Vector
X (0...3, R)
[-127...+127]
0 is the center; -127 is far left, and +127 is far right.
Y (0...3, R)
[-127...+127]
0 is the center; -127 is top, and +127 is bottom.

Vector Env Time

The front-panel knobs control the five Time parameters. The units are in either seconds or note values, depending on
the Vector Env Setup page's Mode parameter.
The first three times are the transitions from 0-1, 1-2, and 2-3.
•
The fourth time, 3-Lp, is the transition from 3 to the next point in the loop, which may vary depending on loop
•
settings.
The fifth time, Rls, is the transition from the position at note-off to the release point.
•
Time
[0.0000...60.0000 sec]
When Mode is set to Time, you can set the segment's duration in seconds.
Beats and multiply ("x")
These parameters are shown when Mode is set to Tempo. You can set the segment's duration in beats (1/32 note to 2
breve) and a multiplier (1...32).

Vector Env Setup

Mode
[Time, Tempo]
This selects whether the Vector Envelope segments will be specified in seconds (Time), or in rhythmic values (Tempo).
Loop
[0->3, 1->3, 2->3, 0<->3, 1<->3]
This selects the start and end points of the loop, and whether the loop is forwards only or forwards-backwards.
0->3, 1->3, and 2->3: These loop forwards only. For instance, 1->3 makes the envelope play as follows: 0, 1, 2, 3, 1, 2, 3,
1, 2, 3 etc.
