Navigating to the Patching screen

The following table shows you how to access the Patching screen from various other
GUI screen locations.
Table 22: Navigating to the Patching screen
Channel or Location on GUI
signal type screen area
Input channel Compressor processing
area - side chain section
Input channel Compressor processing
area
Input channel Gate processing area -
side chain section
Input channel Gate processing area
Input channel Insert processing area
Input channel Insert processing area
Input channel Configuration processing
area
Input channel Configuration processing
area - direct output
section
Return channel Insert processing area
Return channel Insert processing area
Return channel Configuration processing
area
Aux channel Compressor processing
area - side chain section
Aux channel Compressor processing
area
Aux channel Insert/configuration
processing area
Aux channel Insert/configuration
processing area - direct
input section
Aux channel Insert/configuration
processing area - insert
section
Aux channel Insert/configuration
processing area - insert
section
Matrix output Compressor processing
channel area - side chain section
Matrix output Compressor processing
channel area
Matrix output Insert/configuration
channel processing area
Appendix J: Reference Tables
Opens the tab sheet in the ...
Button Page
legend ref.
From section
MENU 259 Not affected
source 259 Not affected
MENU 259 Not affected
source 259 Not affected
dest 259 Ins. Sends
source 259 Not affected
source 259 Not affected
dest 259 Dir. Out
dest 291 Ins. Sends
source 291 Not affected
source 291 Not affected
MENU 290 Not affected
source 290 Not affected
dest 290 Busses
source 290 Not affected
dest 290 Ins. Sends
source 290 Not affected
MENU 292 Not affected
source 292 Not affected
dest 292 Busses
To section
Sidechains
Sidechains
Sidechains
Sidechains
Not affected
Ins. Ret.
Inputs
Not affected
Not affected
Ins. Ret.
Inputs
Sidechains
Sidechains
Not affected
Dir. In
Not affected
Ins. Ret.
Sidechains
Sidechains
Not affected
