General view, right side

1 without Dynamic ESA
Adjuster for spring preload,
rear ( 91).
2 Air cleaner (under center
fairing panel) (
3 Brake-fluid reservoir, front
( 135)
4 Height adjuster for wind-
shield ( 89)
5 Power socket (
6 Vehicle identification num-
ber (on the steering head)
Type plate (on frame at
front right)
7 Coolant level indicator
( 137)
Coolant tank (
8 Oil fill location (
9 Engine oil level indicator
( 132)
10 Behind the side panel:
Battery (
OE
Positive battery connection
point (
Diagnostic connector
( 160)
147)
11 Brake-fluid reservoir, rear
( 136)
164)
138)
133)
155)
153)
