  • Page 1 M M o o d d e e l l S S 6 6 6 6 0 0 ➤ O O w w n n e e r r ’ ’ s s G G u u i i d d e e...

  • Page 2: L L I I M M I I T T E E D D L L I I F F E E T T I I M M E E C C O O N N S S U U M M E E R R W W A A R R R R A A N N T T Y Y

    Warranty shall be limited to the repair or replacement of the product, at the sole discre- tion of Clarion. If it becomes necessary to send the product or any defective part to Clarion, the product must be shipped in its original carton or equivalent carton, fully insured, with shipping charges prepaid.
  • Page 3 ALSO HAVE THE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE. Should you have any difficulties with the performance of this product during warranty, please call: 1-800-GO-CLARION or visit your local Ungo Pro Security dealer. You may also contact the National Service Manager at the following address below for additional service help you may need.

  • Page 4: Table Of Contents

    t t a a b b l l e e o o f f c c o o n n t t e e n n t t s s l l i i m m i i t t e e d d l l i i f f e e t t i i m m e e c c o o n n s s u u m m e e r r w w a a r r r r a a n n t t y y ................i i r r e e m m o o t t e e c c o o n n f f i i g g u u r r a a t t i i o o n n s s .
  • Page 5 c c o o d d e e h h o o p p p p i i n n g g ......................3 3 4 4 h h i i g g h h f f r r e e q q u u e e n n c c y y .

  • Page 6: Lcd 2-Way Configuration

    r r e e m m o o t t e e c c o o n n f f i i g g u u r r a a t t i i o o n n s s ➜...
  • Page 7 Vehicle Interior Temperature Indicator Numeric Display AM/PM Indicator Alarm Clock Mode Indicator Timer Function Indicator Transmit Range Indicator Transmission Indication Vibrate/Beep Mode Indicator Power Saver Mode Indicator Remote Start Timer Mode Indicator No Function Vehicle Page Mode Indicator Full Trigger Shock Sensor Indicator Hood/Trunk Open or Trigger Indicator Parking Light Indicator Door Open or Trigger Indicator...

  • Page 8: Standard 4-Button Configuration

    ➜ standard 4-button configuration controls the A A r r m m and P P a a n n i i c c On/Off function. controls the D D i i s s a a r r m m and P P a a n n i i c c Off function. controls S S i i l l e e n n t t M M o o d d e e ™...
  • Page 9 By carefully reading this Owner's Guide prior to using your system, you will maximize the use of this system and its features. You can print additional or replacement copies of this manual by accessing our web site at www.clarion.com. 2-stage shock sensor ®...

  • Page 10: System Maintenance

    ➜ system maintenance The system requires no specific maintenance other than battery replacement for the remotes. LCD 2-Way Remote Battery Replacement The 2-way remote is powered by a 1.5V AAA battery. The Battery Level indicator has three level indicators that serve as a visual indication of battery charge.

  • Page 11: Fcc/Id Notice

    ➜ fcc/id notice This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesirable operation.

  • Page 12: Lcd 2-Way Remote Standard Configuration

    r r e e m m o o t t e e f f u u n n c c t t i i o o n n s s The remote buttons are used to send commands to the system. The descriptions below reflect the standard configuration for this system.
  • Page 13 Button When pressed and held this button activates the second unlock or other accessory. Buttons The numeric display toggles between the time of the day and the alarm clock when these buttons are pressed simultaneously. Buttons Press these buttons simultaneously to activate the parking timer. Each additional press will toggle through the available options (10 min., 20 min., 30 min., 1 hour, 1.5 hours, 2 hours, and off ).

  • Page 14: Standard Lcd 2-Way Icon Configuration

    Buttons When pressed simultaneously these buttons activate battery saver mode, which will drop power consumption on the transceiver battery to zero when the alarm is inactive or disarmed. ➜ Standard LCD 2-way icon configuration Icon The numeric display icon will show the hours and minutes. Icon The AM/PM icon indicates the time before or after noon.
  • Page 15 Icon The remote transmission indicator icon displays when the trans- ceiver is transmitting a signal. Icon The vibrate/beep mode icon appears when the transceiver is set to vibrate mode. Icon The power saver mode can be turned on or off with the trans- ceiver.
  • Page 16 Icon The parking light icon will flash twice when armed or disarmed. The icon also flashes during WarnAway and at the beginning and end of remote start cycles. Icon The door open or trigger icon illuminates when the door trigger has been activated or the door is open, and bypasses that zone until it is closed.
  • Page 17 optional sensor violation, or a hood/trunk trigger. Icon The arm icon appears when the vehicle is armed and locked. The disarm icon appears when the vehicle is disarmed and unlocked. Standard LCD 2-way button functions F F u u n n c c t t i i o o n n B B u u t t t t o o n n Lamp On (10 sec)
  • Page 18 Timer Count 8 Times*** Down Ending Melody Selection 1** RS Timer Count 9 Times*** Down Mode (on/off )* Remote Start On 10 times*** Melody Selection 2 10 Min Parking Count Down Mode 20 Min Parking Count Down Mode 30 Min Parking Count Down Mode 60 Min Parking Count Down Mode...

  • Page 19: 4-Button Remote Standard Configuration

    alarm clock off. The remote will revert to normal operation from the set mode when 15-seconds has elapsed without a button entry. ➜ 4-button remote standard configuration Button The arming is controlled by pressing this button. The panic alarm is triggered by pressing and holding this button. Press this button again to cancel the panic alarm.

  • Page 20: System Signal Paging Features

    Buttons An optional auxiliary convenience or expansion function that you have added to your system can be activated by pressing these buttons simultaneously. The auxiliary output controls __________________________. Buttons An optional auxiliary convenience or expansion function that you have added to your system can be activated by pressing these buttons simultaneously.
  • Page 21 cation to the user (notifications are audible beeps or the remote vibrates) and the LCD icons will display the current system status. Command Page When a command (arm/disarm, remote start, or auxiliary channel) from the transceiver is sent and received, the system will send a command page back to confirm receipt.

  • Page 22: Warning! Safety First

    u u s s i i n n g g y y o o u u r r s s y y s s t t e e m m ➜ warning! safety first The following safety warnings must be observed at all times: ➤...
  • Page 23 arming countdown, the status LED will flash twice as fast as it does when the system is armed. At the 20-second point of the count- down, the siren will chirp to indicate that the system is about to arm. At the 30-second point, the parking lights will flash to indicate that the system is armed.

  • Page 24: Warn Away Response Description

    ➤ The optional starter kill prevents the vehicle’s starter from cranking. ➜ warn away ® response description A Warn Away Response consists of an alarm page along with the ® responses described below. ➤ S S h h o o c c k k S S e e n n s s o o r r - Light impacts to the vehicle will flash the vehicle lights and chirp the siren for a few seconds.
  • Page 25 ➤ D D o o o o r r T T r r i i g g g g e e r r - If a door is opened the siren will chirp for three seconds, then the siren will sound and the lights will flash for the programmed duration and report Zone 3.

  • Page 26: Multi-Level Security Arming

    ➜ multi-level security arming Multi-Level Security Arming allows you to select which of the system's inputs or sensors will be active and which will be bypassed when the system is armed. (See Table of Zones section of this guide.) Pressing again within five seconds of arming the system will activate the Multi-Level Security feature.

  • Page 27: Arming While Driving

    ➜ arming while driving Your security system can be armed while driving the vehicle! Simply press on the remote for two seconds while the vehicle is running. The siren will chirp once to indicate that the security system is armed, and then once more to indicate that the ignition is on.

  • Page 28: Disarming While Driving

    ➜ disarming while driving Press on the remote or simply turn off the ignition to disarm the system. The lights will flash twice, the doors will unlock, the siren will chirp twice, and the status LED will turn off. The 2- way remote will beep twice (or vibrate).

  • Page 29: Disarming Without A Remote

    ➜ disarming without a remote If your remote is lost or damaged, you can manually disarm your vehicle security system. To disarm the system without a remote, you must have the vehicle's ignition key and know where the Valet button is located. Be sure to check with your installer at ®...

  • Page 30: Silent Mode

    ➜ silent mode To temporarily turn off the arm or disarm chirps, use Silent Mode™. Simply press arming or disarming, and the confirmation chirp(s) will be elim- inated for that one operation only. If you want the arm/disarm chirps turned off permanently, your dealer can do this for you. note: The Warn Away bypassed if the system is armed using Silent Mode.

  • Page 31: Valet ® Mode

    ➜ valet ® mode You can prevent your security system from automatically arming and triggering by using Valet washing the vehicle or having it serviced. In Valet security system will not arm, even with the remote, but all convenience functions (door locks, trunk release, etc.) will continue to work normally.

  • Page 32: Setting The Clock

    ➜ setting the clock To set the clock press and hold ceiver will chirp twice and the hour selection will start flashing. Immediately press the hour selection. Once the correct hour is displayed press again and the minute selection will start flashing. Then press to advance the minute selection to reverse the minute selection.
  • Page 33 Example If the alarm triggers three times within a 60-minute period and each time the same sensor or switch triggers the alarm, NPC will interpret those triggers as false alarms. After the third trigger, ignores, or bypasses, that sensor or switch (along with any ™...

  • Page 34: Arming Diagnostics

    them from disabling the entire system. The microprocessor will also record and report any triggers that occurred during your absence. Refer to the System Status Chirps and Table of Zones sections of this guide for diagnostic information. ➜ arming diagnostics If the security system is armed at the same time that an input is active (such as a door opening or sensor triggering), you will hear one siren chirp to indicate arming and a second siren chirp to indi-...

  • Page 35: System Status Chirps

    bypassed that zone. In either case, the status LED will indicate which zone was involved (see Table of Zones section). The secu- rity system will retain this information in its memory and chirp four or five times each time it is disarmed, until the next time that the ignition is turned on.

  • Page 36: Table Of Zones

    ➜ table of zones A zone is represented by the number of LED flashes used by the system to identify a particular type of input. Standard input assignments are listed in the following table, along with spaces to write in any optional sensors or switches that have been installed. ZONE (Number of LED Flashes)
  • Page 37 note: Your system stores the last two triggered zones in memory. If your system has been triggered but the LED has been reset by turning on the ignition, your dealer can still recall the last two zones that were triggered. Contact your dealer for details.
  • Page 38 h h i i g g h h f f r r e e q q u u e e n n c c y y Your system transmits and receives at 434 MHz. This provides a cleaner spectrum with less interference and a more stable signal. Enjoy a phenomenal increase in range, even in areas with high radio interference.
  • Page 39 r r a a p p i i d d r r e e s s u u m m e e l l o o g g i i c c This ProSecurity system will store its current state to non-volatile memory.
  • Page 40 p p r r o o g g r r a a m m m m i i n n g g o o p p t t i i o o n n s s Programming options control your system's normal, operational set-up.
  • Page 41 arming feature has been programmed on, the system will passively arm after one hour, even if a protected entry has been left open. Forced passive arming ensures that the system will be armed if a door has accidentally been left ajar when leaving the vehicle.
  • Page 42 the Valet button the programmed number of times. AED is ® also disabled when the system is in Valet note: This feature will only function if the FailSafe Starter Kill relay has been installed. ➤ Siren tones and chirp volume. The output of the Revenger Soft Chirp siren consists of six different tones in sequence.
  • Page 43 Prevents the vehicle’s hood from being opened Hood Lock: without a key, keeping thieves away from the system’s siren, the battery connections, and other components under the hood. An invisible dome of coverage is estab- Field Disturbance Sensor: lished by installing the 508D “radar” sensor. Your system can react to any intrusions into this field with the full triggered sequence.
  • Page 44 g g l l o o s s s s a a r r y y o o f f t t e e r r m m s s The “brain” of your system. Usually hidden under- Control Unit: neath the dash area of the vehicle.
  • Page 45 alarm “goes off ” or “trips.” The triggered sequence of your system consists of the siren sounding and parking lights flashing for the programmed duration. A small push-button switch mounted at a discre- Valet ® Button: tionary location inside the vehicle. It is used to override the starter interrupt when a remote is lost or damaged, or to enter or exit Valet Mode.

  • Page 46: Quick Reference Guide

    QUICK REFERENCE GUIDE Arming ■ To arm, press . When the system arms, you will hear a short chirp, and the parking lights will flash once. Arming while driving ■ To arm the system while driving, press is running. The system will chirp once and then once more to indicate that the ignition is on.
  • Page 47 Get Started Get Protected Ungo Pro Security 661 W. Redondo Beach Blvd. Gardena, Ca. 90247 800-GO-CLARION © 2005 Directed Electronics, Inc. - All rights reserved GS660 02-05...
