1-6 RAIL - VS-540i -
PARTS LIST -Main Parts-
Parts No. Parts Name
W701406090 ASSY,FLEX 1 VS-640
1
W702406090 ASSY,FLEX 1 VS-640I
W7014060A0 ASSY,FLEX 2 VS-640
2
W7024060A0 ASSY,FLEX 2 VS-640I
W7014060B0 ASSY,FLEX 3 VS-640
3
W7024060B0 ASSY,FLEX 3 VS-640I
W701406080 ASSY,JUNCTION BOARD VS-640
4
W702406080 ASSY,JUNCTION BOARD VS-640I
5 6700469030 ASSY,PULLEY VP-540
6 1000002589 BASE,RAIL VP-540
7 1000010628 BELT,150S2M2168LW-C
8 1000010558 CABLE-ASSY,CUT-CAR ORG VS-640I
9 1000006822 CABLE-CARD,15P1 2850L BB HIGH-V
10 1000006821 CABLE-CARD,26P1 2330L BB HIGH-V
11 1000004962 CABLE-CARD,36P1 2930L BB HIGH-V
12 1000006704 CABLE-CARD,40P1 400L BB HIGH-V
13 1000006757 COVER,INNER VS-640
14 1000006801 COVER,JUNCTION BOARD VS-640
15 1000010625 COVER,RAIL SIDE L VS-640I
16 1000010576 COVER,RAIL SIDE VS-640I
17 1000010620 CUSHION,TUBE GUIDE VS-640I
18 1000011050 FILTER(E),FRCN40-12-1.7-K
19 1000010639 FRAME,SUPORT RAIL VS-540I
20 1000002591 GUIDE,CABLE FLEX-CUT VP-540
21 1000010640 GUIDE,CUT CABLE VS-540I
22 1000006514 GUIDE,TUBE 10 VS-640
23 1000010114 GUIDE,TUBE XF-640
24 1000009392 HOLDER,BACKUP SHAFTSQUARE RE-640
25 1000010643 HOLDER,CABLE F VS-540I
26 1000010642 HOLDER,CABLE VS-540I
27 1000001555 HOLDER,IDLE PULLEY XC-540
28 21655131 HOLDER,LINEAR SCALE CJ-70
29 1000002971 LABEL,G-ROLLER 170 VP-540 #LA978
30 1000002970 LABEL,G-ROLLER 50 VP-540 #LA977
31 1000002685 LABEL,PINCH ROLL VP-540#LA968
32 1000010668 L-BEARING,SSR15XW1GGE/W2GE+2050L(B)
33 1000002613 PLATE,CABLE CUT VP-540
34 1000002581 PLATE,CUT ORIGIN VP-540
35 1000010641 PLATE,HOLDER CABLE VS-540I
36 22055316 PLATE,LINEAR SCALE CJ-70
37 1000010638 PLATE,RAIL REAR VS-540I
38 1000001904 PULLEY,T55P2S16(B21C26)
39 1000010636 RAIL,GUIDE VS-540I
40 1000007203 RAIL,LINEAR SCALE VS-540
41 22175815 BEARING F8-16ZZ
42 1000006689 SENSOR-INTERRUPTER,EE-SX4009-P1
43 1000001479 SHAFT,IDLE PULLEY XC-540
44 1000010644 SHEET,CHOKE CABLE VS-540I
45 1000003089 SHEET,FRAME SUPPORT RAIL VP-540
46 1000006798 SHEET,HOLDER CABLE VS-640
PARTS LIST -Main Parts-
qt. Parts No. Parts Name
3 47 1000002544 SHEET,LINEAR SCALE VP-540
3 48 1000010637 SHEET,TUBE GUIDE VS-540I
1 49 22175122 SPRING,BACK UP PNC-960
1 50 22715469 STAY,HOLD SHAFT SQUARE SP-540V
1 51 1000002597 STAY,RAILGUIDE L VP-540
1 52 22135441 STOPPER,LINEAR SCALE FJ-540
1 53 1000010579 SUPPORT,CUT CABLE VS-640I
1 54 1000002617 SUPPORT,GUIDE CABLE VP-540
1 55 1000010577 SUPPORT,GUIDE CABLE VS-640I
2
1
1
1
1
3 PARTS LIST -Supplemental Parts-
1 Parts No. Parts Name
1 S1 31029106 BUSH,SQUARE SB-6025
1 S2 3000000033 CLAMP,WIRE PLESS RFC-45VO
1 S3 3000000030 CLAMP,WIRE PRESS RFC-33V0
1 S4 31289111AS CUPSCREW SET, M4*6 NI 100 PCS.
2 S5 31289109AS CUPSCREW SET,M3*4 NI 100 PCS.
3 S6 31289102AS CUPSCREW SET,M3*6 NI 50 PCS.
1 S7 31119904 PIN,SPRING 2.5*8 SUS STRAIGHT 50 PCS
2 S8 31129102 PIPE SET,POLYCA 4*8*10 20PCS
1 S9 31149704AS RING SET,E-RING ETW-6 SUS 100 PCS
1 S10 31299102AS RIVET SET,NYLON P2655B 20 PCS.
24 S11 31409702 SADDLE SET,LOCKING WIRE LES-1010 20P
1 S12 31409811AS SADDLE SET,LOCKING WIRE LWS-1211Z 20P
1 S13 31409801AS SADDLE,LOCKING WIRE LWS-0711Z 20P
1 S14 3000000081 SADDLE,LOCKING WIRE RLWT-0.5V0 20pcs.
1 S15 31049155AS SCREW SET,CAP M3*12 BC+PW 20 PCS.
1 S16 31049173AS SCREW SET,CAP M4*10 NI 50 PCS.
1 S17 31049174AS SCREW SET,CAP M4*15 NI 20 PCS.
6 S18 31049137AS SCREW SET,CAP M4*25 3CBC 20 PCS
1 S19 31049169AS SCREW SET,CAP M4*8 3CBC+PW 20PCS
1 S20 31089110AS SCREW SET,PAN M3*4 NI+PW 100 PCS
1 S21 31239103AS SCREW SET,W-SEMS M3*8 NI+PW 50 PCS
1 S22 31069104 SCREW,CAP M4*6+FL NI
1
1
1
1
1
1
2
1
1
1
4
2
1-10
qt.
1
1
1
1
1
1
1
1
1
qt.
2
6
5
18
30
4
4
2
2
24
1
6
1
5
18
1
2
7
4
5
8
4
