Microtek ScanMaker IIG User Manual page 118

1
Preview area matches
dimensions in Preview
Setup command
2
Preview area changes
as dimensions change.
Note new ruler
measurements.
To use full page preview:
Full page preview is the default view. It will be dimmed
1
if the current view is already the full page preview. It is
available for use only if you are in zoomed preview
mode.
To change the size of the full page preview, click on the
2
Preview Setup command in the Preferences menu. When
the Preview Setup dialog box appears, specify the new
dimensions for the full page preview. (See the Preview
Setup command for more details.)
To make the new preview dimensions take effect, do a
3
new preview by clicking on the Preview button. In a few
moments, the new preview area will appear.
5-10 Microtek User's Guide for Windows
Full page preview
(8.5" x 11") as
determined by
dimensions in the
Preview Setup
Full page preview
changes to 6" x 9"
because dimensions
in Preview Setup were
changed
