Icom IC-705 Basic Manual page 64

8
SET MODE
The call log contents are shown below:
Contents
TX/RX TX
Date 1/1/2020 13:51:48
Frequency 438.010000
Mode DV
My Latitude 34.764667
My Longitude 135.375333
My Altitude 50.5
RPT Call Sign JP3YHJ
TX Call Sign CQCQCQ
RX Call Sign (Blank)
RF Power 20%
S meter (Blank)
RX Latitude (Blank)
RX Longitude (Blank)
RX Altitude (Blank)
Example
RX
1/1/2020 13:51:48
438.010000
DV
34.764667
135.375333
50.5
JP3YHJ A
(Blank)
JA3YUA A/705
(Blank)
S0
34.764667
135.375333
30.5
8-11
Descriptions
Transmission and reception
Date and time the call was started.
Operating frequency
Operating mode
( USB/USB-D/LSB/LSB-D/CW/CW-R/RTTY/
RTTY-R/AM/AM-D/FM/FM-D/WFM/DV)
Your latitude (unit: degrees)
(+: North latitude, –: South latitude)
Your longitude (unit: degrees)
(+: East longitude, –: West longitude)
Your altitude (unit: meters) Records to one decimal
place.
Repeater call sign (DV mode only)
TX Call sign (DV mode only)
RX Call sign/Note (DV mode only)
TX output power level
The relative signal strength of the receive signal
(in 16 levels)
Caller's latitude, if sent. (unit: degrees)
(+: North latitude, –: South latitude)
Records only when you receive in the DV mode.
Caller's longitude, if sent. (unit: degrees)
(+: East longitude, –: West longitude)
Records only when you receive in the DV mode.
Caller's altitude, if sent. (unit: meters)
Records only when you receive in the DV mode.
