HE 1.5 Filter Control Valve Parts List
Item Part No.
01031605 Control, Filter, HE 1.5
Control, HE 1.5, Progressive Flow,
01031606
Filter
1 01031628 Valve Body
Piston Rebuild Kit, includes 4ea Large
Piston Assemblies, 2ea Standard Pis-
2 01031428
ton Assemblies, and 1ea Brine Piston
Assembly
Brine Piston w/80 Duro Quad Seal, HE
3 P1025242
1.25"-1.5", 5ea
5 01031620 Gear Box Assembly, downflow
5 01031623 Gear Box Assembly, progressive flow
6 01024332 Gearmotor
7 P1020415 Retainer, Gearmotor, 10ea
Wire Harness, Position Sensor (not
8 —
available for sale), Kit
9 01022735 Wire Harness, Motor
10 P1020433 Position Sensor Screw, 10ea/Kit
11 P1023546 Gear Box Assy Screw, 10ea
Kit, DAS w/o Knob, Assembly 1½"
13 P1024329
Progressive Flow, 10ea
Eductor Plug Assembly w/ O-Rings,
15 P1020487
10ea
16 P1020290 Eductor Plug Retainer, 10ea
17 P1020489 Plug, Backwash Assy,10ea
18 P1020291 Backwash Bypass Retainer, 10ea
19 P1023030 Kit, Plug, Elbow, Assembly, 5ea
20 P1030127 Retainer, Brine & Drain Elbow, 10ea
21 P1024022 Drain, Straight, Fitting, Assembly, 5ea
Backwash Flow Control, 8 gpm, 10ea
22 P1024790
(needs spacer)
Backwash Flow Control, 10 gpm, 10ea
22 P1024791
(needs spacer)
Backwash Flow Control, E, 10ea
22 P1024792
(needs spacer)
Backwash Flow Control, J, 10ea (needs
22 P1024793
spacer)
Backwash Flow Control, K, 10ea
22 P1024794
(needs spacer)
Backwash Flow Control, L, 10ea (needs
22 P1024795
spacer)
Circuit Board Replacement, Main, GBE,
23 01020745
OLED
Frame,Hood,Compact,HE Control, Out-
24 01030232
door (not available for sale)
25 P1014426 Spacer, Flow Control, 10ea
Cover,Hood,Compact,HE 1 1/2" Con-
29 01024918
trol, Outdoor
Compartment Plate w/ Gaskets (not
—
30
available for sale), Kit
Enclosure w/ Decal and Keyboard (not
—
31
available for sale), Kit
32 P0318383 SCREW, 10ea/Kit
33 P1023122 Retainer,Screw, 10ea/Kit
35 P1025274 Strain Relief Fitting, 10ea
36 P1025277 Liquid Tight Hole Plug, 10ea/Kit
37 01025282 Harness,Meter,28" length
39 01017134 Power Cable,Gold
Culligan® High Efficiency 1.5 Water Filter
58
Description Item Part No.
Connector,Plumbing 1½" NPT,Control
40 01023550
1½"
41 P1009075 Retaining Clip, 10ea/Kit
Electronics Enclosure Kit less Circuit
42 01025650
Board
45 P1022242 Eductor Assembly, Plugged, 10ea
46 P1020603 Eductor Throat O-ring, Large, 10ea/Kit
47 P1020428 Eductor Throat O-ring, Small, 10ea/Kit
51 01019742 Disperser, HE 1½
52 P1023558 Retaining Ring, 10ea
53 P1023560 O-ring, Manifold, 10ea
56 P1024364 Large Piston, O-ring, 25ea/Kit
57 P1025239 Large Piston Quad Ring, 25ea/Kit
60 P1020431 Small Piston, O-ring, 25ea/Kit
61 P1025199 Small Piston Quad Ring, 25ea/Kit
62 P1020426 Brine Piston O-ring 25ea/Kit
Brine Piston Quad Ring (not available
63 —
for sale), Kit
64 P1020252 Main Piston Spring, 10ea
65 P1020286 Brine Piston Spring 10ea
72 P1009099 O-ring, Couplings/Meters, 50ea/Kit
73 01014033 Coupling Kit, 1" Bypass Valve
74 01020486 Progressive Flow Bypass Assy
82 01026849 Meter Kit Assembly, HE 1", LF
86 P1023200 Screw, Compartment Plate, 10ea/Kit
87 P1021162 O-ring, 10ea/Kit
88 P1020424 O-ring, 10ea/Kit
* P1025028 Hose Clamp, 10ea
* P1023559 O-ring, Valve to Tank, 10ea
* 01014897 Transformer, Dual Output
Transformer, Dual Output w/ 6' Power
* 01020620
Cord (optional)
Transformer, Outdoor, 24V, HE
* 01025561
Compact Hood (optional)
* P0443494 Adapter, 1/2" Tube X 1/2" NPT, 10ea
* P0440516 1/2" Tube Insert, 25ea
* 01024216 1½" Bypass Valve
* P1025264 Strain Relief Fitting, 10ea
Kit, Drain Straight Barb Fitting Assem-
* P1025771
bly, 10ea
Kit, Bushing, 3/4" NPT Male,
* P1025064 1/2" NPT Female, Threaded Hex
Reducing, 10ea
* P1023029 Plug for Brine Elbow, 10ea
* 01025281 Bypass Piston Kit for HE 1.25/1.5
* 01024216 Bypass Valve (includes Bypass Piston)
*Not displayed in diagram
