Matrices
EQ safe
The following diagram details the matrix parameters protected by the EQ safe.
4
3
Item
1
2
3
4
5*
6
7*
* Not shown in diagram.
Note: Although bands 1 and 6 are not shown above, the items in the table also apply.
Both bands have items 2, 3 and 4. Additionally, band 1 also has item 5, and band 6
also has item 7.
XL8 Live Performance System
Owner's Manual
5/6/7
1
2
Control
EQ switch
gain control knob
width control knob
freq control knob
SHAPE switch
SHAPE switch
SHAPE switch
matrix overview in
GUI channel strip
1
Parameter
EQ on/off
EQ gain level
EQ width
EQ frequency
Selects band 1 shelving modes: bell, warm, high
pass 6dB or high pass 12dB
Selects band 2 shelving modes: bell or high pass
24dB
Selects band 6 shelving modes: bell, soft, low
pass 6dB or low pass 12dB
451
EQ processing
area in GUI
channel strip
4
2
3
4
2
3
4
2
3
4
6
2
3
