Using the I zone to control an internal effect/GEQ
Item
4
5
6
7
8
>> To operate the assignable controls panel at the master bay GUI
You can use the GUI to operate the effect/GEQ assigned to the I zone by doing any of
the following:
To
Select a different effect/GEQ
Change the I zone control assignments
Operate a button on the front panel of an
effect/GEQ
Operate a control knob on the front
panel of an effect/GEQ
Rack and unit control navigation
The assignable controls panel on the control surface has four navigational buttons
that let you select a rack unit on the GUI and choose which of its page/group of controls
are assigned to the I zone.
Table 9: I zone navigation button functions
Control
button
Left arrow
Up arrow
PRO6 Live Audio System
Owner's Manual
Description
Effects only: Description of the effect's button currently assigned to the
button.
GEQ only: Will show either the text "zoom n" (where n is number from 1 to
8) or "overview" to indicate which display you are in, that is, overview or
zoom, respectively.
Navigation buttons, which replicate the arrow buttons in the I zone (see
Table 9 below).
Parameter description of the assignment of the overlying control knob.
Control knob. Includes gradations and dimensions applicable to the
assigned parameter.
When an I zone control is unassigned, it is displayed as a 'ghost' image.
(This also applies to the buttons.)
Action when controlling the
effects
Scrolls through the 'pages' of
the selected internal effect in
descending order. This has no
affect if you are already at the
first page or there is no effect
selected.
Scrolls up the effects rack,
changing unit selection
accordingly. Stops at the top
rack position.
Do this in the assignable controls
panel
Click the up/down arrow buttons
Click the left/right arrow buttons to
navigate to a different page (effects) or
zoom display (GEQs)
Click the desired LCD button
Use drag on the desired control knob
Action when controlling the
GEQs
In zoom view, scrolls through
the zoom displays. This has no
affect if you are already at
'zoom 1' display.
This has no affect in overview
display.
Scrolls up the GEQ rack,
changing unit selection
accordingly. Stops at the top
rack position.
