Advanced Extron Vector 4K scaling engine — The Vector 4K scaling engine is
•
specifically designed for critical-quality 4K imagery, with best-in-class image upscaling
and downscaling.
• Supports computer and video resolutions up to 4K/60 @ 4:4:4 — Supports
HDMI 2.0 and DisplayPort 1.2 signals up to 4096x2160 at 60 Hz with 4:4:4 color
sampling.
• Supported HDMI 2.0 specification features include data rates up to 18 Gbps,
Deep Color, and HD lossless audio formats.
HDCP 2.2 compliant — Ensures display of content-protected media and
•
interoperability with other HDCP-compliant devices.
Matrix Mode — HDMI inputs 1 and 2 support Matrix Mode, which adds seamless
•
switching and transition effects to any matrix switcher with HDMI outputs.
• PIP - picture-in-picture — Allows any input to be displayed on-screen simultaneously
with another. The PIP window can be dynamically sized and positioned anywhere within
the output and is transitioned into or out of the output using the dissolve effect. Sixteen
PIP presets are also available.
Video keying — Title information or other content from an input source can be keyed
•
over the Program image.
Logo image keying and display — A logo graphic can be positioned and keyed over
•
live video. Logo graphics in BMP, JPG, PNG, or TIFF format may be uploaded to the
unit. Full screen images up to 4K resolution can also be displayed to eliminate loss of
video between presentations. Up to 16 logo images can be stored.
• Take button sends preview content to the audience using the selected effect
— Pressing the Take button on the front panel sends the preview content from the local
monitor to the main display device. The switch is performed with the selected effect,
providing a seamless transition between sources.
Aspect ratio control — The aspect ratio of the video output can be controlled by
•
selecting a FILL mode that provides a full screen output or a FOLLOW mode, which
preserves the original aspect ratio of the input signal.
Motion-adaptive deinterlacing for signals up to 1080i — Advanced deinterlacing
•
for all interlaced signals up to 1080i delivers optimized image quality.
• Automatic 3:2 and 2:2 pulldown detection — Advanced film mode processing
techniques that help maximize image quality for content sources originating from film.
• Auto-Image setup — Automatically optimizes the image by analyzing and adjusting
to the video input signal. This can save time and effort in setting up a newly connected
source, particularly in presentation environments where different guest presenter laptops
with various output resolutions will be connected.
Auto Input Memory — When activated, the unit automatically stores size, position,
•
and picture settings based on the incoming signal. When the same signal is detected
again, these image settings are automatically recalled from memory.
• Input presets — Memory presets are available to store and recall image settings.
• Layout presets — Memory presets are available to store and recall user settings. This
provides a quick method to set up content preview in anticipation of transitioning it to
the Program output.
• Output mute — Allows independent muting for Preview and Program output signals.
Output freeze — Provides independent freeze control of the program and preview
•
output signals. Frozen content can be switched to the Program output using any
transition effect.
