the minute selection or reverse the minute selection. Once the correct time is displayed simply stop pressing any buttons for 10 seconds and the trans- ceiver will automatically exit the clock mode. temperature check mode This system will report the interior temperature of your vehicle with the press of two buttons.

  • Page 36: Starter Anti-Grind Circuitry

    s s a a f f e e t t y y f f e e a a t t u u r r e e s s This system has several important safety features to ensure proper operation of the motor and prevent accidental damage to the engine or its components.

  • Page 37: Over And Under Rev Protection

    over and under rev protection The system monitors the engine speed and will automatically shut the engine off if the RPMs rise above or fall below the programmed levels. This feature prevents damage to the motor due to fuel delivery system failures or other problems which may cause the engine to race.
  • Page 38 Example If the alarm triggers three times within a 60-minute period and each time the same sensor or switch triggers the alarm, false alarm prevention circuitry will interpret those triggers as false alarms. After the third trigger, the false alarm prevention circuitry ignores, or bypasses, that sensor or switch (along with any other sensors or switches sharing the same zone) for 60 minutes.

  • Page 39: Arming Diagnostics

    d d i i a a g g n n o o s s t t i i c c s s The microprocessor at the heart of your system is constantly monitoring all of the switches and sensors connected to it. It is designed to detect any faulty switches and sensors and prevents them from disabling the entire system.

  • Page 40: System Status Chirps

    gered so many times that the false alarm prevention circuitry has bypassed that zone. In either case, the status LED and transceiver LCD will indicate which zone was triggered (see Table of Zones section). The security system will retain this information in its memory and chirp four or five times each time it is disarmed, until the next time that the ignition is turned on.

  • Page 41: Table Of Zones

    table of zones A zone is represented by the LED flashes used by the system to identify a particular type of input. Standard input assignments are listed in the following table. ZONE (Number of DESCRIPTION LED Flashes) Instant trigger - hood pinswitch Instant trigger - a heavier impact detected by the shock sensor Door switch trigger Instant trigger - for optional sensors...
  • Page 42 note: Your system stores the last two triggered zones in memory. If your system has been triggered but the LED has been reset by turning on the ignition, your dealer can still recall the last two zones that were triggered. Contact your dealer for details.
  • Page 43 ever, if the transceiver has been pressed many times out of range of the vehicle, or the battery has been removed, it may fall out of sync with the control unit and fail to operate the system. To re- sync the transceiver simply press of the vehicle.
  • Page 44 p p o o w w e e r r - - u u p p This system will store its current state to non-volatile memory. If power is lost and then reconnected the system will recall the stored state from memory. This means if the unit is in override mode and the battery is disconnected for any reason, such as servicing the car, when the battery is reconnected the unit will still be in override mode.
  • Page 45 p p r r o o g g r r a a m m m m i i n n g g o o p p t t i i o o n n s s Programming options control your system's normal, operational set-up.
  • Page 46 Forced passive arming o o n n or off. If your security system is programmed for passive arming and the forced passive arming feature has been programmed on, the system will passively arm after one hour, even if a protected entry has been left open.
  • Page 47 car, it will be necessary to disarm the system with the trans- ceiver. It is also possible to disarm the AED feature by turning the ignition key to the RUN position and pressing the override switch the programmed number of times. AED is also disabled when the system is in override mode.
  • Page 48 s s e e c c u u r r i i t t y y & & c c o o n n v v e e n n i i e e n n c c e e e e x x p p a a n n - - s s i i o o n n s s Listed below are some of the many expansion options available.
  • Page 49 leases, sometimes an optional relay is required. If the factory release is not power-activated, a trunk release solenoid can often be added. P P o o w w e e r r W W i i n n d d o o w w C C o o n n t t r r o o l l : : Power window control can be provided by one of two systems.
  • Page 50 A physical connection to the system. An input can be Input: provided by a sensor, pinswitch or by existing systems in the vehicle, such as ignition or courtesy lights. A blue light mounted at a discretionary location inside the LED: vehicle.
  • Page 51 Lighter impacts to the vehicle will generate Warning Response: the warning response. It consists of several seconds of siren chirps and parking light flashes. A zone is a separate input that the alarm can recognize as Zone: unique. Each input to the system is connected to a particular zone.
  • Page 52 Get Started Get Protected Ungo Pro Security 661 W. Redondo Beach Blvd. Gardena, Ca. 90247 800-GO-CLARION © 2003 Directed Electronics, Inc. GSR5000_11-03...
