Microtek ScanMaker IIG User Manual page 197

3 Click on the New button in the Scan Job window. When a
dialog box comes up, give a title to the new scan job, then
click OK. In this example, we will call the new scan job
Default Scan#2. The Scan Job window will now have
two titles. At the same time, a new scan frame appears in
the preview window.
New scan frame
appears with the
addition of a new
scan job. Two
titles now appear
in the Scan Job
window.
Draw the second scan frame around the right half of the
4
image. In this case, confine the scan frame to the upper
right half; leave the lower right half free. The reason why
will become apparent in the next step. (For details on
drawing the scan frame, see the Note that comes after #2.)
Reference: The Scan Job Window
Draw second scan
frame around upper
right half of image.
5-89
